Rinnai RCE-592ACPA Installation and operating instructions

THIS IS AN UNVENTED GAS-FIRED HEATER. IT USES AIR (OXYGEN)
FROM THE ROOM IN WHICH IT IS INSTALLED. PROVISIONS FOR
ADEQUATE COMBUSTION AND VENTILATION AIR MUST BE PROVIDED.
REFER TO INSTALLATION INSTRUCTIONS ON PAGE 6.
INSTALLER:Leave this manual with the appliance.
CONSUMER:Retain this manual for future reference.
This appliance may be installed in an aftermarket, permanently located,
manufactured (mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE.
WHAT TO DO IF YOU SMELL GAS
� DO NOT TRY TO LIGHT ANY APPLIANCE.
� DO NOT TOUCH ANY ELECTRICAL SWITCH; DO NOT USE ANY PHONE
IN YOUR BUILDING.
� IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S
PHONE. FOLLOW THE GAS SUPPLIER'S INSTRUCTIONS.
� IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE
DEPARTMENT.
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED
INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
HOME OWNER / INSTALLER
FOR YOUR SAFETY
THIS MANUAL MUST BE READ IN ITS
ENTIRETY BEFORE OPERATING HEATER
RCE-592ACPA
VENT-FREE GAS CONVECTION HEATER
With PlasmaclusterTM +HEPA AIR CLEANING TECHNOLOGY
FC-420 HEPA+
Owner's Operation and lnstallation Manual
CORPORATION
NAGOYA, JAPAN

WARNING
THIS APPLIANCE IS INTENDED FOR SUPPLEMENTAL HEATING.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVlCE OR
MAINTENANCE CAN CAUSE PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE. REFER TO THE OWNER'S INFORMATION
MANUAL PROVIDED WITH THIS APPLIANCE. INSTALLATION AND
SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER,
SERVICE AGENCY OR THE GAS SUPPLIER. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT A QUALIFIED INSTALLER,
SERVICE AGENCY OR THE GAS SUPPLIER.
TABLE OF CONTENTS
GENERAL INFORMATION
THIS SERIES HEATER IS DESIGN CERTIFIED BY CSA INTERNATIONAL AS
A VENT-FREE ROOM HEATER AND MUST BE INSTALLED ACCORDING TO
THESE INSTRUCTIONS.
ANY ALTERATION OF THE ORIGINAL DESIGN INSTALLED OTHER THAN AS
SHOWN IN THESE INSTRUCTIONS OR USED WITH A TYPE OF GAS NOT
SHOWN ON THE RATING PLATE, IS THE RESPONSIBILITY OF THE PERSON AND
COMPANY MAKING THE CHANGE.
SPECIFICATIONS
SAFETY DEVICES
IMPORTANT POINTS
SAFETY POINTS
USAGE AND INSTALLATION INFORMATION
INSTALLATION INSTRUCTIONS
OPERATING INSTRUCTION PLATE
CONTROL PANEL OPERATING INFORMATION
REPLACING THE HEPA FILTER
OPERATING THE HEATER
TIMER OPERATION
MAINTENANCE / SERVICE
TROUBLE SHOOTING CHART
SCHEMATIC DISASSEMBLY
ERROR MESSAGES
LIMITED WARRANTY
................................................................................................................1
................................................................................................................1
...........................................................................................................2
..................................................................................................................3
......................................................................5
..........................................................................................6
....................................................................................9
...............................................................10
.........................................................................................11
................................................................................................12
...........................................................................................................14
...............................................................................................17
..........................................................................................20
..............................................................................................22
..........................................................................................................28
...........................................................................................back cover
Page
WARNING
THIS APPLIANCE IS EQUIPPED FOR (NATURAL OR PROPANE) GAS.
FIELD CONVERSION IS NOT PERMITTED.

