Procom MN200EPC Quick start guide

OWNER SOPERATIONANDINSTALLATIONMANUAL
WARNING:Improper installation,
adjustment,alteration,serviceormain-
tenance cancause injury orproperty
damage.Refer to thismanual forcorrect
installation and operational procedures.
Forassistanceoradditionalinformation
consultaqualifiedinstaller,serviceagency,
orgas supplier. Thisappliance maybeinstalled in an
aftermarket*permanentlylocated, manufac-
tured(mobile)home,wherenotprohib-
ited bylocal codes.
Thisappliance isonlyforusewiththe
typeofgasindicated on theratingplate.
Thisapplianceisnotconvertibleforuse
withother gases.
*Aftermarket:Completion of sale, not forpurpose of
resale, fromthe manufacturer.
Donot store,oruse gasoline orotherflammable
vaporsand liquids inthevicinityof thisorany
otherappliance.
WHATTO DOIF YOUSMELL GAS
l Donottrytolight any appliance.
l Donottouch any electricalswitch;donot
use any phone inyourbuilding.
l Immediatelycallyourgassupplierfroma
neighbor sphone.Followthegassupplier s
instructions.
l Ifyou cannotreach yourgassupplier,call
thefiredepartment.
Installationandservicemust beperformedbya
qualifiedinstaller, service agencyorgas
supplier.
MN200EPCMN200EHPC
MN300EPCMN300EHPC
INFRARED VENT-FREE
NATURALGAS
SPACE HEATER
WARNING: Iftheinformation in
thismanualisnotfollowedexactly, a
fireorexplosionmay resultcausing
propertydamage,personalinjury, orloss
oflife.
WARNING:Thisisanunventedgas-
firedheater. Ituses air(oxygen)fromthe
roomin whichitisinstalled.Provisions
foradequatecombustion and ventilation
airmustbeprovided.RefertoAirFor
Combustion andVentilation sectionon
page5ofthismanual.
WATERVAPOR:ABY-PRODUCTOFUNVENTEDROOM
HEATERS
Watervaporisaby-product ofgascombustion.An
unventedroomheaterproduces approximatelyone(1)
ounce (30ml) of waterforevery1,000 BTU s
(.3KW s) ofgas input perhour. Refertopage 4.
Installer:Pleaseleavetheseinstructionswiththe
consumer.
Consumer:Please retain theseinstructionsfor
futureuse.
Continental Appliance Inc./USOffice
5Musick 4600 HighlandsParkwayS.E.
IrvineSuite#D/E
CA 92618SmyrnaGA30080
TOLLFREENUMBER:1-877-886-5989
Nanjing PRO-COMElectricApplianceCo.,Ltd.
#6 ChuangyeRoad,High NewTech.Zone,
GreatBridgeRoadNorth,Nanjing,210061,China.
PR-MCL051-01-0506

TableofContents
SafetyInformation......................................................................................2
..
ProductFeatures.....................................................................................3
..
LocalCodes..............................................................................................3
..
Unpacking.................................................................................................4
AirforCombustion andVentilation.........................................................5
..
Installation..................................................................................................7
..
ConnectingtoGasSupply....................................................................... 9
CheckingGasConnections...................................................................10
Operating YourHeater.............................................................................11
Cleaning &Maintenance.........................................................................14
...
ReplacementParts..................................................................................16
Specifications..........................................................................................16
Troubleshooting........................................................................................17
PartsList...........................................................................................................20
SAFETYINFORMATION
DANGER:Carbon monoxide
poisoning mayleadtodeath!
IMPORTANT:Read this
owner smanualcarefullyand
completelybeforetrying to
assemble,operate,orservice
thisheater.Improperuseof
thisheatercancause serious
injuryordeathfromburns,
fire,explosion,electrical
shock,andcarbonmonoxide
poisoning.
Makecertainyou readandunder-
stand allwarnings. Keep this
manualfor reference. It isyour
guidetosafeandproperoperation
ofthisheater.
Whenusedwithoutfresh air, heater
maygiveoff CARBON MONOXIDE, an
odorless,poisonous gas.
WARNING
ThisheaterisequippedwithaPILOT
LIGHTSAFETYSYSTEMdesignedto
turnoff theheater ifnotenough freshair
isavailable
DO NOTINSTALLHEATERUNTIL
ALL NECESSARYPROVISIONS ARE
MADEFORCOMBUSTIONANDVEN-
TILATION AIR.CONSULTTHE WRIT-
TENINSTRUCTIONSPROVIDED
WITHTHE HEATERFOR
INFORMTION CONCERNING COM-
BUSTIONANDVENTILATIONAIR.IN
THEABSENCE OFINSTRUCTIONS.
REFERTOTHE NATIONALFUEL
GAS CODE.ANSIZ223.1. SEC-
TION5.3ORAPPLICABLELOCAL
CODES.
DONOTTAMPER WITHPILOTLIGHT
SAFETYSYSTEM!
Ifheatershutsoff, do notrelightuntil
youprovidefreshair.
If heater keepsshuttingoffhaveit ser-
viced.Keepburnerand controlcom-
partmentclean.
Earlysignsofcarbon monoxidepoi-
soningresemblethefluwith
headache,dizzinessand/ornausea.
Ifyou havethesesigns,heatermay
notbe workingproperly.Getfreshair
atonce!Haveheaterserviced.Some
people-pregnantwomen,persons
withheartorlungdisease,anemia,
those undertheinfluenceofalcohol,
thoseathigh altitude-aremoreaf-
fectedbycarbon monoxidethan
others.
CARBON MONOXIDEPOISONING
MAYLEADTODEATH!
Natural Gas: Naturalgas is
odorless.Anodor-makingagent
isadded tonaturalgas. The
odor helpsyoudetectanatural
gasleak. However,theodor
added tonaturalgascan fade.
Naturalgasmaybepresent
even thoughnoodorexists.
WARNING
2

