ProAudio Pw100 Series User manual

User manual
Pw160 - Head/Lavalier Set
Pw150 - Vocal set
Pw100 Series
Wireless

100 CH
UHF PLL DUAL Channel
DIVERSITY Receiver
1. English.................................................................................................................1-11

Wireless Microphone - Pw100 Series2
English
Congratulation for choosing a PROAUDIO® product, please
read the instruction manual carefully before use.
UHF professional wireless system Pw100 series
Built-in mute & audio locked loop design pressing disturbance.
100 frequency spots
PLL module locked loop design
Frequency input separately, perform excellent dynamic features.
Super high dynamic double compressed diversity technology, high and low vocal.
Offer balanced XLR & unbalanced Jack 6.3 mm output socket
MENU, UP, DOWN, SET etc are control function buttons
Special Counter-interference circuit design
PROAUDIO® presents a system of wireless microphones with a UHF radiofrequency technology. This system features as
main peculiarities a diversity receiver and 100 selectable frequencies for a maximum of 5 simultaneous compatible systems.
Easiness in use carachterizes this "entry level" product that yet does not disregard the quality and the efficiency of
professional models.

Wireless Microphone - Pw100 Series 3
English
Pw100 Series
un
1
1

4
EnglishEnglish
Wireless Microphone - Pw100 Series
Hand-held transmitter PW10M
44
44
Batteries
Turn on
Press power for 1 second, the LED wil flash several times and show the final channel setting.that menans the
microphone begin to work.
Channel setting
press SET under microphone working status till wanted channel appear. Then press SET for 2 seconds, the
LCD show “LC” means the current setting has been locked.
Unlock
Press SET under the “LC” locked status for 3 seconds, LCD show “UL” means the microphone unlock.
Turn off
Press power for 1second till LCD show “OF” means handheld microphone has stopped working.
Set button

5
English
Wireless Microphone - Pw100 Series
Specification
Dynamic

6
English
Wireless Microphone - Pw100 Series
Desktop receiver PW10R
Channel setting:Press”SET” until it displays “SET” when the word “FREQ” is showed, then press “ ” or “ ” to set up the channel;
and then press “SET” again.
Sensitivity setting: Press “SET” until it shows “SQL” , and then press “ ” or “ ” to adjust the sensitivity of receiver (0-7) ; and then
press “SET” to store.
Automatic scanning: Press “SET” 3 times until it display the word “SCAN” , and the press “ ” or “ ” to be scanned automatically
to match the frequency channel set from handheld microphone, and then automatically locked the channel, and the press “SET” to memorize.

7
English
Wireless Microphone - Pw100 Series
Specification

8
English
Wireless Microphone - Pw100 Series
PW10B

9
English
Wireless Microphone - Pw100 Series
