OWNER SOPERATIONAND INSTALLATIONMANUAL
BLUE FLAME VENT-FREE
NATURALGAS
SPACEHEATER
MN060HBAMN100HBA MN100TBA
WARNING: Improper installation,
adjustment, alteration, service or mainte-
nance can cause injuryorpropertydamage.
Refer to thismanual for correct installationand
operational procedures. For assistance or
additional information consult aqualified
installer,serviceagency, or gassupplier.
This appliance maybeinstalledinan aftermar-
ket*permanently located,manufactured
(mobile)home, where notprohibited bylocal
codes.
Thisappliance is only for use with the type of
gasindicatedon therating plate.This
appliance is not convertible for use with other
gases.
*Aftermarket: Completionofsale, not forpurpose of
resale, from the manufacturer.
Do notstore,orusegasoline orotherflammable
vapors and liquidsinthe vicinity of this or any
other appliance.
WHATTODOIF YOU SMELLGAS
l Do not tryto light any appliance.
l Donot touchanyelectricalswitch; donot
use any phone in your building.
l Immediatelycallyour gas supplier from a
neighbor sphone. Followthegassupplier s
instructions.
l If youcannot reach your gassupplier, call
thefiredepartment.
Installation and service mustbe performed by a
qualified installer,service agency or gas
supplier.
Table ofContents
Important Safety Information.................................2
ProductFeatures.....................................................3
ProperVentilation&FreshAir...............................4
Installation................................................................6
OperatingYourHeater...........................................10
Cleaning &Maintenance.......................................13
Trouble Shooting...................................................14
Specifications..........................................................17
Parts List.................................................................19
TOLL FREE NUMBER:1-877-886-5989
WARNING:This is an unventedgas-fired
heater.Itusesair(oxygen)fromthe room
inwhich it is installed.Provisions for
adequate combustion andventilationairmust
beprovided. RefertoAirForCombus-
tion and Ventilationsectiononpage4 ofthis
manual.
WARNING: If the information in this
manualisnot followedexactly,afire or
explosion mayresult causingproperty
damage, personal injury,orlossoflife.
CONTINENTALAPPLIANCEINC/U.S.OFFICE
5 Musick 4600 Highlands Parkway S.E.
Irvine Suite#D/E
CA92618 Smyrna,GA30080
Nanjing PRO-COMElectricAppliance Co.,Ltd.
#6ChuangyeRoad,HighNewTech.Zone,
GreatBridge Road North,Nanjing,210061,
China.
WATER VAPOR:ABY-PRODUCTOF UNVENTED
ROOM HEATERS
Water vapor is a by-product of gas combustion. An
unventedroomheaterproducesapproximatelyone
(1) ounce (30ml) ofwater forevery 1,000BTU s
(.3KW s) ofgas input per hour. Referto page3.
Installer: Pleaseleave these instructions with the
consumer.
Consumer:Please retaintheseinstructionsfor
futureuse.
PR-ML062-15-0803

2
IMPORTANT
SAFETYINFORMATION
Keep theappliancearea clear
andfree from combustible
materials, gasoline, andother
flammable vaporsand liquids.
1.This applianceis onlyforuse
with the type of gas indicated
on the rating plate. This
appliance is not convertible for
use with othergases.
2. If you smell gas
lShut off gas supply.
lDonottry tolight anyappliance.
lDo not touch any electrical switch,
do not useany phoneinyour
building.
lImmediatelycallyourgas sup
plier froma neighbor s phone.
Followthe gas supplier s
instructions.
lIf you cannot reach yourgas
supplier, call the firedepartment.
3. This heaterneeds fresh,
outside air ventilation to run
properly. This heater hasan
Oxygen DepletionSensor
(ODS)safety shutoff system.
The ODS shutsdown the
heater if not enough fresh air
isavailable. See Fresh Air For
Combustion And Ventilation
pages 4 through6.
4. Keep all air openings inthe front
andbottomof heater clear
and free of debris. This will
insure enough airforproper
combustion.
5.If heater shuts off. Do not
relightuntilyou providefresh
outsideair. If heater keeps
shutting off, haveitserviced.
6. Do not operate heater
lwhere flammable liquids or
vaporsare usedorstored
lunder dustyconditions
WARNINGS
IMPORTANT: Read this
owner smanualcarefully and
completely before trying to
assemble, operate, or service
thisheater. Improper use of
thisheater can cause serious
injuryordeath from burns,
fire,explosion, electrical
shock, and carbon monoxide
poisoning.
Donot placeclothingorother
flammable materialonornear
theappliance.Neverplaceany
objects on the heater.
Dueto hightemperatures, heater
should be kept out of
traffic and away from furniture
and draperies.
Surface of heater becomes
very hot whenrunningheater.
Keep children and adults away
from hot surface toavoid burns
or clothing ignition.Heater will
remainhot for atimeaftershut
down.Allow surface to cool
before touching.
Carefullysuperviseyoung
childrenwhenthey areinthe
same room with heater.
Makesuregrillguard is in
placebeforerunning heater.
8. Do not use heater ifany part
has been under water.
Immediately call aqualified
service technician to inspect
the roomheaterandto
replace any part of the control
system and any gas control
whichhas been under water.
9. Turn offheater and letcool
before servicing. Onlya
qualified service personshould
service and repairheater.
10.Operatingheaterabove
elevationsof 4,500 feet could
cause pilot outage.
11.Do notinstall in a bathroom
except modelMN060HBA.
DANGER: Carbonmonoxide
poisoningmayleadtodeath!
Carbon MonoxidePoisoning:
Early signsof carbonmonoxide
poisoningresemblethefluwith
headaches,dizziness, or nausea.
If you havethese signs,the heater
may not be workingproperly. Get
fresh air atonce! Haveheater
serviced.Some people are more
affectedbycarbonmonoxidethan
others. These include pregnant
women,personswithheart orlung
disease oranemia, those under the
influenceof alcohol, and those
at high altitudes.
NaturalGas: Naturalgasis odorless.
Anodor-makingagentisaddedto
naturalgas.The odor helpsyoude-
tectanatural gas leak.However,
the odor added to natural gascan
fade. Naturalgas may be present
eventhough noodor exists.Make
certainyou read and understand all
warnings.Keep this manual for
reference.It is yourguidetosafeand
properoperationofthis heater.
WARNING:Donotuseany
accessory not approved for
use with this heater.
WARNING:Anychange to
this heater or its controls can
be dangerous.
7. Turnheater offbeforeusing
furniture polish, wax,carpet
cleaner,orsimilarproducts,If
heated, thevapors from these
products maycreate a white
powder residue within burner
box or on adjacent walls or
furniture.
StateofMassachusetts: The
installation mustbemadebyali-
censedplumberorgasfitterinthe
Commonwealth of Massachusetts.
Sellersof unventedpropaneornatu-
ral gas-fired supplemental room heat-
ersshall provide toeachpurchaser a
copy of 527 CMR30 uponsale ofthe
unit.
Inthe stateof Massachusetts,
unvented propane or nature gas-fired
space heaters shall beprohibited in
bedroomsandbathrooms.
Modeles MN060HBA,MN100HBA,
MN100TBA areequipped for natural
gas. Field conversion is not
permitted.
WARNING

