Pro-face PL3000 Series User manual

1
PL3000 Series Windows® 2000
Multi-Language
Preinstalled Hard Disk Unit
Installation Guide
“The PL3000 Series Windows®2000 Multi-
Language Preinstalled Hard Disk Unit”
includes an HDD drive with Microsoft
corporation's preinstalled Windows®2000
operating system, as well as other driver and
utility software. These items are used when
operating Pro-face's PL3000 Series unit,
hereafter referred to collectively as the “PL”.
Corresponding models: PL3000 Series
The following trade names are registered
trademarks of the following companies.
Pro-face : Digital Electronics Corporation (in
Japan and other countries)
Windows®2000: Microsoft®Corporation
(USA)
Symantec Ghost™: Symantec Corporation
About the Manual
For the detailed information on PL series,
refer to the following manuals.
• PL3000 Series Hardware Manual
(For installing and removing the HDD
unit)
• PL3000 Series Reference Manual
(For recovering and setting up the
HDD unit)
Manuals, drivers and utilities for PL3000
series can be downloaded from Pro-face
Home Page.
URL
http://www.pro-face.com/otasuke/
IMPORTANT - Read Prior to
Opening and Operating
This HDD unit contains a preinstalled version
of Windows®2000 Professional. Be sure to
read and agree to all conditions stated herein
prior to using this product. If you do not
agree to all the conditions stated in this
agreement, please return the entire product.
* This Installation Guide is an important part of this
product. Be sure to keep it in an easyto-find
location.
