PRISM+ CLAYMORE 3Face mini User manual

Warranty
Item
Model No.
Seller
Date of Purchase
CLF-500LG/DG/MG
CLAYMORE 3Face mini
1. Thank you for purchasing CLAYMORE series of Prism Co., Ltd.
2. This product has passed strict quality control and testing process.
When you find some inappropriate working on the product, please contact
authorized service center.
Free Service
1) Failure of the product under normal operating conditions during the warranty
period will be repaired by Prism or authorized service center on free of charge.
Some shipping or handling charges may be involved.
2) Warranty period: 12 months
Charged Service
1) Damage caused when the warranty period is over
2) Damage caused due to the user’s mishandling, abuse, or improper operation
3)
Damage caused by arbitrary or personal repair or disassemble in unauthorized service center
4) Damage from input electricity or cable defect
5) Damage caused by natural disaster
Manufacturer
www.claymorelight.com / www.prismlight.co.kr
[email protected]
101-1501, Chunui-Technopark, Bucheon-ro 198 Road, 36,
Bucheon-si, Gyeonggi-do, Korea
Bigtent Outdoor Equipment Ltd. www.bigtentoutdoors.com
Prism Co., Ltd.
Official Import Distributor
info@bigtentoutdoors.com
Cautions for long-term storage
* Keep 100% battery capacity when storing for a long time.
* Please keep in mind that if stored below 10 degrees Celsius, the battery life may be affected.
* Please keep in a dry place without moisture.
* After the battery is fully discharged, the battery remaining indicator may not flash.
If this happens, plug the USB cable back in or press the button to tn the battery indicator again.
①Claymore 3Face mini ④Carabiner②Pouch ⑤Manual③USB charging cable
(USB Type-C)
6. Parts
5. Specifications
Product name
Model No. CLF-500LG/DG/MG
Run time 6hr 30min ~ 60hr
Color temperature Warm : 3000K , Bright : 4200K , Cool : 6500K (±15%)
Charging time 2hr 40min
Origin
MADE IN KOREA
Input USB 5V 2A
Output 5V 2A
Size 78×102.5×19.7mm
Brightness 40~800Lm
Weight 159g
CLAYMORE 3Face mini
Battery type/capacity Li-Polymer 3.7V 5,000mAh(18.50Wh)
3. Operating Manual
4. How to use a product
USB Out port
(Power bank)
USB In port
(Charging lantern)
Strap
1/4 inch hole
Battery level
indicator
ON/OFF button
(dimming control / SOS flash)
Mode change button
(LED color changing)
Side Light LED
Center Light LED
※ This lantern contains memory function that returns to the last setting when turn off and on.
Push shortly to turn on light.
Repeat to turn off light.
When light is on, press button shortly to adjust the light color in
three steps: Warm -> Bright -> Cool.
Warm
Bright
Cool
LED light with low color temperature, warm light feels like ordinary gas lantern
LED light with a neutral color of daylight and light bulb and comfortable feeling
LED light with high color temperature, cool light feels like ordinary fluorescent light
Three side
Center
※ To mount on camera tripod:
Turn the fixing screw on the camera
tripod into the socket and fix it.
It can be used in various ways by
connecting to products using
1/4 inch screws.
This product can be installed with strap and carabiner.
When using a carabiner, be sure to insert it into the lower hole of
the strap. (Prevent product fall in case of emergency)
Power bank cannot be used at the same time as
charging the product.
INPUT
OUTPUT
LED Lantern
2
X
1
X
Push&hold
When light is ON, Push button twice to change light mode.
Center Light ↔ Three side Light
1) Open rubber cover on the side and connect
USB-C type cable to charge lantern.
2) When the product is being charged, the battery
indicator flickers. If the light is not flicking and all
the lights are on, it indicates that the battery has
been fully charged
Connect various devices and lantern with
USB cable from USB out port and it will automatically
start charging.
(On status : Battery indicator turns on)
ON/OFF
Brightness control
SOS-Flash
Mode Change
LED Color Change
※Light blink once when Maximum and Minimum
brightness is reached.
When light is ON, push and hold button to
increase brightness. Repeat to decrease brightness.
2s
When light is OFF, push button
over 2 seconds to access SOS signal.
Battery level indicator
0~25%
25~50%
50~75%
75~99%
Fully charged
Flickers
Stop
LED Light and Diffusion filter
This portable lantern contains Li-poly battery.
Please follow user's manual before using it. If any abnormality is found in the product,
please discontinue use and contact the dealer or service center that you purchased.
1. Caution
2. Contents
① Do not use it near high temperature such as fire or heating equipment.
It may cause explosion and ignition.
② This product is water resistant. However, if left in the rain for a long time, it may cause malfunction.
If you accidentally fall into the water, please quickly wipe it off
③ Do not store or use in vehicles exposed to direct sunlight. It may cause explosion and malfunction.
④ Do not touch the light source directly as it may become very hot during use.
⑤ Do not use when it exceed the operating temperature range (-10 ° C to 40 ° C).
⑥ Do not look directly into the LED light source.
⑦ Please do not place in the reach of infants. It may cause swallowing of parts or injury.
⑧ Supervisor by guardian is necessary when used by children. Misuse of lantern may cause injury or
electric shock.
⑨ Do not insert any metal parts into the terminal block of the connector. It may cause heat, explosion
or electric shock.
⑩ Do not disassemble or modify the product.
⑪ Do not touch the connector with wet hands. There is a danger of electric shock.
⑫ After use, be sure to turn off the power If not, it may cause leakage.
⑬ Dropping or impacting the product can cause damage to the inside of the product, resulting an
unexpected failures in normal use. Be careful not to apply impact to the body.
Power bank function
Charging the lantern
1
X