- 1 -
SPECIFICATIONS
 Overheat Switch
When the heater gets too hot during operation (for example when the filters or air outlet louvers are
blocked) this device turns the gas off automatically. Remove cause of overheat (clean filters) allow
heater to cooI, then re-ignite.
 Fuse
The electrical circuits are protected by a fuse. When the fuse blows, the heaters will not operate at all.
The fuse must be replaced by an authorized person.
 Flame Failure Device
This device automatically cuts off the gas supply to the heater in the event of a gas failure. To restore
the gas supply to the heater, turn it off, then follow the ignition procedure.
 Oxygen Depletion Safety Device
If the oxygen level in the room drops below a pre-set limit, this device cuts the gas supply off to the
heater. If the oxygen depletion device operates, turn the heater off, ventilate the room, then follow the
ignition procedure to re-light. Heater will not re-Iight until room is fully ventilated.
 Tilt Switch
If the heater is knocked over, the tilt switch will cut the gas supply off. The fan keeps running. To
restore the gas supply, stand the heater upright, turn it off then follow the ignition procedure. The tilt
switch may also operate if the heater is jolted or picked up while in operation.
 Power Failure
In the event of a power failure or power cut, the gas valves will automatically close. After the power is
re-instated the appliance must be restarted manually.
"-N" Models are for Natural Gas. (Inlet Pressure within 5.9"-10.5" W.C.)
"-N" Models manifold pressure: 5.1" W.C.
"-P" Models are for L.P. Gas. (Inlet Pressure within 7.9"-13" W.C.)
"-P" Models manifold pressure: 6.2" W.C.
Gas connection pipe size 1/2" N.P.T.all models.
SAFETY DEVICES
Model
RCE-592ACPA-N
RCE-592ACPA-P
Input Rating
BTU/H HIGH
20,000
18,000
Input Rating
BTU/H LOW
4,000
6,000
Thermostat
YES
YES
Weight
in pounds
32
Dimension
in inches
Height: 26 3/10"
Width: 18 9/10"
Depth: 11 4/10"
Fan CFM
Output
High:129
Low:82

UNPACK HEATER:
Check for damage. (DO NOT INSTALL DAMAGED HEATER.) If heater is damaged, contact your
supplier for advice. Before installing a heater, check the label for the correct gas type (see label on back
of heater). Refer to local gas authority for confirmation of gas type if you are in doubt.
INCLUDED IN CARTON:
Customers Operating Information/Manual Gas Valve
IMPORTANT
1. The appliance must be installed in accordance with state and local codes.
2. For information on gas rate, see data plate on the appliance.
3. When using this appliance, ensure that the room is correctly ventilated. Check the local gas
authority for information on ventilation requirements.
4. The heater must not be installed where curtains or other combustible materials could come into
contact with it. In some cases, curtains may need restraining. It must be installed 2" (50mm) away from
walls.
5. This appliance is not designed to be built in.
6. If you move, check the gas type in the area where you are moving to. The local gas authority will be
able to advise on local regulations.
7. This heater discharges a large volume of warm air at low level to provide even heat distribution. If
the air in the room contains cooking vapor or cigarette smoke, and the heater is used on a carpet,
the surface of the carpet may become discolored.
In addition, some nylon carpets contain dyes which may be affected by the warm air flow. Some soft
vinyl surfaces are also subject to distortion, or discoloration by warm air. To prevent discoloration of
carpets etc., a nonflammable board should be placed under the appliance, extending about 30" (750mm)
in front of it.
- 2 -
IMPORTANT POINTS

- 3 -
SAFETY POINTS
Do not install this heater in areas where
spray painting or plating is taking place, or
in places such as hair dressers, where
there may be a lot of fluff and dust, and
where aerosols are used. May create
strong odors and irritate eyes and sinuses.
Do not move the heater while it is turned on.
Do not spray aerosols near this heater while
it is in use. Many aerosols contain flammable
gas and can be a fire hazard. Use of
aerosols, paint, polishes etc., while this
heater is in use will cause unpleasant smells.
Turn off heater when not in use and when
away for long periods of time.
Do not allow children or elderly persons to
sleep in the warm air discharge from the
heater.
Do not sit on this heater.
ON / OFF BUTTON

- 4 -
SAFETY POINTS
Do not unplug during operation
Do not allow children to put articles in the
louvers.
Supervise children playing near this heater.
Do not place wet articles on this heater, the
water may drip into the electrical parts.
Do not turn the heater off by unplugging it
from the wall, or while the fan is cooling the
heater off. (This heater is not suitable for use
with a plug in type timer.)
Ventilate the room when this heater is in
use. Correct, fixed ventilation is usually
sufficient, consult your local gas authority
for local regulations.
Keep away from flammable materials.
Combustible materials must not be placed
where the heater could ignite them.
Do not place articles in front of the hot air
discharge.
Do not place containers of liquid on top of
the heater. Water in the heater can cause
extensive damage.

