VENTURI VALVE RETROFIT
MANUAL v100

VVR - MANUAL
i | VVR– Manual | AntecControls.com
TABLE OF CONTENTS
INTRODUCTION ...............................................................................................................................................................................2
General..........................................................................................................................................................................................2
Product Overview..........................................................................................................................................................................2
Safety Precautions ........................................................................................................................................................................2
GETTING STARTED WITH THE VVR ................................................................................................................................................3
In the Box......................................................................................................................................................................................3
Additional Components.................................................................................................................................................................6
Required Tools ..............................................................................................................................................................................7
Installation and Calibration.........................................................................................................................................................7
When using a VVR with PACE...................................................................................................................................................7
When using a VVR with the FHC...............................................................................................................................................7
When using a VVR with the LMX ..............................................................................................................................................7
MOUNTING THE RETROFIT.............................................................................................................................................................8
Mounting Instructions for a Single Valve ......................................................................................................................................9
Mounting Instructions for a Dual Valve .......................................................................................................................................15
POTENTIOMETER CURVES ...........................................................................................................................................................22
Configuring a POT Curve for PACE .............................................................................................................................................22
Configuring a POT Curve for FHC ...............................................................................................................................................26
Configuring a POT Curve for LMX...............................................................................................................................................29
Creating a New POT Curve .........................................................................................................................................................31
CALIBRATING THE RETROFIT .......................................................................................................................................................32
Calibrating the VVR when using PACE........................................................................................................................................32
POTENTIOMETER REPLACEMENT ...............................................................................................................................................35
Potentiometer Replacement (Option #1) ....................................................................................................................................35
CURVE SHEETS..............................................................................................................................................................................37
TROUBLESHOOTING.....................................................................................................................................................................38
Technical Support........................................................................................................................................................................38

VVR - MANUAL
2 | VVR– Manual | AntecControls.com
INTRODUCTION
General
In this manual, you will find information regarding:
•Venturi Valve Retrofit (VVR) specifications
•How to install the VVR with the PaceTM Critical Space Controller
(PACE), the Fume Hood Controller (FHC) and the Linear Module
(LMX)
•Detailed description of all options available for each setup and
controller
Product Overview
Antec Controls Retrofit are designed to replace obsolete controls
on currently installed Venturi Valves. The VVR is built to mount
directly onto the existing valves. Retrofits are designed to tether
into an existing potentiometer feedback airflow system or airflow
sensing system depending on application.
Safety Precautions
•Installation work and electrical wiring must be done by qualified
person(s) in accordance with all applicable codes and standards,
including fire-rated construction.
•When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
•Use this unit only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
•Before servicing or cleaning unit, switch power off at service
panel and lock service panel to prevent power from being
switched on accidentally.
•Protect flammable materials nearby when brazing, Use flame
and heat protection barriers where needed. Always have a fire
extinguisher ready.
The manufacturer assumes no responsibility for personal injury or
property damage resulting from improper handling, installation,
service or operation of the product.
CAUTION
This mark indicates an important point for the proper
function of the Venturi Valve Retrofit. Improper setup
may cause unit failure. Pay close attention to all caution
points throughout this manual.
For local area support, please
contact your local Antec Controls
Representative
For more information visit
www.AntecControls.com

VVR - MANUAL
3 | VVR– Manual | AntecControls.com
GETTING STARTED WITH THE VVR
In the Box
For each of the available controllers the order includes the following components outlined in this section.
PACE (Single Valve)
The single venturi valve retrofit for PACE ships with several different components. The
components are outlined in this section for a single venturi valve with a PACE.
Component
Quantity
Description
PACE
1
Single PACE controller.
Green Pressure
Tubing
1
The low-pressure tubing comes with a length of
tubing and a connector tee.
Red Pressure
Tubing
1
The high-pressure tubing comes with a length of
tubing and a connector tee.
Actuator
1
The actuator comes mounted on the mounting
bracket and shaft.
Mounting Bracket
with Linkages
1
The single venturi valve mounting bracket and
linkages comes pre-assembled. The unit just needs
to be positioned and fastened with 4 self-tapping
screws.
NOTE: Unit is shipped with label on the bottom of the PACE to indicate which valve it should
be installed on. The image on the left hand side shows the bottom of a PACE with the
corresponding identification label.
CAUTION
Please ensure all components are included in the box.
Do not proceed if any components are missing, contact
your local Antec Controls representative.
CAUTION
When units are shipped mounted in an
enclosure, the label will be shown on the
enclosure.

