Pro-Form E35S User manual

Serial Number Decal
Model No. PFTL61730
Serial No.
CAUTION
Read all precautio s a d i struc-
tio s i this ma ual before usi g
this equipme t. Save this ma ual
for future refere ce.
USER'S MANUAL
QUESTIONS?
If you have questio s, or if there
are missi g or damaged parts,
we will guara tee complete sat-
isfactio through direct assis-
ta ce from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trai ed tech icia s o our
Customer Hot Li e will provide
immediate assista ce, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mo .–Fri., 6 a.m.–6 p.m. MST
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
All manuals and user guides at all-guides.com
all-guides.com

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING is attached in the center of this manual.
1. It is the respo sibility of the ow er to e sure
that all users of this treadmill are adequately
i formed of all war i gs a d precautio s.
2. Use the treadmill o ly as described.
3. Place the treadmill o a level surface, with at
least eight feet of cleara ce behi d it a d two
feet o each side. Do ot place the treadmill
o a y surface that blocks air ope i gs. To
protect the floor or carpet from damage, place
a mat u der the treadmill.
4. Keep the treadmill i doors, away from mois-
ture a d dust. Do ot put the treadmill i a
garage or covered patio, or ear water.
5. Do ot operate the treadmill where aerosol
products are used or where oxyge is bei g
admi istered.
6. Keep childre u der the age of 12 a d pets
away from the treadmill at all times.
7. The treadmill should be used o ly by perso s
weighi g 250 pou ds or less.
8. Never allow more tha o e perso o the
treadmill at a time.
9. Wear appropriate exercise clothes whe
usi g the treadmill. Do ot wear loose clothes
that could become caught i the treadmill.
Athletic support clothes are recomme ded for
both me a d wome . Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. Whe co ecti g the power cord (see page 8),
plug the power cord i to a surge suppressor
( ot i cluded) a d plug the surge suppressor
i to a grou ded circuit capable of carryi g 15
or more amps. No other applia ce should be o
the same circuit. Do ot use a exte sio cord.
11. Use o ly a si gle-outlet surge suppressor that
meets all of the specificatio s described o
page 8. To purchase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-
3651 a d order part umber 146148.
12. Failure to use a properly fu ctio i g surge
suppressor could result i damage to the co -
trol system of the treadmill. If the co trol sys-
tem is damaged, the walki g belt may cha ge
speed or stop u expectedly, which may result
i a fall a d serious i jury.
13. Keep the power cord a d the surge suppres-
sor away from heated surfaces.
14. Never move the walki g belt while the power
is tur ed off. Do ot operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is ot worki g properly. (See BE-
FORE YOU BEGIN o page 4 if the treadmill is
ot worki g properly.)
WARNING:To reduce the risk of bur s, fire, electric shock, or i jury to perso s, read the
followi g importa t precautio s a d i formatio before operati g the treadmill.
IMPORTANT PRECAUTIONS
2
All manuals and user guides at all-guides.com

The decals show have bee placed o your treadmill. If a
decal is missi g, or if it is ot legible, please call our
Customer Service Departme t, toll-free, to order a free re-
placeme t decal (see the fro t cover of this ma ual). Apply
the decal i the locatio show .
15. Never start the treadmill while you are sta d-
i g o the walki g belt. Always hold the
ha drails while usi g the treadmill.
16. The treadmill is capable of high speeds.
Adjust the speed i small i creme ts to
avoid sudde jumps i speed.
17. Never leave the treadmill u atte ded while it
is ru i g. Always remove the key, u plug
the power cord a d move the o /off circuit
breaker to the off positio whe the treadmill
is ot i use. (See the drawi g o page 4 for
the locatio of the o /off circuit breaker.)
18. Do ot attempt to raise, lower, or move the
treadmill u til it is properly assembled. (See
ASSEMBLY o page 5, a d HOW TO FOLD
AND MOVE THE TREADMILL o page 21.)
You must be able to safely lift 45 pou ds (20
kg) to raise, lower, or move the treadmill.
19. Whe foldi g or movi g the treadmill, make
sure that the storage latch is fully closed.
20. Whe usi g iFIT.com CDs a d videos, a
electro ic “chirpi g” sou d will alert you
whe the speed of the treadmill is about to
cha ge. Always liste for the “chirp” a d be
prepared for speed cha ges. I some i -
sta ces, the speed may cha ge before the
perso al trai er describes the cha ge.
21. Whe usi g iFIT.com CDs a d videos, you
ca ma ually override the speed setti g at
a y time by pressi g the speed butto s.
However, whe the ext “chirp” is heard, the
speed will cha ge to the ext setti g for the
CD or video program.
22. Remove iFIT.com CDs a d videos from your
CD player or VCR whe you are ot usi g
them.
23. I spect a d properly tighte all parts of the
treadmill regularly.
24. Never i sert a y object i to a y ope i g.
25. DANGER:Always u plug the power
cord immediately after use, before clea i g the
treadmill, a d before performi g the mai te-
a ce a d adjustme t procedures described i
this ma ual. Never remove the motor hood u -
less i structed to do so by a authorized ser-
vice represe tative. Servici g other tha the
procedures i this ma ual should be performed
by a authorized service represe tative o ly.
26. This treadmill is i te ded for i -home use
o ly. Do ot use this treadmill i a commer-
cial, re tal, or i stitutio al setti g.
SAVE THESE INSTRUCTIONS
WARNING:Before begi i g this or a y exercise program, co sult your physicia . This
is especially importa t for perso s over the age of 35 or perso s with pre-existi g health problems.
Read all i structio s before usi g. ICON assumes o respo sibility for perso al i jury or property
damage sustai ed by or through the use of this product.
3
All manuals and user guides at all-guides.com