1. Read these rules and the instructions carefully. Check all local codes. Failure to follow these could
cause a malfunction of the heater resulting in death, serious bodily injury and/or property damage.
2. This heater is designed for use only with one type of gas, either L.P.G. or Natural Gas. Make sure
that the type of gas to be supplied to this unit matches that shown on the rating plate on the heater.
This unit is not convertible to another fuel.
3. WARNING: Any change to this heater or its controls can be dangerous.
4. If a gas leak is suspected, turn heater off, turn gas supply valve off at regulator or appliance
connecter valve. Open windows to ventilate area immediately and contact your dealer or gas
company.
5. WARNING: Failure to keep the primary air opening(s) of the burner(s) clean may result in sooting
and property damage.
6. Installation and repair should be done by a qualified service person. Heater should be inspected
before use and at least annually by a professional service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material, etc. It is imperative that control
compartment, burners and circulating air passageways be kept clean.
7. An unvented room heater having an input rating of more than 10,000 BTU's per hour shall not
be installed in a bedroom or bathroom or where state or local codes do not allow.
An unvented room heater having an input rating of more than 6,000 BTU's per hour shall not
be installed in a bathroom or where state or local codes do not allow.
8. Keep area near the heater clear and free from combustible materials, gasoline and other flammable
vapors and liquids.
9. Due to its high temperature, the heater should be located out of traffic and away from furniture and
draperies.
10. Do not place clothing or flammable material on or near the heater.
11. Any safety panel or guard removed for servicing must be replaced prior to operating the heater.
12. An unvented gas heater will increase the amount of humidity in the room.
13. This heater is intended for space heating purposes only. Do not use for other purposes such as
drying clothes or baking paints.
14. Do not touch the outlet area while the heater is in use. To avoid burns, do not move the heater
during use and avoid touching the heater just after turning off.
15. Children and adults should be alerted to the hazard of high surface temperatures and should stay
away to avoid burns or clothing ignition.
16. Young children should be carefully supervised when they are in the same room with the heater.
17. L.P.G. containers must not be installed indoors.
18. Do not install in a windy area such as facing a window or a door leading to the outside.
19. Do not use this room heater if any part has been under water. lmmediately call a qualified service
technician to inspect the room heater and to replace any part of the control system and any gas
control which has been under water.
20. Carpet lint or cigarette smoke may pass through the heater, discolor, and be deposited into the
room.
21. This unit discharges a large volume of warm air at a low level to provide even heat distribution. If the
air in the room contains cooking vapors, cigarette smoke, and if used on carpet, the surface in front
of unit is subject to discoloration. Some carpets contain dyes which can be effected by warm air flow
and could discolor. To aid in prevention of discoloration, place a mat under the unit to extend to the
front 30".
- 5 -
USAGE AND INSTALLATION INFORMATION

