PRO Light elumen8 User manual

Order code: ELUM056
Meteor 784 IP Batten
User Manual

www.prolight.co.uk Meteor 784 IP Batten User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and
the warranty becomes void. Incorrect operation may lead to danger e.g: short-circuit, burns and electric shocks etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and/or property.
Please note: These xtures are intended for stage lighting and entertainment applications only, and are not intended for
extended periods of use, including but not limited to house-light, industrial or architectural applications and should only be
operated with short duty cycles.
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Pro Light
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is
not designed for or suitable for household use. The
product must be installed by a qualied technician in
accordance with local territory regulations. The safety of
the installation is the responsibility of the installer. The
xture presents risks of severe injury or death due to re
hazards, electric shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• WARRANTY: One year from date of purchase.

www.prolight.co.uk Meteor 784 IP Batten User Manual 3
Product overview & technical specications
Generating intense white strobing and multicoloured pixel zone effects the Meteor 784 IP Batten features a central
strip of 112 x 3W cool white SMD LEDs, surrounded on both sides by a total of 672 x 1.5W RGB colour mixing
SMD LEDs. All the LEDs are divided into independently controllable zones (16 white and 32 colour). With a wide
beam angle the xture is ideally suited to concerts, festival stages and installations. A clever twist to this xture
is the ability to switch the front glass to a frosted output. The Intelliglass Technology® developed on this xture
allows the user to simply switch a DMX channel and alternate between clear and frost effects eliminating the need
for additional frost lters. A quick-positioning twist-lock mechanism on two sides ensures the xtures always line
up when used in multiples, and the IP65 rated housing weighs in at only 8.7kg.
• 2 year warranty
• 672 x 1.5W SMD LEDs (RGB) plus 112 x 3W SMD LEDs (CW)
• RGB beam angle: 101° (eld angle: 149°)
• CW beam angle: 108° (eld angle: 152°)
• Pixel zone mapping: 32 x RGB LED zones and
16 x CW LED zones can be controlled individually
• Intelliglass Technology® allows the user to simply alternate
between clear and frost effects eliminating the need for
additional frost lters
• Control protocols: DMX, Art-net and sACN
• DMX channels: 7/15/17/21/33/39/65/68/70/112/117
or 121 selectable
• 0 - 100% dimming
• 4 dimming curves: Linear, square law, inverse square law and
S-curve
• Variable strobe
• Supplied with installation brackets
• Multiple units can be seamlessly jointed tool-free
• 4 button menu with OLED display
• Bracket allows for multiple rigging or oor standing applications
• Quick release omega clamps included
• powerCON TRUE1 input/output
• IP rated 5-Pin XLR input/output
• etherCON input/output
• Fan cooled
Meteor 784 IP Batten
Specications Meteor 784 IP Batten
Power consumption 420W
Power supply 100~240V, 50/60Hz
IP rating IP65
Dimensions 165 x 1000 x 114mm
Weight 8.7kg
Order code ELUM056
IP65
1000mm
165mm
114mm

www.prolight.co.uk Meteor 784 IP Batten User Manual 4
Technical specications
01 - Bracket tightening knobs
02 - Mounting brackets
03 - Fans
04 - powerCON TRUE1 input
05 - powerCON TRUE1 output
06 - Locking pin
07 - IP rated 5-Pin XLR input
08 - etherCON input
09 - OLED display
10 - Function buttons
11 - etherCON output
12 - IP rated 5-Pin XLR output
In the box: 1 x xture,
2 x omega clamps
& 1 x power cable
DMX OUTPUT
ETHERNET OUTPUT
DMX INPUT ETHERNET INPUT
06 08 1007 1109 12
02
01
03
02
03
01
0504
DMX OUTPUT
ETHERNET OUTPUT
DMX INPUT ETHERNET INPUT

