PROCET EN-S4P1C User manual

ＥＮ－Ｓ４Ｐ１Ｃ ＰｏＥ Ｓｗｉｔｃｈ
ｗｗｗ．ｐｒｏｃｅｔｐｏｅ．ｃｏｍ
Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ

Ｄｅｃｌａｒａｔｉｏｎ
Ｃｏｐｙｒｉｇｈｔ ©２０２3Ｃｒｅａｔｉｖｅ Ｌｉａｎｊｉｅ Ｎｅｔｗｏｒｋ Ｔｅｃｈｎｏｌｏｇｙ Ｃｏ．Ｌｔｄ
Ａｌｌ ｒｉｇｈｔｓ ｒｅｓｅｒｖｅｄ．
Ｄｅｃｌａｒａｔｉｏｎ
The symbol indicates that the product should not be discarded as unsorted
This document belongs to PROCET company. It is not allowed to reproduce and
modify without the original author's permission. It is PROCET's policy to improve
its products as new technology, components, software, and firmware at any time.
PROCET, therefore, reserves the right to change specifications without prior notice.
Please follow WEEE (Waste Electrical and Electronic Equipment) disposal
instructions for old electronic products.
Please do not dispose of the old product in your general household waste bin.
waste but must be sent to separate collection facilities for recovery and recycling.

Ｉｎｔｒｏｄｕｃｔｉｏｎ
Ｏｖｅｒｖｉｅｗ
Network Engineers
Network Administrators
The installation Guide for EN-S4P1C and mainly introduces the hardware
specification, installation methods, and precautions of the installation. There
may be differences in the appearance and configuration from other
models. All product images in this manual are for illustration purposes only
and may differ from the actual product.
This manual includes the following chapters:
1. Product Introduction. Including the basic functions and specification of
EN-S4P1C, as well as the product appearance and applications introduction.
2. Installation Introduction. Introducing the preparation work and
precautions before installing the product.
3. Product Installation. Two methods of product installation.
Field Technicians
Fｏｒ Ｗｈｏｍ

Ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ
１．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１
１．２ Appearance．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１
１．３ Specification．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０３
２．１ Ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４
２．２ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４
Ｔａｂｌｅ ｏｆ Ｃｏｎｔｅｎｔｓ
１． Ｉｎｔｒｏｄｕｃｔｉｏｎ 01
２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ 04
３．１ Ｉｎｓｐｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０６
３． Ｉｎｓｔａｌｌａｔｉｏｎ 06

Ｉｎｔｒｏｄｕｃｔｉｏｎ ０１
１． Ｉｎｔｒｏｄｕｃｔｉｏｎ
１．１ Ｉｎｔｒｏｄｕｔｉｏｎ
１．２ Ａｐｐｅａｒａｃｅ
Ｕｐｐｅｒ Ｖｉｅｗ
１－１ Ｕｐｐｅｒ Ｖｉｅｗ
Ｃｏｏｌｉｎｇ ｈｏｌｅ
ＥＮ－Ｓ４Ｐ1C ｉｓ ａ ４－ｐｏｒｔ Ｇｉｇａｂｉｔ ＰｏＥ ｓｗｉｔｃｈ ｗｉｔｈ ａｎ ｕｐｌｉｎｋ ＲＪ４５ ＬＡＮ ｄａｔａ ｐｏｒｔ．
Ｄｅｓｉｇｎｅｄ ｗｉｔｈ ＯＶＰ， ＯＣＰ， ＳＣＰ ｆｕｎｃｔｉｏｎ， ｃａｎ ｄｅｌｉｖｅｒ ｐｏｗｅｒ ａｎｄ ｔｒａｎｓｍｉｔ
ｄａｔａ ｔｏ ４ ８０２．３ａｆ／ａｔ ＰＤｓ ｓｉｍｕｌｔａｎｅｏｕｓｌｙ， ｔｏｔａｌ ｐｏｗｅｒ ｂｕｄｇｅｔ ｉｓ ６０Ｗ． Ｃｏｍｅ
ｗｉｔｈ ａｎ ＡＣ ｔｏ ＤＣ ｐｏｗｅｒ ｓｕｐｐｌｙ ａｔ Ｌｅｖｅｌ ６ ｅｎｅｒｇｙ ｅｆｆｉｃｉｅｎｃｙ． Ｇｏｏｄ ｈｅａｔ
ｄｉｓｓｉｐａｔｉｏｎ ｗｉｔｈ ｖｅｎｔｉｌａｔｉｏｎ ｈｏｌｅｓ ｔｏ ｅｎｓｕｒｅ ｌｏｎｇ ｔｅｒｍ ｓｔａｂｌｅ ｏｐｅｒａｔｉｏｎ．
ＥＮ－Ｓ４Ｐ１Ｃ ｉｓ ｅｑｕｉｐｐｅｄ ａ ＵＳＢ－Ｃ ｐｏｒｔ， ｗｈｉｃｈ ｃａｎ ｄｅｌｉｖｅｒ ｐｏｗｅｒ ｔｏ ｍｏｂｉｌｅ
ｐｈｏｎｅ， ｔａｂｌｅｔ， ａｎｄ ｍｏｓｔ ＵＳＢ－Ｃ ｄｅｖｉｃｅｓ．