NOTICE BEFORE INSTALLATION
The heater must be installed by a qualified service person according to these installation instructions.
When used without adequate combustion and ventilation heater air the heater may give off carbon
monoxide.
Check your local building codes for the proper method of installation. In the absence of local codes, this
heater installation must conform with American National Standard (National Fuel Gas Code) ANSI
Z223. 1/NFPA54.
Available from the American National Standards lnstitute, Inc.,
1430 Broadway, New York, NY 10018, or from the National Fire
Protection Association, Batterymarch Park, Quincy, MA 02269.
All correspondence should refer to Model No., Serial No., and type of gas.
WARNING: Electrical Grounding Instructions
This appliance is equipped with a three-prong (grounding) plug for your protection against shock hazard
and should be plugged directly into a properly grounded three-prong receptacle.
This appliance may be installed in an aftermarket manufactured (mobile) home when not prohibited by
state or local code. (Aftermarket = completion of sale, not for purpose of resale from manufacturer.)
This heater shall not be installed in a confined space or unusually tight construction unless provisions
are provided for adequate combustion and ventilation air.
The National Fuel Gas Code ANSI Z223. 1/NFPA54 defines a confined space as a space whose volume
is less than 50 cubic feet per 1,000 Btu per hour (4.8m3 per kW) of the aggregate input rating of all
appliances installed in that space and an unconfined space as a space whose volume is not less than 50
cubic feet per 1,000 Btu per hour (4.8m3 per kW) of the aggregate input rating of all appliances installed
in that space.
Rooms communicating directly with the space in which the appliances are installed, through openings
not furnished with doors, are considered a part of the unconfined space.
The folIowing formula can be used to determine the
maximum heater rating per the definition of
unconfined space:
BTU/HR=(L1+L2)Ft × (W)Ft × (H)Ft × 1000
50
Consider two connecting rooms with an open area
between, with the following dimensions:
BTU/HR=(151/2+12) × (12) × (8) × 1000
50
=52800 BTU/HR
If there is a door between the two rooms that can
be closed the calculation must be based only on the
room with the heater.
BTU/HR=(151/2) × (12) × (8) × 1000
50
=29760 BTU/HR
WARNING: If the area in which the heater may be operated is smaller than that defined as an
unconfined space or if the building is of unusually tight construction, provide adequate combustion and
ventilation air by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA54,
Section 5.3 or applicable local codes.
- 6 -
INSTALLATION INSTRUCTIONS
W
H
L2
L1

Unusually tight construction is defined as construction where:
a) Walls and ceilings exposed to the outside atmosphere have a continuous water vapor retarder with a
rating of 1 perm (6×10-11kg per pa-sec-m2) or less with openings gasketed or sealed, and
b) Weather stripping has been added on openable windows and doors, and
c) Caulking or sealants are applied to areas such as joints around window and door frames, between
sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations for plumbing,
electrical, and gas lines, and at other openings.
LOCATION AND CLEARANCES
1. The minimum clearances from the combustible materials are as follows:
40 inches from top
2 inches from back
2 inches from sides
30 inches from front
0 inches from bottom
2. This heater may be installed on combustible flooring. When the heater is installed directly on
carpeting, tile or other combustible material other than wood flooring, the heater shall be installed on
a metal or wood panel extending the full width and depth of the heater.
3. Adequate clearances for accessibility for purposes of servicing and proper operation must be provided.
4. Adequate clearances around air openings must be provided.
5. Do not install this heater in bedrooms or bathrooms.
6. Right and left sides are determined when facing the front.
7. Do not install in areas where curtains, drapes, clothing, or other moving flammables are within 12
inches of this unit.
8. This unit is not designed to mount directly to a wall.
9. Make certain of adequate combustion and ventilation air.
10. Do not oversize the heater to the room.
GAS CONNECTION
1. Attach (2) floor fixing plates in the bottom of base plate
before gas connecting.
2. The gas supply line shall be gas-tight, sized and installed so as to
provide a supply of gas sufficient to meet the maximum demand of the
heater without loss of pressure.
3. A shut off valve (or appliance connector valve) should be installed in the upstream of the gas line to
permit servicing.
4. Flexible pipe and any appliance connector valve used for gas piping shall be types approved by
nationally recognized agencies.
- 7 -
40''
2''
2''
2''
30''
Base plate
Heater
Fixing plate

5. Any compound used on the threaded joint of gas piping shall be a type which resists the action of
liquefied petroleum gas.
6. Supplied gas pressure must be within the limits shown in the specifications.
7. After completion of gas pipe connections, all joints including the heater must be checked for gas-
tightness by means of leak detector solution, soap and water, or an equivalent nonflammable
solution, as applicable.
CAUTION: Since some leak test solutions, including soap and water, may cause
corrosion or stress cracking, the piping shall be rinsed with water after testing, unless
it has been determined that the leak test solution is noncorrosive.
8. The appliance and its appliance main gas valve must be disconnected from the gas supply piping
system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5kPa).
The appliance must be isolated from the gas supply piping system by closing its equipment shut-off
valve during any pressure testing of the gas supply piping system at test pressures equal to or less
than 1/2 psi (3.5kPa).
9. A valve supplied must be installed on back of unit at time of installation. This is for compliance to
ANSI standard Z21.11.2. Valve is packaged with unit.
MANUAL VALVE
10. After completing pipework, secure the heater to the floor.
Use the two screws provided,as shown in the drawing.
To prevent deforming floor fixing plate ,do not over torque screws.
- 8 -
OPENCLOSED
2 SCREWS