www.prolight.co.uk Meteor 784 IP Batten User Manual 5
Installation
Installation:
1. Fasten each clamp to the omega clamps with a bolt and lock nut through the hole in the
omega clamp.
2. Align and insert the omega clamp quick-lock fasteners with the respective holes on the bottom
of the unit.
3. Tighten both locking fasteners clockwise on each omega clamp ensuring they’re fully secure.
4. Mount the xture onto your truss system via the clamps and tighten to ensure secure.
5. Pull the safety cable through the safety cable holes located on the metal base plate on the
underside of the xture and around the truss.
1
2
5
3
4

www.prolight.co.uk Meteor 784 IP Batten User Manual 6
Main Menu Sub Menu Options/Values Description
1. DMX
Address 001-512 DMX Address Setting
Channels
7
DMX Channel Modes
15
17
21
33
39
65
68
70
112
117
121
2. ARTNET/sACN
1. 192.168.001.xxx 192.168.001.xxx IP Address
2. 255.255.255.000 255.255.255.000 Subnet Mask
3. Net 000-127 Net
4. Sub-Net 00-15 Sub-net
4. Universe 00-15 Universe
5. sACN-Uni 1-63999 sACN Universe
3. Slave Yes Slave Mode
No
4. AUTO Yes Auto Mode
No
5. Program
Mode 1-35 Built-in program
Colour (Mode:1) 1-38 Static colour mode
Speed (Mode:2-35) 1-100 (81) Speed
Strobe: 0-99 Strobe
6. Dimmer
Red 000-255
Manual Dimming mode
Green 000-255
Blue 000-255
S-White 000-255
7. Glass fog 000-255 Glass Frost
Operating instructions
IMPORTANT! PLEASE NOTE:The OLED display for this xture has a menu locking function where
after 30 seconds ofinactivity it will lock. To unlock the menu hold the “MODE” and “SET” buttons
for 3 seconds.

www.prolight.co.uk Meteor 784 IP Batten User Manual 7
Operating instructions
Main Menu Sub Menu Options/Values Description
8. Settings
1. Curves Select 1-4 (2) Dimming Curve Setting
2. Dimmer Speed Fast Dimming Speed Setting
Smooth
3. Pixel Dir Normal Pixel Direction
Inverted
4. Display Normal Display setting
Inverted
5. DMX Fail
Blackout
DMX Fail Setting
Hold
Manual
Program
6. Fan Mode
Auto
Fan Speed SettingHigh
Slow
7. Backlight Time
5s
Backlight Time setting
10s
20s
30s
ON
8. Lock On Lock Screen
Off
9. Factory Yes Restore Factory Setting
No
9. Information
Version: x.x
Fixture Information
T1:xx°C T2:xx°C
Work Time:xxxxxh
UID: 0x09A5-xxxxxxxx
MAC:xxxxxxxxxxxx

www.prolight.co.uk Meteor 784 IP Batten User Manual 8
Operating instructions
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
1 1 - 1 - - - - - - - - 000-255 Red dimmer (0-100%)
2 2 - 2 - - - - - - - - 000-255 Green dimmer (0-100%)
3 3 - 3 - - - - - - - - 000-255 Blue dimmer (0-100%)
4 4 - - - - - - - - - - 000-255 White Strobe (0-100%)
5 6 - 5 - 25 - 1 1 - 1 1 000-255 RGB dimmer (0-100%)
6 7 - 6 - 26 - - - - - - 000-255 RGB dimmer ne (0-100%)
- - - - - - - 2 2 - - -
RGB Strobe Effect
000-007 No function
008-127 Strobe
128-130 No function
131-250 Random
251-255 No function
- 8 - 7 - 27 - - - - 2 2 000-255 RGB strobe duration
- 9 - 8 28 - - - - 3 3
RGB Strobe Rate
000-006 No function
007-255 Speed (slow-fast)
-10 - 9 - 29 - - - - 4 4
RBG Strobe Mode
000-005 No function
006-050 Ramp up
051-100 Ramp down
101-150 Ramp up-down
151-200 Lightning
201-255 Random
5 6 - 13 - 34 - 1 - - 1 5 000-255 White strobe dimmer (0-100%)
6 7 - 14 - 35 - - - - - - 000-255 White strobe dimmer ne (0-100%)
- - - - - - - 3 3 - - -
White Strobe Effect
000-007 No function
008-127 Strobe
128-130 No function
131-250 Random
251-255 No function
- 8 - 15 - 36 - - - - 2 6 000-255 White strobe duration
- 9 - 16 -37 - - - - 3 7
White Strobe Rate
000-006 No function
007-255 Speed (slow-fast)
-10 -17 - 38 - - - - 4 8
White Strobe Mode
000-005 No function
006-050 Ramp up
051-100 Ramp down