１－２
０２ Ｉｎｔｒｏｄｕｃｔｉｏｎ
Ｓｉｄｅ Ｖｉｅｗ
１－３ Ｆｒｏｎｔ Ｖｉｅｗ
Ｓｉｄｅ Ｖｉｅｗ
Ｆｒｏｎｔ Ｖｉｅｗ
ＰｏＥ Ｏｕｔ
ＰｏＥ Ｌｏａｄ Ｉｎｄｉｃａｔｏｒ
Ｄａｔａ Ｉｎｄｉｃａｔｏｒ
ｐｕｔ Ｐｏｒｔ
Ｔｙｐｅ－Ｃ
Ｏｕｐｕｔ Ｐｏｒｔ
ＤＣ Ｐｏｗｅｒ Ｐｏｒｔ
Ｄａｔａ Ｉｎｄｉｃａｔｏｒ
Unused
ＬＡＮ Ｉｎｐｕｔ Ｐｏｒｔ

１．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ
Power
Items
Ｉｎｐｕｔ
Data Input
ＰｏＥ Ｏｕｔｐｕｔ：802.3af/at, 30W(max)*4 Ports, total 60W
Ｔｙｐｅ－Ｃ Ｏｕｔｐｕｔ：５Ｖ ／ ２．０Ａ （10 W max）
３／６（＋）， １／２（－）
Ｄｅｓｃｒｉｐｔｉｏｎ
Ｏｕｔｐｕｔ
ＰｏＥ Ｐｏｗｅｒ Ｐｉｎｓ
Ｗｏｒｋ Ｔｅｍｐ．
Ｏｐｅｒａｔｉｎｇ Ｈｕｍｉｄｉｔｙ
Ｏｐｅｒａｔｉｎｇ Ａｌｔｉｔｕｄｅ
Ｓｔｏｒａｇｅ Ｔｅｍｐ．
Ｓｔｏｒａｇｅ Ｈｕｍｉｄｉｔｙ
０℃ ｔｏ ４０℃
２０％－８０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ
Ｕｐ ｔｏ ２０００ ｍｅｔｅｒｓ
－２０℃ ｔｏ ７０℃
ＩＥＥＥ８０２．３ｉ ／ ＩＥＥＥ８０２．３ｕ ／ ＩＥＥＥ８０２．３ａｂ
１１６．４ｍｍ Ｘ ７１．３ｍｍ Ｘ ３０．５ｍｍ （１５１．３ｇ）
ＲＪ４５: １０／１００／１０００Ｍｂｐｓ
ＣＥ
ＩＰ２０
Ｎｅｔｗｏｒｋ Ｐｒｏｔｏｃｏｌ
Data Speed
ＩＰ Ｒａｔｅｄ
Ｒｅｇｕｌａｔｏｒｙ Ｃｏｍｐｌｉａｎｃｅ
Ｄｉｍｅｎｓｉｏｎｓ & NW
ＤＣ Ｉｎｐｕｔ：５５Ｖｄｃ １．１Ａ
ＥＮ ５５０３２:２０１５／Ａ１１:２０２０
ＥＮ ５５０３５:２０１７／Ａ１１:２０２０
ＥＭＣ
10％－90％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ
ＬＡＮ Ｉｎｐｕｔ：ＲＪ４５ Ｅｔｈｅｒｎｅｔ
Ｉｎｔｒｏｄｕｃｔｉｏｎ ０３
ＰｏＥ Ｌｏａｄ
Ｉｎｄｉｃａｔｏｒ
Green
Ｉｔｅｍｓ Ｓｔａｔｕｓ
Ｓｏｌｉｄ Light
Light Off
Light Off
Ｆｌａｓｈｉｎｇ Light
Light Ｏff
Ｉｎｄｉｃａｔｏｒ Ｄｉｓｐｌａｙ：
PoE Switch is powered off/defective.
No Data transmission
No connection to PD
PD is powered(Default/Normal)
Ｄｅｓｃｒｉｐｔｉｏｎ
Ｄａｔａ ａｖａｉｌａｂｌｅ（Ｎｏｒｍａｌ）
Ｄａｔａ
Ｉｎｄｉｃａｔｏｒ
Yellow

