Proctor PCW-107R User manual

1.3 Megapixel
Compact IP
Dome Camera
User’s Manual
Ver1.4

1
Table of Contents
1. Software Version........................................................................................................3
2. Introduction.................................................................................................................4
2.1 Features.............................................................................................................4
2.2 Package Contents..............................................................................................5
2.3 Camera Overview..............................................................................................5
3. Preparations for IP Camera Setup ............................................................................7
3.1 System Requirements........................................................................................7
3.2 Ethernet Connection ..........................................................................................7
4. Accessing Camera.....................................................................................................9
5. Configuration & Operation.......................................................................................16
5.1 Browser-based Viewer Introduction .................................................................16
5.2 Home Page......................................................................................................18
5.3 System Related Settings..................................................................................19
5.3.1 Host Name and System Time Setting................................................20
5.3.2 Security..............................................................................................21
5.3.3 Network .............................................................................................23
5.3.4 DDNS ................................................................................................26
5.3.5 Mail ....................................................................................................27
5.3.6 FTP....................................................................................................28
5.3.7 Motion Detection................................................................................29
5.3.8 Snapshot...........................................................................................31
5.3.9 Iris Adjustment (Box Camera and Vandal Proof Dome).....................32
5.3.10 View Log File.....................................................................................33
5.3.11 View User Information .......................................................................34
5.3.12 View Parameters...............................................................................36
5.3.13 Factory Default ..................................................................................37
5.3.14 Software Version ...............................................................................38
5.3.15 Software Upgrade..............................................................................39
5.4 Video and Audio Streaming Settings...............................................................42
5.4.1 Video Resolution and Rotate Type ....................................................42
5.4.2 Video Compression ...........................................................................44
5.4.3 Video OCX Protocol...........................................................................45
5.4.4 Video Frame Skip ..............................................................................46
5.4.5 Privacy Masking Function..................................................................47
5.4.6 Audio Setting .....................................................................................49
5.5 Camera Settings ..............................................................................................50
5.5.1 Exposure Setting ...............................................................................50
5.5.2 White Balance Setting .......................................................................51

2
5.5.3 Backlight Setting................................................................................52
5.5.4 Brightness Setting..............................................................................52
5.5.5 Sharpness Setting .............................................................................53
5.5.6 Contrast Setting.................................................................................53
5.5.7 Digital Zoom Setting ..........................................................................53
5.6 Logout..............................................................................................................54
6. CMS Software Introduction......................................................................................55
Appendix A: Technical Specifications...........................................................................56
Appendix B: Internet Security Settings .........................................................................58
Appendix C: DC Viewer Download Procedure ..............................................................61

3
1. Software Version
The Compact IP Dome Camera’s current software version is as follows:
Time Released Version
Oct., 2012 p20091016PS

4
2. Introduction
The 1.3 Megapixel Compact IP Dome Camera features a 1/3.8” Sony
Progressive CMOS Sensor and generates excellent image quality. Having
excellent high definition image quality in low-light conditions, this camera could
identify the individuals and objects of interest easily.
With Power over Ethernet (IEEE 802.3af) feature, the need of power outlets
could be totally eliminated; likewise installation and cabling cost would be
significantly reduced.
The IP Dome Camera’s flat and sophisticated design enhances more
application possibilities, such as indoor/outdoor and mobile surveillance.
Additionally, its light weight and compact size offer quick and simple installation
on the ceilings or walls of houses and vehicles.
2.1 Features
•1/3.8” 1.3M progressive CMOS
•Simultaneous MPEG-4 and MJPEG video stream (dual stream)
•Resolution: MPEG-4 VGA,QVGA,CIF,QCIF
MJPEG 1280 x 960(4 VGA), VGA, QVGA, CIF, QCIF
•Frame Rate: MPEG-4 30fps@VGA; MJPEG 15fps@1280 x 960
•Image Setting:
Rotation: Flip, Mirror, and 180 Rotate∘
Brightness, Sharpness, Contrast, White Balance, Exposure Control
Digital Zoom: x1 ~ x12
•Audio Compression: G.711 PCM 64 kbit/s
G.726 ADPCM 32 or 24 kbit/s
•Shutter Speed: 1.5~1/15000 sec
•Interface: 10/100 Ethernet
•Compact Size Dome Cover and Housing
•Power over Ethernet

5
2.2 Package Contents
Please check the package contains the following items listed below.
Security Torx
Indoor Camera/
Rugged Camera (with Cable )
Quick GuideCD
2.3 Camera Overview
Designation Description
1Reset Button Restore to default setting; press the
button with a proper tool
2Lens Rotate the lens right/left to adjust focus
3Focus Fixed Screw Loosen the screw to adjust the lens
4Tilt Fixed Screw Loosen the screw to adjust tilt angle

6
Dimensions

7
3. Preparations for IP Camera Setup
This chapter outlines information about system requirements for IP Dome
Camera operation, power and Ethernet connection for Indoor/Outdoor IP Dome
Camera, and access to the camera.
3.1 System Requirements
To perform the IP Dome Camera via web browser, please ensure your PC is in
good network connection, and meet system requirements as described below.
Items Minimum Requirement
Personal Computer
1. Intel Pentium IV, 3GHz or higher, Intel Core2 Duo, 2
GHz or higher
2. 1 GB RAM or more
3. AGP graphics card 64 MB RAM, Direct Draw
Operating System Windows VISTA or Windows XP
Web Browser Microsoft Internet Explorer 6.0 or later
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE
3.2 Ethernet Connection
Please follow the instructions below to connect Indoor/Rugged IP Dome
Camera’s Ethernet cable.
Indoor Camera
PoE Connection
Connect the one end of the PoE cable to the Ethernet port on the camera,
and the other end to Power Sourcing Equipment (PSE) like hubs or routers.

8
Check the status of the link indicator and activity indicator LEDs; if the LEDs
are unlit, please check the connections.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
Rugged Camera
M12 D-Coded Connector PoE Waterproof Switch
M12 D-Coded Connection
For the Rugged IP Dome Camera, connect its Ethernet cable to a M12
waterproof switch as shown above.
NOTE: Please use a PoE waterproof switch/hub so that the camera
can work.
M12 D-Coded Connector’s Pin Definition
Pin 1: Rx＋
Pin 2: Tx＋
Pin 3: Rx－
Pin 4: Tx－

9
4. Accessing Camera
For initial access to the IP Dome Camera, users can search the camera through
the installer program: DeviceSearch.exe, which can be found in “DeviceSearch”
folder in the supplied CD.
Device Search Software Setup
Step 1: Double click on the program Device Search.exe (see the icon below);
its window will appear as shown below. Then click the “Device Search”
button.
Step 2: The security alert window will pop up. Click “Unblock” to continue.
