Principal LED T3M RGB User manual

T3M RGB
CONTROLLER

T3M
2.4G LED RGB Controller
T3M is the 2.4GHZ RF wireless synchronization/zone RGB controller which adopts LTECH multiple globalinitiate technology.
The control system consists of two parts, the RF remote control and receiver, realize the signal synchronization on multiple
receivers, zone controlled arbitrarily (no more than 10 zones) within effective distance, a very good solution for the LED project
needs sync control wirelessly. User-friendly touch full-color wheel for color selection, unique LED state light for sync change
indicated, user can simply know the LED working state from distance by checking the remote control.
Can RF remote the functions of switch, pause, changing modes, changing speed and the brightness and so on. Satisfied
with your requirement of sync control multiple zones, group control or control separately, which t is easy to use.
1. Technical Specs:
Input Voltage: DC5V Built-in Lithium Battery
Working Current: <30mA
Working Frequency: 2.4GHZ
RF Remote Distance: 30m
Remote Option: Sync or Zone Control
Change mode: 18 Fantastic modes
Battery Capacity: 1000mAh
Standby Time: 6 months
Normal Using Time: 30 days
Dimension: L145×W55×H22(mm)
Package Size: L168×W102×H28(mm)
Weight (G.W.): 200g
Input voltage: DC12V-DC24V
Max current load: 5A×3CH Max 15A
Max output power: 180W/360W(12V/24V)
Control button: 8 touch button
Compatible remote control: workable with T3, T3M, T3X
T3-5A CV Receiving controller
Working temperature: -30℃㹼55℃
Dimension: L211×W40×H30mm
Package size: L215×W42×H32mm
Weight (G.W.): 180g
T3M Remote Control
2. Product Size:
T3M RF remote control
T3-5A
Remote holder
3. The learning ID method of remote control:
T3-5A learning ID:
T3-5A cancelling ID:
1. Turn on the receiver and remote control.
2. Press “on/off button” on the T3-5A for 2 seconds, there is a buzzer sound, and do not release your hand on the
button , at the same time press any keys of 1-10 zone on the remote control, until the green indicator light of
remote control flashes 3 times(a voice prompt at the same time), release all the keys.
1. Turn on the receiver and remote control.
2. Press “on/off button” on the T3-5A for 2 seconds, there is a buzzer sound, and do not release your hand on the
button , after 5 seconds press any keys of 1-10 zone on the remote control, until the red indicator light of remote
control flashes 3 times(a voice prompt at the same time), release all the keys.
T3M 2.4G LED RGB Controller Manual T3M 2.4G LED RGB Controller Manual

6. Tables of Changing Mode:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Description
No.
Mode
Description
No.
Mode
3 Colors Skipping
7 Colors Skipping
White Strobe
7 Colors Strobe
Rgb Fade out and Fade in
Red Green Color Smooth
Red Blue Color Smooth
Green Blue Color Smooth
Red Yellow Color Smooth
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Speed/Brightness Adjustable
Green Cyan Color Smooth
Blue Purple Color Smooth
Green Yellow Color Smooth
Blue Cyan Color Smooth
Red Purple Color Smooth
Blue White Color Smooth
Yellow Purple Cyan Color Smooth
RGB Color Smooth
Full-color Smooth
4. Operation Panel and Component Instruction:
OnOff
PauseKey
ModeKey
ZoneSelectionyeKs
Scene-save Keys
TouchFull-colorCircle
SpeedKey BrightnessKey
Sync Status Indicator Light
M1 M2
32
10
6
5
4
9
87
(Keep pressing to adjust brightness continuously)
Select one of the zone: Press keys 1-10 on the remote control.
All choose(10 zones): Press" " twice.
Select zone control arbitrarily :Press" +any number+ ",
eg: take 456 as a zone, should press" 456 "
Zoning Instructions:


Press “Pause” button in 3 seconds, the buzzer can be on or off.
(Press for 3 seconds, can save the
scene mode in the 10 current
zone control)
5. Other Special Functions:
Turn on the remote, long press the on/off key for 5 seconds until the red light flashes 3 times, and then the
green light flashes, the numbers of the green flash will be the frequency point of the remote. you can only edit the
frequency point after 3 seconds.
Method 2: long press “on/off” key over 5 seconds, the green light flashes, the flash times plus 1 means the
frequency point accumulate 1. In short, long press the “on/off” key 5 seconds each time, the frequency
point will accumulate 1, which will again become value 1 when added to 12, and that cycle repeats.
A. Reset Function:
B. Check and Edit the Frequency Point on the Remote:
Longpress simultaneouslyreleasethe 2keysafter3secondstheremotewillautooff
meansresetcompletedand thencouldrestart the remote.
Feature: Reset function is available when remote operates abnormally.
Operation:
a.
Multiple remotes sync-control becomes available when they use the same frequency point.
Revising the frequency point to eliminate the external disturbance. 12 revisable frequency points for user.
b.
After reset or revised the frequency points in the remote, receivers only can be used after relearn the ID. Attn:
Feature:
Check the Frequency Point on the Remote:
Edit the Frequency Point on the Remote: In frequency changing state
Method 1: short press any key from 1-9, the frequency point will be 1-9 correspondingly, the green light will flash in
the same numbers. Press again any key or touch the color circle to exit the frequency edit state.
On/Off Key
Pause Key
Mode Keys
SpeedKeys
Brightness Keys
Power Input Socket
DC12d24V
LED Lamp connected socket
T3-5A
PAUSE
MODE MODE
BRT BRT
SPEED SPEED
T3M 2.4G LED RGB Controller Manual T3M 2.4G LED RGB Controller Manual

8. Wiring Diagram:
T3M 2.4G LED RGB Controller Manual T3M 2.4G LED RGB Controller Manual
The receivers can be divided into 1~10 zones within effective distance(1pc receiver per zone), no wiring
needed between the receivers.
7. System Diagram: 9. The Charging Methods for Remote Control:
1. When charging, please connect USB cable to the mobile charger or computer with the USB interface.
4. Red indicator light flickers meaning low battery and need to be charged. charging in low battery will affect life of
battery.
3. No memory effect in the lithium battery of remote control. Follow the standard charging procedure even for the first
three times, no need over charge.
2. The blue indicator light flickers while charging, and turns green means the charging is completed. The remote
control can be chargeable even at the OFF state, on which the indicator light is black.
5. The remote should be full charged and stored under low cold drying while a long time without being operated.
And please full recharge every 3 months.
10. Attention:
1. The product shall be installed and serviced by a qualified person.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the product.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please ensure it is
mounted in a water proof enclosure.
