Private Reserve HPRV100 User manual

HPRV100
USER MANUAL
VACUUM SEALER

Hydrofarm.com
2

TABLE OF CONTENTS
IMPORTANT POINTS FOR YOUR SAFETY 6
TIPS FOR VACUUM SEALING DRIED HERBS 6
FOOD STORAGE & SAFETY 7
FOOD PREPARATION HINTS AND TIPS FOR AIRTIGHT VACUUM SEALING 7
PREPARATION HINTS FOR MEAT AND FISH 7
PREPARATION HINTS FOR CHEESES 7
PREPARATION GUIDLINES FOR VEGETABLES 7
MORE ON VEGETABLES 7
PREPARATION HINTS FOR POWDERY FOODS 8
PREPARATION HINTS FOR LIQUIDS 8
KEY FEATURES OF YOUR NEW VACUUM SEALER 8
BEFORE INITIAL USE 8
HOW TO MAKE CUSTOMSIZED BAGS 8
HOW TO VACUUM SEAL WITH THE VACUUM BAGS 9
HOW TO USE THE PULSE VACUUM BUTTON PULSE 10
HOW TO USE THE VACUUM SEALER WITH A CANISTER 10
CARE & CLEANING 10
TROUBLESHOOTING 10
SERVICE INSTRUCTIONS 11
WARRANTY 12
NOTES FOR DISPOSAL 12
3

OVERVIEW
Thank you for purchasing the HPRV100 Vacuum Sealer. With this new vacuum sealer, just close the
lid by pressing down on both sides. When the lid is locked in place, press the vacuum button and let
the vacuum sealer do the rest! The machine will continue to vacuum out air and then seal the bag;
release the lid by pressing its left and right corners simultaneously, and your items are now vacuum
fresh!
For information on additional Private Reserve products please visit Hydrofarm.com.
SPECIFICATIONS
Amperage 1.38A
Wattage 175W
Voltage 120V, 60Hz
Dimensions 13.3" L x 5.9" W x 2.5" H (340 x 150 x 64 mm)
Weight 2.86 lbs
Vacuum Degree -0.6 ~ -0.8 bar
4

LEGEND
A. VACUUM button - Press to vacuum package and seal food airtight. Machine shuts off
automatically.
B. CANCEL button - Immediately halts the current function.
C. PULSE button - Is used when extreme control of the vacuuming process is needed for delicate
foods. Press the button and the vacuum pumps turns on, release the button and it shuts off.
D. SEAL button
Press to create a seal when making bags from bag roll.
Press to immediately stop the vacuum process and begin sealing the bag, preventing delicate
foods from being crushed.
Press to create a seal on foil bags (such as a potato chip bag) to keep food sealed airtight.
E. HEATING LINE - The heating wire is covered by the high-temperature resistant tape. Do not tear
it away.
F. VACUUM CHAMBER - Make sure to place the open end of the bag down into the vacuum
chamber for successful vacuuming.
G. SEALING GASKETS/SEALING RINGS
A B C D
5

IMPORTANT POINTS FOR YOUR SAFETY
Read and fully understand all instructions and warnings prior to using this machine. Your safety is
most important!
1. Read the instructions carefully.
2. Do not allow the machine to be used as a toy.
3. This machine should not be operated by children.
4. Do not operate the machine with a damaged power cord or plug.
5. Do not use the machine on a wet or hot surface, or near a heat source.
6. Always use the machine on a level surface.
7. Do not immerse any part of the machine, power cord or plug into water or other liquid.
8. To disconnect, unplug the power cord from the electrical outlet. Do not disconnect by pulling
on the cord. Always unplug the machine before cleaning and when not in use.
9. Do not operate the machine if it malfunctions or is any way damaged. If the cord or the machine
is damaged, please contact our Return Authorization department at [phone] extension
110 for proper service, replacement or repair.
10. Close supervision is required when this product is used near children.
11. The machine is not for commercial use. If sealing more than 20 bags continuously, wait at least
25 minutes before resuming use of your machine.
12. Keep the upper lid of the machine unlocked when not in use.
This machine is for HOUSEHOLD USE ONLY.
Do not attempt to service this product. Service should be performed by an authorized service
representative.
A short power-supply cord is provided to reduce the risk resulting from becoming entangled in
or tripping over a longer cord. Extension cords are not prohibited from being used when care is
exercised in their use. When an extension cord is used, the marked electrical rating of the extension
cord shall be no less than the marked electrical rating of the machine. The longer cord shall be
arranged so that it does not drape over the countertop or tabletop where it might be tripped over,
snagged, or pulled on unintentionally, especially by children.
Start Enjoying the Benefits of your Vacuum Sealer System!
TIPS FOR VACUUM SEALING DRIED HERBS
When preparing dried herbs for vacuum sealing, a few important points should always be observed:
Be certain that your herbs are very dry. When your dried flowers and herbs are ready for vacuum
sealing, make sure there isn’t additional moisture hidden in the stems. If you attempt to bend the
stems, they should snap and break. When stems crease instead of breaking, this indicates that there
is still too much moisture contained in them. If you vacuum seal herbs that are not sufficiently dry,
mold and/or anaerobic bacteria is very likely to grow within the sealed package and will ruin the
aroma, safety, and quality of the herbs.
Don’t over-vacuum your dried herbs. During the vacuum process, before the heat seal happens,
dried flowers and herbs can become crushed if the vacuum is engaged for too long a period. Once
the package starts to form around your herbs, engage the heat seal function. This will stop the
vacuum from removing the last bit of air from the package, and prevent your herbs from being
smashed. You may need to try different vacuum times to achieve the desired effect.
Prevent stems from puncturing the vacuum bag. Our vacuum bags are very strong, so punctures
are unlikely. However, if a stem or other sharp object should cause a puncture in the vacuum bag,
VACUUM SEALING GUIDELINES
6