www.prolight.co.uk Meteor 784 IP Batten User Manual 9
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
-10 -17 - 38 - - - - 4 8
White Strobe Mode (cont.)
101-150 Ramp up-down
151-200 Lightning
201-255 Random
- 5 - 4 - - - - - - - -
Colour Macro
000-010 No function
011-016 R(255) G(000) B(000)
017-022 R(255) G(080) B(000)
023-028 R(255) G(008) B(000)
029-034 R(255) G(052) B(000)
035-040 R(255) G(063) B(000)
041-046 R(247) G(214) B(000)
047-052 R(230) G(215) B(000)
053-058 R(225) G(232) B(000)
059-064 R(210) G(255) B(000)
065-070 R(045) G(094) B(000)
071-076 R(008) G(226) B(000)
077-082 R(080) G(232) B(000)
083-088 R(075) G(255) B(000)
089-094 R(032) G(223) B(000)
095-100 R(029) G(255) B(000)
101-106 R(000) G(255) B(000)
107-112 R(000) G(255) B(094)
113-118 R(006) G(255) B(043)
119-124 R(015) G(255) B(065)
125-130 R(205) G(255) B(099)
131-136 R(219) G(232) B(075)
137-142 R(213) G(220) B(222)
143-148 R(037) G(255) B(227)
149-154 R(049) G(246) B(255)
155-160 R(000) G(255) B(234)
161-166 R(000) G(099) B(255)
167-172 R(000) G(078) B(255)
173-178 R(000) G(000) B(255)
179-184 R(040) G(001) B(255)
185-190 R(226) G(075) B(226)
191-196 R(255) G(038) B(219)
197-202 R(255) G(059) B(013)
203-208 R(255) G(000) B(044)
Operating instructions

www.prolight.co.uk Meteor 784 IP Batten User Manual 10
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
- 5 - 4 - - - - - - - -
Colour Macro (cont.)
209-214 R(214) G(034) B(048)
215-220 R(255) G(235) B(052)
221-226 R(255) G(200) B(040)
227-232 R(255) G(050) B(030)
233-255 R(255) G(255) B(255)
-11 -10 --------
RBG Macro
000-021 No function
022-030 Macro 1
031-039 Macro 2
040-048 Macro 3
049-057 Macro 4
058-066 Macro 5
067-075 Macro 6
076-084 Macro 7
085-093 Macro 8
094-102 Macro 9
103-111 Macro 10
112-120 Macro 11
121-129 Macro 12
130-138 Macro 13
139-147 Macro 14
148-156 Macro 15
157-165 Macro 16
166-174 Macro 17
175-183 Macro 18
184-192 Macro 19
193-201 Macro 20
202-210 Macro 21
211-219 Macro 22
220-228 Macro 23
229-237 Macro 24
238-246 Macro 25
247-255 Macro 26
-13 -11 - - - - - - - - 000-255 RGB Macro speed (slow-fast)
- 12 - 18 -------- White Macro
------------
000-090 No function
091-105 Macro 1
106-120 Macro 2
Operating instructions