3
SAFETYINFORMATION
9. Donot use heater if anypart
hasbeenunderwater.
Immediatelycallaqualified
service techniciantoinspect
theroomheater andtoreplace
anypartofthecontrolsystem
andanygas controlwhichhas
beenunder water.
10.Turnoff heaterand let cool
beforeservicing.Onlyaqualified
service personshouldservice
and repairheater.
WARNING:Do notuseany
accessorynotapprovedfor
usewiththisheater.
WARNING: Anychangeto
thisheateroritscontrolscan
bedangerous.
1. Thisapplianceisonlyfor use
withthetype ofgas indicated
ontherating plate. This
appliance isnotconvertiblefor
use withothergases.
2.If you smellgas
lShut offgassupply.
lDonot trytolightanyappliance.
lDonot touch anyelectrical
switch,donot useanyphonein
your building.
l Immediatelycallyourgas
supplierfromaneighbor s
phone. Followthegas
supplier sinstructions.
lIf you cannotreach yourgas
supplier,call thefiredepartment.
3. Thisheatershall notbe
installedinabedroomor
bathroom
4. Thisheaterneeds fresh,
outside airventilationtorun
properly.Thisheaterhasan
OxygenDepletionSensor
(ODS) safetyshutoffsystem.
TheODS shutsdownthe
heaterifnotenough freshair
isavailable.See Fresh Air for
Combustion andVentilation
pages 5and 6.
5. Keepallairopenings infront
andbottomof heater clear
andfreeofdebris.Thiswill
insureenoughairfor proper
combustion.
6.Ifheater shutsoff.Donot
relight until you provide fresh,
outside air.If heaterkeeps
shutting off,have it serviced.
7. DonotoperateT
lWhereflammableliquidsor
vaporsareused orstored
lUnderdustyconditions
8.Beforeusingfurniturepolish,
wax,carpet cleaner, orsimilar
products, turnheater off. If
heated,thevaporsfromthese
productsmaycreateawhite
powderresidue withinburner
boxor on adjacent wallsor
furniture.
SAFETYPILOT
Thisheaterhasapilotwithan
OxygenDepletion Sensor(ODS)
safetyshutoff system.TheODS/
pilotshutsoff theheater if thereis
notenoughfreshair.
AUTOMATICIGNITION
SYSTEM
Thisheater isequippedwithan
automaticsystem.
Thissystemrequires no
matches, or batteries tolight
heater.
TOUCHPADTHERMO-
STATICHEATCONTROL
Thisheaterhasacontrolmodule
withathermostatsensing bulb.
Setdesiredtemperaturewithtouch
pad.Thisresultsinthegreatest
heater comfortandmay resultin
lowergasbills.
MANUALOVERRIDE
CONTROLSYSTEM
(MN200EHPC,MN300EHPC)
Therearetwocontrolsystems,
electricandmanual override.
Ifnoelectricpowerisavailable,
youcanoperateheaterby
manualoverride.
LOCALCODES
Thisheaterisdesignedforvent-free
operation.Somestateand local
codesprohibit the use ofvent-free
heater.
11.Operatingheaterabove
elevationsof4,500 feet could
cause pilot outage.
WARNING
Modles MN200EPCMN200EHPC
MN300EPCMN300EHPCareequipped
fornaturalgas.Fieldconversionis
notpermitted.
Donotplaceclothingorother
flammablematerialon ornear
theappliance.Neverplaceany
objectson the heater.
Duetohightemperatures,heater
shouldbekeptoutof
trafficand away fromfurniture
and draperies.
Keep theappliancearea clear
andfreefromcombustible
materials,gasoline,andother
flammablevaporsandliquids.
Makesuregrillguardisin
placebeforerunningtheheater.
Carefullysupervise young
childrenwhen theyareinthe
sameroomwithheater.
Front surface ofheaterbecomes
veryhotwhen running heater.
Keepchildrenandadultsaway
fromhot surface toavoidburns
orclothing ignition.Heaterwill
remainhotforatimeaftershut
down.Allowsurfacetocool
beforetouching.

4
PRODUCTFEATURES
Figure1Vent-Free Heater
Water vaporisaby-productof gascombustion.Anvent-
freeroomheater producesapproximatelyone(1)ounce
(30ml)ofwaterforevery1,000 BTU s(.3KW s)ofgas
inputperhour.
Unventedroomheatersareintended forassupplemental
heat(aroom) ratherthanaprimaryheatsource(anentire
house).Inmostsupplementalheat application,thewater
vapordoes notcreateaproblem.Inmostapplications,
the watervapor enhancesthelowhumidityatmosphere
experienceduringcoldweather.
WATERVAPOR:ABY-PRODUCTOFUNVEN-FREEROOMHEATERS
Thefollowingstepswillhelpinsurethatwatervapordoes
notbecomeaproblem.
1. Besuretheheater issizedproperlyfor the application,
including amplecombustion and ventilation air.
IMPORTANT: Vent-free heatersaddmois-
turetotheair.Althoughthisisbeneficial,
installingheaterinroomswithoutenough
ventilationairmay causemildewtoformfrom
toomuchmoisture.See FreshAirforCombus-
tion andVentilation,pages5and6.
UNPACKING
1. Removeheaterfromcarton.
2.Removeall protective packaging appliedto
heaterforshipment.
3. Check heater for anyshipping damage.Ifheater
isdamaged. promptlyinformdealer whereyou
boughtheater.
2.Ifhigh humidityisexperienced,adehumidifier
may beused tohelplower the watervapor content
oftheair.
3.Donotuse avent-free roomheater astheprimary
heatsource.
Installanduseheater withcare.Followall local
codes. Intheabsenceoflocalcodes,usethe
latesteditionof NationalFuelGascode ANSI
Z223.1, alsoknownasNFPA54*.
*Availablefrom:
AmericanNationalStandards Institute, Inc.
1430Broadway
NewYork, NY10018
NationalFireProtectionAssociation, Inc.
1Batterymarch Park
Quincy,MA02269 -9101
LOCALCODES CONTINUED
TouchPad
ON/OFF Switch
Burners
LowerFrontPanel
SafetyPilot ControlKnob for ManualOverride
ControlSystem
Door
Ignitor for ManualOverride Control
System
GrillGuard
CabinetTop
StateofMassachusetts:Theinstallation mustbe
made byalicensedplumberorgas fitter intheCom-
monwealthofMassachusetts.
Sellersofunventedpropaneornaturalgas-fired
supplementalroomheatersshallprovide toeach
purchaseracopyof527CMR30 upon saleofthe
unit.
IntheStateofMassachusetts,unventedpropane and
naturalgas-firedspaceheatersshall beprohibited
inbedroomsand bathrooms.