this will ruin the vacuum seal. Simply open the bag, remove the sharp object, replace the punctured
bag, and complete the vacuum sealing process again.
Folds in the seal create leaks. Make sure the bag lays flat on the sealer before securing the lid
closed. If a fold occurs before the sealing process, the bag will not have an air tight seal. If this
happens, trim off the faulty seal, reinsert the bag making sure it is flat on the sealing element,
and complete the process again. Faulty seals can lead to mold and anaerobic bacteria, which will
damage your goods.
FOOD STORAGE & SAFETY
IMPORTANT: Vacuum packaging is NOT a substitute for refrigeration or freezing. Any perishable
foods that require refrigeration must still be refrigerated or frozen after vacuum packaging.
For best result in extending the life of foods, it is important to vacuum package foods that are fresh.
Once food has begun to deteriorate, vacuum packaging may only slow the deterioration process.
Vacuum sealing cannot prevent the growth of mold. Other disease-causing microorganisms can still
grow in low oxygen environments and may require further measures to be eliminated.
FOOD PREPARATION HINTS AND TIPS FOR AIRTIGHT VACUUM SEALING
Cooking, Thawing and Reheating – Simmering in a vacuum bag helps food retain its flavor and it
helps with the clean up as well (no dirty saucepans!). When reheating foods in the microwave using
your vacuum bags, always puncture the bag to allow hot air to escape. You can also reheat foods in
the vacuum bags by placing them in water at a low simmer below 170°F (75°C).
IMPORTANT: Always thaw foods in either the refrigerator or microwave—do not thaw perishable
foods at room temperature.
PREPARATION HINTS FOR MEAT AND FISH
Try pre-freezing meats and fish for 1-2 hours before vacuum packaging. This helps retain the juice
and shape, and provides for a better seal.
If you can’t pre-freeze, place a folded paper towel between the food and top of the bag, but below
seal area. Leave paper towel in bag to absorb excess moisture and juices during vacuum packaging
process.
PREPARATION HINTS FOR CHEESES
Vacuum package cheese after each use. If you make your bag just a little longer than needed, you
can reseal the bag after each use.
IMPORTANT: Due to the risk of anaerobic bacteria, soft cheeses should never be vacuum packaged.
PREPARATION GUIDLINES FOR VEGETABLES
Blanching is a process that should be done before vacuum packaging vegetables. This process stops
the enzyme action that could lead to loss of flavor, color and texture. To blanch vegetables, place
them in simmering water or in a microwave until they are cooked, but still crisp. Blanching times can
range from 1 to 2 minutes for leafy greens and peas; 3 to 4 minutes for snap peas, sliced zucchini
or broccoli; give carrots about 5 minutes; and 7 to 11 minutes for corn on the cob. After blanching,
immerse vegetables in cold water to stop the cooking process.
NOTE: All vegetables (including broccoli, Brussels sprouts, cabbage, cauliflower, kale, turnips)
naturally emit gases during storage. Therefore, after blanching, it’s best if they’re stored in the freezer.
MORE ON VEGETABLES
Vegetables are a great candidate for portion control. When storing vegetables, try pre-freezing them
7