3
PRODUCTFEATURES
SAFETY DEVICE
Astandard requirementfor all vent-free room
heaters.ThisheaterhasapilotwithanOxygen
DepletionSensor(ODS)safetyshutoffsystem.
TheODS/pilotshuts offthe heater ifthere is
notenoughfresh air.
PIEZO IGNITION SYSTEM
This heater is equippedwith apiezo ignitor.
Thissystem requires nomatches,batteries, or
othersourcesto lightheater.
THERMOSTATIC CONTROLON
THERMOSTATMODEL
Theseheaters haveacontrolvalve with a
thermostat sensingbulb.This resultsinthe
greatestheater comfort andmayresult in
lower gas bills.
LOCAL CODES
Installand use heater with care. Follow alllocal
codes. In the absence of local codes, usethe
latest edition ofNationalFuelGas CodeANSZ223.1,
also known as NFPA54*.
*Available from:
AmericanNational Standards Institute, Inc.
1430Broadway
NewYork, NY10018
National Fire Protection Association,Inc.
Batterymarch Park
Quincy,MA 02269
UNPACKING
1. Remove heater from carton.
2.Removeall protective packaging appliedto
heater for shipment.
3. Check heater foranyshippingdamage. Ifheater
is damaged. promptlyinformdealer where you
boughtheater.
Figure1-Vent-Free NaturalGas Heater
WATER VAPOR: ABY-PRODUCT OF UNVENTED ROOM HEATERS
Water vapor is aby-productof gas combustion.An
unventedroomheaterproduces approximately one
(1) ounce (30ml) ofwater forevery 1,000BTU s
(.3KW s)of gas input per hour.
Unventedroom heaters arerecommendedas supple-
mentalheat (a room) rather than aprimaryheat
source (an entire house). Inmostsupplemental heat
applications, the water vapor does not create a
problem. In most applications, the water vapor en-
hancesthe low humidity atmosphere experienced
duringcold weather.
Thefollowing steps willhelp insurethat water vapor
doesnotbecomeaproblem.
1. Be sure theheater issizedproperly for the
application, includingamplecombustionairand
circulation air.
2. If high humidity is experienced, adehumidifier
maybe usedto helplower thewatervapor con-
tentofthe air.
3.Donotuseanunvented room heater asthe pri-
mary heatsource.

4
FRESH AIR FOR
COMBUSTION AND
VENTILATION
PROVIDING ADEQUATE
VENTILATION
The followingareexcerptsfrom
NationalFuelGasCode. NFPA
54/ANS Z223.1,Section 5.3. Air for
Combustionand Ventilation. All
spaces in homes fall into one of
the threefollowing ventilation
classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4
through6 will help you classify
your space and provide adequate
ventilation.
WARNING:This heater
shallnot be installed in a
confined space orunusually
tight constructionunless
provisions are provided for
adequatecombustionand
ventilationair. Readthe
following instructions to
insureproperfresh air for this
andother fuel-burning
appliances in your home.
Confined and
Unconfined Space
TheNational Fuel Gas Code ANS
Z223.1 definesaconfinedspaceas
aspace whose volume is less than
50 cubic feet per 1,000 Btuper hour
(4.8m
3
per kw) of the
aggregateinput rating of all
appliancesinstalledinthat space
andan unconfined spaceas a
spacewhosevolumeis notless
than50cubicfeet per 1,000Btu per
hour(4.8m
3 perkw) ofthe
aggregateinput rating of all
appliances installedinthatspace.
Rooms communicatingdirectly with
the space in which the
appliances are installed*, through
openingsnot furnished with doors,
areconsideredapartof the
unconfined space.
This heater shallnot be installed
in aconfined space or unusually
tight constructionunless
provisionsareprovided for
adequate combustion and
ventilation air.
*Adjoiningroomsare
communicating only if there are
doorless passageways or
ventilation grills between them.
WARNING: Iftheareain which the heatermaybeoperated issmallerthanthatdefinedasanunconfined
spaceor if thebuilding isof unusually tightconstruction, provideadequate combustionandventilationair byone
ofthe methods describedinthe NationalFuel Gas Code,ANS Z223.1, Section 5.3
or applicablelocal codes.
UnusuallyTight Construction
Theairthat leaks around doors and
windows mayprovideenoughfresh
airfor combustion andventilation.
However, inbuildingsof unusually
tight construction. youmust provide
additional fresh air.
Unusually tight construction is
definedasconstruction where:
a. walls and ceilings exposed to the
outside atmospherehavea
continuouswater vaporretarder
witharating ofoneperm(6 × 10-11 kg
per pa-sec-m2)or less with
openings gasketed or sealed and
b. weather stripping has been
addedonopenablewindows and
doors and
c.caulkingorsealants areappliedto
areassuch asjointsaround
window anddoorframes, between
sole plates andfloors,between
wall-ceiling joints, between wall
panels,at penetrationsfor plumbing,
electrical, andgas lines, andat
otheropenings. If your home meets
all of the three criteria above, you
must provide additional freshair.
SeeVentilationAir FromOutdoors,
page 6.
Ifyourhomedoesnotmeet allof
the three criteria abovesee
Determining Fresh-Air Flow for
Heater Location, page 5.
DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION
Determining if you have a Confined or Unconfined Space*
Use this worksheet to determine if you have a confined or unconfined space.
Space: Includes theroomin which youwillinstall heaterplusanyadjoining roomswithdoorless passageways
or ventilation grills betweenthe rooms.
1. Determine the volume of thespace (length×width×height).
Length×Width×Height= cu.ft. (volume of space)
Example:Spacesize 18ft. (length)×16ft.( width)×8ft. (ceilingheight)=2304cu.ft. (volume of space)
If additional ventilation to adjoining room is supplied withgrills or openings, add the volume of these
rooms to the total volume of the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
(volumeof space) 50cu.ft.=(MaximumBtu/Hrthe spacecansupport)
Example: 2304 cu. ft.(volume ofspace) 50 cu.ft.=46.1or 46.100(maximumBtu/Hr thespacecansupport)