０４ Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ
２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ
2.1 Package Contents
２．２ Ｉｎｓｐｅｃｔｉｏｎ
Ｃａｕｔｉｏｎ：
Ｐｌｅａｓｅ ｕｓｅ ＰｏＥ ｐｏｗｅｒｅｄ ｄｅｖｉｃｅ（ＰＤ） ｔｈａｔ ｃｏｍｐｌｉｅｓ ｗｉｔｈ
ＩＥＥＥ８０２．３ａｆ／ａｔ ｔｏ ｃｏｎｎｅｃｔ ｔｈｉｓ ｐｒｏｄｕｃｔ． Can not feed
non-802.3af/at standard PD, nor 24Vdc PD.
!
Ｏｐｅｒａｔｉｏｎ ｍａｎｕａｌ AC to DC Power Supply Adapter
Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＥＮ－Ｓ４Ｐ1C ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， ｔｈｅ
ｂｏｘ ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ：
2.2.1 Connect the device to the AC to DC power supply, the power
cable is 1.5 meters with DC barrel jack at 5.5*2.1mm.
2.2.2 Connect the PoE port to the PoE powered device(PD). Such as
the IP Cameras or Wireless APs.
As showed in Figure 2-1；
ＥＮ－Ｓ４Ｐ１Ｃ

２－１
Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ０５
Ｄｅｖｉｃｅ Ｃｏｎｎｅｃｔｉｏｎ
!
Ｓｗｉｔｃｈ
Ｄａｔａ Ｉｎｐｕｔ
ＰｏＥ Ｄａｔａ＆ Ｐｏｗｅｒ
Ｏｕｔｐｕｔ
Type-C
Power
Output
DC
Power
Input
ＥＮ－Ｓ４Ｐ１Ｃ
ＰＤ
Ｔｙｐｅ－Ｃ
Ｄｅｖｉｃｅ
Cautions:
１． Ｐｌｅａｓｅ ｒｅａｄ ｔｈｅ ｉｎｓｔｒｕｃｔｉｏｎｓ ｃａｒｅｆｕｌｌｙ ａｎｄ ｆｏｌｌｏｗ ｔｈｅ ｓｔａｎｄａｒｄ ｏｐｅｒａｔｉｎｇ
ｐｒｏｃｅｄｕｒｅｓ ｂｅｆｏｒｅ ｕｓｉｎｇ．
２． Ｐｌｅａｓｅ ｐｌａｃｅ ｉｔ ｉｎ ａ ｗｅｌｌ－ｖｅｎｔｉｌａｔｅｄ ａｎｄ ｄｒｙ ａｒｅａ， ａｎｄ ｉｔ ｉｓ ｆｏｒ ｉｎｄｏｏｒ ｕｓｅ ｏｎｌｙ．
3. Connect the AC to DC power supply adapter cable with DC barrel jack into the
rear of the Procet PoE switch. On the other end of the power cable plug into a
