Probrite STLR15-PC-4K-BZ Setup guide

Model No. STLR15-PC-4K-BZ
STLR22-PC-5CCT-BZ
STLR22-PC-5CCT-WH
Before returning to the store, call, text, or email PROBRITE
Customer Care 9am-5pm EST Monday to Friday.
1-844-507-5651
[email protected]om
PROBRITE.COM
Questions? / Missing Parts? / Need Accessories?
Visit us online anytime or call us to get information on our product range, download
detailed spec & photometric files, find product and mounting accessories, view
installation tutorials and videos, and learn about our DLC® rebate eligible products.
INSTALLATION,
USAGE, & CARE GUIDE
DUO LED TWIN HEAD
FLOOD LIGHT

2
Visit www.probrite.com/install for installation video tutorials and product support
Table of Contents.......................... 2
Safety Information........................ 2
Pre-Installation.............................. 3
Planning Installation............................ 3
Specifications........................................ 3
Tools Required...................................... 3
Hardware Included............................... 4
Package Contents............................... 4
Installation...................................... 5
Operation ....................................... 9
Care & Cleaning............................. 10
Troubleshooting............................ 10
Warranty.......................................... 11
TABLE OF CONTENTS
SAFETY INFORMATION
IMPORTANT
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
NATIONAL ELECTRICAL CODE AND LOCAL BUILDING CODES BY A PERSON FAMILIAR
WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS
INVOLVED.
PRECAUTIONS
☐Please read and understand this entire
manual before attempting to assemble,
install, or operate this light fixture.
☐This light fixture requires a 120-Volt AC
power source.
☐Some codes require installation by a
qualified electrician.
☐This light fixture must be properly
grounded.
☐Make sure connections are secure using
connecting devices
☐This light fixture should be installed
outdoors to a wall or eave.
WARNING:
breaker or fuse. Place tape over the circuit
Turn the power off at the circuit
light fixture.
WARNING: Risk of fire. Keep the fixture heads at
least 3 in. (76mm) from combustible materials.
CAUTION: Burn hazard. Allow the light fixture
to cool before touching.
NOTICE: Do not connect this fixture to a
dimmer switch.
NOTICE: FCC Regulations state that any
unauthorized changes or modifications to
this equipment not expressly approved by the
manufacturer could void the user’s authorization
to operate this equipment.
INFORMATION: The device is tested and found to comply with Part 15 of the FCC Rules. Operation is subject
to two conditions: (1) This device may not cause harmful interference and, (2) this device must accept any
interference received, including any interference that may cause undesired operation.
These limits are designed to provide reasonable protections against harmful interference when the
equipment is operated in a commercial environment.
wire nuts, crimp-on lugs or other approved

3PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
PREINSTALLATION
PLANNING INSTALLATION
Before installing the light fixture, ensure that all parts are present. Compare parts with the
Hardware Included and Package Contents sections. If any part is missing or damaged, do
not attempt to assemble, install, or operate this light fixture.
Lumens (Light Output) 1500 Lumens
STLR 15 STLR 22
Watts (Power Consumption) 15 Watts LED
2250 Lumens
22 Watts LED
Replaces 75W Halogen bulbs
Lumens/Watts (Efficacy) 100 Lumens per watt 102 Lumens per watt
Power Requirements (Input Voltage) 120VAC, 60 Hz
Light Color (CCT) 4000 Kelvin 2700K, 3000K, 3500K,
4000K, 5000K
Dimmable Non-Dimming (do not wire to dimming switch)
Operating Modes Dusk-to-Dawn:
Automatically turns light fixture ON during night
and OFF during day.
Switch-Controlled:
Flip switch to turn light fixture ON and OFF. Use
included light sensor cap on fixture's light sensor
to utilize this mode setting.
SPECIFICATIONS
TOOLS REQUIRED
Phillips
screwdriver
Wire strippers/
cutters
Circuit tester
Wrench Power
drill
Work
gloves
Silicone
sealant
Ladder
Safety
goggles