VVR - MANUAL
4 | VVR– Manual | AntecControls.com
FHC (Single Valve)
The single venturi valve retrofit for the FHC ships with several different components. The
components are outlined in this section for a single venturi valve with an FHC.
Component
Quantity
Description
FHC
1
Single FHC controller.
FHC Mounting
Bracket
1
Bracket used to mount the FHC to the controls
enclosure.
Potentiometer
Cable
1
Cable used to connect the FHC to the
potentiometer.
Green Pressure
Tubing
1
The low-pressure tubing comes with a length of
tubing and a connector tee.
Red Pressure
Tubing
1
The high-pressure tubing comes with a length of
tubing and a connector tee.
Terminal Block
1
3-pole terminal block that will be used to wire the
potentiometer cable to the existing potentiometer
Actuator
1
The actuator comes mounted on the mounting
bracket and shaft.
Mounting Bracket
with Linkages
1
The single venturi valve mounting bracket and
linkages comes pre-assembled. The unit just needs
to be positioned and fastened with 4 self-tapping
screws.
NOTE: Unit is shipped with label on the bottom of the FHC to indicate which valve it should
be installed on. The image on the left hand side shows the bottom of a FHC with the
corresponding identification label.
CAUTION
When units are shipped mounted in an
enclosure, the label will be shown on the
enclosure.

VVR - MANUAL
5 | VVR– Manual | AntecControls.com
LMX (Single Valve)
The single venturi valve retrofit for LMX ships with several different components. The
components are outlined in this section for a single venturi valve with an LMX.
Component
Quantity
Description
LMX
1
Single LMX controller.
LMX Mounting
Bracket
1
Bracket used to mount the LMX to the controls
enclosure.
Potentiometer
Cable
1
Cable used to connect the FHC to the
potentiometer.
Green Pressure
Tubing
1
The low pressure tubing comes with 29” of length
and a connector tee.
Red Pressure
Tubing
1
The high pressure tubing comes with 18” of length
and a connector tee.
Terminal Block
1
3-pole terminal block that will be used to wire the
potentiometer cable to the existing potentiometer
Actuator
1
The actuator comes mounted on the mounting
bracket and shaft.
Mounting Bracket
with Linkages
1
The single venturi valve mounting bracket and
linkages comes pre-assembled. The unit just needs
to be positioned and fastened with 4 self-tapping
screws.
NOTE: Unit is shipped with label on the bottom of the LMX to indicate which valve it should
be installed on. The image on the left hand side shows the bottom of a LMX with the
corresponding identification label.
CAUTION
When units are shipped mounted in an
enclosure, the label will be shown on the
enclosure.

VVR - MANUAL
6 | VVR– Manual | AntecControls.com
Additional Components
The additional components for each available option are outlined in this section.
Controls Enclosure
The venturi valve retrofit has an option to order a controls enclosure. The controls enclosure
comes with two different components.
Component
Quantity
Description
Enclosure Bracket
1
Enclosure bracket mounted to the base plate of the
venturi valve.
Enclosure Lid
1
Used to cover the enclosure.
Potentiometer
The venturi valve retrofit has an option to order a potentiometer. The potentiometer comes
in two different options.
Component
Quantity
Description
Potentiometer
(Option #1)
1
Potentiometer with cable, potentiometer plate, and
shaft coupler. This potentiometer assembly is the
most commonly used option and is used with base
plates that have slotted design
NOTE: See the Potentiometer Installation section
for more detail.
Potentiometer
(Option #2)
1
Potentiometer with cable, potentiometer plate,
mounting bracket, shaft couplers and extension pin.
This potentiometer assembly is required when the
existing base plate does not have tab slots.
NOTE: When ordering potentiometers a specials quote will need to be entered in Antec
Select. Please contact the Antec Applications team for assistance with the specials quote.
Option #1
Option #2
Lid
Enclosure Bracket
CAUTION
When units are shipped mounted in an
enclosure, the label will be shown on the
enclosure. This will indicate where the
controller is to be installed.