5
WARNING: Rework worksheet, add-
ingthespaceof theadjoining
unconfinedspace. The combined spaces
musthaveenough fresh airto supplyall
appliances inboth spaces.
AIRFORCOMBUSTION AND
VENTILATION
Continued
VENTILATION AIR
Ventilation AirFrom InsideBuilding
This fresh air wouldcome from an adjoining
unconfinedspace. When ventilatingto an
adjoining unconfined space, youmust
providetwopermanent openings:onewithin
12"of the ceiling and one within 12"of the
floor onthe wallconnectingthe two spaces
(see options1and 2, Figure 2). You can also
removedoor into adjoining room (see option
3, Figure2). FollowtheNationalFuelGas
CodeNFPA54/ANS Z223.1.Section 5.3, Air
forCombustion and Ventilation forrequired
size of ventilation grills or ducts
If the actualBtu/Hrusedislessthan the maximum Btu/Hrthe space can support, the spaceis an
unconfinedspace. Youwillneed noadditionalfreshairventilation.
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free heater Btu/Hr
Gaswaterheater*Btu/Hr
Gas furnace Btu/Hr
Vented gas heater Btu/Hr
Gas Fireplacelogs Btu/Hr
Other gas appliances*+ Btu/Hr
Total =Btu/Hr
*Do not include direct-ventgas appliances. Direct-vent drawscombustion air from theoutdoorsand
vents tothe outdoors.
4. Comparethe maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
Btu/Hr (maximum the space can support)
Btu/Hr (actual amount of Btu/Hrused)
Example : 51,200 Btu/Hr(maximum the space can support)
54,000 Btu/Hr(actual amount of Btu/Hr used)
The space inthe aboveexampleis aconfinedspacebecausethe actual Btu/Hr used ismorethanthe
maximum Btu/Hr the space can support.
Youmustprovideadditionalfresh are. Youroptionsareas follows:
A. Rework worksheet, adding the space of an adjoining room. If the extra space providesan unconfined
space, removedoor to adjoining room or add ventilation grills between rooms. See Ventilation AirFrom
inside Building,page 5.
B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6 .
C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.
Figure2 -VentilationAir fromInsideBuilding
Example:
Gas water heater 44,000 Btu/Hr
Vent free heater + 10,000 Btu/Hr
Total = 54,000 Btu/Hr

6
VENTILATIONAIR
Ventilation AirFromOutdoors
Provideextrafreshairbyusing
ventilation grills or duels: You must
provide two permanent openings: onewithin
12"of the ceiling andonewithin
12"of the floor.
Connectthese items directlyto the
outdoors or spaces open tothe outdoors.
These spaces include atticsand crawl
spaces. Follow the National FuelGas
CodeNFPA54/ANS Z223.1, Section 5.3.
AirforCombustionandVentilation for
requiredsizeofventilationgrillsorducts.
IMPORTANT: Donotprovideopeningsfor
inletor outletair into attic ifattic has a
thermostat-controlled powervent.
Heated air enteringthe attic will activate
the power vent.
NOTICE: This heater is
intendedfor useassupplemental
heat. Use thisheater along with
your primaryheating system.Do
not install this heateras your
primary heat source. If you have
acentralheatingsystem,you
may runsystem scirculating
blower while using heater. This
will helpcirculatethe heat
throughoutthe house. In the
eventof apoweroutage, youcan
usethisheateras yourprimary
heat source.
WARNING: Aqualified
servicepersonmust install
heater. Follow all local codes.
CHECK GAS TYPE
Useonly naturalgas. Ifyour
gas supply is not natural, donot
install heater.Call dealerwhere you
boughtheaterforpropertype heater.
*A CSA/AGA design-certified equip-
ment shutoffvalve with1/8"NPT
tap is an acceptable alternative to
test gaugeconnection. Purchase
theoptionalCSA/AGAdesigncer-
tified equipment shutoffvalvefrom
yourdealer. See Accessories, page
17.
LOCATING HEATER
This heaterisdesignedto be
mountedonawall.
For convenience andefficiency,
install heater
l wherethere is easyaccessfor
operation, inspection, and service
l in coldest part of room
INSTALLATION
CAUTION: Ifyouinstall the
heaterinahome garage
l heater pilot and burner must
be atleast 18 inches above
floor.
l locateheaterwheremoving
vehiclewillnot hitit.
CAUTION: This heater cre-
ates warmaircurrents.Thesecur-
rents move heat to wall surfaces
next to heater. Installingheater
nextto vinyl or cloth wall cover-
ings or operating heater where
impurities(such astobacco
smoke, aromatic candles,clean-
ing fluids,oil or kerosene lamps,
etc.) inthe airexist maydiscolor
walls.
Figure3 -VentilationAir fromOutdoors
INSTALLATION NEEDS
Beforeinstallingheater,make sure
youhavethe itemslistedbelow:
l piping (check local codes)
l sealant (resistant tonatural gas)
l equipment shutoff valve*
l ground joint union
l test gauge connection*
l sediment trap
l tee joint
l pipe wrench
WARNING: Never install
the heater
l inabathroom (Models
MN100HBAand MN100TBA,only
MN060HBA is allowed in bathroom.
Checklocalcodes.)
l inarecreationalvehicle.
l wherecurtains, furniture,
clothing,or other flammable ob-
jectsare less than36 inches
fromthefront, top,or sides of the
heater.
l as afireplace insert.
l in hightraffic areas.
l in windyordrafty areas.
When the heateris installedin
Bathrooms,donotuseflammable
productssuchasaerosol hairspray,
foot spary or any productthat contains
flammablevaporsandkeep towels
away from heater.(only MN060HBAis
allowed in abathroom.)

7
INSTALLATION
Figure 8 - Mounting Bracket
Clearances
Figure 7-Removing Lower Front
PanelOf Heater
Figure 4-Mounting clearancesAs
View From Front ofHeater
WARNING: Maintain the
minimum clearances shown
in Figure 4. If you can,
providegreaterclearancesfrom
floor, ceiling, and joining wall.
INSTALLINGTHERMOSTAT
SENSINGBULB
ForT-StatModelOnly
1.Pulloutthesensingbulbfrom the
two clips located in the shippng
position accordingtothe direction
as shownby the arrow. There is no
needtotake outthetwobulbclips.
2.Takeoutthe bulbclipfromthe
hardwarepackageandinsertitinto
thesquareholeandtheninsert the
sensingbulbintothe bulb clip (see
Figure 5).
FASTENING HEATER TOWALL
Mounting Bracket
The mounting bracket is located
onbackpanelofheater(see
Figure 6). Ithasbeentapedthere
for shipping. Removemounting
bracket from back panel.
Removing Lower Front Panel Of
Heater
1. Remove two Screws near
bottom cornersoflowerfront
panel.
2. Pullbottomof lowerfrontpanel
forward, then down (see Figure
7).
Methods For Attaching Mounting
BracketToWall
Only use last holeoneach end of
mounting bracket to attachbracket
towall. Attach mountingbracketto
wallonlyin oneof two ways:
1.Attachingto wallstud
2. Attachingto wallanchor
Attachingto WallStud: This method
providesthe strongesthold.Insert
mountingscrewsthrough mounting
bracket and into wallstuds.
Attaching to Wall Anchor: This
method allows you toattach
mountingbracket to hollow walls (wall
areasbetweenstuds) or to
solidwalls(concreteor masonry).
Decide which methodbetter suits
your needs. Eithermethodwill
provide asecure hold for the
mountingbracket.
Marking Screw Locations
1.Tape mountingbracket to wall
whereheaterwillbelocated.
Makesuremounting bracket is
level.
2.Markscrewlocationson
wall. (see Figure 8)
Note: Only mark lasthole on
each end of mounting bracket.
Insert mounting screws through
these holes only.
3. Remove tapeand mounting
bracket from wall.
WARNING: Maintain
minimumclearancesshownin
Figure 8. If youcan,provide
greaterclearances from floor
and joiningwall.
Figure 5-Moving Thermostat
SensingBulb
Figure6-MountingBracket
Location