A. This appliance does not have a pilot. It is equipped
with an ignition device which automatically lights the
burner. Do not try to light the burner by hand.
B. BEFORE OPERATING smell all around the appliance
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will settle on
the floor.
WHAT TO DO IF YOU SMELL GAS.
· Do not try to light any appliance.
· Do not touch any electrical switch; do not use any
phone in your building.
· Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
· If you cannot reach your gas supplier, call the fire
department.
C. Use only your finger to push with. Never use tools. If
the button will not reactivate by touch, don't try to repair
it, call a qualified service technician. Force or
attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
· STOP! Read the safety information above on this
label. This appliance is equipped with an ignition
device which automatically lights the burner. Do not try
to light the burner by hand.
1. Turn off all electric power to the appliance via the
ON/OFF button on the control panel. Locate manual
gas valve to be found on back side of heater.
2. Turn Manual valve clockwise to the full OFF
position.
3. Wait five (5) minutes to clear out any gas. Then smell
for gas, including near the floor. If you then smell gas,
STOP! Follow "B" in the safety information above on
this label. lf you don't smell gas, go to next step.
4. Turn Manual gas valve to the full ON position.
5. Turn on all electric power to the appliance.
6. Press ON/OFF button to "ON".
7. Set the thermostat to desired setting.
8. Burner is lit when operation lamp glows red.
9. If operation lamp is flashing red, burner has not been
lit.
10. If the appliance will not operate, follow the instructions
"To turn off gas to appliance" and call your service
technician or gas supplier.
1. Turn off electric power to the appliance using the
ON/OFF switch located on the control panel.
2. Turn manual valve clockwise to the full OFF
position.
NOTE: The fan will continue to operate until the appliance is
cooI, do not turn the appliance off by unplugging it from the
wall. Keep burner and control compartment clean. See
installation and operating instructions accompanying heater.
WARNING: Improper installation, adjustment, alteration,
service or maintenance can cause personal injury or loss of
life. Refer to the owner's information manual provided with
this appliance. lnstallation and service must be performed
by a qualified installer, service agency or the gas supplier.
OPERATING INSTRUCTION PLATE
CONVECTOR RCE-592ACPA
FOR YOUR SAFETY READ BEFORE OPERATING
WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
- 9 -
OPENCLOSED
OPERATING INSTRUCTIONS
TO TURN OFF GAS TO APPLIANCE
MANUAL VALVE Room
Temperature Display Ignition Button
Temperature UpTemperature Down

- 10 -
CONTROL PANEL OPERATING INFORMATION
INSTALLATION
Check room size and ventilation. Do not
oversize. Improper sizing may cause nuisance
lock outs.
CONTROL PANEL LAYOUT
Make certain the heater is connected into both
the gas and the electric power.
OFF TIMER BUTTON
Selects operating
mode for delay OFF
Timer function.
ON TIMER BUTTON
Selects operating
mode for delay ON
Timer function.
TIME/TEMP DISPLAY
Shows either the
temperatures or coded
error messages.
FUNCTION LOCK
Lock all controls
when pressed.
(EXCEPT OFF)
ECONOMY INDICATOR
Indicates that the
Economy mode is in
operation.
AUTO-OFF BUTTON
Selects thermostat-off
function.
FILTER INDICATOR
Indicates that the
filter needs cleaning
INDICATORS
Indicate what information
is currently displayed on
the LED display
ION OPERATION INDICATOR
Indicates the ion operation
mode of the Plasmacluster
ion generator.
HEATER OPERATION BUTTON
Main switch for turning
ON/OFF
ION OPERATION BUTTON
Selects the ion operation
mode of the Plasmacluster
ion generator.
TIME/TEMP ADJUSTMENT
Increases or decreases the
temperature setting as well
as changing hours or
minutes.
FUNCTION LOCK INDICATOR
Indicates Function lock
is activated.
ON/OFF INDICATOR
Indicates that the
ON/OFF is activated.
ON TIMER INDICATOR
Indicates that the ON
Timer mode is in operation.
HEPA FILTER RESET BUTTON
Indicates that the
Change HEPA Filter reset.
OFF TIMER INDICATOR
Indicates that the OFF
Timer mode is in operation.
CHANGE HEPA FILTER
Indicates that the HEPA
filter needs replacing.
AUTO-OFF INDICATOR
Indicates the thermostat-off
function is activated.
ECONOMY BUTTON
Select operating
mode for ECONOMY
function.