5
AIRFORCOMBUSTION
ANDVENTILATION
PROVIDING ADEQUATE
VENTILATION
Thefollowing areexcerptsfrom
National Fuel Gas Code. NFPA
54/ANSIZ223.1, Section 5.3. Air
for CombustionandVentilation.
Allspacesinhomesfall intoone
ofthethreefollowingventilation
classifications:
1. UnusuallyTightConstruction
2.Unconfined Space
3. Confined Space
The informationonpages5
through6willhelpyouclassify
yourspaceand provideadequate
ventilation.
WARNING:Thisheatershall
notbeinstalledinaconfined
spaceorunusuallytightcon-
struction unlessprovisionsare
providedforadequatecombus-
tionand ventilationair. Readthe
followinginstructionstoinsure
proper freshairfor thisandother
fuel-burningappliancesinyour
home.
Confinedand
UnconfinedSpace
TheNational FuelGasCodeANSI
Z223.1 defines aconfined spaceas
aspacewhose volumeisless than
50 cubicfeet per1,000Btuper hour
(4.8m3 perkw)ofthe aggregate
inputrating ofall appliances in-
stalledinthatspaceand anuncon-
finedspaceasaspace whose
volumeisnotless than50 cubic
feetper1,000Btuperhour(4.8m3
perkw)oftheaggregateinput
ratingof allappliances installedin
thatspace.Roomscommunicating
directlywiththespaceinwhichthe
appliances areinstalled*,through
openings notfurnishedwithdoors,
areconsideredapart of theuncon-
finedspace.
Thisheatershall notbeinstalled
inaconfinedspaceorunusually
tight construction unlessprovisions
areprovidedforadequatecombus-
tionandventilationair.
*Adjoiningroomsarecommuni-
catingonlyif therearedoorless
passagewaysorventilation grills
between them.
WARNING:Ifthearea inwhich theheatermaybeoperatedissmallerthanthatdefinedas an
unconfinedspaceorifthebuilding isofunusuallytightconstruction,provideadequatecombustion and
ventilationairbyone ofthe methodsdescribedinthe NationalFuelGasCode,ANSZ223.1, Section5.3
or applicablelocalcodes.
UnusuallyTightConstruction
Theairthat leaks around doorsand
windowsmayprovideenoughfresh
airforcombustionand ventilation.
However, inbuildingsofunusually
tightconstruction, youmustprovide
additionalfreshair.
Unusuallytightconstructionis
defined as constructionwhere:
a.Wallsand ceilingsexposed to
theoutsideatmospherehave a
continuouswatervaporretarder
witharating of oneperm(6×10-11 kg
perpa-sec-m2)orless with
openingsgasketedorsealedand
b. Weather stripping has been
added onopenablewindowsand
doorsand
c.Caulking orsealantsareapplied
toareas suchas jointsaround
windowanddoorframes,between
soleplates and floors,between
wall-ceilingjoints,betweenwall
panels,atpenetrationsforplumbing,
electrical,and gas lines,and at
otheropenings. If yourhomemeets
all ofthe threecriteriaabove,you
must provide additional fresh air.
SeeVentilationAirFromOutdoors,
page 6.
If your homedoesnot meetall of
thethreecriteriaabove,see
Determining Fresh-AirFlowfor
HeaterLocation, page 5.
DETERMINING FRESH-AIRFLOWFORHEATERLOCATION
Determining if you haveaConfined orUnconfined Space*
Usethisworksheet todetermine if youhave aconfinedorunconfinedspace.
Space: Includesthe roominwhichyouwillinstallheaterplus anyadjoiningroomswithdoorlesspassageways
or ventilation grillsbetweentherooms.
1. Determinethe volumeofthespace(length×width×height).
Length×Width×Height= cu.ft. (volumeofspace)
Example: Spacesize20ft. (length)×16ft.( width)×8ft. (ceiling height)=2560cu. ft. (volumeof space)
If additionalventilationtoadjoiningroomissupplied withgrillsoropenings,addthevolumeoftheserooms
tothe totalvolumeofthespace.
2.Dividethespacevolumeby50 cubicfeettodeterminethemaximumBtu/Hrthespacecansupport.
(volumeof space) 50 cu. ft.=(MaximumBtu/Hr thespacecansupport)
Example: 2560 cu. ft. (volumeof space) 50 cu.ft.=51.2or 51.200(maximumBtu/Hr thespacecansupport)

6
Reworkworksheet, addingthe spaceofthe adjoining
unconfined space. Thecombinedspacesmust have
enough freshair tosupplyallappliancesinboth
spaces.
VENTILATIONAIR
VentilationAir FromInsideBuilding
Thisfresh airwouldcomefroman adjoining
unconfinedspace.Whenventilatingtoan adjoin-
ingunconfined space, youmustprovidetwoper-
manent openings: onewithin12"oftheceilingand
onewithin12"of theflooron thewall connecting
thetwospaces (see options1and 2, Figure2). You
canalsoremovedoor intoadjoining room(see
option 3,Figure2). Followthe NationalFuelGas
Code NFPA54/ANSIZ223.1. Section5.3, Airfor
CombustionandVentilation forrequired
size of ventilationgrillsorducts.
If the actualBtu/Hrusedisless than the maximumBtu/Hrthespace cansupport,thespaceisan
unconfined space.You will neednoadditionalfresh airventilation.
Example:
Gas water heater 40,000 Btu/Hr
Ventfree heater + 18,000 Btu/Hr
Total=58,000 Btu/Hr
3. Add the Btu/Hrofallfuelburningappliancesinthe space.
Vent-free heaterBtu/Hr
Gas waterheater* Btu/Hr
GasfurnaceBtu/Hr
Ventedgas heaterBtu/Hr
GasFireplacelogsBtu/Hr
Other gas appliances*+Btu/Hr
Total=Btu/Hr
*Donotincludedirect-ventgas appliances.Direct-ventdrawscombustion airfromtheoutdoorsand
ventstotheoutdoors.
4.Comparethe maximumBtu/Hr thespacecan support withtheactualamountofBtu/Hrused.
Btu/Hr(maximumthespace can support)
Btu/Hr(actualamount ofBtu/Hrused)
Example : 51,200Btu/Hr(maximumthespace can support)
58,000Btu/Hr(actualamountofBtu/Hr used)
Thespaceintheaboveexampleisaconfinedspacebecause theactualBtu/Hrused ismorethan the
maximumBtu/Hrthespace cansupport.
Youmustprovideadditionalfresh air.Youroptions areasfollows:
A.Reworkworksheet, adding thespaceof an adjoining room. Iftheextraspaceprovidesanunconfined
space,removedoortoadjoining roomoradd ventilation grillsbetweenrooms.See VentilationAirFrom
insideBuilding.
B.Vent roomdirectlytotheoutdoors.SeeVentilationAir FromOutdoors.
C. InstallalowerBtu/Hrheater,if lowerBtu/Hrsizemakesroomunconfined.
Figure2-Ventilation AirfromInsideBuilding
Figure3-Ventilation AirfromOutdoors
Ventilation AirFromOutdoors
Provideextrafreshair byusing ventilation grillsor
ducts:You mustprovidetwopermanentopenings:
onewithin12"of theceiling and onewithin12"of
thefloor.
Connectthese itemsdirectlytothe outdoorsor
spacesopen tothe outdoors.These spacesinclude
atticsandcrawlspaces.Followthe National Fuel
GasCodeNFPA54/ANSI Z223.1, Section5.3.Air for
Combustion and Ventilation forrequiredsizeof
ventilationgrillsorducts.
IMPORTANT: Donotprovide openings forinletor
outletairintoatticifattichas athermostat-con-
trolledpowervent.. Heatedair entering the atticwill
activatethepowervent..
WARNING:Ifthearea inwhichthe heater may be operatedissmallerthan thatdefinedasan unconfinedspace
or if thebuildingisof unusuallytight construction,provide adequatecombustionandventilationairbyoneof the
methods describedintheNationalFuelGasCode,ANSIZ223.1/NFPA54,Airfor Combustionand Ventilation,or
applicablelocalcodes.