8
INSTALLATION
Figure 11-MountingHeater Onto
MountingMracket
Figure9-FoldingAnchor
Figure 10 - Popping Open Anchor
Wing For Thin Walls
Figure 12 - InstallingBottom
MountingScrew
3. Insert wall anchor(wings
first) into hole. Tap anchor
flush to wall.
4. For thin walls (1/2"or less),
insert red key into wall
anchor. Push red key to
"pop"open anchor wings.
(see Figure 10)
IMPORTANT: Donot
hammer key! For thick walls
(over 1/2"thick) or solid walls,
do not popopen wings.
5. Place mounting bracket onto
wall. Line up lasthole on
eachend of bracket with wall
anchors.
6. Insert mounting screws through
bracket and into wall anchors.
7. Tighten screws until mounting
bracket is firmly fastened to
wall.
Placing Heater On Mounting
Bracket
1. Locate two horizontalslots on
back panel ofheater(see
Figure 11).
2.Place heater ontomounting
bracket.Slidehorizontal slots
onto stand-out tabs on
mounting bracket.
Installing Bottom Mounting
Screw
1.Locatebottom mounting
hole.Thishole is near bottom
on back panelof heater
(see Figure 12).
2. Markscrew locations on wall.
3.Remove heater from
mounting bracket.
4. Ifinstallingbottommounting
screw intoholloworsolidwall,
installwallanchors. Follow steps
1through 4under Attaching To
Wall Anchor Method.Ifinstalling
bottommountingscrew into wall
stud,drill hole at marked
locations using9/64"drill bit.
5. Replaceheaterontomounting
bracket.
6. Placespacerbetweenbottom
mounting holes andwallanchor
or drilled hole.
7.Holdspacerinplacewithone
hand.With otherhand,insert
mountingscrewthrough bottom
mounting hole andspacer. Place
tip ofscrew in openingof wall
anchoror drilled hole.
8.Tighten screw until heateris firmly
securedto wall.Donot overtighten.
l Note:Do notreplacelowerfront
panelat thistime.Replace lower
front panelafter making gas
connections andchecking for
leaks (see page 9).
Attaching Mounting BracketTo
Wall
Note: Wall anchors, mounting
screws, and spacers are in
hardware package. The hardware
packageisprovidedwith heater.
Attachingto WallStudMethod
For attaching mounting bracket to
wallstuds
1. Drill holes at marked locations
using 9/64"drillbit.
2.Place mounting bracket onto
wall. Lineup last holeoneach
endof bracket withholesdrilled
inwall.
3.Insert mounting screws through
bracket and into wall studs.
4. Tightenscrews until mounting
bracket is firmlyfastened to
wall studs.
AttachingtoWallAnchor Method
For attaching mounting bracket to
hollowwalls (wall areasbetween
studs) or solid walls (concrete or
masonry)
1. Drillholesat marked locations
using 5/16"drill bit.For solid
walls(concrete or masonry),
drillat least 1"deep.
2. Foldwall anchor as shown in
Figure9below.

9
INSTALLATION
CONNECTING TOGAS SUPPLY
WARNING: Aqualified
servicepersonmust connect
heater gas supply. Follow all
local codes.
WARNING:This appliance
requiresa3/8"NPT(NationalPipe
Thread) inletconnection
to the pressure regulator.
WARNING: Never connect
heater toprivate (non-utility) gas
well.This gas is commonly
known aswell-headgas.
IMPORTANT:Check your gas line
pressurebeforeconnectingheaterto
gasline.Gas line pressuremustbe
no greater than 10.5 inches of water.
If gas line pressure is higher, heater
regulatordamage couldoccur.
CAUTION: Use onlynew,
blackironor steelpipe.
Internally-tinnedcopper tubing
maybeused in certain areas.
Check your localcodes. Use pipe
oflarge enoughdiameter to
allow proper gas volume to heater.
If pipeis too small,
undue loss ofpressure will
occur.
Typical InletPipe Diameters
All models upto 20,000 BTU suse
3/8 or greater pipe;
All models 25,000BTU sandhigher,
use1/2”or greater pipe.
*ACSA/AGAdesign-certifiedequipmentshutoffvalvewith 1/8"NPT tapis
an acceptable alternativeto test gauge connection. Purchase the optional
CSA/AGAdesign-certified equipment shutoffvalvefrom
your dealer. See Accessories, page 17.
IMPORTANT:Installanequipment
shutoffvalve inan accessible
location. Theequipmentshutoff
valveisfor turningonorshutting
off the gas to the appliance.
Apply pipe jointsealant lightlyto
male threads. This willprevent
excesssealant fromgoinginto
pipe. Excess sealant inpipecould
result in clogged heater valves.
Install sedimenttrapinsupply line
asshowninFigure13. Locate
sediment trapwhereit is within
reachforcleaning. Locate
sedimenttrapwheretrapped
matterisnot likely to freeze. A
sedimenttrap traps moistureand
contaminants. This keeps them
from goingintoheatercontrols.If
sedimenttrap is notinstalledoris
installedwrong,heater may
not run properly.
IMPORTANT:Hold pressure
regulator with wrench when
connectingit to gaspipingand/or
fittings.
CAUTION: Use pipe joint
sealant that is resistantto
natural gas.
Figure 13 -Gas Connection
Installationmust includeanequip-
ment shutoff valve, union, and
plugged1/8"NPTtap.LocateNPT
tap withinreachfor test gaugehook
up. NPT tap mustbe up streamfrom
heater(see Figure 13).