VVR - MANUAL
7 | VVR– Manual | AntecControls.com
Required Tools
See below for a list of required tools when performing a VVR installation.
Installation and Calibration
When installing the controls enclosure and calibrating the linkage, the installer will require the following tools:
•
#8 x 5/16” screws
•
Drill
•
1/4” Hex Driver
•
#2 Phillips Screw Driver
•
Controls screwdriver
•
Wire Cutters
•
Wire Strippers
•
7/16” Wrench (x2)
•1/2” Wrench
When using a VVR with PACE
After installing the VVR, the following tools are required to configure the POT curve for the VVR when using PACE.
•Computer running Windows 7 or higher with Antec Toolbox installed
•Ethernet cable with RJ45 to 4-wire connection
NOTE: Please see the POT Curves – PACE section of the manual for connection instructions.
When using a VVR with the FHC
After installing the VVR, the following tools are required to configure the POT curve for the VVR when using an FHC controller.
•Computer running Windows 7 or higher with Field Flash installed (along with any pre-requisite installers)
•BACnet Commissioning Tool (BCT)
•USB-A to USB-B cable (provided when ordering the BCT)
•Ethernet cable with RJ45 (type B) to 3-wire connection
NOTE: Please see the POT Curves – FHC section of the manual for connection instructions.
When using a VVR with the LMX
After installing the VVR, the following tools are required to configure the POT curve for the VVR when using an LMX.
•Computer running Windows 7 or higher with Field Flash installed (along with any pre-requisite installers)
•Linker2 Tool
•USB-A to USB-B cable (provided when ordering the Linker2)
•RJ12 Cable
NOTE: Please see the POT Curves – LMX section of the manual for connection instructions.

VVR - MANUAL
8 | VVR– Manual | AntecControls.com
MOUNTING THE RETROFIT
Pre-Installation Checks
The following checks are required prior to installation:
•Visually inspect the valve for damage – If damage is found DO NOT INSTALL. Please
contact a Price representative.
•Visually inspect the Retrofit for damage – if damage is found DO NOT INSTALL.
Please contact Antec Field Support.
•Locate Calibration Data Tag with CFMs and VPOT points.
•Verify the potentiometer excitation voltage using a voltmeter, while the original
controller or equipment powers it. Measure the voltage across the red and black
wires.
Valve Preparation
The following steps should be performed for any VVR installation.
•Disconnect the three (3) potentiometer (POT) wires from the terminals on the control
board.
NOTE: Remove the control components from the base plate on the valve. Components may
vary depending on the control solution mounted on the valve but the valve should be left
with the control arm, POT and POT wires.
Calibration Data Tag
Control Arm
POT Cable
CAUTION
DO NOT cut the POT cable.
The system may still have airflow, to
reduce the chance of damage to the
existing valve, set the valve to the min
position before removing control
components.

VVR - MANUAL
9 | VVR– Manual | AntecControls.com
Mounting Instructions for a Single Valve
STEP 1
Make a mark 2.25” from the middle of the control arm shaft.
STEP 2
Align the groove so that it's in-line with the pressure tap. Ensure that the bracket is lined up
with the 2.25” mark and is still parallel to the main base plate.
NOTE: Ensure the mounting bracket isn’t sitting on top of any hardware.
STEP 3
Ensure the edge of the actuator mounting bracket is parallel with the edge of the base plate.
Marked by the orange lines in the figure.
2.25
2.25