7
LOCATING HEATER
Thisheaterisdesignedformount-
ing onawall,seton floor, away
fromawall.Purchaseoptionalfloor
mountingstand isneeded.Purchase
the floormountingstandfromyour
dealer. SeeAccessories,page16.
Forconvenienceand efficiency,
installheater
l Wherethereiseasyaccessfor
operation,inspection,andservice
l incoldest part of room
INSTALLATION
WARNING:Aqualifiedservice
person mustinstallheater.Fol-
lowalllocalcodes.
NOTICE:Thisheater isin-
tendedforuseas supplemental
heat. Use thisheateralongwith
yourprimaryheatingsystem. Do
notinstall thisheaterasyour
primaryheatsource.If youhave
acentralheatingsystem,you
mayrunsystem scirculating
blowerwhileusing heater.This
willhelpcirculatetheheat
throughoutthehouse.Inthe
event ofapower outage,you can
use thisheateras yourprimary
heatsource.
WARNING: Neverinstall
theheater
l inabedroomor bathroom.
l inarecreationalvehicle.
l wherecurtains,furniture,
clothing,orotherflammable
objectsarelessthan 36inches
fromthefront, top,orsides
of theheater.
l asafireplaceinsert.
l inhigh trafficareas.
l inwindyordraftyareas.
CHECKGASTYPE
UseonlyNaturalgas.If your gas
supplyisnotNatural,do notinstall
heater. Calldealerwhereyou
boughtheater forpropertypeheater.
WARNING:ElectricalGrounding
Instructions
Thisapplianceisequipped witha
three-prong(grounding)plugfor
yourprotectionagainst shockhaz-
ardandshouldbeplugged directly
intoaproperlygrounded three-
prong receptacle
WARNING:Maintainthemini-
mumclearancesshowninFig-
ure4.If you can,providegreater
clearancesfromfloor, ceiling,
andjoining wall.
CAUTION:Ifyouinstallthe
heaterinahomegarage
l heaterpilotand burnermust
beatleast18inches above
floor.
l locateheaterwheremoving
vehiclewill not hit it.
CAUTION:Thisheatercreates
warmaircurrents. These currents
moveheat towall surfaces next
toheater. Installingheaternextto
vinylorclothwall coveringsor
operating heaterwhereimpuri-
ties (such as tobacco smoke, aro-
maticcandles,cleaning fluids,
oil orkerosene lamps,etc.) inthe
airexistmaydiscolorwalls.
Figure4-Mounting ClearancesAs
Viewed FromFrontOfHeater
FASTENING HEATERTOWALL
Mounting Bracket
Themountingbracketislocated
onback panelofheater(see
Figure5).It hasbeen taped there
forshipping.Removemounting
bracketfrombackpanel.
Figure5-Mounting Bracket
Location

8
INSTALLATION
CONTINUED
Methods ForAttachingMounting
BracketToWall
Onlyuselastholeoneachend
ofmounting brackettoattach
brackettowall. Thesetwoholes
are16inchesapartfromtheir
centers.Attachmountingbracket
towall onlyinoneof twoways:
1. Attaching towall stud
2. Attaching towall anchor
Note: Wall anchors, mounting
screws,andspacersarein
hardwarepackage.The hardware
packageisprovided withheater.
AttachingtoWallStud: Thismethod
provides the strongest hold.Insert
mountingscrewsthroughmounting
bracket andintowallstuds.
AttachingtoWallAnchor: This
methodallowsyoutoattach
mountingbrackettohollowwalls
(wallareasbetween studs)orto
solidwalls(concreteor masonry).
Decide whichmethodbetter
suitsyourneeds.Eithermethod
willprovide asecureholdfor the
mountingbracket.
MarkingScrewLocations
1.Tapemountingbrackettowall
whereheaterwillbelocated.
Makesuremounting bracketis
level.
Attaching toWall StudMethod For
attachingmounting bracket towall
studs
1. Drillholes at markedlocations
using9/64"drill bit.
2.Placemounting bracketonto
wall. Line uplastholeoneach
end ofbracket withholes drilled
inwall.
3. Insertmountingscrewsthrough
bracketand intowall studs.
4.Tightenscrewsuntilmounting
bracketisfirmlyfastenedto
wallstuds.
AttachingtoWall AnchorMethod
Forattachingmountingbracket to
hollowwalls(wall areas between
studs)orsolidwalls(concreteor
masonry)
1.Drillholes atmarkedlocations
using5/16"drill bit.Forsolid
walls(concreteor masonry), drill
at least1"deep.
2.Foldwall anchor asshownin
Figure7below.
Figure7-FoldingAnchor
3.Insert wall anchor(wings
first) intohole.Tapanchor
flushtowall.
4.Forthinwalls(1/2"orless),
insert redkeyintowall
anchor. Push redkeyto
"pop"openanchorwings
(see Figure8).
Model MN200EPCMN200EHPC
Figure6- Mounting Bracket
Clearances
Model MN300EPCMN300EHPC
IMPORTANT: Donot
hammerkey!Forthickwalls
(over1/2"thick)orsolidwalls,
donot popopenwings.
Figure8-Popping Open Anchor
WingForThinWalls
5. Placemounting bracketonto
wall. Lineuplastholeon
each endof bracket withwall
anchors.
6.Insert mounting screwsthrough
bracket andintowall anchors.
7.Tightenscrewsuntilmounting
bracket isfirmlyfastenedtowall.
PlacingHeateronMounting
Bracket
1. Locatetwohorizontalslotson
back panelofheater(see
Figure9).
2.Place heaterontomounting
bracket. Slide horizontalslots
ontostand-outtabs on
mountingbracket.
Figure9- Mounting HeaterOnto
Mounting Bracket
WARNING: Maintainmini-
mumclearancesshowninFigure
6. If youcan,providegreater clear-
ances fromfloor and joining wall.
2. Markscrewlocations onwall.
(seeFigure6)
Note: Onlymarklastholeon
eachend ofmountingbracket.
Insert mountingscrewsthrough
theseholesonly.
3.Removetapeand mounting
bracket fromwall.
Floor
OnlyInsertMounting
ScrewsThrough
LastHoleOnEach
End
Adjoining
Wall
Floor
OnlyInsertMounting
ScrewsThrough
LastHoleOnEach
End
Adjoining
Wall