Thank you for selecting the revolutionary PROFORM®
E3 S treadmill. The E3 S treadmill combines ad-
vanced technology with innovative design to help you
get the most from your exercise program in the conve-
nience and privacy of your home. And when you’re not
exercising, the unique E3 S treadmill can be folded up,
requiring less than half the floor space of other tread-
mills.
For your be efit, read this ma ual carefully before
usi g the treadmill. If you have questions after read-
ing this manual, please call our Customer Service
Department toll-free at 1-800-999-37 6, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time (ex-
cluding holidays). To help us assist you, please note
the product model number and serial number before
calling. The model number of the treadmill is
PFTL61730. The serial number can be found on a
decal attached to the treadmill (see the front cover of
this manual for the location).
Before reading further, please review the drawing
below and familiarize yourself with the labeled parts.
BEFORE YOU BEGIN
4
Handrail
Upright
Storage Latch
Accessory Tray
Fan
Key/Clip
On/Off
Circuit Breaker
Walking Belt
Cushioned Walking Platform
for maximum exercise comfort
Foot Rail
Power Cord
RIGHT SIDE
Rear Roller
Adjustment Bolts
Console
CD Holder
BACK
All manuals and user guides at all-guides.com

1. Make sure that the power cord is u plugged.
With the help of a second person, carefully raise the
Uprights (97) to the position shown. Insert one of the
Extension Legs (92) into the right Upright. (Note: It may
be helpful to tip the Uprights forward as you insert the
Extension Leg.) Make sure that the Warning Decal (91)
is in the indicated location.
Insert the other Extension Leg (not shown) in the same
way.
5
92
97
1
1/4” Washer
(39)–4 Internal Star
Washer (77)–4
Extension Leg Bolt (96)–4 1” Tek Screw (80)–2
Upright Bolt (76)–4
Latch Screw (79)–2
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART LIST on pages 26 and 27. The number after the parentheses shows
the quantity needed for assembly. Note: If a part is ot i the parts bag, check to see if it is preattached to
o e of the parts to be assembled.
ASSEMBLY
Assembly requires two perso s. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is
coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the
top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor-
mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild,
non-abrasive cleaner.
Assembly requires the i cluded alle wre ches a d your ow phillips screwdriver
a d wire cutters .
91
All manuals and user guides at all-guides.com

3. Attach the Latch Assembly (82) to the Left Upright (84)
with the two Latch Screws (79). Start both Latch Screws
before tightening either of them. Note: The Latch Screws
may be preattached to the Left Upright.
79
84
82
3
4. Refer to drawing 4c. With the help of a second person,
hold the Console Base (101) near the Uprights (80, 84).
Look under the Console Base and locate the wires on
the sides of the Console Base. Make sure that the wires
are ot routed through the openings for the Trays (109,
111). Drawing 4a shows the correct route for the wires.
Drawing 4b shows an incorrect route.
Refer to drawing 4c. Cut the plastic ties holding the Wire
Harness (74) and the pulse wire in the Uprights (80, 84).
Locate the Wire Harness (74) and pulse wire in the
Uprights (97). Connect the Wire Harness and the pulse
wire to the connectors on the sides of the Console Base
(101). Make sure to co ect the co ectors properly
(see the i set drawi gs). IF THE CONNECTORS ARE
NOT CONNECTED PROPERLY, THE CONSOLE MAY
BE DAMAGED WHEN THE POWER IS TURNED ON.
The co ectors should slide together easily a d
s ap i to place. If the connectors do not slide together
easily and snap into place, turn a connector and try to in-
sert it again. Insert the excess Wire Harness and pulse
wire up into the Console Base.
101
111 109
97 97
4c
74
Pulse
Wire
2. With the help of a second person, carefully tip the
Uprights (97) down as shown. (Note: It may be helpful to
place your foot on one of the Extension Legs [92] as you
tip the Uprights.) Make sure that the Exte sio Legs
remai i the Uprights.
Attach each Extension Leg (92) with two Extension Leg
Bolts (96) and two 1/4” Washers (39) as shown. Thread
a Leveling Foot (9 ) into each side of the Upright Base
(97); do ot thread the Leveli g Feet fully i to the
Upright Base.
Attach the two Base Pads (99) to the Upright Base (97)
in the locations shown with two 1” Tek Screws (80).
With the help of a second person, raise the Upright Base
(97) to the vertical position.
96
80
80
99
99
39
96
92 9
9
96
92
96
97
39
39
97
2
6
4a 4b
Correct Incorrect
74
All manuals and user guides at all-guides.com
all-guides.com