4
Visit www.probrite.com/install for installation video tutorials and product support
PREINSTALLATION CONTINUED
CC
HARDWARE KIT
NOTE: Hardware not shown to actual size.
AA BB
Part Description Quantity
AA #8-32 x 3/4" Philips head screw 2
BB Wire nut 3
CC Hex head screwdriver 1
CC
PACKAGE CONTENTS
Part Description Quantity
ALight fixture 1
BPhotocell (light sensor) 1
CMounting plate set screw (pre-installed) 1
DMounting plate with gasket (pre-installed) 1
EHanger wire for hands-free installation (pre-installed) 1
FBlack photocell cover 1
GRemote control 1
A
BC
F
EG
D

5PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
INSTALLATION
1FOR BEST RESULTS
☐Install light 8-15 feet above the ground.
☐Do not mount fixture close to reflective
surfaces such as windows, white walls,
white surfaces and water.
Wall Mount Eave Mount
1-1/2" 1-1/2"
Round Octagonal (fig 3).
(fig 1).
NOTE:
Mounting plate (D) mounts to standard recessed
junction boxes. Junction box must be at least
1-1/2 inch deep for proper installation. (fig 3).
2SHUT OFF ELECTRIC
POWER OFF
☐Verify wall switch is in OFF position (fig 4).
☐
the circuit breaker that supplies power
At the main electrical panel, turn off
to the junction box you are working on
(fig 5).
☐For screw-in type fuses, unscrew the
fuse that supplies power to the junction
box you are working on (fig 6). (fig 4). (fig 5). (fig 6).
☐Do NOT wire to dimming switch.
☐When mounting fixture, make sure the
photocell orientation is at the bottom
for wall mount and away from building
for eave mount.
☐When mounting to a wall, make sure
the fixture is 7 in. on center away from
eave and 13 inches on center away from
inside corner of the exterior wall (fig 2).
(fig 2).
13 in. 13 in
7 in

6
Visit www.probrite.com/install for installation video tutorials and product support
INSTALLATION CONTINUED
3REMOVE THE
MOUNTING PLATE
C
DD
D
NOTE: The mounting plate (D) comes
pre-assembled on the light fixture (A)
for shipping.
NOTE: The mounting plate set screw (C)
comes pre-installed on the light fixture.
☐Remove the mounting plate (D) from
the back of the fixture by loosening
the mounting plate set screw (C)
using the hex head screwdriver (DD).
4
☐For wall mount, the "TOP" arrow must
point upward.
☐For eave mount, the "TOP" arrow must
point toward the building.
TIP: Only unscrew the set screw (C) far
enough to remove the mounting plate (D).
Do not fully remove the set screw (C).
AA
D
(fig 7).(fig 6).
☐Route the junction box wires through
the large center hole in the mounting
plate (D).
☐Align the holes on the mounting plate
(D) with the holes of the junction box.
Use two #8 screws (AA) to attach the
mounting plate (D) to the junction box.
INSTALL THE
MOUNTING
PLATE TO THE
JUNCTION BOX

7PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
INSTALLATION CONTINUED
5HANG FIXTURE TO
MOUNTING PLATE
☐Place the small sphere head of the hanger
wire (E) between the back of the small groove
located on the bottom of the center hole of
the mounting plate (D).
☐For wall mount , ensure the photocell (B)
is facing downwards when light fixture
(A) is installed.
☐For eave mount , ensure the photocell (B)
is facing away from the building when
light fixture (A) is installed.
6MAKE THE ELECTRICAL
CONNECTIONS
TIP: Ensure the light fixture (A) can safely hang
onto the mounting plate (D) to allow both hands to
make the electrical connections (fig 8).
A
D
E
B
E
D
B
(fig 8).
A
A
E
D
BB
(fig 9).
Black (Line)
White (Common)
Green (Ground)
Junction Box
☐
☐
If necessary, strip 3/8" of insulation
from junction box and lighting fixture
wires (fig 9). Connect wires by twisting
the exposed wires together and using
the wire nuts (BB). Ensure no loose
wires.
Connect lighting fixture black wire to
junction box black wire (line), lighting
fixture white wire to junction box white
wire (common), the junction box ground
wire to the green lighting fixture ground
wire, which is attached to the mounting
plate (D)
Non-Dimming Wiring Diagram
TIP:
Hold stripped ends near each other and
align any frayed strands (do not twist wires).
Push the wires into wire nut (BB) and use
your fingers to twist the wire nut clockwise
until tight. Check for tightness by pulling
wires.