9
Installing BottomBracket
(See Figure10)
1. Installbottombrackettoheater
bottomwithtwoscrews.It may
bemoreconvienenttoremove
heater fromwall mounting bracket
toattach bottombracket.
2. Placeheater on mounting bracket.
3.Locatetwobottommounting
holesonwall. Theseholesare
near bottomon heater.
4.Markscrewlocationsonwall.
5.Removeheaterfrommounting
bracket..
6. If installingbottommounting
screwsintohollowor solidwall,
install wallanchors.Followsteps
1through 4under Attaching
ToWall AnchorMethod.If
installing bottommountingscrew
intowall stud, drill holes atmarked
locations using9/64" drillbit..
7. Replace heaterontomounting
bracket..
8.Tightenbothscrewsuntil heater
isfirmlysecuredtowall.Donot
over tighten.
Figure10 - Installing BottomBracket
CONNECTING TOGAS
SUPPLY
IMPORTANT: Check yourgas
linepressurebeforeconnecting
heatertogasline.Gaslinepres-
suremust benogreaterthan 14
inchesofwater.Ifgaslinepres-
sureishigher,heaterregulator
damage couldoccur.
Figure11-GasMeter
INSTALLATION
CONTINUED
WARNING:Aqualifiedservice
person mustconnectheaterto
gas supply.Followall localcodes.
WARNING:Thisappliancere-
quires a3/8"NPT(NationalPipe
Thread)inletconnectiontothe
pressureregulator.
WARNING: Donotovertighten
gas connections.
WARNING: Neverconnect
heatertoprivate( non-utility)
gas well.Thisgas iscommonly
knownas well-headgas.
CAUTION: Use onlynew, black
iron or steelpipe.Internally-tinned
copper tubing maybeusedin
certainareas. Check your local
codes.Use pipeof largeenough
diameter toallowproper gas volume
toheater. If pipeistoo small,
undueloss of pressurewill occur.
CAUTION: Use pipe joint
sealantthatisresistantto
naturalgas.
CAUTION: Avoiddamageto
regulator. Holdgas regulatorwith
wrenchwhenconnectingtogas
pipingand/orfittings.
*ACSA/AGAdesign-certifiedequip-
ment shutoff valvewith1/8"NPT
tapisanacceptablealternative to
testgauge connection.
INSTALLATION NEEDS
Beforeinstalling heater, makesure
youhavethe itemslisted below.
l piping(checklocalcodes)
l sealant (resistanttoNatural
gas)
l equipment shutoff valve*
l groundjoint union
l test gauge connection*
l sediment trap
l teejoint
l pipe wrench

10
INSTALLATION
*ACSA/AGAdesign-certifiedequipment shutoff valvewith1/8"NPT tap
isanacceptablealternative totest gaugeconnection.Purchasethe
optionalCSA/AGAdesign-certified equipmentshutoff valve from
your dealer.
IMPORTANT:Install anequipment
shutoffvalveinanaccessible
location.Theequipmentshutoff
valveisforturningonor shutting
off thegastotheappliance.
Installsedimenttrapinsupplyline
as showninFigure12.Locate
sedimenttrapwhereitiswithin
reach forcleaning.Locate
sedimenttrapwheretrapped
matterisnotlikelytofreeze.A
sediment trap traps moistureand
Figure12 -Gas Connection
Applypipejointsealantlightlyto
malethreads.Thiswillprevent
excess sealantfromgoing into
pipe.Excesssealantinpipecould
result inclogged heatervalves.
Pressure Testing GasSupply
Piping System
TestPressuresIn Excess Of
1/2PSIG (3.5KPa)
1. Disconnectappliancewithits
appliancemaingasvalve
(controlvalve)and equipment
shutoff valvefromgas supply
pipingsystem.Pressuresin
excess of1/2psigwill damage
heater regulator.
2.Capoff openendofgas pipe
whereequipment shutoff valve
wasconnected.
3.Pressurize supplypipingsystem
byeither usingcompressedair
or openingmaingas valve
locatedon orneargasmeter.
4.Checkalljointsofgas supply
pipingsystem. Applymixtureof
liquidsoapand watertogas
joints. Bubbles forming show
aleak.
5. Correctallleaksat once.
6.Reconnectheater andequipment
shutoff valvetogas supply.Check
reconnected fittings forleaks.
TestPressuresEqualToor
LessThan 1/2PSIG(3.5KPa)
1.Closeequipmentshutoffvalve
(seeFigure13).
2.Pressurizesupplypiping system
byeither usingcompressedair
oropening maingas valve lo
cated onorneargasmeter.
3.Checkall jointsfromgasmaterto
equipmentshutoff valve(See
Figure14) Applymixtureof liquid
soapandwater togasjoints.
Bubblesformingshowaleak.
4. Correctallleaksat once.
StateofMassachusetts:The instal-
lation mustbemadebyalicensed
plumber orgas fitterintheCommon-
wealthofMassachusetts.
Sellersof unvented propaneornatu-
ralgas-fired supplementalroom
heatersshall providetoeach pur-
chaseracopyof527 CMR30 upon
saleofthe unit.
IntheStateofMassachusetts,
unventedpropaneandnaturalgas-
firedspaceheatersshallbeprohib-
itedinbedroomsand bathrooms.
CHECKINGGAS
CONNECTIONS
WARNING:Testall gas
piping and connectionsforleaks
after installing or servicing. Correct
all leaks at once.
WARNING: Neverusean
open flametocheckfora
leak. Applyamixtureofliquid
soapandwater toall joints.
Bubbles formingshowaleak.
Correctallleaksatonce.
contaminants.Thiskeepsthem
fromgoingintoheatercontrols.If
sediment trapisnotinstalled oris
installed wrong,heatermay
not run properly.
CAUTION: Make sureexternal
regulatorhasbeeninstalled be-
tween gassupplyand heater.See
guidelines under ConnectingtoGas
Supply.