7
If you purchase the optio al chest pulse se sor (see
page 20), follow the steps below to i stall the receiver
i cluded with the chest pulse se sor.
1. Make sure that the power cord is u plugged. Remove
the indicated Screw (108) and the Access Door (116).
2. Remove the paper from the adhesive pad on the back of
the receiver (A). Hold the receiver so the small cyli -
der is ear the lower edge of the receiver a d faci g
the Co sole (107) as show . Firmly press the Receiver
onto the indicated corner of the Access Door (116).
Connect the wire on the receiver to the indicated wire ex-
tending from the Console.
3. Make sure that o wires are pi ched. Reattach the
Access Door (116) with the Screw (108). The wires in-
cluded with the receiver may be discarded.
7. Make sure that all parts are properly tighte ed before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place. The large allen wrench is used to adjust the
walking belt (see page 23). To protect the floor or carpet, place a mat under the treadmill. If there are thin
sheets of clear plastic on the decals, remove them.
A
107
116 Cylinder
108
Wire
Wire
6. Fold the treadmill to the storage position (see page 21).
If the Wheels (94) are resting on the floor, or if the tread-
mill rocks slightly, turn one or both of the Leveling Feet
(9 ) under the Uprights (97) until the Wheels are off the
floor and the rocking motion is eliminated. Note: If neces-
sary, tip the treadmill and use a phillips screwdriver to
turn the Leveling Feet.
6
9 94
94 97
. Set the Console Base (101) on the Uprights (97). Thread
the four Upright Bolts (76) with four Internal Star
Washers (77) into the Uprights and the Console Base.
Be careful ot to pi ch the Wires ( ot show ) i the
Uprights. Tighten the two Upright Bolts indicated by the
arrows first; then, tighten the remaining two Upright Bolts.
Make sure that the Left and Right Trays (109, 111) are
pressed into the Console Base (101).
76 77
101
76
77
111 109
97
84
77
All manuals and user guides at all-guides.com

8
OPERATION AND ADJUSTMENT
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with
PERFORMANT LUBETM, a high-performance lubricant.
IMPORTANT: Never apply silico e spray or other
substa ces to the walki g belt or the walki g plat-
form. Such substa ces will deteriorate the walki g
belt a d cause excessive wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill bei g damaged, always use a surge
suppressor with your treadmill (see drawi g 1 at
the right). To purchase a surge suppressor, see
your local PROFORM dealer or call 1-800-806-3651
a d order part umber 146148.
Use o ly a si gle-outlet surge suppressor that is
UL 1449 listed as a tra sie t voltage surge sup-
pressor (TVSS). The surge suppressor must have a
UL suppressed voltage rati g of 400 volts or less
a d a mi imum surge dissipatio of 450 joules.
The surge suppressor must be electrically rated
for 120 volts AC a d 15 amps. There must be a
mo itori g light o the surge suppressor to i di-
cate whether it is fu ctio i g properly. Failure to
use a properly fu ctio i g surge suppressor could
result i damage to the co trol system of the
treadmill. If the co trol system is damaged, the
walki g belt may cha ge speed or stop u expect-
edly, which may result i a fall a d serious i jury.
This product must be grou ded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord i to a surge suppressor,
a d plug the surge suppressor i to a appropriate
outlet that is properly i stalled a d grou ded i
accorda ce with all local codes a d ordi a ces.
Importa t: The treadmill is ot compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are ot grou ded. Co tact a qualified elec-
tricia to determi e if the outlet box cover is
grou ded before usi g a adapter.
DANGER:Improper co ectio
of the equipme t-grou di g co ductor ca
result i a i creased risk of electric shock.
Check with a qualified electricia or service-
ma if you are i doubt as to whether the
product is properly grou ded. Do ot modify
the plug provided with the product—if it will
ot fit the outlet, have a proper outlet
i stalled by a qualified electricia .
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin
All manuals and user guides at all-guides.com

9
FEATURES OF THE CONSOLE
The treadmill console offers an impressive array of
features that help you get the most from your workouts.
When the manual mode of the console is selected, the
speed and incline of the treadmill can be changed with
the touch of a button. As you exercise, the console will
display instant exercise feedback. You can even mea-
sure your heart rate using the handgrip pulse sensor or
the optional chest pulse sensor (see page 20).
In addition, the console offers six preset workout pro-
grams. Each program automatically controls the speed
and incline of the treadmill as it guides you through an
effective workout. Two pulse programs are also offered.
Each program automatically adjusts the speed and in-
cline of the treadmill to keep your heart rate within a tar-
get range while you exercise.
The console also features iFIT.com interactive technol-
ogy. Having iFIT.com technology is like having a per-
sonal trainer in your home. Using the included audio
cable, you can connect the treadmill to your home
stereo, portable stereo, or computer and play special
iFIT.com CD and video programs (one iFIT.com CD is
included; additional CDs and videocassettes are avail-
able separately). iFIT.com CD and video programs au-
tomatically control the speed and incline of the treadmill
as a personal trainer guides you through every step of
your workout. High-energy music provides added moti-
vation. To purchase iFIT.com CDs or videocas-
settes, call toll-free 1-800-735-0768.
With the treadmill connected to your computer, you
can also go to our Web site at www.iFIT.com and ac-
cess programs directly from the internet. Additional op-
tions are soon to be available. See www.iFIT.com for
more i formatio .
To use the ma ual mode of the co sole, follow the
steps beginning on page 10. To use preset programs,
see page 12. To use heart rate programs, see page
13. To use a iFIT.com CD or video program, see
page 17. To use iFIT.com programs directly from
our Web site, see page 19.
Note: If there are thin sheets of clear
plastic on the console, remove them. Clip
Key
All manuals and user guides at all-guides.com