for 1 to 2 hours, then separate them into meal portions within your vacuum bags. After they have
been vacuum packaged, return them to the freezer.
IMPORTANT: Due to the risk of anaerobic bacteria, fresh mushrooms, onions & garlic should never
be vacuum packaged.
PREPARATION HINTS FOR POWDERY FOODS
When vacuum packaging powdery items like flour, it’s best to use their original packaging inside of
the vacuum bags. The fine powder could get sucked into the machine and cause enough damage to
shorten the life of the sealer.
PREPARATION HINTS FOR LIQUIDS
Before you vacuum package liquid such as soup stock, pre-freeze it in a casserole dish, loaf pan or
ice cube tray until solid. Remove frozen liquid from pan and vacuum package in the vacuum bags.
You can then stack in the freezer. When you’re ready to use, just cut a corner of the bag and place in
either a microwave dish or drop into water at a low simmer, below 170°F (75°C).
KEY FEATURES OF YOUR NEW VACUUM SEALER
• Compact design
• Wide sealing line prevents air leakage and keeps high vacuum degree for a longer time
• ’’Pulse’’ function to stop or continue vacuuming any time you wish—ideal for soft food
packaging
• Easy lock system—slightly press the machine to lock
• Pressing two buttons at bottom sides unlocks the cover easily.
• ’’Seal Only’’ function
• Pre-seal the vacuum bag any time when vacuuming
• Sealing width: 11"/28 cm maximum
BEFORE INITIAL USE
• Wipe off the machine with a damp towel.
• The sealing rings and the bag sealing bar must be clean and level, otherwise it will not be
possible to generate a vacuum.
• It is recommended to wait 15 seconds for the machine to warm up before starting the first
sealing or vacuum packing.
HOW TO MAKE CUSTOM-SIZED BAGS
1. Pull enough bag material to hold item to be vacuum packaged, plus 2 inches. With a pair of
scissors or a sharp knife, cut desired bag length from bag roll. Make sure to cut in a straight line.
Plug in power cord.
2. Open lid. Place one end of cut bag (ensuring that it is smooth and free of creases) against the
black oval sealing lip. Don’t worry if you accidentally place any material onto the gasket area.
3. Press the lid closed at the right and left sides with palms (confirmed by an audible click).
8

4. To begin sealing, press the SEAL button and the red light will come on. When the light goes off,
the sealing process is complete.
5. To remove the bag, press the release buttons at the right and left sides of the machine and open
the lid.
6. The custom sized bag is now ready for vacuum sealing.
CAUTION: The sealing bar will be hot! Make sure you give the machine time to cool down. Wait at
least 20 seconds between seals. Under very heavy usage, the machine will shut off automatically to
prevent overheating. If it does, wait 25 minutes to allow the machine to cool off.
HOW TO VACUUM SEAL WITH THE VACUUM BAGS
1. Place the item(s) to be sealed into the pre-cut or custom sized bag. Ensure that the bag is not
damaged by any sharp objects. Leave at least 2 inches between the contents and the top of the
bag to allow for bag contraction.
2. Open lid and place the open end of the bag down into the vacuum chamber. Ensure that the
bag is free of creases, dry and free of residue.
3. Press the lid closed at the right and left sides with palms (confirmed by an audible click).
Otherwise, the vacuum function cannot operate.
4. To begin the vacuum process, press the VACUUM button. The unit will continue to vacuum and
then seal once the air has been removed.
5. Once the indicator light has turned off, press the release buttons at the right and left sides of the
machine and open the lid.
CAUTION :
• Do not seal spoiled food or flammable liquids.
• Ensure that the vacuum pump does not suck up any liquids. If this occurs, press the CANCEL
9

button immediately.
• Do not seal twice in the same place, since this may cause the bag to burn.
• If the machine becomes overloaded, the overheating protection will switch the machine off. It
this happens, disconnect the machine from the power supply and leave it to cool for about 25
minutes.
HOW TO USE THE PULSE VACUUM BUTTON (PULSE)
With the pulse function, you can decide the strength of vacuum by pressing the PULSE button,
step by step. Soft food does not require the same strength of vacuum as solid food. When the
desired vacuum is reached, press the SEAL button.
HOW TO USE THE VACUUM SEALER WITH A CANISTER
NOTE: Canister and hose is not included.
1. Wipe the canister cover and canister base and ensure they are clean and dry.
2. Place food into canister and leave at least one inch of space between food and cover.
3. Place cover onto canister and insert one end of hose into vacuum port on machine. Place the
other end onto canister port, pressing down firmly to ensure a tight fit.
4. Press the lid closed at the right and left sides with palms (confirmed by an audible click).
5. To begin the vacuum process, press the VACUUM button. The unit will continue to vacuum and
then seal once air has been removed.
6. Once the vacuum indicator light has turned off, it is safe to remove hose from machine and
canister.
CARE & CLEANING
• Always unplug the unit before cleaning.
• Do not immerse in water.
• Do not use abrasives to clean the unit.
• Wipe the outer surface with a soft, damp cloth and soapy water.
• To clean the inside of the unit, wipe away any food or liquid with a paper towel.
• Dry all parts thoroughly before you plug in and operate the unit again.
• Vacuum chamber may trap liquids that were drawn from the bag; use a mild dish soap and
a warm, damp cloth to wipe away any left behind liquid from the vacuum chamber. Dry
thoroughly.
• Keep the lid of the machine unlocked when not in use.
TROUBLESHOOTING
Nothing happens when I press the ’’VACUUM’’ button:
• Make sure the power cord is correctly plugged into the electrical outlet.
• Make sure the power cord is not damaged in any way.
• Make sure the electrical outlet is operative by plugging in another appliance. If it’s not, please
check the circuit breakers or fuses in your home.
• Make sure the bag is positioned correctly down in the vacuum chamber.
• Press down on both sides of the lid and make sure it is locked in place.
• Wait 25 minutes to allow the machine to cool off, and then try using again.
The air is not being vacuumed from the bag:
• Check that there are no gaps, folds, wrinkles or holes in the pre-sealed bags.
• Check for loose, worn or cracked upper and lower sealing gaskets.
10