10
Figure14 -Equipment ShutoffValve
INSTALLATION
CHECKING GAS
CONNECTIONS
WARNING:Testallgas
pipingand connections forleaksafter
installing or servicing. Correctall
leaks at once.
WARNING:Neveruseanopen
flametocheckfor aleak.Apply a
mixture of liquid soap and water
toall joints. Bubblesforming
showaleak.Correctallleaksat
once.
Pressure Testing Gas Supply
Piping System
Test Pressures In Excess Of
1/2 PSIG (3.5 K Pa)
1. Disconnect appliancewith its
appliance main gas valve
(controlvalve)andequipment
shutoffvalvefrom gassupply
pipingsystem. Pressuresin
excess of 1/2 psig will damage
heater regulator.
2. Capoffopen endofgas pipe
where equipment shutoffvalve
was connected.
3. Pressurizesupply piping
system by either using
compressed airoropening
main gasvalve located onor
near gas meter.
4. Checkalljoints of gassupply
piping system. Apply mixture of
liquidsoap andwater to gas
joints.Bubblesforming show
aleak.
5. Correct all leaks at once.
6. Reconnect heater andequipment
shutoffvalveto gas supply.Check
reconnectedfittingsfor leaks.
Test PressuresEqual Toor
Less Than 1/2PSIG(3.5 K Pa)
1. Close equipment shutoffvalve
(see Figure 14).
2. Pressurize supply piping system
by eitherusing compressed air
or opening main gasvalve
located on or near gas meter.
3. Check alljoints from gas meterto
equipment shutoffvalve(see
Figure15).Apply mixtureof liquid
soapandwatertogasjoints.
Bubbles forming show a leak.
4. Correct all leaks at once.
Pressure Testing Heater Gas
Connections
1.Open equipment shutoffvalve
(see Figure 14).
2. Openmain gasvalvelocated on
or near gas meter.
3.Make sure control knobof
heater is inthe OFF position.
4. Check all joints fromequipment
shutoffvalve to control valve
(seeFigure 15). Applymixtureof
liquidsoapandwater togas
joints. Bubblesformingshow
aleak.
5. Correct all leaks at once.
6. Light heater (seeOperating
Heater,pages10and11for
non-thermostat models orpage
12 for thermostat model).Check
the rest of the internaljointsfor
leaks.
7. Turn offheater (see ToTurn Off
Gas to Appliance, page 11for
non-thermostat models or page
12 for thermostat model).
8. Replacelower front panel.
OPERATING YOUR HEATER
nFOR YOUR SAFETYn
READ BEFORE LIGHTING
A.When lighting thepilot,follow,
these instructions exactly.
B.BEFORE LIGHTINGsmellall
aroundthe appliance areafor
gas. Be sure to smell next to
the floor because somegas is
heavierthanairandwillsettle
on the floor .
WHATTODOIF YOUSMELLGAS
l Donottry to light anyappliance.
l Donot touchany electricswitch;
donot useanyphoneinyour
building.
l Immediately call your gas
supplierfrom aneighbor s
phone. Follow the gas
supplier sinstructions.
l If you cannot reachyour
gas supplier,call the fire
department.
C.Use only your handto push in
or turn thegascontrolknob.
Never usetools.If the knob
will not pushinorturn by
hand,don ttry torepairit,call
aqualifiedservice technicianor
gassupplier.Forceor attempted
repair mayresult inafireor
explosion.
D.Donot usethis appliance ifany
part has been under water.
Immediatelycall aqualified
servicetechnician to inspect
theapplianceandtoreplace
anypartofthecontrolsystem
andanygascontrolwhichhas
been under water.
Figure 15 -Checking GasJoints
WARNING: If you do not
followthese instructions
exactly, afireor explosionmay
resultcausingproperty
damage,personalinjuryor
loss of life.
NON-THERMOSTATMODEL
WARING:Do notovertightengas
connections.

11
Figure 16-2 -Control Knobin The
OFF Position
(MN100HBA&MN100TBA)
Figure 17-Pilot
OPERATINGYOUR HEATER
ManualControlModels
nLIGHTINGn
INSTRUCTIONS
1. STOP!Readthesafety
informationonthe sideof
heater.
2. Check thatgassupplyto
heater is on.
3. Push in gascontrolknob
slightly and turn clockwise to
the OFF position.
4.Waitfive (5)minutesto clear
out any air. Then smell for
gas, including nearthe floor.
Ifyousmellgas, STOP!
Follow“B”in the safety
informationon the sideof the
heater.Ifyou donot smell
gas, go tothe next step.
5. Pushingascontrol knob
slightly and turn
counterclockwiseto
“PILOT/IGN”and depress for
five(5)seconds
NOTE:Thefirst timethat the
heaterisoperated after
connectingthegassupply ,the
controlknobshouldbe depressed
for about thirty(30) seconds. This
willallowair to bleed from the gas
system.
6. With control knob pressed in,
pushdown and releasethe
ignitorbutton.This willlight
pilot.Ifneeded,keeppressing
ignitor buttonuntil pilotlights.
7. Keepcontrol knob depressed
forten(10)secondsafter
lightingpilot. Ifpilot goesout,
repeat steps 5,6 and 7.
8.Toselect the desiredheating
level,partially press down the
control knobslightly and rotate
counterclockwise . Release the
downwardpressureon the knob
whilecontinuingtoturn until the
knob locks atthe desired setting
position. Do not operate
between locked positions.
lSetcontrolknobtodesired
heating position.
NOTE: BothHIGHand LOW
arelockedpositions. You
must press in control knob
beforeturningitfromthese
positions.
nTO TURN OFFn
GASTOAPPLIANCE
Shutting Off Heater
1. Turn controlknobclockwise
to the OFF position.
2. Turn off all electricpower to
the appliance ifservice is to
be performed.
ShuttingOff Burner Only
(PilotStays Lit)
Turn controlknob clockwise
tothePILOT/IGNposition.
nMANUAL LIGHTINGn
PROCEDURE
1. Remove lowerfront panel(see
Figure 7page 7).
2. Follow steps1through 5
under LightingInstructions.
3. With control knob pressed in,
strikematch. Holdmatchto
pilot untilpilot lights.
4. Keepcontrol knobpressedin
for 30 secondsafterlighting
pilot. After 30 seconds, release
control knob.Followstep8
under Lighting Instructions.
5.Replacelowerfront panel.
CAUTION:Donot tryto
adjust heating levelsbyusing
the equipment shutoff valve.
Figure 16 -1-Control KnobIn
The OFFPosition(MN060HBA)