VVR - MANUAL
10 | VVR– Manual | AntecControls.com
STEP 4
Secure the mounting bracket to the mounting plate of the valve using four 3/8” self-tapping
screws. Pick two holes from the discharge side and two from the inlet side.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 5
If a new controls enclosure is ordered with the VVR, the controller will come factory
mounted. The enclosure can be fastened to the base plate with two 3/8” self-tapping
screws.
If re-using the existing controls enclosure, proceed to Step 6.
After mounting the ordered controls enclosure, proceed to Step 11.
NOTE: The ordered controls enclosure comes factory wired with a 3-pole terminal block.
When using the exsisting controls enclosure the PACE will ship loose without a 3-pole
terminal block.
STEP 6
Mount the PACE, FHC, or LMX.
For PACE mounting proceed to Step 7.
For FHC mounting proceed to Step 8.
For LMX mounting proceed to Step 9.
STEP 7
To mount the PACE, install 3 self-tapping screws. Two for the holes on the right hand side of
PACE and one for the left hand side.
To mount the PACE in the correct location please follow steps 7A-7C.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
CAUTION
Longer screws (1/2”+) can risk damaging
the valve coating and penetrating the valve.
Existing Controls Enclosure
New Controls Enclosure

VVR - MANUAL
11 | VVR– Manual | AntecControls.com
STEP 7A
Mount the PACE below the top tab insert on the encloure. There must be a minor gap so the
lid of the enclosure can slide on after.
STEP 7B
Pressure ports must be mounted facing the right hand side of the enclosure.
PACE is mounted a minimum of 3” from the right side of the enclosure.
STEP 7C
PACE is mounted above the base channnel on the valve.
3”

VVR - MANUAL
12 | VVR– Manual | AntecControls.com
STEP 8
To mount the FHC, use the mounting bracket and install 4 self-tapping screws.
To mount the FHC in the correct location please ensure the following:
1. The controller leaves enough room for the pressure tubing to be connected.
2. There is sufficient space for the 3-pole terminal block to be mounted and wired in.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 9
To mount the LMX, use the mounting bracket and install 4 self-tapping screws.
To mount the LMX in the correct location pleasure ensure the following:
1. The controller leaves enough room for the pressure tubing to be connected.
2. There is sufficient space for the 3-pole terminal block to be mounted and wired in.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 10
Mount the 3-pole terminal block on the left hand side of the enclosure. The terminal block
should be mounted on the oppposite side of the pressure tubing. The terminal block can be
fastened to the enclosure with two 3/8” self-tapping screws for metal.

VVR - MANUAL
13 | VVR– Manual | AntecControls.com
STEP 11
Connect the wiring to the PACE, FHC, or LMX.
For PACE wiring proceed to Step 11A.
For FHC wiring proceed to Step 11B.
For LMX wiring proceed to Step 11C.
STEP 11A
Wire the:
1. Actuator signal wire into AO4 on PACE.
2. POT cable in the POT1 terminal on PACE.
3. Power into the orange power terminal block on PACE.
STEP 11B
Wire the:
1. Actuator signal wire to AO1 on the FHC.
2. POT cable to the Venturi POT terminal on the FHC.
3. Power into the power terminal block on the FHC.
Actuator
Power
Venturi POT
Power
POT
Actuator

VVR - MANUAL
14 | VVR– Manual | AntecControls.com
STEP 11C
Wire the:
1. Actuator signal wire to AO1 on the LMX.
2. POT cable to the Venturi POT terminal on the LMX.
3. Flow and pressure signal into the FLO SIG and PRESSURE SIG terminal blocks,
respectively.
4. Power into the power terminal block on the LMX.
STEP 12
Attach pressure tubing to pressure taps on the valve. Connect the red tube to the high
pressure side (inlet) and the green tube to the low pressure side (discharge).
STEP 13
Route the other end of the pressure tubing through the knockout holes to the Pace pressure
taps. Connect the red tubing to the high pressure side (H) and the green tubing to the low
pressure side (L).
NOTE: For the LMX and FHC the tap marked with green is for low pressure and the tap
marked with red is for high pressure.
STEP 14
Once power is turned on to the unit, please proceed to the POT Curves section for
instructions to configure the controllers POT curves.
Pressure Signal
Venturi POT
Power
Flow Signal