www.prolight.co.uk Meteor 784 IP Batten User Manual 11
Operating instructions
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
- 12 - 18 --------
White Macro (cont.)
121-135 Macro 3
136-150 Macro 4
151-165 Macro 5
166-180 Macro 6
181-195 Macro 7
196-210 Macro 8
211-225 Macro 9
226-240 Macro 10
241-255 Macro 11
-13 -19 - - - - - - - - 000-255 White macro speed (slow-fast)
-14 - 12 - - - - 69 - - - 000-255 RGB Fade (fast-slow)
-14 - 20 - - - - 70 - - - 000-255 White fade (fast-slow)
715 17 21 33 39 65 4 4 - 5 9 000-255 Glass frost (0-100%)
- -
1
-
111551610 000-255 Red 1 dimmer (0-100%)
2 2 2 2 6 6 2 7 11 000-255 Green 1 dimmer (0-100%)
3 3 3 3 7 7 3 8 12 000-255 Blue 1 dimmer (0-100%)
1 1 1 4 8 8 4 9 13 000-255 Red 2 dimmer (0-100%)
2 2 2 5 9 9 5 10 14 000-255 Green 2 dimmer (0-100%)
3 3 3 6 10 10 611 15 000-255 Blue 2 dimmer (0-100%)
1 4 1 7 11 11 7 12 16 000-255 Red 3 dimmer (0-100%)
2 5 2 8 12 12 8 13 17 000-255 Green 3 dimmer (0-100%)
3 6 3 9 13 13 914 18 000-255 Blue 3 dimmer (0-100%)
1 4 1 10 14 14 10 15 19 000-255 Red 4 dimmer (0-100%)
2 5 2 11 15 15 11 16 20 000-255 Green 4 dimmer (0-100%)
3 6 3 12 16 16 12 17 21 000-255 Blue 4 dimmer (0-100%)
4 7 4 13 17 17 13 18 22 000-255 Red 5 dimmer (0-100%)
5 8 5 14 18 18 14 19 23 000-255 Green 5 dimmer (0-100%)
6 9 6 15 19 19 15 20 24 000-255 Blue 5 dimmer (0-100%)
4 7 4 16 20 20 16 21 25 000-255 Red 6 dimmer (0-100%)
5 8 5 17 21 21 17 22 26 000-255 Green 6 dimmer (0-100%)
6 9 6 18 22 22 18 23 27 000-255 Blue 6 dimmer (0-100%)
410 419 23 23 19 24 28 000-255 Red 7 dimmer (0-100%)
511 5 20 24 24 20 25 29 095-100 Green 7 dimmer (0-100%)
6 12 6 21 25 25 21 26 30 101-106 Blue 7 dimmer (0-100%)
410 4 22 26 26 22 27 31 107-112 Red 8 dimmer (0-100%)
511 5 23 27 27 23 28 32 113-118 Green 8 dimmer (0-100%)
6 12 6 24 28 28 24 29 33 119-124 Blue 8 dimmer (0-100%)
713 7 25 29 29 25 30 34 125-130 Red 9 dimmer (0-100%)