12
OPERATING YOURHEATER
nFOR YOUR SAFETYn
READ BEFORELIGHTING
A. When lighting the pilot, follow
these instructions exactly.
B. BEFORELIGHTING smell all
around the appliancearea for gas.
Be sure to smell next to the floor
because somegas is heavierthan
airandwill settleon thefloor.
WHATTODOIF YOU SMELLGAS
l Donot try to light any appliance.
l Do not touchany electric
switch, do notuse any phone
inyourbuilding.
l Immediately callyour gas
supplier from aneighbor s
phone. Follow the gas
supplier sinstructions.
l If you cannotreach your gas
supplier,callthefire department.
C.Useonlyyourhandtopush
in or turn the gas control knob.
Never usetools.Ifthe knob will
notpushin orturn byhand,don t
trytorepairit,call aqualified
service technician or gassupplier.
Forceor attempted repair may
resultin afire orexplosion.
D. Do not use this appliance if
anypart has beenunderwater.
Immediately callaqualified service
technician to inspect the appliance
andto replace any partofthecontrol
systemandanygascontrol which
hasbeenunder water.
nLIGHTINGn
INSTRUCTIONS
WARNING: Ifyoudonot follow
these instructionsexactly, afireor
explosionmayresult causing
property damage, personal injury
orlossoflife.
1. STOP! Read the safety
informationonthesideofheater.
2. Makesure equipmentshutoff
valveisfully open.
3. Turncontrolknob clockwise
to the OFFposition.
4. Wait five(5) minutes toclear
out any gas. Then smell for gas,
includingnearthe floor.Ifyou
smellgas, STOP! Follow “B”in the
safetyinformation on theside of
heater. If you don tsmell
gas, go to the next step.
5. Turn control knob counterclock-
wiseto the PILOTposition.
Press incontrolknob for five(5)
seconds. (see Figure18).
Note: Youmay be running
thisheater for the firsttime
afterhookinguptogassupply.
Ifso, the control knobmay
need tobe pressed infor 30
seconds. This will allow air to
bleedfromthe gassystem.
l Ifcontrolknobdoesnot pop
upwhenreleased,contact a
qualified service person or
gas supplier for repairs.
6.With controlknob pressedin,
push down and release ignitor
button. This will light pilot. The
pilot isattached to the front of
burner.Thepilot canbeseen
through the glass panel. If
needed, keeppressingignitor
buttonuntilpilot lights.
Note:Ifpilotdoesnotstay lit,refer
toTroubleshooting,pages14through
16.Also contacta qualified service
person or gas supplier for repairs.
Untilrepairsare made, light pilot with
match.Tolight pilotwithmatch,see
Manual Lighting Procedure.
7.Keepcontrolknobpressed
in for 30 seconds after lighting
pilot.After 30 seconds,release
controlknob.
l Ifcontrol knobdoesnotpop
up when released,contact aquali-
fied service person or gas
supplierfor repairs.
Note:If pilotgoesout,repeat steps3
through 7.This heater has asafety
interlocksystem.Wait one(1)
minutebefore lighting pilotagain.
8. Turncontrolknobcounter-
clockwise to desired heating
level.The main burner should
light. Setcontrol knobto any
heatlevel betweenHIand LO.
nTOTURNOFFGASn
TOAPPLIANCE
ShuttingOffHeater
1.Turn controlknob clockwise
to the OFF position.
2. Turn offall electric powertothe
appliance if serviceis to
be performed.
Shutting Off Burner Only (pilot
stayslit )
Turncontrol knob clockwiseto
the PILOTposition.
Figure 18-ControlKnobinThe
OFFPosition
Figure19 -Pilot
CAUTION:Do not tryto ad-
just heatinglevels byusingthe
equipment shutoff valve.
nTHERMOSTATCONTROLOPERATIONn
Thethermostatic controlusedonthis
model differs from standard
thermostats.Standardthermostats
simplyturn onandoff theburner.The
thermostat usedonthis heatersenses
the room temperature. At times the
roommayexceed theset temperature.
If so,the burner will shut off. The burner
willcycle backonwhenroomtempera-
ture dropsbelowthe set temperature.
The controlknob canbe set to any com-
fort level betweenHI andLO.
Note: Thethermostat sensingbulbmea-
suresthe temperature of air nearthe
heatercabinet.Thismaynot always agree
with roomtemperature(dependingon
housingconstruction, installationlocation,
room size, open air temperatures,etc.)
Frequentuse of your heaterwill letyou
determine your owncomfort levels.
THERMOSTATMODEL

13
Figure 20 - Correct Pilot Flame
Pattern
Figure 21 - Incorrect Pilot Flame
Pattern
Figure 23 - Incorrect Burner
Flame Pattern
Figure 22 - Correct Burner Flame
Pattern
BURNERFLAME PATTERN
Figure 22 showsacorrect burner
flame pattern. Figure 23shows an
incorrect burner flamepattern. If
pilot flamepatternisincorrect, as
shown in Figure 23.
l turn heateroff(seeToTurnOff
Gasto Appliancepages10&11
for non-thermostat models and
page12forthermostat models)
lseeTroubleshooting. pages14
through 16
ODS/PILOT AND BURNER
l Use avacuumcleaner, pres-
surized air orasmall,soft
bristledbrushto clean.
CLEANING BURNER
PILOT AIR INLET HOLE
Figure24 - PilotInlet AirHole
CABINET
Air Passageways
lUseavacuumcleaneror
pressurized air to clean.
Exterior
lUse asoftclothdampened with
amild soapand water mixture.
Wipethecabinettoremovedust.
WARNING: If yellow tipping
occurs, yourheatercould produce
increasedlevelsofcarbon
monoxide. Ifburnerflame pattern
shows yellow tipping,follow instruc-
tionsat bottomof this page.
Notice: Donotmistake orange
flameswith yellowtipping. Dirt or
otherfineparticles enter theheater
andburncausing brief
patches of orange flame.
PILOT FLAME PATTERN
Figure 20 shows acorrect pilot
flame pattern. Figure 21 shows an
incorrect pilotflame pattern. The
incorrect pilotflameis not touching
thermocouple.This will causethe
thermocoupleto cool. When the
thermocouple cools, the heater will
shutdown. If pilot flame pattern is
incorrect, as shown in Figure 21.
l turn heateroff(see ToTurnOff
GastoAppliance onpage11
fornon-thermostat models or
page12 for thermostat models.)
l seeTroubleshooting. pages14
through 16.
WARNING: Turn offheater
andletcoolbeforeservicing.
CAUTION: Youmust keepcon-
trol areas, burner,andcirculating
airpassagewaysof heater clean.
Inspect these areas of heater
beforeeachuse.Haveheater
inspected yearly by aqualified
service person. Heatermayneed
more frequentcleaningdueto
excessivelint from carpeting,
beddingmaterial, pet hair,etc.
CLEANING AND
MAINTENANCE
nINSPECTING BURNERn
Check pilotflamepatternand
burnerflame patternoften.
We recommend that you clean the
unitevery2,500 hoursof operation or
every three months. We also
recommendthatyoukeeptheburner
tubeandpilot assembly cleanandfree
of dust and dirt. Toclean these parts
we recommend using compressed
air no greater than 30 PSl. Your local
computer store, hardwarestore, or
home center maycarry compressed
air in a can. You can use a vacuum
cleaner in the blowposition. If using
compressed airinacan, pleasefollow
the directions on the can. If you don t
followdirectionsonthe can, youcould
damagethe pilot assembly.
1. Shut off the unit,including the
pilot. Allow the unit to cool for
at least thirty minutes.
2.Inspectburner andpilot for dust
and dirt.
3.Blowairthroughtheports/slots
and holes in the burner.
Also cleanthe pilot assembly. A
yellow tip on the pilot flame indi-
cates dust and dirtin the pilot
assembly.There is asmall pilotair
inlet holeabout two inchesfrom
where the pilotflame comes out of
thepilot assembly(seeFigure 24).
With the unitoff,lightly blowairthrough
theairinlet hole.Youmayblowthrough
adrinkingstrawifcompressedairis
not available.
OPERATINGHEATER
Continued
1. Remove lower front panel (see
Figure 7page7).
2. Follow stepsthrough 5under
Lighting Instructions on page12.
3. With control knob pressedin,
strike match. Hold match to pilot
untilpilotlights.
4. Keepcontrolknob pressed in for
30 seconds after lighting pilot. After
30 seconds, release control knob.
Followstep8underLighting
Instuctions on page 12.
5.Replacelower frontpanel.
nMANUALLIGHTINGn
PROCEDURE

