INSTRUCTIONS FOR USE
Pro-Ject Phono Box MM

© ATR-Audio Trade GmbH · Pro-Ject Phono Box MM · Revision 2013.1.15
2
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO phono amplifier.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Safety instructions
!
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
DC
DC
!
Make all connections whilst the phono amplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red, the
left channel black or white.
Do not connect the phono amplifiers output to a phono input (sometimes labelled gram, disc or RIAA)
on the amplifier.
Never use any other power supply than the one supplied with the unit.
Connecting the record player (MM or high output MC cartridges only)
Connect the tonearm signal lead to the INPUT of the phono amplifier. The earthing wire may be connected to
the screw terminal if you encounter hum problems when using the record player.

© ATR-Audio Trade GmbH · Pro-Ject Phono Box MM · Revision 2013.1.15
3
Connection to the amplifier
Connect the OUTPUT of the phono amplifier to a line input (such as AUX, CD, Tuner, Tape or Video) on
your amplifier.
Mains power connection
The phono amplifier is supplied with a power supply suitable for your country's mains supply. Check the label
before connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug
from the power supply to the INPUT DC socket of the phono amplifier before connecting the power supply to
the mains.
Technical specifications Pro-Ject Phono Box MM
* typical for MM or high output MC cartridges
Input capacitance/input impedance, MM: 47kohms/120pF *
Gain: 32dB
Output voltage typically: 200mV/1kHz at 5mV/1kHz
Noise floor: 88dB (A weighted)
THD: <0,05%
RIAA-equalisation curve accuracy: 20Hz - 20kHz / max. 0,5dB
Input: 1 pair RCA/phono sockets
Line-level output: 1 pair RCA/phono sockets
Outboard power supply: ±18V/250mA DC, suitable for your country's mains supply
Power consumption: 20mA DC
Dimensions W x H x D (D with sockets): 107 x 30 x 61 (75)mm
Weight: 280g without power supply
Potential incorrect use and fault conditions
No signal on one or both channels:
No connection between player and phono amplifier or amplifier. This could be due to a faulty plug,
broken wire or solder joint or simply loose plug/socket connection.
Strong hum:
No earth connection from cartridge or arm, or arm cable to phono amplifier, or earth loop.
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
Copyright
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright ©2012. All rights reserved.
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