www.prolight.co.uk Meteor 784 IP Batten User Manual 12
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
- -
8
-
14 8 26 30 30 26 31 35 131-136 Green 9 dimmer (0-100%)
915 927 31 31 27 32 36 000-255 Blue 9 dimmer (0-100%)
713 7 28 32 32 28 33 37 000-255 Red 10 dimmer (0-100%)
814 8 29 33 33 29 34 38 000-255 Green 10 dimmer (0-100%)
915 9 30 34 34 30 35 39 000-255 Blue 10 dimmer (0-100%)
716 731 35 35 31 36 40 000-255 Red 11 dimmer (0-100%)
817 8 32 36 36 32 37 41 000-255 Green 11 dimmer (0-100%)
918 9 33 37 37 33 38 42 000-255 Blue 11 dimmer (0-100%)
716 7 34 38 38 34 39 43 000-255 Red 12 dimmer (0-100%)
817 8 35 39 39 35 40 44 000-255 Green 12 dimmer (0-100%)
918 9 36 40 40 36 41 45 000-255 Blue 12 dimmer (0-100%)
10 19 10 37 41 41 37 42 46 000-255 Red 13 dimmer (0-100%)
11 20 11 38 42 42 38 43 47 000-255 Green 13 dimmer (0-100%)
12 21 12 39 43 43 39 44 48 000-255 Blue 13 dimmer (0-100%)
10 19 10 40 44 44 40 45 49 000-255 Red 14 dimmer (0-100%)
11 20 11 41 45 45 41 46 50 000-255 Green 14 dimmer (0-100%)
12 21 12 42 46 46 42 47 51 000-255 Blue 14 dimmer (0-100%)
10 22 10 43 47 47 43 48 52 000-255 Red 15 dimmer (0-100%)
11 23 11 44 48 48 44 49 53 000-255 Green 15 dimmer (0-100%)
12 24 12 45 49 49 45 50 54 000-255 Blue 15 dimmer (0-100%)
10 22 10 46 50 50 46 51 55 000-255 Red 16 dimmer (0-100%)
11 23 11 47 51 51 47 52 56 000-255 Green 16 dimmer (0-100%)
12 24 12 48 52 52 48 53 57 000-255 Blue 16 dimmer (0-100%)
1 1 13 1 5 5 49 54 58 000-255 Red 17 dimmer (0-100%)
2 2 14 2 6 6 50 55 59 000-255 Green 17 dimmer (0-100%)
3 3 15 3 7 7 51 56 60 000-255 Blue 17 dimmer (0-100%)
1 1 13 4 8 8 52 57 61 000-255 Red 18 dimmer (0-100%)
2 2 14 5 9 9 53 58 62 000-255 Green 18 dimmer (0-100%)
3 3 15 610 10 54 59 63 000-255 Blue 18 dimmer (0-100%)
1 4 13 711 11 55 60 64 000-255 Red 19 dimmer (0-100%)
2 5 14 8 12 12 56 61 65 000-255 Green 19 dimmer (0-100%)
3 6 15 913 13 57 62 66 000-255 Blue 19 dimmer (0-100%)
1 4 13 10 14 14 58 63 67 000-255 Red 20 dimmer (0-100%)
2 5 14 11 15 15 59 64 68 000-255 Green 20 dimmer (0-100%)
3 6 15 12 16 16 60 65 69 000-255 Blue 20 dimmer (0-100%)
4 7 16 13 17 17 61 66 70 000-255 Red 21 dimmer (0-100%)
5 8 17 14 18 18 62 67 71 000-255 Green 21 dimmer (0-100%)
6 9 18 15 19 19 63 68 72 000-255 Blue 21 dimmer (0-100%)
4 7 16 16 20 20 64 69 73 000-255 Red 22 dimmer (0-100%)
Operating instructions