14
TROUBLESHOOTING
Note :All troubleshooting
items are listed in order of
operation.
WARNING: Only aqualified
service person should serviceand
repair heater.
CAUTION: Never use awire,
needle, orsimilarobject toclean
ODS/pilot.This candamage
ODS/pilot unit.
OBSERVED PROBLEM
When ignitor button is pressed in,
thereis no spark atODS/pilot.
When ignitor buttonis pressed in,
there is aspark at ODS/pilot but no
ignition.
ODS/pilotlights but flame goes out
when controlknobis released.
POSSIBLE CAUSE
1.Ignitor electrodeis positioned
wrong.
2.Ignitorelectrode isbroken.
3.Ignitor electrodeis notconnected
to ignitorcable.
4.Ignitorcable is pinched or wet.
5.Broken ignitorcable.
6. Bad piezo ignitor.
1.Gas supply turned offor
equipment shutoffvalve is closed.
2.Controlknobnot fullypressedin
while pressing ignitor button.
3. Air in gas lines when installed.
4.ODS/pilot is clogged.
5. Gasregulator settingisnot cor-
rect
6. Control knob not inPILOT position.
1. Controlknob is not fully pressed
in.
2. Controlknob is not pressed in
long enough.
3. Equipment shutoff valveisnot
fully open.
4. Thermocoupleconnection is
looseat controlvalve.
5. Thermocouple damaged.
6. Controlvalve damaged.
REMEDY
1. Replaceignitor.
2. Replaceignitor.
3.Reconnectignitorcable.
4. Free ignitorcable if pinchedby
anymetalor tubing. Keep
ignitor cabledry.
5.Replace ignitor cable.
6.Replace piezo ignitor.
1. Turn ongas supplyoropen
equipmentshutoff valve.
2. Fully press in control knob
while pressing ignitor button.
3.Continueholdingdowncontrol
knob.Repeatignitingoperation
until air is removed.
4. CleanODS/pilot (see Cleaning
and Maintenance Page 13)or
replace ODS/pilot assembly.
5.Replace gasregulator.
6. Turn control knob to PILOT
position.
1.Press in control knob fully.
2. AfterODS/pilotlights, keepcontrol
knob pressed in 30 seconds.
3.Fully openequipment shutoffvalve.
4. Hand tighten untilsnug, then
tighten 1/4 turn more.
5. Replace thermocouple.
6. Contact DealerorPRO-COM.

15
TROUBLESHOOTING
Continued
OBSERVED PROBLEM
Burner(s)does not lightafter
ODS/pilotis lit.
Delayed ignitionof burner(s).
Burner backfiringduring combustion.
Yellow flame during burner
combustion.
Slightsmokeor odor during
initial operation.
Heaterproducesawhistlingnoise
when burner islit.
Heaterproduces aclicking/ticking
noisejustafterburneris lit or
shut off.
Whitepowder residue forming within
burner box or on adjacent
walls or furniture.
POSSIBLECAUSE
1. Burner orifice is clogged.
2. Burner orifice diameteristoo small.
3. Inletgas pressure is too low.
1.Manifoldpressureis toolow.
2.Burner orifice is clogged.
1. Burner orifice iscloggedor
damaged.
2. Burnerisdamaged.
3.Gas regulatoris defective.
1. Notenough air.
2.Gas regulatoris defective.
3. Inletgas pressure is too low .
1. Residuesfrom manufacturing
processes
.
1. Turningcontrolknobto HI position
whenburner is cold.
2. Airin gas line.
3. Air passageways on heater
blocked.
4.Dirtyor partially cloggedburner
orifice.
1. Metalisexpanding whileheating
orcontractingwhilecooling.
1.Whenheatedthevapors from
furniture polish,wax, carpet
cleaners, etc. turn into white
powder residue.
REMEDY
1.Clean burner orifice (see Cleaning
andMaintenance Page 13)or
replace burner orifice.
2.Replace burnerorifice.
3.Contactlocalnaturalgascompany.
1. Contactlocalnaturalgas company.
2. Cleanburner(see Cleaningand
Maintenance Page13) or replace
burner orifice.
1. Cleanburnerorifice (seeCleaning
andMaintenancePage13) or
replace.
2. Contact DealerorPRO-COM.
3.Replace gasregulator.
1.Check burner for dirtand debris.
If found, clean burner(see Cleaning
AndMaintenancePage 13).
2. Replace gas regulator.
3. Contact localnaturalgascompany.
1. Problem will stop aftera few hours
of operation.
1. TurncontrolknobtoLO position
and letwarm up for aminute.
2. Operate burneruntilairisremoved
fromline. Havegaslinechecked
by localnatural gas company.
3. Observe minimum installation
clearances(see Figure 4, Page7).
4. Clean burner (see Cleaning and
Maintenance Page 13)or replace
burner orifice.
1. This is common with most
heaters.if noise is excessive,
contact qualified service person.
1. Turnheater offwhen using
furniture polish, wax, carpet
cleanerorsimilarproducts.