10
HOW TO TURN ON THE POWER
Plug in the power cord (see page 8).
Locate the on/off cir-
cuit breaker near the
power cord. Make
sure that the circuit
breaker is in the on
position.
Stand on the foot rails of the treadmill. Find the clip
attached to the key (see the drawing on page 9)
and slide the clip onto the waistband of your
clothes. Next, route the cord attached to the clip
u der the ha dgrip pulse se sor, and insert the
key into the console. After a moment, the displays
and various indicators will light. Test the clip by
carefully taki g a few steps backward u til the
key is pulled from the co sole. If the key is ot
pulled from the co sole, adjust the positio of
the clip.
HOW TO USE THE MANUAL MODE
I sert the key fully i to the co sole.
See HOW TO TURN ON THE POWER above.
Select the ma ual mode.
When the key is in-
serted, the manual
mode will be selected.
To reselect the manual
mode, press the
Program Select button
repeatedly until a track
appears in the matrix. Make sure that the indicator
on the iFIT.com button is not lit.
Press the Start butto or the Speed ▲▲ butto to
start the walki g belt.
A moment after the button is pressed, the walking
belt will begin to move at 1 mph. Hold the handrails
and begin walking.
As you exercise, change the speed of the walking
belt as desired by pressing the Speed ▼▼ and ▲▲
buttons. Each time a
button is pressed, the
speed setting will
change by 0.1 mph; if a
button is held down, the
speed setting will
change in increments of 0. mph. To change the
speed setting quickly, press the Quick Speed but-
tons. Note: The co sole ca display speed a d
dista ce i either miles or kilometers. For sim-
plicity, all i structio s i this sectio refer to
miles.
To stop the walking belt, press the Stop button.
The Time/Pace display will begin to flash. To
restart the walking belt, press the Start button or
the Speed ▲▲ button.
Note: The first time the treadmill is used, observe
the alignment of the walking belt, and align the
walking belt if necessary (see page 23).
Cha ge the i cli e of the treadmill as desired.
To change the incline of
the treadmill, press the
Incline
▼▼ and ▲▲ buttons.
Each time a button is
pressed, the incline will
change by 0. %.
Follow your progress with the matrix a d the
displays.
The matrix—When the
manual mode or the
iFIT.com mode is se-
lected, the matrix will
display a 1/4-mile track.
As you exercise, the in-
dicators around the track
will light in succession until the entire track is lit.
The track will then darken and the indicators will
again begin to light in succession.
Speed display—This
display shows the speed
of the walking belt. Note:
When the KM/H indica-
tor is lit, the console will
display speed and dis-
tance in kilometers; when the KM/H indicator is
not lit, the console will display speed and distance
in miles.
5
4
3
2
1
3
2
1
Reset
Position
All manuals and user guides at all-guides.com

11
To change the unit of
measurement, first hold
down the Stop button
while inserting the key
into the console. An “E”
for English miles or an
“M” for metric kilometers will appear in the Speed
display. Press the Speed
▲▲ button to change the
unit of measurement. When the desired unit of
measurement is selected, remove the key.
Calories/Pulse
display—This display
shows the approximate
numbers of calories and
fat calories you have
burned (see FAT BURN-
ING on page 24). The
display will change from one number to the other
every few seconds. The display will also show
your heart rate when you use the handgrip pulse
sensor or the optional chest pulse sensor.
Dista ce/I cli e dis-
play—This display
shows the distance that
you have walked or run
and the incline level of
the treadmill. The display
will change from one number to the other every
few seconds. Note: Each time the incline changes,
the display will show the incline setting for several
seconds.
Time/Pace display—
When the manual mode
or the iFIT.com mode is
selected, this display will
show the elapsed time
and your current pace
(pace is measured in minutes per mile). The dis-
play will change from one number to the other
every few seconds. When a preset program or a
heart rate program is selected, the display will
show the time remaining in the program rather
than the elapsed time.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Measure your heart rate if desired.
You can measure your heart rate using either the
handgrip pulse sensor or the optional chest pulse
sensor.
To use the hand-
grip pulse sen-
sor, first make
sure that your
hands are clean.
Next, sta d o
the foot rails
and hold the
handgrip pulse
sensor, with your hands on the metal contacts.
Avoid movi g your ha ds. When your pulse is
detected, two dashes (– –) will appear in the
Calories/Pulse display, and then your heart rate
will be shown. For the most accurate heart rate
readi g, co ti ue to hold the co tacts for
about 15 seco ds.
Tur o the fa if desired.
To turn on the fan, press the button below the fan.
To turn on the fan at high speed, press the button
a second time. To turn off the fan, press the but-
ton a third time. Note: A few minutes after the
walking belt is stopped, the fan will automatically
turn off.
Whe you are fi ished exercisi g, remove the
key from the co sole.
Step onto the foot rails, press the Stop button, and
adjust the i cli e of the treadmill to the lowest
setti g. The i cli e must be at the lowest setti g
whe the treadmill is folded to the storage posi-
tio or the treadmill will be damaged. Next, re-
move the key from the console and put it in a se-
cure place. Note: If the displays a d various i di-
cators o the co sole remai lit after the key is
removed, the co sole is i the “demo” mode.
See page 20 a d tur off the demo mode.
When you are finished using the treadmill, move
the on/off circuit breaker switch near the power
cord to the off position and unplug the power cord.
8
7
6
Contacts
All manuals and user guides at all-guides.com
all-guides.com