8
Visit www.probrite.com/install for installation video tutorials and product support
A
B
INSTALLATION CONTINUED
7MOUNT THE LIGHT
FIXTURE
☐Once the fixture is wired, place the light
fixture (A) onto the mounting plate (D)
so the top sloped groove on the plate rests
on the top sloped groove on the back of the
fixture.
☐Verify the fixture is flush with the
mounting surface and photocell (B) is
pointed downward for wall mount or
away from building on eave mount.
☐Tighten the mounting plate set screw
(C) on the bottom of the fixture (A) until
the screw firmly pushes against the
mounting plate (D).
8CAULK AROUND THE
LIGHT FIXTURE
☐
9
☐After fixture is securely mounted, manually aim
each lamp head on the fixture (A) to point toward
the direction desired.
☐If one or both heads on the fixture (A) appear
loose, use a philips head screwdriver to
tighten the screws located on the arms of
the light heads.
☐To test light fixture illumination, cover
photocell (B) and turn power back ON from the
breaker and switch. Adjust lamp heads as
needed to achieve desired lighting pattern.
A
B
WARNING: Risk of fire. Keep the lamp heads
at least 3 in. (76mm) from combustible
materials.
CAUTION: Keep lamp heads 30° below
horizontal to prevent water damage and
electrical shock.
C
DD
(fig 10).
(fig 11).
(fig 12).
NOTICE: Failure to properly caulk around the
back face of the light fixture and mounting surface
could lead to water damage and is not covered under
warranty.
NOTE: When attaching the light fixture (A) to a
surface mount junction box, caulk between the
mounting plate and junction box.
Caulk around the fixture and surface
with silicone sealant (not included) as
shown in (fig 11).
AIM THE LAMP
HEADS AND TEST
D

9PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
OPERATION
1DUSKTODAWN MODE OPTION
A
B
F
(Leave the black cover on the
photocell)
B
AUTOMATIC
NIGHTTIME ON
DAYTIME OFF
(fig 13).
(fig 14).
☐To enable dusk-to-dawn operation, remove
the black photocell cover (F) installed
on the fixture. Note: Ensure the
photocell is unobstructed.
☐Ensure the switch powering the light fixture is
turned to the ON position and leave it ON
at all times to enable automatic dusk-to-dawn
operation.
Dusk-to-dawn operation enables the light fixture to automatically turn
ON when dark outside and turn OFF when the sun rises, thus saving you
energy.
NOTE: If photocell is located in an area
under heavy shade, the photocell may not
detect enough light and may turn the light
fixture on.
TIP: To test if the light fixture and photocell
work properly, run power to the fixture and
cover the photocell to turn fixture ON.
Shine a light into the photocell to see if
fixture turns OFF.
SWITCHCONTROLLED OPTION
Switch controlled operation enables the light fixture to
turn ON and OFF by flipping a switch that controls
the electricity to the junction box powering the fixture.
The light fixture will not turn ON and OFF
automatically, but is manually controlled.
☐To enable switch activated operation, leave
the black photocell cover (F) on the photocell.