1. To remove the HEPA filter
· Remove the screw using Philips head.
· Remove the Filter Screen and the HEPA Filter.
2. To install the HEPA filter
· Remove the HEPA Filter from bag and place
into the Filter Screen.
· Install into the back of Appliance using
the top and bottom left-tab as locators.
· Apply screw using Philips head.
Note: Please turn off the “Air Purifier
With Ion” button when replacing
the HEPA filter.
- 11 -
REPLACING THE HEPA FILTER
SCREW 1 OPEN
2 PULL
BLACK SIDE
MOUNTING
HEPA FILTER SCREEN
1
2
3
TAB
HOLE

 TURNING ON
Press the ON/OFF button to operate the heater. The ON
indicator will glow green. After approximately 20 seconds
the spark generator will be heard before the burner
ignites and the ON indicator glows red, indicating that the
burner is lit. Warm air can be felt coming from the
louvers 15 seconds later.
If the heater does not ignite on initial try, air may be remaining in the gas supply line.
The spark generator will only continue for 30 seconds. After this, it will be necessary to press the
ON/OFF button OFF, then ON again.
 TURNING OFF
Simply press the ON/OFF button to switch off the heater. The
ON indicator will go out. The convection fan will continue to
operate for several minutes after the burner has gone out in
order to cool the appliance. Do not unplug the appliance
while the convection fan is running.
DO NOT turn heater off by unplugging.
The convection fan will continue to run until the appliance cools.
 ROOM TEMPERATURE ADJUSTMENT
The room temperature and pre-set temperatures can only be displayed and adjusted when the
heater is running.
Press the " " button to increase the temperature setting
or " " button to decrease the temperature setting.
The temperatures can be preset to:
a) [L] low (about 50°F)
b) [60°F] to [80°F] in 2°F increments
c) [H] (continuously high)
If the heater does not ignite then the pre-set temperature may not be set to a setting which is
higher than the actual room temperature.
 AUTO-OFF FUNCTION
When you select AUTO-OFF, the indicator light will glow.
You have selected a Full Thermostat Control Function.
The heater will cycle High, Low and OFF to maintain the
selected room temperatures.
When the AUTO-OFF indicator is not glowing, you have
selected a manual on/off mode of operation. The unit will
continue to produce at least 4000 BTU/h of heat until you
turn the unit off manually.
- 12 -
OPERATING THE HEATER

Press the Economy button to start
the Economy function.The Economy
indicator will glow.
Press the Economy button once more
to switch off the function.
gECONOMY MODE
The Economy mode may only be operated when the heater is turned on, and remains in the
system memory once set until deactivated.
After the room is heated initally the air temperature may
be dropped to a lower level without affecting comfort. 30
minutes after the selected room temperature (set with the
thermostat) is reached, the Economy mode, if set,
reduces the temperature by 2°F. After another 30
minutes it reduces the temperature by a further 2°F. This
is an energy saving feature. The Economy mode does
not operate if the heater is under capacity for the room
size.
gFUNCTION LOCK
The Function Lock will help to prevent accidental operation as well as making the control
panel child resistant.
To operate the Function Lock simply press the " " and " " buttons
at the same time.
The function is activated immediately and the
Function Lock indicator will glow.
To deactivate the Function Lock simply press the " " and " " buttons
at the same time for 2 seconds and the Function Lock indicator will
go out.
During normal operation the Function Lock may be activated and all controls other than the OFF
switch will be locked. Deactivating the lock releases the controls. If the lock is activated while the
heater is turned OFF, then all functions will be locked. If the heater is turned OFF while the
Function Lock is activated, it cannot be turned ON again until the lock is deactivated.
- 13 -
OPERATING THE HEATER
30min30min
2°F reduction
2°F reduction
Preset temperature

