ProAudio P976L User manual
User Manual
Lavalier condenser microphone
P976L
P976L is a lavalier condenser microphone with omni-directional polar pattern designed
for TV shows and conferences.
Great transparency that grants an high speech intelligibility
Connection: 4 poles mini XLR
Suitable also for acoustic instruments
Wide dynamic range and frequency response for excellent sound reinforcement
Small size for minimum visibility
Together with clothing clip for easy attaching to a tie, lapel, dress etc.
Cable length: 1,2 mt
PROAUDIO® presents a line of microphones suitable for the different recording
situations. Quality, reliability and above all, precision in the sound recording, are the
main features that make this series an essential reference point for the sound
recording professional.
Lavalier condenser microphone P976L
P976L
Lavalier condenser microphone
Congratulation for choosing a PROAUDIO® product.
Please read the instruction manual carefully before use.
Specifications
Polar pattern
Element
Frequency response
Impedance
Max. SPL
Power supply
Current consumption
Connector
Type Back electret
Omni-directional
Pressure gradient FET preamplifier
100-15,000Hz
2.2K ± 30%
130dB
3.5mA
Mini XLR connector
Phantom power 9-52V DC
Dimensions 30 x16 x 12 mm
Weight 12 g
P976L
Lavalier condenser microphone
P976L
Lavalier condenser microphone
Music & Lights Srl Via Appia Km 136.200 - 04020 -Itri (LT) ITALY
Tel:+39 0771 721966 Fax:+39 0771 721977 Web:www.musiclightsitaly.com