11
Figure13-Equipment Shutoff Valve
PressureTestingHeaterGas
Connections
1.Openequipmentshutoff valve
(seeFigure13).
2. Openmaingasvalvelocatedon
ornear gasmeter.
3.Make surecontrolknobof
heaterisintheOFFposition.
4.Check all jointsfromequipment
shutoff valvetocontrolvalve
(see Figure14 ). Applymixtureof
liquidsoapand water togas
joints.Bubblesformingshow
aleak.
5. Correct all leaks atonce.
6.Lightheater(see Operating
Heater,pages11and12). Check
therestoftheinternaljointsfor
leaks.
7.Turnoff heater(seepage12 ).
A. Thisapplianceisequippedwith
an ignition devicewhich
automaticallylightsthepilot.Do
nottry tolightthe pilot by
hand.
B.BEFORE LIGHTINGsmell all
aroundtheappliancearea for
gas.Besuretosmell next to
thefloorbecausesomegas is
heavierthanairand will settle
on thefloor .
WHATTODOIFYOU SMELLGAS
l Donottrytolightanyappliance.
l Do not touch anyelectricswitch;
donotuseanyphone inyour
building.
l Immediatelycallyourgas
supplier fromaneighbor s
phone.Followthegas
supplier sinstructions.
l Ifyou cannot reach your
gassupplier,callthe fire
department.
C.Useonlyyour hand topushon
button. Neveruse tools.If
thedoesnotoperatewill not
pushbyhand, don t tryto
repairit,callaqualifiedservice
technicianorgassupplier. Force
orattemptedrepair may result in
afireor explosion.
D.Donot usethisapplianceif any
parthas beenunder water.
Immediatelycall aqualified
servicetechniciantoinspect
theapplianceand toreplace
anypart ofthecontrolsystem
andanygascontrolwhichhas
beenunder water.
Figure14 -Checking Gas
Connections
OPERATINGYOUR
HEATER
FORYOUR SAFETY
READBEFORELIGHTING
WARNING:If you donot
followtheseinstructionsexactly,
afireorexplosion may result
incausingpropertydamage,
personalinjuryorloss of life.
1. STOP! Read thesafetyinforma-
tion abovebeforelighting.
2. Disconnect orturnoffallelectric
power toheater.
3. Thisapplianceisequippedwith
anignition device which automati-
callylightsthepilot.Donot trytolight
thepilotbyhand.
4.Waitfive(5)minutes toclearout any
gas.Then smell forgas,including
nearthefloor. If you smellgas,
STOP! Follow “B”inthesafetyinfor-
mation above.Ifyoudon tsmell
gas, gotonext step.
5.Plugintoaproperlygroundedthree-
prong receptacle,setON/OFF
switch on, you will hear ahigh pitch
sound thatindicates theburneris
readytobeoperated.
6.MakesureControlKnob isin
ELECTRICposition.
7. PressIGN/OFF button an electric
sparkwillignitethepilot.
MAN:Burner operates continuously.
OFF:Themainburnerwillshutoff.
9.Iftheappliancewill not operate,
followtheinstructions “ToTurnOff
Gas ToAppliance”andcall your
service technicianorgassupplier.
Note:Thethermostat sensing bulb
measuresthetemperatureofair
near theheatercabinet. Thismay
notalwaysagree withroomtempera-
ture(depending on housing
construction, installation location,
roomsize, airtemperatures,etc.)
Frequent useofyourheaterwilllet
youdetermine yourowncomfort
levels.
8.PressBURNERbuttonfor desired
burneroperation.
AUTO:Burner will automaticallyturn
onorofftodesiredtemperature
setting, press or fordesired
temperaturesetting.
Clock setting:Press CLOCKbutton
toselectitem(hour,minute). The
selected itemwillflash. Pressor
tochangetocorrecttime(hour,
minute). PressCLOCKbutton again,
tosetclock.
SETTINGCLOCK
CHECKINGGAS
CONNECTIONS
CONTINUED
OPERATIONG
INSTRUCTION
For MN200EHPC, MN300EHPC
modelswithmanualoverridecontrol
system,makesuretheELECTRIC
ControlKnobintheelectric
postion.(SeeFigure15).

12
OPERATINGYOURHEATER
continued
AUTOON: Withburneroff, press
TIMER button.Thenpress or to
change tothescheduled time,then
presstheTIMERbuttonagain, the
TIMERstartstimingand theTIMER
will flash.Burnerwill automatically
comeonatthesettime.
SETTINGTIMER
AUTOOFF:Withburner operating,
pressTIMERbutton.Thenpress
or tochange tothescheduled
time,thenpress theTIMERbutton
again, theTIMERstartstimingand
the TIMER will flash.Burnerwill
automaticallyshutoff atthedesired
time.
LOCKINGTOUCH-PAD
(childproof)
A.Key-presslocking: Press LOCK
buttonontheoperatingpanel,
asymbolwill appearonthe
LCD.
B.Key-pressunlocking:Press,
thenpressLOCKbuttontounlock.
1.PresstheIGN/OFF button on the
touchpad.
2.Set theON/OFFswitch toOFF
positionontoppanel.
IFNO ELECTRICPOWER IS
AVAILABLE,HEATERCAN BE OPER-
ATEDMANUALLY
If themanualcontrolknobpointsto
ELECTRICposition,pressinthe
controlknob andturncounter clock-
wise toOFFposition.
4. Wait five(5) minutestoclear any
gas.Thensmell for gas,includ-
ingnearthefloor.If you smell
gas,STOP!Follow “B”inthe
safetyinformation on page11.If
you do notsmellgas,go tothe
nextstep.
5.Pushingas controlknob slightly
andturncounterclockwise to
PILOT/IGNand depress for five(5)
seconds. NOTE: Thefirsttimethe
heaterisoperatedafterconnect-
ingthegas supply,thecontrol
knobshouldbe depressedfor
about thirty(30)seconds.Thiswill
allowair toexitthegas system.
6. Withcontrolknobpressed, push
andreleaseignitor button. This
willlight the pilot.If needed, keep
pressing ignitorbutton untilpilot
lights.
7.Keep controlknob depressedfor
ten(10)seconds after lighting
pilot. If pilotgoesout, repeat
steps 5,6and 7.
8.Rotatecounterclockwiseto
ONpositiontolight burner. Donot
operatebetween locked positions.
NOTE: Wait one minutetolight
againaftershutting off heater.
MANUALOPERATING
INSTRUCTIONS
TO TURN OFFGASTO
HEATER
MAN:Bloweroperates continuously.
OPERATINGBLOWER
PressBLOWERbutton,fordesired
burneroperation.
OFF: Blowerisoff.
AUTO:Blowerwill comeon several
minutes afterburnercomes on and
willgo off severalminutes after
burner goes off.
1. STOP!Readthesafetyinfor-
mation on page11beforelighting.
2. Check thatgassupplytothe
3.Removeroundaccess door of
rightsidepanel. Pushincontrol
knobslightlyandturnclockwise
totheOFFposition.
heaterison.
Weprovidethe manualcontrolsys-
temjust incase ofpowershortage.
InstallbatteryforManual Ignitor:
1.Unscrewthe ignitor cap.
2.Insert aAAAtypebatterywithits
anode(“+”)pointingout.
3.Screwthe ignitorbackcap.
Note:Werecommend that thebattery
betakenoutofthe ignitorwhenthe
powersupplygetsright.
ControlKnob
IgnitorButton

13
Figure15- Manual Control
Pushingascontrolknob slightly
and turnclockwise toOFF.
Donot useforce.NOTE:Wait one
(1) minutewithcontrolknobin
OFFposition beforeoperating
heater.
9.When electricpowerisavailable
andelectronicoperationis
desired, turnclockwise to
OFFpositionfor oneminute. Then
pressdownknobandrotate
clockwisetoELECTRIC
position. Donot operatebetween
locked positions.
1. Remove lowerfrontpanel.
2.Followsteps1through 5
under ManualOperatting
Instructionson page12.
3.Withcontrolknobpressedin,
strike match.Holdmatch
topilotuntilpilotlights.
MANUALLIGHTING
PROCEDURE
INSPECTINGBURNER
Check pilotflamepatternand
burner flamepatternoften.
PILOTFLAMEPATTERN
Figure16showsacorrectpilot
flamepattern.Figure16showsan
incorrect pilotflamepattern.The
incorrect pilotflameisnot touch-
ingthermocouple.Thiswill cause
thethermocoupletocool.When
the thermocouplecools, thehealer
will shut down.If pilotflamepattern
isincorrect,asshowninFigure
17.
l turnheateroff(see page11)
l see Troubleshooting,pages 17
through 19.
Figure17- Incorrect Pilot Flame
Pattern
BURNERFLAMEPATTERN
Figure17showsacorrect burner
flamepattern.Figure19showsan
incorrectburnerflamepattern. If
burner flamepatternisincorrect,
asshowninFigure19.
l turnheater off(seepage 11).
lsee Troubleshooting. pages17
through 19.
Figure19 - IncorrectBurner
FlamePattern
Figure18 - Correct Burner
FlamePattern
MANUALOPERATING
INSTRUCTIONS
continued
4.Keepcontrolknob pressedin
for30 secondsafterlighting
pilot.
5.Rotatecounterclockwise to
ONposition tolight burner. Do
not operatebetweenlooked
positions.
4.Replace lower front panel
Figure16 - CorrectPilot Flame
Pattern
TO TURN OFFGASTO
APPLIANCE
(MatchLight)