12
HOW TO USE PRESET PROGRAMS
I sert the key fully i to the co sole.
See HOW TO TURN ON THE POWER on page
10.
Select o e of the preset programs.
When the key
is inserted, the
manual mode
will be se-
lected. To se-
lect a preset
program,
press the Program Select button repeatedly until
one of the six preset program indicators lights.
When a preset program is selected, the Speed
display will flash the maximum speed setting of
the program, and the Distance/Incline display will
flash the maximum incline setting, for six seconds.
The Time/Pace display will show how long the
program will last.
The matrix will show
the first seven speed
settings of the program.
Note: The profiles
below the matrix show
how the speed and in-
cline of the treadmill
will change during the programs.
Press the Start butto or the Speed ▲▲ butto to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each program is divided into several time seg-
ments of different lengths. One speed setting and
one incline setting are programmed for each seg-
ment. Note: The same speed setting and/or in-
cline setting may be programmed for two or more
consecutive segments.
The speed setting for the
first segment is shown in
the flashing Current
Segment column of the
matrix. (The incline set-
tings are not shown in
the matrix.) The speed
settings for the next
seven segments are
shown in the seven columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
series of tones will sound. If the speed and/or in-
cline of the treadmill is about to change, the Speed
display and/or the Distance/Incline display will
flash to alert you. When the first segment ends, all
speed settings will move one column to the left.
The speed setting for the second segment will then
be shown in the flashing Current Segment column
and the treadmill will automatically adjust to the
speed and incline settings for the second segment.
Note: If all of the indicators in the Current Segment
column are lit after the speed settings have moved
to the left, the speed settings will move downward
so that only the highest indicators appear in the
matrix. If some of the indicators in the Current
Segment column are not lit when the speed set-
tings move to the left again, the speed settings will
move back up.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column of the matrix and the
Time/Pace display counts down to zero. The walk-
ing belt will then slow to a stop.
If the speed or incline setting is too high or too low
at any time during the program, you can manually
override the setting by pressing the Speed or
Incline buttons. Every few times a Speed button is
pressed, an additional indicator will light or darken
in the Current Segment column. (If any of the
columns to the right of the Current Segment col-
umn have the same number of lit indicators as the
Current Segment column, an additional indicator
may light or darken in those columns as well.)
Note: Whe the ext segme t of the program
begi s, the treadmill will automatically adjust
to the speed a d i cli e setti gs for the ext
segme t.
3
2
1
Current Segment
All manuals and user guides at all-guides.com

13
To stop the program temporarily, press the Stop
button. The Time/Pace display will begin to flash.
To restart the program, press the Start button or
the Speed ▲▲ button. To end the program, press
the Stop button, remove the key, and then reinsert
the key.
Follow your progress with the displays.
See step on page 10.
Measure your heart rate if desired.
See step 6 on page 11.
Tur o the fa if desired.
See step 7 on page 11.
Whe the program is fi ished, remove the key
from the co sole.
When the program has ended, make sure that
the i cli e of the treadmill is at the lowest set-
ti g. Next, remove the key from the console and
put it in a secure place. Note: If the displays a d
various i dicators o the co sole remai lit
after the key is removed, the co sole is i the
“demo” mode. Refer to page 20 a d tur off the
demo mode.
When you are finished using the treadmill, move
the on/off circuit breaker switch near the power
cord to the off position and unplug the power cord.
HOW TO USE HEART RATE PROGRAMS
Follow the steps below to use a heart rate program.
Note: You must wear the optio al chest pulse se -
sor (see page 20) to use a heart rate program.
Put o the chest pulse se sor.
See the instructions included with the optional
chest pulse sensor.
I sert the key fully i to the co sole.
See HOW TO TURN ON THE POWER on page
10.
Select a heart rate program.
When the key
is inserted, the
manual mode
will be se-
lected. To se-
lect a heart
rate program,
press the Program Select button repeatedly until
one of the two heart rate program indicators lights.
The two profiles on the left side of the matrix show
how the target heart rate will change during the
programs. During heart rate program 1, your heart
rate will reach approximately 8 % of your esti-
mated maximum heart rate; during heart rate pro-
gram 2, your heart rate will reach approximately
80% of your estimated maximum heart rate.
Note: Your estimated maximum heart rate is de-
termined by subtracting your age from 220. For
example, if you are 30 years old, your estimated
maximum heart rate is 190 beats per minute
(220 – 30 = 190).
3
2
1
7
6
5
4
CAUTION:If you have heart prob-
lems, or if you are over 60 years of age a d
have bee i active, do ot use the heart rate
programs. If you are taki g medicatio regu-
larly, co sult your physicia to fi d whether the
medicatio will affect your exercise heart rate.
All manuals and user guides at all-guides.com