www.prolight.co.uk Meteor 784 IP Batten User Manual 13
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
- -
5
-
817 17 21 21 65 70 74 000-255 Green 22 dimmer (0-100%)
6 9 18 18 22 22 66 71 75 000-255 Blue 22 dimmer (0-100%)
410 16 19 23 23 67 72 76 000-255 Red 23 dimmer (0-100%)
511 17 20 24 24 68 73 77 000-255 Green 23 dimmer (0-100%)
6 12 18 21 25 25 69 74 78 000-255 Blue 23 dimmer (0-100%)
410 16 22 26 26 70 75 79 000-255 Red 24 dimmer (0-100%)
511 17 23 27 27 71 76 80 000-255 Green 24 dimmer (0-100%)
6 12 18 24 28 28 72 77 81 000-255 Blue 24 dimmer (0-100%)
713 19 25 29 29 73 78 82 000-255 Red 25 dimmer (0-100%)
814 20 26 30 30 74 79 83 000-255 Green 25 dimmer (0-100%)
915 21 27 31 31 75 80 84 000-255 Blue 25 dimmer (0-100%)
713 19 28 32 32 76 81 85 000-255 Red 26 dimmer (0-100%)
814 20 29 33 33 77 82 86 000-255 Green 26 dimmer (0-100%)
915 21 30 34 34 78 83 87 000-255 Blue 26 dimmer (0-100%)
716 19 31 35 35 79 84 88 000-255 Red 27 dimmer (0-100%)
817 20 32 36 36 80 85 89 000-255 Green 27 dimmer (0-100%)
918 21 33 37 37 81 86 90 000-255 Blue 27 dimmer (0-100%)
716 19 34 38 38 82 87 91 000-255 Red 28 dimmer (0-100%)
817 20 35 39 39 83 88 92 000-255 Green 28 dimmer (0-100%)
918 21 36 40 40 84 89 93 000-255 Blue 28 dimmer (0-100%)
10 19 22 37 41 41 85 90 94 000-255 Red 29 dimmer (0-100%)
11 20 23 38 42 42 86 91 95 000-255 Green 29 dimmer (0-100%)
12 21 24 39 43 43 87 92 96 000-255 Blue 29 dimmer (0-100%)
10 19 22 40 44 44 88 93 97 000-255 Red 30 dimmer (0-100%)
11 20 23 41 45 45 89 94 98 000-255 Green 30 dimmer (0-100%)
12 21 24 42 46 46 90 95 99 000-255 Blue 30 dimmer (0-100%)
10 22 22 43 47 47 91 96 100 000-255 Red 31 dimmer (0-100%)
11 23 23 44 48 48 92 97 101 000-255 Green 31 dimmer (0-100%)
12 24 24 45 49 49 93 98 102 000-255 Blue 31 dimmer (0-100%)
10 22 22 46 50 50 94 99 103 000-255 Red 32 dimmer (0-100%)
11 23 23 47 51 51 95 100 104 000-255 Green 32 dimmer (0-100%)
12 24 24 48 52 52 96 101 105 000-255 Blue 32 dimmer (0-100%)
13 25 30 49 53 53 97 102 106 000-255 Strobe White 1 dimmer (0-100%)
13 25 30 50 54 54 98 103 107 000-255 Strobe White 2 dimmer (0-100%)
13 26 30 51 55 55 99 104 108 000-255 Strobe White 3 dimmer (0-100%)
13 26 30 52 56 56 100 105 109 000-255 Strobe White 4 dimmer (0-100%)
14 27 31 53 57 57 101 106 110 000-255 Strobe White 5 dimmer (0-100%)
14 27 31 54 58 58 102 107 111 000-255 Strobe White 6 dimmer (0-100%)
14 28 31 55 59 59 103 108 112 000-255 Strobe White 7 dimmer (0-100%)
Operating instructions

www.prolight.co.uk Meteor 784 IP Batten User Manual 14
Channel
Value Function
7
CH
15
CH
17
CH
21
CH
33
CH
39
CH
65
CH
68
CH
70
CH
112
CH
117
CH
121
CH
- -
14
-
28 31 56 60 60 104 109 113 000-255 Strobe White 8 dimmer (0-100%)
15 29 32 57 61 61 105 110 114 000-255 Strobe White 9 dimmer (0-100%)
15 29 32 58 62 62 106 111 115 000-255 Strobe White 10 dimmer (0-100%)
15 30 32 59 63 63 107 112 116 000-255 Strobe White 11 dimmer (0-100%)
15 30 32 60 64 64 108 113 117 000-255 Strobe White 12 dimmer (0-100%)
16 31 33 61 65 65 109 114 118 000-255 Strobe White 13 dimmer (0-100%)
16 31 33 62 66 66 110 115 119 000-255 Strobe White 14 dimmer (0-100%)
16 32 33 63 67 67 111 116 120 000-255 Strobe White 15 dimmer (0-100%)
16 32 33 64 68 68 112 117 121 000-255 Strobe White 16 dimmer (0-100%)
Operating instructions

www.prolight.co.uk Meteor 784 IP Batten User Manual 15
To connect more Meteor 784 IP Battens
together you can use the quick positioning
twist lock system shown below.
Twist Lock System
Rotate in pin 90° until
it holds its position.
Rotate the pin 90°
until it releases and
locks into the catch.
1. Pull the locating pin upwards.
Positioned at the output end
of the batten.
2.
5. Repeat until
all battens are
joined together.
6.
Push and hold the catch
outwards. Positioned at the
input end of the batten.
3.
Align the battens and slide together ensuring
the catch locates inside the next batten.
4.

