PRO SIGNAL PSG08418 User manual

1
4:2 HDMI Matrix Switch
PSG08418
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

2
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future reference.
When using electrical appliances basic safety precautions should always be followed.
• To prevent fire or shock hazard, do not expose this product to rain or moisture.
• Beware of static electricity which may damage the device. Use ESD precautions
when installing.
WHAT'S INCLUDED
• HDMI switcher splitter unit
• 5V DC PSU
• Remote control
• Instruction manual
• Switches easily between any four HDMI sources.
• Distributes any of the four inputs to any or any combination of the two HDMI output
displays.
• Supports highest video resolution 1080p.
• Supports 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth.
• Supports 12bit per channel (36bit all channel) deep colour.
• Supports HDCP
• Supports uncompressed audio such as LPCM.
• Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD
and Dolby True HD).
• Support 3D all format, including [email protected]/24Hz, [email protected]/60Hz/50Hz,
bandwidth up to 225MHz
The HDMI SWITCH SPLITTER Matrix routes high definition video in multiple resolutions
up to 1080p plus multichannel digital audio from any of the four HDMI sources to two
displays. Two outputs give you the choices of sending high definition audio and video
signals up to two displays. Any four to any two matrix switching allows for maximum
versatility for integrated systems. It eliminates the needing of disconnects and
reconnects sources to a display equipped with one input.
Compatible with HD-DVD players, Blue Ray DVD, PS3, and satellite set top boxes that
connect to two HDMI displays.
OVERVIEW
FEATURES

3
INSTALLATION
OPERATION
PANEL DESCRIPTIONS
• Connect the HDMI input source into this product (Input cables are optional)
*please refer to connection diagram section.
• Insert the 5V DC PSU into the mains socket and connect the DC output to the
switcher splitter DC input jack.
PSG3429
• Press the power button on the front panel to switch the unit on or into standby mode
• Press any of the 4 buttons marked A to select four source devices to display on the
output A display device.
• Press any of the 4 buttons marked B to select four source devices to display on the
output B display device.
Remote control
• The power button on the remote control duplicates the power button on the front
panel.
• The two off buttons can switch off either of the A or B outputs
• The buttons marked 1, 2, 3, 4 can select the source device for either or both A and
B outputs.

4
CLEANING & MAINTENANCE
Clean the outside plastic casing with a soft cloth lightly moistened with mild soap and
water. Never use any abrasive or solvents.
SPECIFICATIONS
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China
PO Box 13362 Dublin 2
PR2 9PP
Man Rev 1.0
Signal Input/Output
Input Video Signal 5 Volts p-p (TTL)
Max single link range 1920 x 1080p
Output Video HDMI Type A 19 pin
Operating Frequency
Vertical Frequency Range 50/60Hz
Video Amplier Bandwidth 2.25Gbps/225MHz
Transmission distance
UTP cable with cross stand inside 35m for 1080p
Resolutions(HDTV)
Interlaced (50&60Hz) 480i, 576i, 1080i
Progressive (50&60Hz) 480p, 576p, 720p, 1080p
Environmental
Operating Temperature 0oC to +70oC
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10oC to +80oC
Storage Humidity 5% to 90% RH (no condensation)
Dimensions (HxWxD) 25x260x110mm
Weight 85g
Power Requirement
External Power Supply 5V DC 2A
Power consumption (Max) 8W