14
During heart rate pro-
grams, the matrix will
show a graphic that
represents your heart
rate. Each time a heart-
beat is detected, an ad-
ditional peak will ap-
pear.
E ter your age a d a maximum speed setti g.
When a heart rate pro-
gram is selected, the
word “AGE” and the
current age setting will
flash in the Calories/
Pulse display. If you
have already entered
your age, simply press the Enter Age button. If
you have not entered your age, press the
▲▲ and ▼▼
buttons beside the Enter Age button to enter your
age. Then, press the Enter Age button.
After you have entered
your age, the letters
“SPd” and the maxi-
mum speed setting of
the program will flash in
the Calories/Pulse dis-
play. If desired, press
the
▲▲ and ▼▼ buttons beside the Enter Age button
to adjust the maximum speed setting. When the
desired setting is shown, press the Enter Age but-
ton.
Press the Start butto or the Speed ▲▲ butto to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings of the program. Hold the handrails
and begin walking.
Each heart rate program is divided into several time
segments of different lengths. One target heart rate
is programmed for each segment.
During each segment, the console will regularly
compare your heart rate to the current target heart
rate. If your heart rate is too far below or above
the target heart rate, the speed of the treadmill will
automatically increase or decrease to bring your
heart rate closer to the target heart rate. If the
speed reaches the maximum speed setting of the
program (see step 4 at the left) and your heart
rate is still too far below the current target heart
rate, the incline of the treadmill will also increase
to bring your heart rate closer to the target heart
rate.
During the last three seconds of each segment, a
series of tones will sound and the Speed display
and the Distance/Incline display will flash.
The program will continue until no time remains in
the program. The walking belt will then slow to a
stop.
If the speed or incline setting is too high or too low
at any time during the program, you can adjust the
setting with the Speed or Incline buttons. However,
each time the console compares your heart rate to
the current target heart rate, the speed and/or in-
cline of the treadmill may automatically change to
bring your heart rate closer to the target heart
rate.
If your pulse is not detected during the program,
the letters “PLS” will flash in the Calories/
Pulse display and the speed and incline of the
treadmill may automatically decrease until your
pulse is detected. If this occurs, refer to the instruc-
tions included with the optional chest pulse sensor.
To stop the program at any time, press the Stop
button. Heart rate programs cannot be stopped
temporarily and then restarted. To use a heart rate
program again, reselect the program and start it at
the beginning.
Follow your progress with the displays.
See step on page 10.
Tur o the fa if desired.
See step 7 on page 11.
Whe the program is fi ished, remove the key
from the co sole.
See step 7 on page 13.
8
7
6
5
4
All manuals and user guides at all-guides.com

15
HOW TO CONNECT THE TREADMILL TO YOUR
CD PLAYER, VCR, OR COMPUTER
To use iFIT.com CDs, the treadmill must be connected
to your portable CD player, portable stereo, home
stereo, or computer with CD player. See pages 1 and
16 for connecting instructions. To use iFIT.com video-
cassettes, the treadmill must be connected to your
VCR. See page 17 for connecting instructions. To use
iFIT.com programs directly from our i ter et site,
the treadmill must be connected to your home com-
puter. See page 16 for connecting instructions.
HOW TO CONNECT YOUR PORTABLE CD PLAYER
Note: If your CD player has separate LINE OUT a d
PHONES jacks, see i structio A below. If your CD
player has o ly o e jack, see i structio B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your CD player. Plug your headphones into the
PHONES jack.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3. mm Y-adapter (avail-
able at electronics stores). Plug the Y-adapter into
the PHONES jack on your CD player. Plug your
headphones into the other side of the Y-adapter.
HOW TO CONNECT YOUR PORTABLE STEREO
Note: If your stereo has a RCA-type AUDIO OUT
jack, see i structio A below. If your stereo has a
3.5mm LINE OUT jack, see i structio B. If your
stereo has o ly a PHONES jack, see i structio C.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter. Plug
the adapter into an AUDIO OUT jack on your stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your stereo.
C. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3. mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your stereo. Plug your
headphones into the other side of the Y-adapter.
LINE OUT
PHONES LINE OUT
PHONES
Audio
Cable
Head-
phones
A
AUDIO OUT
RIGHT
LEFT
Audio
Cable Adapter
A
LINE OUT
Audio
Cable
B
PHONES
Audio
Cable
C
PHONES
PHONES
Audio
Cable
3. mm
Y-adapter
Headphones
B
3. mm
Y-adapter
Headphones
All manuals and user guides at all-guides.com