 OFF TIMER OPERATION
This feature is useful on cold nights when the unit continues to operate after you have gone to
bed.
The OFF Timer can be selected when the heater is operating manually, in OFF, or in ON Timer mode.
When the OFF Timer feature is selected, the heater will automatically switch off after 60 minutes.
1 Press the OFF Timer button. The OFF Timer indicator
lights up.
The heater will operate at the preset temperature selected in the system memory.
The temperature will automatically run at 80°F if the set temperature is "H".
If selected while the ON Timer is set, the heater will come on and run for 60 minutes, after which it will remain in
ON Timer standby mode.
If the ON Timer is selected after the OFF Timer has been selected, the unit will run for 60 minutes (OFF Timer
mode) and then remain in the ON Timer standby mode.
In all cases where the ON and OFF Timers are selected together, the OFF Timer will take precedence and run
the heater for 60 minutes after which the heater will remain in the ON Timer standby mode.
OFF TIMER STOPS AFTER 1 HOUR.
Five minutes before the finish of the OFF Timer, the OFF Timer indicator will flash, indicating that the function is
nearing completion.
The OFF Timer indicator will then go out at completion of the 60 minute time delay.
In cases where both the ON and OFF Timers are selected, once the OFF Timer has run the heater for 60
minutes, the ON Timer indicator will remain lit and the heater will be in ON Timer standby mode.
To cancel the OFF Timer, press either the ON-OFF button or the OFF Timer button at any time.
 ON TIMER OPERATION
The ON Timer allows you to program the heater to turn on after a pre-determined time period.
As an example, if the time now is10:30 pm and you wish the heater to start at 6:00 am tomorrow morning, then
the ON Timer must be set to 7.5 (hours)
The ON Timer preset times are from 30 minutes to 24 hours.
These times can be selected in 30 minute increments up to 10 hours and then 1 hour increments up to the
maximum of 24 hours.
BEFORE SELECTING THE ON TIMER CONFIRM:
That the desired preset room temperature has been set (see page 12)
- 14 -
TIMER OPERATION

WARNING
· Ensure there are no obstacles or foreign materials directly in front of the appliance where the
warm air will discharge into the room.
· Ensure the appliance is not positioned where warm air discharge will blow directly on
someone sleeping.
1 Press the "ON Timer" button
The "ON Timer" and "ON/Combustion" (green)
indicators will light up.
A preset time will be displayed on the digital monitor.
(The first time the ON Timer is preset, this time will
be "8.0")
The ON Timer can be selected while the unit is in operation, or while it is off (if set during operation,
pressing the ON Timer button will stop the unit heating and the ON/Combustion indicator will change
from red to green). The appliance will remain in standby mode.
2 Presetting the time
Pressing the " " or " " buttons alters the preset time.
After 10 seconds the digital monitor will go out.
If the display has gone out:
Pressing the " " or " " buttons once will show the
remaining time on the digital monitor.
Pressing the button more than once will alter the preset time.
3 The heater will operate after reaching the end of the preset time.
"ON/Combustion" lndicator glows red.
The heater will operate at the preset temperature selected in the system memory.
The heater will automatically operate at 80°F if the preset temperature is set to "H".
4 The heater stops automatically after 1 hour.
The "ON Timer" indicator wilI flash to indicate that heating is about to stop (at approximately 55 minutes).
After another 5 minutes the heater will automatically stop heating and turn off completely.
The "ON Timer" indicator will continue to flash until the heater is manually operated again. The
"ON/Combustion" indicator will go out.
Pressing the ON-OFF button will turn off the ON Timer indicator.
TO CANCEL THE ON TIMER
Press the "ON Timer" button or press the "ON-OFF" button.
The setting will be cancelled and the timer indicators will go out.
The ON Timer will be cancelled if the power plug is disconnected, a power failure occurs while
the appliance was in standby mode, or if the ON Timer setting is cancelled. "00" will flash on the digital
monitor when power is reinstated. Pressing the ON button and starting the unit will delete the "00".
- 15 -