OPERATION CONTINUED
1B SELECT COLOR TEMPERATURE CCT
STLRPCCCT MODEL ONLY
10
Visit www.probrite.com/install for installation video tutorials and product support
(fig 15).
TROUBLESHOOTING
Problem Possible Cause Solution
Light does not
turn ON
No power to the fixture
Check if circuit breaker is tripped
Confirm wall switch is ON
Verify wiring to fixture is correct (turn
power OFF to fixture beforehand)
Fixture is sensing daylight Cover photocell. Wait several
seconds until fixture turns ON.
Light cycles
ON and OFF
continuously
Photocell light sensor is
sensing reflected light
Relocate light fixture to a location
where there is no reflected light.
OR place the black cover over
the photocell and use the wall
switch to turn the light fixture
ON and OFF.
CARE AND CLEANING
☐
appearance, clean the light fixture with clear water and a soft, damp cloth only.
☐Do not use abrasive cleaners or cleaners that contain alcohol. Do not apply paints,
solvents, or any other chemicals on this light fixture. They could cause a premature
deterioration of the finish and may void the warranty.
☐Do not spray the light fixture with a hose or power washer.
Shut off main power supply before cleaning the product. To prolong the original
☐
☐
☐
☐
Standing within 15 feet, aim the remote control (H) at the front of the
light fixture. Note: IR receiver is behind fixture lens.
The remote has six buttons: ON/OFF, 2700K, 3000K, 3500K, 4000K
and 5000K. Press the buttons to preview the correlated color
temperatures (CCT).
Once you make a selection, keep the light turned on at the selected
color temperature for at least 5 seconds to store the selected color
into memory (this will ensure it always turns on to the last selected
color).
To change light color at any time, point the remote at the fixture lens
(within 15 feet) and select desired color temperature.

11 PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
TROUBLESHOOTING
Problem Possible Cause Solution
Light
FLICKERS
The light fixture is wired to a
dimmer
Remove dimmer, fixture
is nondimming.
Light stays ON
Photocell is in a shaded area
Shine a flashlight into the photocell
and wait a couple minutes.
If the light turns OFF, the fixture
should be moved to a location
with enough light in the daylight
hours for the photocell to work.
OR Cover the photocell
and use the wall switch to
turn the light ON and OFF.
Photocell is faulty
a flashlight is shone on the photocell
If the light does not turn OFF when
for a few minutes, then the photocell
may be faulty. Please contact
customer service.
NOTE: Photocell may have a few minutes delay during troubleshooting.
When testing, shine a light and/or cover the photocell and allow a few minutes
for fixture to function properly.
YEAR LIMITED WARRANTY
This is a limited warranty offered by Probrite for a period of five years from the date of purchase to its
customers. Probrite warrants to customers that the products will be free from defects in material and
workmanship. The obligation of Probrite under this warranty is limited to the provision of replacement of
products and is extended to the original purchaser of the product on presenting valid purchase receipt or
other proof of date of original purchase acceptable to Probrite. The receipt is required for rendering the
warranty performance. Any warranty claims without original proof of purchase would not be accepted.
It should be noted that the warranty does not apply to Probrite products that have been altered or repaired by
unauthorized personnel, have been subjected to neglect, abuse, misuse or accident or damages caused
during shipping. Any other products not manufactured by Probrite which have been supplied, installed and/or
used in conjunction with Probrite products are not covered under this warranty. Any damages caused by
replacements bulbs, LEDs or corrosion or discoloration of brass components are also not covered by this
warranty.
Limitation of Liability:
In no event Probrite shall be liable for indirect, consequential, incidental or special damages, or lost profits.
Probrite is not liable for any claims or damage arising out of or connected with the manufacture, sale, delivery,
use, maintenance and repair or modification of Probrite products, or supply of any replacement parts that,
exceed the purchase price of Probrite products giving rise to a claim. Labor charges to remove or install the
fixtures will not be accepted.
To Claim:
Please contact PROBRITE customer service at 1-844-507-5651 or email [email protected] and
include your name, address and contact number, along with a copy of the purchase receipt and a brief
description of the problem.

Before returning to the store, call or email PROBRITE
Customer Service 9am-5pm EST Monday to Friday.
1-844-507-5651
[email protected]om
PROBRITE.COM
Questions? / Missing Parts? / Need Accessories?
RETAIN THIS MANUAL FOR FUTURE USE
Para las translaciones en español,
visit www.probrite.com/install