14
CLEANINGAND
MAINTENANCE
DISCONNECTWIRINGOF
CONTROLMODULE
1.Removetwoscrewsfromthelower
frontpanel , pullthelowerfront panel
forwardthendowntakeout thermostat
sensingbulbfromtheclip,thendisco-
nnectthewires fromcontrolmodule.
Note:Donotconfuse themarkon each
wire.
2.Remove twoscrewsand hex nuts,
Figure20 ControlModel Access
2.Markortageachwireremoved for
itsexact reconnection. Removethe
fourscrewsfromthefan,when
installing, reversethesteps above.
(SeeFigures21,23and24)
Figure21-Fan Access
CLEANINGODS/PILOTANDBURNER
lUse avacuumcleaner,pressurized
air.
CLEANING BURNER AND PILOT
AIRINLETHOLE
Werecommendthat youclean the
unit every2,500hoursofoperation
oreverythreemonths.Wealso
recommend thatyoukeeptheburner
tubeand pilotassemblycleanand
free ofdustand dirt.
Tocleanthese partswerecommend
using compressed airnogreater
than30PSl. Yourlocalcomputer
store, hardwarestore,or homecenter
maycarrycompressedairinacan.
Youcan useavacuumcleaner inthe
blowposition.Ifusingcompressed
airinacan, pleasefollowthedirec-
tionson thecan.Ifyoudon tfollow
directionson thecan, you coulddam-
age thepilotassembly.
1. Shut off the unit, including the
pilot. Allowtheunittocoolfor
at leastthirtyminutes.
2.Inspectburner,pilotfordust
and dirt.
3.Blowairthroughtheports/slots
andholes intheburner.
Cleanthepilotassemblyalso. A
yellowtiponthepilot flameindi-
catesdustand dirtinthe pilot
assembly.Thereisasmall pilotair
inletholeabout twoinchesfrom
wherethe pilot flamecomesout of
the pilotassembly(seeFigure22).
Withthe unitoff, lightlyblowair
throughthe airinlethole.Youmay
blowthroughadrinkingstrawif
compressedairisnotavailable.
DISCONNECTFAN
1.Removescrewsfromthefan
bracketpanel,pull thefan bracket
panelout toremove. Disconnect
twowires oftemperaturesensor.
CAUTION:Labelallwiresprior to
WARNING:
WARNING: Failuretokeep
the primaryairopening(s)ofthe
burner(s) cleanmayresultinsoot
causing propertydamage.
takeoutthecontrolmodule.When
installing , reverse thestepsabove.
(SeeFigures20, 23and24)
CLEANING HEATERCABINET
AirPassageways
lUseavacuumcleaner or
pressurizedairtoclean.
Exterior
lUseasoft clothdampenedwith
amildsoapand water mixture.
Wipethecabinettoremove dust.
Figure22- Pilot Inlet AirHole
disconnection whenservicing
controls.Wiring errorscancause
improperand dangerousoperation.
Verifyproperoperationafter
servicing.
Disconnect
powerbeforeattemptingany
maintenanceorcleaning toreduce
theriskoffire, electricshockor
personalinjury.Turnoffheaterand
let cool beforecleaning.
CAUTION: You mustkeep
control areas,burner, and circulat-
ingairpassagewaysofheater
clean. Inspectthese areas ofheater
beforeeachuse.HaveheaterIn-
spected yearlybyaqualifiedser-
viceperson.Heater may need more
frequentcleaningduetoexcessive
lintfromcarpeting,bedding material,
pethair, etc.

15
Figure24-DoubleControlSystemDiagram
(ModelMN200EHPCMN300EHPC)
Figure23-
(ModelMN300EPC)

16
Note: Dimensionslisted areoutermostpointson theheater(includesgrill).
*Forpurposesofinputadjustment.
MN200EPC(MN200EHPC)
20,000
NaturalGasOnly
Automatic(Automatic/Electronic)
120 V
20 W
6"W.C.
10.5"
7"
23 5/8×19 5/8×9
271/2×22×101/8
33(34)
38(39)
REPLACEMENTPARTS
Note: Use onlyoriginalreplacement
parts.Thiswillprotectyour warranty
coveragefor partsreplacedunder
warranty.
PARTSNOT UNDER
WARRANTY
Contactauthorizeddealersofthis
product. If theycan t supplyoriginal
replacement part(s), call PRO-COM s
phonenumber(877)886-5989.
TECHNICALSERVICE
You mayhavefurtherquestions
aboutinstallation,operation,or
troubleshooting.Ifso,contact
PRO-COM Sphonenumber(877)
886-5989.
FLOORMOUNTINGSTAND
Forlocatingheateronthe floor,
awayfromawall.Completeinstalla-
tioninstructionsprovided withfloor
mounting base stand.
FLOORSTAND MODEL:
PF0920C
ACCESSORIES
Purchase these heateraccesso-
riesfromyourlocaldealer. If they
l yourname
l your address
l modeland serialnumbersof
your heater
l howheater wasmalfunctioning
l typeofgas used(propane/LPor
naturalgas)
l purchase date
l warrantycard
Usually, wewillask youtoreturnthe
defectivepart tothefactory.
If theyareunabletosupplyoriginal
replacementpart(s), callthenumber
onthefrontof manual. Whencon-
tacting yourdealeror PRO-COM, have
ready:
PARTS UNDERWARRANTY
Contactauthorizeddealerfrom
whomyoupurchased thisproduct.
SPECIFICATIONS
BTU/Hr
GasType
Ignition
Volts
Watts
ManifoldPressure
InletGas Pressure(inches of
water)
Maximum
Minimum
Dimensions,Inches (HxWxD)
Heater
Carton
Weight (pounds)
Heater
Shipping
cannotsupplythese accessories,
contactPRO-COMforinformation.
You canalsowritetotheaddress
listedonthefrontofthismanual.
MN300EPC(MN300EHPC)
30,000
NaturalGasOnly
Automatic(Automatic/Electronic)
120 V
27W
4"W.C
10.5"
7"
235/8×271/16×9
27 1/2×297/16×111/8
42(43)
55(56)