VVR - MANUAL
15 | VVR– Manual | AntecControls.com
Mounting Instructions for a Dual Valve
STEP 1
The airflow direction and location of the control arm will determine where the VVR is
mounted. The VVR will be mounted following the airflow direction on the left hand side
valve as shown in the figure.
STEP 2
Mark 2.25 inches from the middle of the control arm shaft.
Mounting
Location
2.25

VVR - MANUAL
16 | VVR– Manual | AntecControls.com
STEP 3
Align the edge of the actuator mounting bracket with the edge of the base plate so they are
parallel.
STEP 4
Secure the mounting bracket to the mounting plate of the valve using four self-tapping
screws. Pick two holes from the discharge side and two from the inlet side.
STEP 5
If a new controls enclosure is ordered with the VVR, the controller will come factory
mounted. The enclosure can be fastened to the base plate with two 3/8” self-tapping
screws.
NOTE: The ordered controls enclosure comes factory wired with a 3-pole terminal block.
When using the exsisting controls enclosure the PACE will ship loose without a 3-pole
terminal block.
STEP 6A
DUAL (Flat type Base Channels):
Align how indicated thus far.
NOTES:
•The crank arm assembly may need to be slid laterally along the D-shaft and re-
tightened to ensure that the threaded position rod is in-line with the control arm.
•The linkage must be attached to the center control arm by sliding the linkage
through the hole and fastening it with the nut.
New Controls Enclosure
Existing Controls Enclosure
Crank Arm
Assembly
D-Shaft
Control Arm
CAUTION
Longer screws (1/2”+) can risk damaging
the valve coating and penetrating the valve.

VVR - MANUAL
17 | VVR– Manual | AntecControls.com
STEP 6B
DUAL (V-type Base Channels):
Align the front edge of the VVR 2.25 inches from the control arm (as mentioned in the
steps above (STEP 2).
Align VVR baseplate onto base channels such that the angled portion of the base plate
sits flush against the base channel and the 2 crank arm assemblies are positioned
approximately in-line with the 2 control arms. The linkage will must be attached to the
center control arm by sliding the linkage through the hole and fastening it with the nut.
STEP 7
Mount the PACE, FHC, or LMX.
For PACE mounting proceed to Step 8.
For FHC mounting proceed to Step 9.
For LMX mounting proceed to Step 10.
STEP 8
To mount the PACE, install 3 self-tapping screws. Two for the holes on the right hand side of
PACE and one for the left hand side.
To mount the PACE in the correct location please follow steps 8A-8C.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 8A
Mount the PACE below the top tab insert on the encloure. There must be a minor gap so the
lid of the enclosure can slide on after.
Crank Arm Assemblies

VVR - MANUAL
18 | VVR– Manual | AntecControls.com
STEP 8B
Pressure ports must be mounted facing the right-hand side of the enclosure.
PACE is mounted a minimum of 3” from the right side of the enclosure.
STEP 8C
PACE is mounted above the base channnel on the valve.
STEP 9
To mount the FHC, use the mounting bracket and install 4 self-tapping screws.
To mount the FHC in the correct location please ensure the following:
1. The controller leaves enough room for the pressure tubing to be connected.
2. There is sufficient space for the 3-pole terminal block to be mounted and wired in.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 10
To mount the LMX, use the mounting bracket and install 4 self-tapping screws.
To mount the LMX in the correct location pleasure ensure the following:
1. The controller leaves enough room for the pressure tubing to be connected.
2. There is sufficient space for the 3-pole terminal block to be mounted and wired in.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
3”

VVR - MANUAL
19 | VVR– Manual | AntecControls.com
STEP 11
Mount the 3-pole terminal block with two self-tapping screws.
NOTE: Self-tapping screws are not provided with the VVR. The recommended size is a 3/8”
self-tapping screw for metal.
STEP 12A
Wire the:
1. Actuator signal wire into AO4 on PACE.
2. POT cable in the POT1 terminal on PACE.
3. Power into the orange power terminal block on PACE.
Power
POT
Actuator