• Foods with high liquid content may prevent the bag from sealing properly. Cut bag open and
wipe top inside of bag and reseal.
• Check to see if bag is properly inserted into the vacuum chamber.
• Make sure you’ve placed the bag in the proper place. When making a bag from a roll, make
sure end of cut piece is on the sealing strip.
The bag is melting:
• The sealing strip may have been too hot during the sealing process. Allow the unit to cool for
20 seconds between uses. If the bag continues to melt, allow unit to cool with the lid in the
upright position for 25 minutes before using.
Air has seeped back into the vacuumed bag:
• Check the seal of the bag. There may be a hole or wrinkle that is allowing air to reenter the bag.
Carefully cut the bag open and reseal it, or use an entirely new bag.
• Make sure there is no moisture or liquid from the food present within the bag seal. You may
need to cut open the bag and reseal it, or use an entirely new bag. Partially freeze foods with
excess liquids prior to vacuum sealing.
• Make sure there are no food items with sharp edges that may have punctured the bag. If you
find a puncture hole, seal the item in an entirely new bag.
• Make sure no liquids were drawn to the sealing strip area.
• Check for loose, worn or cracked upper and lower sealing gaskets.
• Moisture of foods with high liquid content will prevent the bag from sealing properly. Cut bag
open and wipe top inside of bag and reseal.
Bag will not seal:
• Check that there aren’t any gaps, folds, wrinkles or holes in pre-sealed edges.
• Moisture from foods with high liquid content will prevent the bag from sealing properly. Cut
bag open, wipe the top inside of bag, and reseal.
• Make sure you’ve placed the bag in the proper place. When making a bag from a roll, make
sure end of cut piece is on the sealing strip.
• Make sure you’ve given the machine time to cool down. Wait 20 seconds between seals.
SERVICE INSTRUCTIONS
• Do NOT attempt to repair or adjust any electrical or mechanical functions on this unit. Doing so
will void the warranty.
• If you have any questions or comments regarding the unit’s operation or believe any repair is
necessary, please contact our Return Authorization department at [phone] extension
110.
11

Hydrofarm.com
WARRANTY
HPRV100 Instructions revised - September 25, 2017 10:13 AM
Thank you for choosing HPRV100 by Hydrofarm. For further information
about Private Reserve products, videos, and technical information,
please visit Hydrofarm.com
LIMITED WARRANTY
Hydrofarm warrants the HPRV100 to be free from defects in materials and workmanship. The warranty term is for
1 year beginning on the date of purchase. Misuse, abuse, or failure to follow instructions is not covered under this
warranty. Hydrofarm’s warranty liability extends only to the replacement cost of the product. Hydrofarm will not be
liable for any consequential, indirect, or incidental damages of any kind, including lost revenues, lost profits, or other
losses in connection with the product. Some states do not allow limitation on how long an implied warranty lasts or
the exclusion of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
Hydrofarm will, at our discretion, repair or replace the HPRV100 covered under this warranty if it is returned to the
original place of purchase. To request warranty service, please return the HPRV100, with original sales receipt and
original packaging, to your place of purchase. The purchase date is based on your original sales receipt.
Like us on Facebook, follow us on Twitter,
and check out Hydrofarmtv on YouTube and Instagram!
Get Connected with the Hydrofarm Community:
NOTES FOR DISPOSAL
Dispose of the appliance and packaging must be effected in accordance with the corresponding local regulations
and requirements for electrical appliances and packaging. Please contact your local disposal company.
Appliances marked with this symbol must not be disposed of along with household refuse ! You are legally bound to
dispose of old appliances separately from household waste. Information about collection points where old appliances
can be disposed of free of charge is available from your local authorities.