 Air purifier with Plasmacluster Ion Operation
1 Press Air Purifier with Ion button.
· When "H" is selected, the unit will
continually clean air at the air at the
highest fan speed. During this operation,
the same number of positive and negative
ions are discharged.
(Plasmacluster light is Blue during this
operation.)
2 Press Air Purifier with Ion button.
· When "M" is selected, the unit will
continually clean air at the air at the
medium fan speed. During this operation,
the same number of positive and negative
ions are discharged.
(Plasmacluster light is Blue during this
operation.)
3 Press Air Purifier with Ion button.
· When "L" is selected, the unit will
continually clean air at the air at the
lower fan speed. During this operation,
the same number of positive and negative
ions are discharged.
(Plasmacluster light is Blue during this
operation.)
 Air purifier with Minus Ion Operation
4 Press Air Purifier with Ion button.
· When "Minus Ion" is selected, the unit
will maintain an ion balance at the
lower fan speed. Ion balance is achieved
by increasing the ratio of negative ions.
(Plasmacluster light is Green during this
operation.)
5 By pressing the Ion Operation Button the operation mode will change.
Notice · When you use Plasmacluster Ion or Minus Ion,Air purifier operates together with Plasmacluster Ion
or Minus Ion.
· When you use this appliance for the first time,you must remove plastic bag of Air purifier filter.
· Air purifier with ion will begin to blow from top of appliance.
· Do not obstruct the Air purifier and Plasmacluster Ion air inlet or outlet. Obstruction may result in
unit malfunction.
- 16 -
GREEN light indicates
plasmacluster is in
"Minus Ion" mode
Blue light indicates
plasmacluster ion
operation is ON
Blue light indicates
plasmacluster ion
operation is ON
Blue light indicates
plasmacluster ion
operation is ON
OFF
Air Purifier with Minus Ion
Air Purifier with Plasmacluster Ions:HIGH
Air Purifier with Plasmacluster Ions:MID
Air Purifier with Plasmacluster Ions:LOW

MAINTENANCE SUGGESTIONS
This heater has been designed and constructed for a long performance life when installed and
operated properly under normal conditions. Regular inspections, as outlined in this section, are
strongly recommended as means of keeping your heater operating efficiently and throughout the season.
Access to internal parts is from the front of the heater.
 Cleaning (HEPA Filter)
1. Remove the HEPA Filter Screen
1) Remove the screw.
2) Remove the HEPA Filter Screen.
2. Clean the HEPA Filter Screen
· Clean the HEPA Filter Screen with a vacuum cleaner.
· If the HEPA Filter Screen is so dirty, wash it.
3. Remove the HEPA Filter
4. Clean the HEPA Filter
· Clean the HEPA Filter (white area) with a
vacuum cleaner.
Notice: Do not wash a HEPA Filter.
- 17 -
MAINTENANCE / SERVICE
SCREW 1
OPEN
2 PULL
HEPA FILTER SCREEN
WHITE SIDE
HEPA FILTER

5. Install the HEPA Filter in the HEPA Filter Screen
· Install the HEPA Filter as illustrated beside.
An arrow indicates position of filter installation.
6. Install the HEPA Filter Screen into the appliance
1) Cover the HEPA Filter with the HEPA Filter Screen
using the top and bottom left tab as locators.
2) Apply the screw.
HEPA Filter Replacement Indicator
When the air purifier with Ion has operated for
4000 hours, "Change HEPA Filter" will illuminate to
let you know that the HEPA Filter needs to be
replaced.
To reset the HEPA Filter Button
· Press “HEPA Filter Reset” button for 3
sec after replacing the HEPA filter by
using sharp object.
· Be careful not to damage the surface.
Note: DO NOT press the “HEPA Filter Reset”
Button except after replacing with a new
HEPA filter.
Note: If the consumer has trouble finding
the replacement HEPA filters at the
dealer where they bought the unit,
they could contact us directly at
our web site. ( www.rinnai.us )
- 18 -
1
2
3
TAB
HOLE
BLACK SIDE
MOUNTING
HEPA FILTER SCREEN