16
HOW TO CONNECT YOUR HOME STEREO
Note: If your stereo has a u used LINE OUT jack,
see i structio A below. If the LINE OUT jack is
bei g used, see i structio B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the LINE OUT jack on your
stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the LINE OUT jack on your
stereo and plug the wire into the unused side of the
Y-adapter. Plug the Y-adapter into the LINE OUT
jack on your stereo.
HOW TO CONNECT YOUR COMPUTER
Note: If your computer has a 3.5mm LINE OUT jack,
see i structio A. If your computer has o ly a
PHONES jack, see i structio B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your computer.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3. mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your computer. Plug your
headphones or speakers into the other side of the
Y-adapter.
LINE OUT
CD
VCR
Amp
LINE OUT
Audio
Cable Adapter
A
LINE OUT
Audio
Cable
A
CD
VCR
Amp
LINE OUT
Audio
Cable
RCA
Y-adapter
Wire removed from
LINE OUT jack
B
Adapter
PHONES
Audio
Cable
B
3. mm
Y-adapter
Headphones/Speakers
All manuals and user guides at all-guides.com
all-guides.com

17
HOW TO CONNECT YOUR VCR
Note: If your VCR has a u used AUDIO OUT jack,
see i structio A below. If the AUDIO OUT jack is
bei g used, see i structio B. If you have a TV
with a built-i VCR, see i structio B. If your VCR
is co ected to your home stereo, see HOW TO
CONNECT YOUR HOME STEREO o page 16.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the AUDIO OUT jack on your
VCR.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the AUDIO OUT jack on your
VCR and plug the wire into the unused side of the
Y-adapter. Plug the Y-adapter into the AUDIO OUT
jack on your VCR.
HOW TO USE IFIT.COM CD AND VIDEO
PROGRAMS
To use iFIT.com CDs or videocassettes, the treadmill
must be connected to your portable CD player, portable
stereo, home stereo, computer with CD player, or
VCR. See HOW TO CONNECT THE TREADMILL TO
YOUR CD PLAYER, VCR, OR COMPUTER on pages
1 to 17. Note: To purchase iFIT.com CDs or video-
cassettes, call toll-free 1-800-735-0768.
Follow the steps below to use an iFIT.com CD or video
program.
I sert the key i to the co sole.
See HOW TO TURN ON THE POWER on page 11.
Select the iFIT.com mode.
When the key
is inserted, the
manual mode
will be se-
lected. To use
iFIT.com CDs
or videocas-
settes, press the iFIT.com button. The iFIT.com
indicator will light.
I sert the iFIT.com CD or videocassette.
If you are using an iFIT.com CD, insert the CD
into your CD player. If you are using an iFIT.com
videocassette, insert the videocassette into your
VCR.
Press the PLAY butto o your CD player or
VCR.
A moment after the button is pressed, your per-
sonal trainer will begin guiding you through your
workout. Simply follow your personal trainer’s
instructions. Note: If the Time/Pace display is
flashing, press the Start button or the Speed ▲▲
button on the console. The treadmill will not re-
spond to a CD or video program when the
Time/Pace display is flashing.
During the CD or video program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always liste for the “chirp” a d be
prepared for speed a d/or i cli e cha ges. I
some i sta ces, the speed a d/or i cli e may
cha ge before the perso al trai er describes
the cha ge.
4
3
2
1
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT. IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
A
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
B
Wire removed from
AUDIO OUT jack
RCA Y-adapter
All manuals and user guides at all-guides.com

18
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, whe the ext “chirp” is
heard, the speed a d/or i cli e will cha ge to
the ext setti gs of the CD or video program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Pace dis-
play will begin to flash. To restart the program,
press the Start button or the Speed
▲▲ button. After
a moment, the walking belt will begin to move at 1
mph. Whe the ext “chirp” is heard, the
speed a d i cli e will cha ge to the ext set-
ti gs of the CD or video program.
When the CD or video program is completed, the
walking belt will stop and the Time/Pace display
will begin to flash. Note: To use another CD or
video program, press the Stop button or remove
the key and go to step 1 on page 17.
Note: If the speed or i cli e of the treadmill
does ot cha ge whe a “chirp” is heard:
• Make sure that the iFIT.com i dicator is lit a d
that the Time/Pace display is ot flashi g. If
the Time/Pace display is flashi g, press the
Start butto or the Speed
▲▲ butto o the
co sole.
• Adjust the volume of your CD player or VCR.
If the volume is too high or too low, the co -
sole may ot detect the program sig als.
• Make sure that the audio cable is properly
co ected, that it is fully plugged i , a d that
it is ot wrapped arou d a power cord.
• If you are usi g your portable CD player a d
the CD skips, set the CD player o the floor or
a other flat surface i stead of o the co sole.
Follow your progress with the matrix a d the
displays.
See step on page 10.
Measure your heart rate if desired.
See step 6 on page 11.
Tur o the fa if desired.
See step 7 on page 11.
Whe the program is completed remove the
key.
See step 7 on page 13.
CAUTION: Always remove iFIT.com CDs a d
videocassettes from your CD player a d VCR
whe you are fi ished usi g them.
8
7
6
5
All manuals and user guides at all-guides.com