www.prolight.co.uk Meteor 784 IP Batten User Manual 16
DMX setup
Further DMX cables can be purchased from all good sound and lighting suppliers or Prolight Concepts dealers.
Please quote: CABL10 – 2m CABL11 – 5m CABL12 – 10m3-Pin:
CABL185 – 2m CABL187 – 5m CABL188 – 10m5-Pin:
Setting the DMX address:
The DMX mode enables the use of a universal DMX controller. Each xture requires a “start address”
from 1- 512. A xture requiring one or more channels for control begins to read the data on the channel
indicated by the start address. For example, a xture that occupies or uses 7 channels of DMX and was
addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104,
105 and 106. Choose a start address so that the channels used do not overlap. E.g. the next unit in
the chain starts at 107.
DMX 512:
DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent
xtures and controllers. A DMX controller sends DMX data instructions form the controller to the xture.
DMX data is sent as serial data that travels from xture to xture via the DATA “IN” and DATA “OUT”
XLR terminals located on all DMX xtures (most controllers only have a data “out” terminal).
DMX linking:
DMX is a language allowing all makes and models of different manufactures to be linked together
and operate from a single controller, as long as all xtures and the controller are DMX compliant.
To ensure proper DMX data transmission, when using several DMX xtures try to use the shortest
cable path possible. The order in which xtures are connected in a DMX line does not inuence the
DMX addressing. For example; a xture assigned to a DMX address of 1 may be placed anywhere in
a DMX line, at the beginning, at the end, or anywhere in the middle. When a xture is assigned a
DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit,
no matter where it is located in the DMX chain.
DATA cable (DMX cable) requirements (for DMX operation):
This xture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit.
Your unit requires either a standard 3-pin or 5-pin XLR connector for data input/output,
see images below.
Also remember that DMX cable must be daisy chained and cannot be split.

www.prolight.co.uk Meteor 784 IP Batten User Manual 17
Notice:
Be sure to follow the diagrams below when making your own cables.
Do not connect the cables shield conductor to the ground lug or
allow the shield conductor to come in contact with the XLRs
outer casing. Grounding the shield could cause a short circuit
and erratic behaviour.
Line termination:
When longer runs of cable are used,
you may need to use a terminator on
the last unit to avoid erratic behaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL90,
5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR xtures
may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a
3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
5-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (female)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (male)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup
Termination reduces signal
transmission problems and
interference. It is always
advisable to connect a DMX
terminal, (resistance 120
Ohm 1/4W) between pin 2
(DMX-) and pin 3 (DMX+) of
the last xture.
5-Pin
1
2 4
5
3
3-Pin
1 2
3
Pin Conguration
3-Pin 5-Pin
Pin 1 - Ground
Pin 2 - Negative
Pin 3 - Positive
– Pin 4 - N/C
– Pin 5 - N/C
1
2
3
1
2
3
DMX 512
3-Pin XLR output
DMX 512
3-Pin XLR input
GROUND
DMX +
DMX –
DMX 512
5-Pin XLR output
DMX 512
5-Pin XLR input
1
2
45
3
12
4
5
3
GROUND
N/C
DMX –
N/C DMX +
1 ground
3 hot
2 cold
3-Pin XLR male 3-Pin XLR female
2 cold
3 hot
1 ground
2 cold
1 ground 5 N/C
3 hot 4 N/C
5-Pin XLR male 5-Pin XLR female
4 N/C
5 N/C 1 ground
3 hot 2 cold

www.prolight.co.uk Meteor 784 IP Batten User Manual 18
Multiple xture power linking
Power linking:
This xture provides power linking via the power output on the rear allowing multiple units to be
connected together. The maximum number of xtures that can be connected is 2 xtures @ 240V
or 3 xtures @ 120V (including the rst xture). After the maximum number of xtures are
connected a new power run will need to be started.
Please note: Caution should be used when power linking other xtures to the Meteor 784 IP Batten
as the power consumption of other xtures will vary. Fixtures tted with lamps often require 2/3 times
more current on startup, these may require their own power source.
Power ln
Power Out
DMX l n
Network
Network
DMX O ut
Power ln
Power Out
DMX l n
Network
Network
DMX O ut

www.prolight.co.uk Meteor 784 IP Batten User Manual 19
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed of
with other household wastes at the end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their
local government ofce, for details of where and how they can take this item for environmentally
safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
