Probrite AUR20-3K-WH Setup guide

Before returning to the store, call or email PROBRITE
Customer Service 9am-5pm EST Monday to Friday.
1-844-507-5651
[email protected]om
PROBRITE.COM
Questions? / Missing Parts? / Need Accessories?
Visit us online anytime or call us to get information on our product range, download
detailed spec & photometric files, find product and mounting accessories, view
installation tutorials and videos, and learn about our DLC® rebate eligible products.
INSTALLATION,
USAGE,& CARE GUIDE
AURA LED
ARCHITECTURAL
WALL SCONCE
Model No.
Mfr. SKU
AUR20-3K-WH
103-07800002-1

3PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
2
Visit www.probrite.com/install for installation video tutorials and product support
Pre-Installation
PLANNING INSTALLATION
Before installing the light fixture, ensure that all parts are present. Compare parts with the
Hardware Included and Package Contents sections. If any part is missing or damaged, do
not attempt to assemble, install, or operate this light fixture.
Estimated installation time: 15 minutes
Lumens (Light Output) 1400 Lumens
Watts (Power Consumption) 20 Watts LED
Replaces 100 Watt Incandescent Bulbs
Lumens/Watts (Efficacy) 70 lumens per watt
Power Requirements (Input Voltage) 120VAC, 60 Hz
Light Color (CCT) 3000 Kelvins (Warm White)
Dimmable Non-Dimming (Do not wire to dimming switch)
Operating Modes Switch-Controlled:
Flip switch to turn light fixture ON and OFF.
Use external photocell light sensor, timer or
motion sensor for automatic functionality
(sold separately)
SPECIFICATIONS
TOOLS REQUIRED
Phillips
Screwdriver
Wire strippers/
cutters
Circuit tester
Safety
goggles
Work
gloves
Silicone
Sealant
Ladder
Table of Contents.......................... 2
Safety Information........................ 2
Pre-Installation.............................. 3
Planning Installation...................... 3
Specifications................................... 3
Tools Required................................. 3
Hardware Included......................... 4
Package Contents.......................... 4
Installation......................................5
Operation .......................................8
Care & Cleaning.............................9
Troubleshooting............................ 9
Warranty........................................10
Table of Contents
Safety Information
IMPORTANT
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE NA-
TIONAL ELECTRICAL CODE AND LOCAL BUILDING CODES BY A PERSON FAMILIAR
WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS
INVOLVED.
PRECAUTIONS
☐Please read and understand this entire
manual before attempting to assemble,
install, or operate this light fixture.
☐This light fixture requires a 120-Volt AC
power source.
☐Some codes require installation by a
qualified electrician.
☐This light fixture must be properly
grounded.
☐Make sure connections are secure using
wire nuts, crimp-on lugs or other ap-
proved connecting devices
☐This light fixture should be installed
outdoors to a wall or eave.
☐This product may contain chemicals
known to be hazardous. Thoroughly
wash hands after installing, handling,
cleaning or otherwise touching the
product.
WARNING: Turn the power o at the circuit
breaker or fuse. Place tape over the circuit
breaker switch and verify power is o at the
light fixture.
WARNING: Risk of fire. Keep the lamp heads at
least 3 in. (76mm) from combustible materials.
CAUTION: Burn hazard. Allow the light fixture
to cool before touching.
NOTICE: Do not connect this fixture to a
dimmer switch.
NOTICE: FCC Regulations state that any
unauthorized changes or modifications to
this equipment not expressly approved by the
manufacturer could void the user’s authoriza-
tion to operate this equipment.
INFORMATION: The device is tested and found to comply with Part 15 of the FCC Rules. Operation is subject
to two conditions: (1) This device may not cause harmful interference and, (2) this device must accept any
interference received, including any interference that may cause undesired operation.
These limits are designed to provide reasonable protections against harmful interference when the equip-
ment is operated in a commercial environment.

5PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
4
Visit www.probrite.com/install for installation video tutorials and product support
Pre-Installation (continued)
HARDWARE KIT
NOTE: Hardware not shown to actual size.
AA BB CC
Part Description Quantity
AA #8-32 x 3/4" philips mounting bracket screw 2
BB Wire nut 3
CC Allen key 1
PACKAGE CONTENTS
Part Description Quantity
ALight heads & fixture 1
BMounting plate tightening bolt (pre-installed) 1
CMounting plate with gasket (pre-installed) 1
DHanger Wire for hands-free installation (pre-installed) 1
Installation
1For best results
Wall Mount
1-1/2" 1-1/2"
Round Octagonal
A
B
D
C
NOTE: Mounting plate (D) mounts to recessed
mounted standard junction boxes. Junction box
must be at least 1-1/2 inch in depth for proper
installation for recessed mount application
(fig 1).
(fig 1).
2Shut electric power off
☐At wall switch verify it is in the o posi-
tion (fig 1).
☐At the main electrical panel turn o the
circuit breaker that supplies power to
the outlet box you are working on (fig
2).
☐For screw-in type fuses unscrew the
fuse that supplies power to the outlet
box you are working on (fig 3).
(fig 1). (fig 2).
(fig 3).
☐Install light 5-15 feet above the ground.
☐When installing two fixtures on one
switch, make sure the switch is rated for
at least a 1A inductive load.
☐Do NOT wire to dimming switch.

7PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
6
Visit www.probrite.com/install for installation video tutorials and product support
Installation (continued)
3Remove the
mounting plate
B
CC
C
NOTE: The mounting plate (C) comes pre-as-
sembled on the light fixture (A) for shipping.
NOTE: The mounting plate tightening bolt (B)
comes pre-installed on the light fixture.
4Installing the
mounting plate
AA
C
Installation (continued)
5Hang fixture to
mounting plate
6Making the electrical
connections
TIP: Ensure the light fixture (A) can safely hang
onto the mounting plate (D) to allow for use
of two hands to make the wiring connections
(fig 2). A
A
D
D
C
C
C
A
D
BB
(fig 1).
(fig 2).
TIP: Only unscrew the tightening bolt (C) far
enough to remove the mounting plate (D). Do
not fully remove the tightening bolt (C).
LIGHTING
FIXTURE
(+) LINE
(-) COMMON
GROUND
BLACK
WHITE
GREEN
☐Route the junction box wires through
the large center hole in the mounting
plate (C).
☐Align the holes on the mounting bracket
(C) with the holes on your junction box.
Use two #8 screws (AA), depending
on the size of the holes in your junction
box, attach the mounting bracket (C) to
your junction box
☐Please make sure, the "TOP" arrow is
pointing upwards.
☐Place the small sphere head of the
hanger wire (D) between the back of
the small grove located on the bottom
of the center hole of the mounting plate
(C).
☐Remove the mounting plate (C) from
the back of the fixture by loosening
the mounting plate tightening bolt (B)
using the allen key (CC).
☐If necessary, strip 3/8" of insulation
from junction box or fixture (A) wires
(fig 1).
☐Connect fixture black wire to house
black wire, the (+) line, and fixture
white wire to house white wire, the (-)
common by twisting the exposed wires
together and using the wire nuts (BB).
Ensure no loose wires.
☐Connect house ground wire to the
green fixture ground wire, by twisting
the exposed wires together and using
the wire nuts (BB).
TIP: Hold stripped ends near each other and
align any frayed strands (do not twist wires).
Push the wires into wire nut (BB) and use your
fingers to twist the wire nut clockwise until tight.
Check for tightness by pulling wires.

9PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
8
Visit www.probrite.com/install for installation video tutorials and product support
Installation (continued)
7Mounting the light
fixture
☐Once the fixture is wired, place the light
fixture (A) onto the mounting plate (C)
so the top sloped grove on the plate
rests on the top sloped grove on the
back of the fixture.
☐Tighten the mounting plate by tighten-
ing bolt (B) back through the hole on
the bottom of the fixture (A) until the
bolt firmly pushes against the mounting
plate (C).
8Caulking around the
light fixture
C
NOTICE: Failure to properly caulk around the
surface and mounting plate (C) could lead
to water damage and is not covered under
warranty.
NOTE: When attaching this fixture (A) to an
external, surface mount junction box, caulk the
inside of the light fixture before attaching to the
mounting plate (C).
Care and Cleaning
☐Shut o main power supply before cleaning the product. To prolong the original ap-
pearance, clean the light fixture with clear water and a soft, damp cloth only.
☐Do not use abrasive cleaners or cleaners that contain alcohol. Do not apply paints,
solvents, or any other chemicals on this light fixture. They could cause a premature
deterioration of the finish and may void the warranty.
☐Do not spray the light fixture with a hose or power washer.
C
CC
A
B
☐Caulk around the mounting plate (C)
and surface with silicone sealant (not
included).
Operation
☐Once the fixture is installed, turn power
back on from the circuit breaker and
switch.
☐Flip switch ON and OFF to ensure light
functions properly.
Switch-controlled operation enables the light fixture to turn ON and OFF
by flipping a standard light switch. To add automatic Dusk to Dawn control
or motion sensing external sensors like a photo-control, motion-sensor or
timer is required (sold separately).
SWITCH-CONTROLLED
NOTE: This fixture is not dimmable, so it
is best to not wire to a dimming switch.
SWITCH
CONTROLLED
Troubleshooting
If Light does not come on:
☐Verify that the power is turned ON from the circuit breaker and wall switch.
☐Verify the wiring for the fixture is done properly.
☐Verify the line voltage is correct.
If Light flickers:
☐Do not wire to a dimming switch, use a standard ON/OFF switch

11 PROBRITE.COM
Please call 1-844-507-5651 or email [e-mail] for further assistance.
10
Visit www.probrite.com/install for installation video tutorials and product support
This is a limited warranty oered by Probrite for a period of five years from the date of
purchase to its customers. Probrite warrants to customers that the products will be free
from defects in material and workmanship. The obligation of Probrite under this warranty is
limited to the provision of replacement of products and is extended to the original purchaser
of the product on presenting valid purchase receipt or other proof of date of original purchase
acceptable to Probrite. The receipt is required for rendering the warranty performance. Any
warranty claims without original proof of purchase would not be accepted.
It should be noted that the warranty does not apply to Probrite products that have been
altered or repaired by unauthorized personnel, have been subjected to neglect, abuse, misuse
or accident or damages caused during shipping. Any other products not manufactured
by Probrite which have been supplied, installed and/or used in conjunction with Probrite
products are not covered under this warranty. Any damages caused by replacements bulbs,
LEDs or corrosion or discoloration of brass components are also not covered by this warranty.
Limitation of Liability:
In no event Probrite shall be liable for indirect, consequential, incidental or special damages,
or lost profits. Probrite is not liable for any claims or damage arising out of or connected
with the manufacture, sale, delivery, use, maintenance and repair or modification of Probrite
products, or supply of any replacement parts that, exceed the purchase price of Probrite
products giving rise to a claim. Labor charges to remove or install the fixtures will not be
accepted.
To Claim:
Please contact PROBRITE customer service at 1-844-507-5651 or email
[email protected]om and include your name, address and contact number, along with a
copy of the purchase receipt and a brief description of the problem.
5-Year Limited Warranty

Before returning to the store, call or email PROBRITE
Customer Service 9am-5pm EST Monday to Friday.
1-844-507-5651
[email protected]om
PROBRITE.COM
Questions? / Missing Parts? / Need Accessories?
RETAIN THIS MANUAL FOR FUTURE USE
Para las translaciones en español,
visit www.probrite.com/install