19
HOW TO USE PROGRAMS DIRECTLY FROM
OUR WEB SITE
To use programs from our Web site, the treadmill must
be connected to your home computer. See HOW TO
CONNECT YOUR COMPUTER on page 16. In addi-
tion, you must have an internet connection and an in-
ternet service provider. A list of specific system re-
quirements is found on our Web site.
Follow the steps below to use a program from our
Web site.
I sert the key i to the co sole.
See HOW TO TURN ON THE POWER on page 10.
Select the iFIT.com mode.
When the key
is inserted, the
manual mode
will be se-
lected. To use
a program
from our Web
site, press the iFIT.com button. The iFIT.com indi-
cator will light.
Go to your computer a d start a i ter et
co ectio .
Start your web browser, if ecessary, a d go to
our Web site at www.iFIT.com.
Follow the desired li ks o our Web site to se-
lect a program.
Read and follow the on-line instructions for using a
program.
Follow the o -li e i structio s to start the
program.
When you start the program, an on-screen count-
down will begin.
Retur to the treadmill a d sta d o the foot
pads. Fi d the clip attached to the key a d slide
the clip o to the waistba d of your clothes.
When the on-screen countdown ends, the program
will begin and the walking belt will begin to move.
Hold the handrails, step onto the walking belt, and
begin walking. During the program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always liste for the “chirp” a d be
prepared for speed a d/or i cli e cha ges.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, whe the ext “chirp” is
heard, the speed a d/or i cli e will cha ge to
the ext setti gs of the program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Pace dis-
play will begin to flash. To restart the program,
press the Start button or the Speed ▲▲ button. After
a moment, the walking belt will begin to move at 1
mph. Whe the ext “chirp” is heard, the speed
a d i cli e will cha ge to the ext setti gs of
the program.
When the program is completed, the walking belt
will stop and the Time/Pace display will begin to
flash. Note: To use another program, press the
Stop button and go to step .
Note: If the speed or i cli e of the treadmill
does ot cha ge whe a “chirp” is heard, make
sure that the iFIT.com i dicator is lit a d that
the Time/Pace display is ot flashi g. I addi-
tio , make sure that the audio cable is properly
co ected, that it is fully plugged i , a d that it
is ot wrapped arou d a power cord.
Follow your progress with the matrix a d the
displays.
See step on page 10.
Whe the program has e ded, remove the key.
See step 7 on page 13.
9
8
7
6
5
4
3
2
1
All manuals and user guides at all-guides.com

20
THE INFORMATION MODE/DEMO MODE
The console features an information mode that keeps
track of the total number of hours that the treadmill has
been operated and the total number of miles that the
walking belt has moved. The information mode also al-
lows you to switch the console from miles per hour to
kilometers per hour. In addition, the information mode
allows you to turn on and turn off the demo mode.
To select the information mode, hold down the Stop
button while inserting the key into the console. When
the information mode is selected, the following informa-
tion will be shown:
The Distance/Incline display
will show the total number of
miles (or kilometers) that the
walking belt has moved.
The Time/Pace display will
show the total number of
hours the treadmill has been
used.
An “E” for English miles or
an “M” for metric kilometers
will appear in the Speed dis-
play. Press the Speed
▲▲ but-
ton to change the unit of
measurement.
IMPORTANT: The
Calories/Pulse display
should be bla k. If a “d” ap-
pears in the display, the con-
sole is in the “demo” mode.
This mode is intended to be
used only when a treadmill is displayed in a store.
When the console is in the demo mode, the power cord
can be plugged in, the key can be removed from the
console, and the displays and indicators on the console
will automatically light in a preset sequence, although
the buttons on the console will not operate. If a “d” ap-
pears i the Calories/Pulse display whe the i for-
matio mode is selected, press the Speed
▼▼ butto
so the display is bla k.
To exit the information mode, remove the key from the
console.
THE OPTIONAL CHEST PULSE SENSOR
An optional chest pulse sensor adds even more
features to the console. The chest pulse sensor provides
hands-free operation and allows the console’s heart
rate programs to be used. To purchase the optio al
chest pulse se sor, call toll-free 1-800-734-2377.
HOW TO LEVEL THE TREADMILL
If the treadmill wheels are touching the floor or if the
treadmill rocks slightly, turn one or both of the leveling
feet under the upright base until the wheels are off the
floor and the rocking motion is eliminated. Note: If nec-
essary, tip the treadmill and use a phillips screwdriver
to turn the leveling feet.
Leveling
Feet
Wheels
All manuals and user guides at all-guides.com