17
TROUBLESHOOTING
POSSIBLECAUSE
1. Nopowertoheater
2.ON/offswitch notON
3.Wireisdamagedorloose
4. Pilotelectrodepositionisnotcorrect
5. Touchpad cableisnot connected
6.Systemhalt
1.Gassupplyturnedofforequipment
shut off valveclosed
2. Air ingaslines wheninstalled
3. Depletedgassupply
4. ODS/pilotisclogged
5.Gasinletsupplypressurenot correct
6.Wireisdamagedorloose
7. Pilotelectrudepositionisnotcorrect
8.Gas valveorregulatorisdamage
1. Equipmentshutoff valveisnot
fullyopen
2.Thermocoupleconnection
looseatcontrolmodule
3Lowgaspressure
4. DirtorpartiallycloggedODS/pilot
5.Thermocoupledamaged
6.Gasvalveorregulatordamaged
WARNING: If you smell gas
l Shut off gassupply.
l Donottrytolight anyappliance.
l Donottouchanyelectrical switch; donot useanyphoneinyourbuilding.
l Immediatelycallyourgassupplierfromaneighbor sphone. Followthe gas
supplier sinstructions.
l If you cannot reachyourgassupplier,callthefiredepartment.
IMPORTANT:Operatingheaterwhereimpuritiesinairexistmaycreateodors.
Cleaning supplies,paint,paintremover, cigarettesmoke,cementsandglues, new
carpetortextiles, etc.,createfumes.Thesefumesmaymixwithcombustion air
and createodors.
Warning : Makesurethat power
isturnedoff beforeproceeding.
CAUTION:Neveruseawire,
needle, orsimilarobject toclean
ODS/pilot.Thiscan damage
ODS/pilotunit.
OBSERVED PROBLEM
When ignitionbutton ispressed,
thereisno sparkatODS/pilot
whenIGN/OFF ispressed
Sparkat ODS/pilotbut noignition.
ODS/pilothas flame,butcontinues
tospark.
WARNING: Turnoff andlet coolbe-
foreservicing.Onlyaqualifiedser-
viceperson shouldserviceand re-
pairheater.
REMEDY
1. Checkthe electricpower
2.TurnON/OFFswicthon
3.Check thewirefordamageand
makesureconnection istight
4.ReplacePilot
5. Reconnecttouch padcable
6.Placethecontrolknobof
manualoverrideor OFFposition
forat least1minute,thentrun to
ELECTRICposition
1.Turnongassupplyor open
equipmentshutoff valve
2.Press ignitorbutton againuntil
airisremoved
3.Contract localgascompany
4.CleanODS/pilot(see cleaning
and Maintenance, Page 12)or
replaceODS/pilot assembly
5.Havequalifiedservicetechnician
checkinlet pressure
6.Checkthe wirefor damage and
makesureconnectionistight
7.ReplacePilot
8.Contactdealeror PRO-COM
1.Fullyopen equipment shutoffvalve
2.Checkthatconnectorssecureon
module
3.Contactlocalnaturalgas company
4.CleanODS/pilot(see Cleaningand
Maintenance, Page13) orreplace
ODS/pilot assembly
5.Replacethermocouple
6.Contactdealeror PRO-COM

18
TROUBLESHOOTING
Continued
OBSERVED PROBLEM
ODS/pilot hasflame,butburner(s)
doesnotlight
Delayedignitionofburner(s)
Burner backfiring duringcombustion
BurnerPlaque(s)doesnotglow
Slight smoke or odorduring
initialoperation
Heaterproducesaclicking/ticking
noisejustafter burnerislit or
shut off
Whitepowderresidue forming
withinburnerboxor onadjacent
wallsorfurniture
POSSIBLECAUSE
1.Burnerinjector isclogged
2.Inletgaspressureistoolow
3.Thermocoupleleads disconnected
orimproperlyconnected
4.Batteriesweak
1. Manifoldpressureistoolow.
2.Burner injector isclogged
1. Burnerinjector isclogged or
damaged
2. Burnerisdamaged.
3. Excessivesupplypressure
damaged regulator
1.Plaquedamaged
2.Inletgas pressureistoolow
1.Residues frommanufacturing
processes
1. Metalexpandingwhileheating or
contracting whilecooling
1. Heatedvaporsfromfurniture
polish,wax, carpet cleaners,
etc. turnintowhitepowder
residue
REMEDY
1.Cleanburnerinjector (see Cleaning
andMaintenance,Page14)or
replaceburner injector
2.Contactlocalnaturalgascompany
3.Reconnectleads (Seewiring
diagram)
4.Replacebatteries
1.Contact localnaturalgascompany.
2.Cleanburner(see Cleaningand
Maintenance,Page14)orreplace
burnerinjector
1.Clean burnerinjector(see Cleaning
and Maintenance, Page14)or
replaceburner injector(s)
2. Replaceburner
3.Replace gasregulator
1. Replaceburner
2.Contact localnaturalgas
company.
1.Problemwillstopafter afewhours
ofoperation
1.Thisiscommonwithmost
heaters. If noiseisexcessive,
contactqualifiedserviceperson
1. Turnheater off whenusingfurniture
polish,wax, carpetcleaner, or
similarproducts

19
TROUBLESHOOTING
Continued
REMEDY
1. Ventilateroom.Stopusing odor
causingproductswhileheater
isrunning
2.Locateandcorrectall leaks(see
Checking GasConnections,
Page10)
1. Open windowand/ordoor for,
ventilation
2. Contactlocalnaturalgas
company.
3.Clean ODS/pilot(seeCleaning
Page14)
1. Locateandcorrectallleaks(see
CheckingGasConnections,
Page10)
1. Removeforeign matter.
2.Locateandcorrect all leaks
(seeCheckingGas
Connections, Page10)
1.Refer toAirforCombustion and
Ventilation requirements, Page
5
POSSIBLECAUSE
1. Heater isburning vaporsfrom
paint, hairspray, glues,etc.
(SeeIMPORTANTstatement
at beginningof troubleshooting)
2. Gas leak.See WARNING
Statement at beginning of
troubleshooting
1.Notenoughfreshairisavailable.
2.Lowlinepressure
3.ODS/pilotispartiallyclogged
1.Gasleak. See WARNING
Statement atbeginning of
troubleshooting
1. Foreignmatterbetweencontrol
valveandburner
2.GasleakSee WARNING
Statement at beginning of
troubleshooting
1.Notenough combustion/
ventilation air
OBSERVED PROBLEM
Heaterproducesunwantedodors
Heater shutsoffinuse(ODS
operates)
Gasodorexistsevenwhenheateris
shut off
Gasodor duringcombustion
Moisture/condensation onwindows
NOTE: BEFOREYOUSWITCHTO “ELECTRIC”CONTROLLEVELFROMMANUALCONTROL,YOUNEED
TOTURN THEKNOBTO “OFF”LEVELFIRSTANDWAIT FORONEMINUTE,THENTURN THEKNOBTO
“ELECTRIC”.
INCASEOF “ELECTRONIC”CONTROLLEVELDOESNOTWORK,PLEASE TURNTHECONTROLKNOB
COUNTERCLOCKWISETO “OFF”LEVELAND WAIT FORONEMINUTE.

20
ILLUSTRATED
PARTSBREAKDOWN
MN200EPC