16
TROUBLESHOOTING
Continued
WARNING: If you smell gas
l Shut off gassupply.
l Do nottry to light any appliance.
l Do not touch any electrical switch; do not useany phone in your building.
l Immediately call yourgas supplier from a neighbor s phone. Follow the gas
supplier s instructions.
l If you cannotreach your gas supplier, call the firedepartment.
IMPORTANT:Operating beater where impuritiesin air existmaycreate odors.Clean-
ing supplies,paint, paint remover, cigarette smoke,cementsand glues,newcarpet or
textiles,etc.,create fumes. Thesefumesmaymix withcombustionair andcreate odors.
REMEDY
1. Ventilate room. Stop using odor
causing productswhile heater
is running.
2.Locateandcorrect allleaks(see
Checking GasConnections,
page10).
1. Open window and/or door for
ventilation.
2.Contactlocal naturalgas
company.
3.Clean ODS/pilot (seeCleaning
page 12).
1. Locate and correct all leaks(see
CheckingGasConnections,
page 10).
2.Replacecontrolvalve.
1. Takeapart gastubing and
remove foreign matter.
2. Locate and correct all leaks
(seeChecking GasConnections,
page 10).
1. Refer to Air for Combustion and
Ventilation requirements, page
4.
POSSIBLECAUSE
1. Heater isburning vapors from
paint, hair spray, glues, etc.
(See IMPORTANTstatement
above).
2. Gas leak.See Warning
Statementat topofpage.
1. Not enough fresh air is available.
2. Low line pressure.
3.ODS/pilot ispartiallyclogged.
1. Gas leak.See Warning
Statement at topof page.
2.Controlvalve isdefective.
1. Foreign matter between control
valve and burner.
2. Gasleak.SeeWarning
Statementattop of page.
1. Notenoughcombustion/ventilation
air.
OBSERVED PROBLEM
Heaterproducesunwantedodors.
Heatershutsoff inuse(ODS operates).
Gas odorexistseven whencontrol
knob is in OFF position.
Gas odorduringcombustion.
Moisture/condensationnoticedon
windows.

17
SPECIFICATIONS
Btu(available)
Gas Type
Ignition
Pressure Regulator setting
InletGas Pressure* (inchesof water)
Maximum
Minimum
Dimensions,Inches (HxWxD)
Heater
Carton
Weight (pounds)
Heater
Shipping
MN100HBA
6,000/10,000
Natural Only
Piezo
3"W.C
10.5"
4"
19-1/8×14-1/8×6-3/8
22×16-3/4×8-1/8
13
16
Note: Dimensions listed are outer most points on the heater (includes control knobs and grill).
* For purposes of input adjustment.
EQUIPMENT SHUTOFF VALVE
Forallmodels. Equipment shutoff
valve with1/8" NPT tap.
TECHNICALSERVICE
Youmayhave furtherquestions
about installation, operation, or
troubleshooting.If so, contact
PRO-COMthrough the phonenum-
ber 1-877-886-5989.The information
is listedonthe front of manual.
SERVICE HINTS
When Gas PressureIs Too
Low
lPilot willnot stay lit
lBurnerwillhavedelayedignition
lHeaterwillnot producespecified
heat
When Gas Quality Is Bad
l Pilot will not stay lit
l Burner will produce flamesand
soot
l Heater will backfirewhen lit
You may feelyourgas pressure is
toolow orthegasqualityispoor.If
so,contact yourlocal naturalgas
supplier.
REPLACEMENT PARTS
Note: Useonlyoriginal replacement
parts. This will protect your warranty
coveragefor partsreplacedunder
warranty.
PARTS UNDER WARRANTY
Contactauthorizeddealerfrom
whomyoupurchased this product.
If they are unableto supply original
replacement part(s),call the num-
ber on the front ofthis manual. When
contactingyourdealer or PRO-COM,
haveready:
l your name
l your address
l model andserialnumbersof
yourheater
l how heaterwasmalfunctioning
l type of gas used (propane/LP or
natural gas)
l purchasedate
l warranty card
Usually, we will ask you to return the
defectivepartto the factory.
PARTS NOTUNDER
WARRANTY
Contact authorized dealers of this
product. Iftheycan tsupply original
replacement part(s),contact PRP-
COMthroughthephone number1-
877-886-5989.
MN100TBA
10,000
Natural Only
Piezo
3"W.C
10.5"
4"
19-1/8×14-1/8×6-3/8
22×16-3/4×8-1/8
14
17
FLOORMOUNTING STAND
Models MN060HBA,MN100HBA,
MN100TBA
Forlocatingheateronthe flooraway
from awall. Complete installation
instructions provided with floor
mountingstand.
ACCESSORIES
Purchase these heateraccesso-
riesfromyourlocal dealer.Ifthey
cannotsupply these accessories,
contact PRO-COM for information.
Youcanalsowriteto the address
listedonthefront of thismanual.
MN060HBA
6,000
Natural Only
Piezo
3"W.C
10.5"
4"
19-1/8×14-1/8×6-3/8
22×16-3/4×8-1/8
12
15

18
ILLUSTRATEDPARTS
BREAKDOWN
MN060HBA

19
PARTSLIST
MN060HBA
This list contains replaceable partsforyour heater. When orderingreplacement
parts, follow the instructions listed underReplacement Parts on page17ofthis
manual.
KEY
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23-1
23-2
24
25
26
27
28
29
PARTNO.
MB10008
MB09003
MB11005
ML086-03
ML087-03
ML088-03
ML069-02
NV2020-12
ML073-01
ML029-01
MB16002
NRV81FI-3
ML079-01
ML119-01
MB40033
MB40045
MB40043
NBB10-000M1
ML101-02
ML091-06
ML103-02
ML129-02
ND1103x600x9
ND0803-6
ND0807
ML105-01
6170-5Z
MB29003
ML084-03
ML060-02
ML083-03
MB28001
ML070-11
ML071-01
DESCRIPTION
CabinetAssembly
LowerFront PanelAssembly
ReflectorUnit
Glass
UpperGlass Retainer
LowerGlass Retainer
SelfTapping Screw
ControlValve
IgnitorLine
ControlValveFixed Nut
ControlKnob Assembly
Pressure Regulator
SelfLocking Screw
PressureTap
MainInletTube Assembly
ODS LineAssembly
GasOutlet Tube Assembly
Burner
BurnerConnector
Injector
Left Burner Support Bracket
Regulator Mounting Bracket
ODS/Pilot Assembly
Thermocouple
Ignitor Electrode
ODS Deflector
Nut
GrillGuard
MiddlePanel
Mounting Bracket
Ignitor Assembly
Assembly Hardware
CSA/AGALabel
GasInstruction Decal
QTY.
1
1
1
1
1
1
12
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1

20
ILLUSTRATED
PARTSBREAKDOWN
MN100HBA