standard grounded wall outlet for safety.
4. Connect a CAT5/5e/6 cable with the RJ45 connector into the RJ45 socket
labeled PoE 1, PoE2, PoE3 and PoE4. On the other end of the CAT5e/6 cable,
connect to your PoE powered Device (PD, such as IP Cameras etc). The total
Ethernet cable length can not exceed 100 meters.
5． Ｔｈｅ ｄｅｖｉｃｅ ｍｕｓｔ ｂｅ ｐｌａｃｅｄ ｏｎ ａ ｓｔａｂｌｅ ｓｕｒｆａｃｅ， ｐｒｅｆｅｒａｂｌｙ ａｆｆｉｘｅｄ ａｎｄ ｍｏｕｎｔｅｄ
ｐｅｒｍａｎｅｎｔｌｙ． Ｄｏ ｎｏｔ ｌｅａｖｅ ｉｔ ＂ｄａｎｇｌｉｎｇ＂ ａｎｄ ｕｓｅ ｐｌｕｇｇｅｄ－ｉｎ ｃａｂｌｅｓ ｉｎ ｔｅｎｓｉｏｎ ａｓ
ｓｕｐｐｏｒｔ． Ｄｒｏｐｓ， ｆａｌｌｓ， ａｎｄ ｉｍｐａｃｔｓ ｅｘｐｅｒｉｅｎｃｅｄ ｂｙ ｔｈｅ ｉｎｊｅｃｔｏｒ ｃａｎ ｃｏｍｐｒｏｍｉｓｅ
ｔｈｅ ｉｎｔｅｒｎａｌ ｃｏｍｐｏｎｅｎｔｓ ＆ ｃａｕｓｅ ｐｒｅｍａｔｕｒｅ ｆａｉｌｕｒｅ．
6． Ｄｏ ｎｏｔ ｐｌａｃｅ ｈｅａｖｙ ｏｂｊｅｃｔｓ ｏｎ ｔｏｐ ｏｆ ｔｈｉｓ ｉｎｊｅｃｔｏｒ． Ａｌｌｏｗ ａｔ ｌｅａｓｔ ５ｃｍ ｏｆ
ｃｌｅａｒａｎｃｅ ｏｎ ａｌｌ ｓｉｄｅｓ ｏｆ ｔｈｅ ｄｅｖｉｃｅ ｆｏｒ ｈｅａｔ ｖｅｎｔｉｌａｔｉｏｎ ／ ｎａｔｕｒａｌ ｃｏｎｖｅｃｔｉｏｎ．

０６ Ｉｎｓｔａｌｌａｔｉｏｎ
３． Ｉｎｓｔａｌｌａｔｉｏｎ
Ｃａｕｔｉｏｎ：
If it is placed in an outdoor environment, please install the device
in a waterproof case with a height of 45cm if possible.
Ｗａｔｅｒｐｒｏｏｆ Ｅｔｈｅｒｎｅｔ ｃａｂｌｅｓ ｓｈｏｕｌｄ ｂｅ ｗｉｔｈ ａ ｐｒｏｔｅｃｔｉｖｅ ｓｈｅａｔｈ．
ＣＡＴ５ｅ／６ ｃａｂｌｅｓ ａｒｅ ｒｅｃｏｍｍｅｎｄｅｄ．
!
３．１ Ｉｎｓｐｅｃｔｉｏｎ
Inspect the installed equipment before putting it into operation：
· Make sure the PD is compliant with our product.
· Make sure the Ethernet cable connection is correct.
Make sure all connections are correct, and turn on the power,
inspect all the indicators.

Qualication Card
PASS
