PROEL CS602WIFI User manual

CS602WIFI
Ceiling Wireless Speakers
USER’S MANUAL
MANUALE D’USO
ENGLISH
ITALIANO

33
IMPORTANT SAFETY INSTRUCTIONS
Watch for these symbols:
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the appliance.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power
supply adapter is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Warning: to reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
16. Do not expose this equipment to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on the
equipment.
17. To completely disconnect this apparatus from the ac mains, disconnect the power supply adapter from the ac receptacle.
18. The mains plug of the power supply cord shall remain readily operable.
19. This apparatus contains potentially lethal voltages. To prevent electric shock or hazard, do not remove the chassis, input module or ac
input covers. No user serviceable parts inside. Refer servicing to qualified service personnel.
20. This owner’s manual should be considered as a part of the product, it must accompany it at all times, and it needs to be delivered to the

4
new user when this product is sold. In this way the new owner will be aware of all the installation, operating and safety instructions.
21. This apparatus should only be connected to a power source of type specified in this owner’s manual or on the unit.
22. You can clean the exterior of the unit with compressed air or with a dry cloth.
23. Don’t clean the unit using solvents like trichloroethylene, thinners, alcohol, or other volatile or flammable fluids.
24. To reduce the risk, close supervision is necessary when the product is used near children.
DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the
end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government office, for
details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check
the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.
DECLARATION OF CONFORMITY
The product is in compliance with the following European Directives:
EMC 2014/30/EU, RED 2014/53/EU, LVD 2014/35/EU, RoHS 2011/65/EU and 2015/863/EU, WEEE 2012/19/EU.
CONDITIONS OF USE
Proel do not accept any liability for damage caused to third parties due to improper installation, use of non-original spare parts, lack of
maintenance, tampering or improper use of this product, including disregard of ascertainable and applicable safety standards. Proel strongly
recommends that this apparatus must be installed taking into consideration all current National, Federal, State and Local regulations. The
product must be installed by qualified personal. Please contact the manufacturer for further information.
PACKAGING, SHIPPING AND COMPLAINT
This unit package has been submitted to ISTA 1A integrity tests. We suggest you control the unit conditions immediately after unpacking it.
If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspection.
Proel is not responsible for any damage that occurs during shipment.
Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
Possible damages to unit should be immediately notified to forwarder. Each complaint for manumitted package should be done within eight
days from product receipt.
WARRANTY AND PRODUCTS RETURN
Proel products have operating warranty and comply their specifications, as stated by manufacturer.
Proel warrants all materials, workmanship and proper operation of this product for a period of two years from the original date of purchase.
If any defects are found in the materials or workmanship or if the product fails to function properly during the applicable warranty period,
the owner should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect
detailed description. This warranty does not extend to damage resulting from improper installation, misuse, neglect or abuse. Proel S.p.A.
will verify damage on returned units, and when the unit has been properly used and warranty is still valid, then the unit will be replaced or
repaired. Proel S.p.A. is not responsible for any "direct damage" or "indirect damage" caused by product defectiveness.

55
Index
1. Introduction..............................................................................................................................................................6
2. What's in the Box .....................................................................................................................................................6
3. Main Features ..........................................................................................................................................................7
4. Specification .............................................................................................................................................................8
5. Interface ................................................................................................................................................................... 9
6. Installation..............................................................................................................................................................10
7. How to Use.............................................................................................................................................................11
7.1 APP Download ...................................................................................................................................................11
7.2 Connecon ........................................................................................................................................................12
7.2.1 First me usage & BLE WiFi Setup.................................................................................................................12
7.2.2 First me usage, WIRED NETWORK Setup ...................................................................................................14
7.2.3 Bluetooth ......................................................................................................................................................14
7.3 App Features......................................................................................................................................................15
7.3.1 Device seng................................................................................................................................................ 15
7.3.2 To play local storage music............................................................................................................................15
7.3.3 To play music from a NAS home server using DLNA......................................................................................16
7.3.4 To use Line in Mode ......................................................................................................................................16
7.3.5 To use Bluetooth Mode.................................................................................................................................17
7.4 Streaming Services............................................................................................................................................17
7.4.1 Spofy ........................................................................................................................................................... 18
7.4.2 AirPlay ...........................................................................................................................................................18
7.4.3 Tidal...............................................................................................................................................................19
7.5 Mulroom and Mulzone..................................................................................................................................19
7.5.1 Add / Remove Device to Mulroom..............................................................................................................20
7.6 Le and Right channel assignment....................................................................................................................20
7.7 Preset.................................................................................................................................................................21
7.8 Source mode Change ........................................................................................................................................21
7.9 Restore Factory Seng......................................................................................................................................21
7.10 Firmware Update.............................................................................................................................................22
8. Play on PC...............................................................................................................................................................22
8.1 To Play Music From iTunes on Mac and Windows PC........................................................................................22
8.2 To Play Music From Windows PC via Foobar2000 .............................................................................................23
9. Web Interface.........................................................................................................................................................25
9.1 Playback Interface..............................................................................................................................................25
9.2 Web Interface Menu .........................................................................................................................................26
9.3 Audio Sengs....................................................................................................................................................27
9.4 Sengs Menu....................................................................................................................................................27

6
CS602WIFI is a stereo system consisng of two premium 2-way 6.5” ceiling speakers, one acve and one passive.
The acve unit features a double 50+15W amplier with integrated DSP able to power both speakers in stereo or
mono conguraon. Thanks to the WiFi and Bluetooth interface, you can stream high quality music from your smart
device, NAS or streaming services such as Spofy, Tidal, Deezer, Qobuz, Amazon Music and others by 4Stream APP,
Airplay, Bluetooth or other DLNA apps. By adding mulple CS602WIFI to your network you can setup a wireless
mulroom whole audio system for house, oce, restaurant, bar, it will give you totally new and great experience to
play and enjoy music.
Acve loudspeaker (MAIN)
Acve Speaker x1
Passive Speaker x1
Power Adapter x1
and power cord
with appropriate
regular plug
Phoenix connector x1
User Manual x1 Screw Driver x1 Phoenix connector x1
Passive loudspeaker (SLAVE)
1. Introduction
2. What's in the Box

77
3. Main Features
• 6.5” Kevlar low frequency driver with rubber suspension.
• 1” pivong aluminum dome tweeter with EOS waveguide design.
• LF amplier 50W @4ohm x2, HF amplier 15W @8ohm x2.
• Streaming music via ETHERNET network (WIFI and WIRED) with no distance limitaon or thru
BLUETOOTH 5.0 up to 15 meters.
• High quality music streaming with sample rate decoding up to 192kHz, 24bit.
• Supports streaming source from online services, smart device memory, NAS, BLUETOOTH and
line in.
• Spofy, Airplay, Qplay, DLNA, UPnP streaming protocols supported, 3rd party app compable.
• Mulroom and mulzone streaming enabled by mulple units connected in the same network.
• Free iOS and Android app available with global online update for new features.
• Spofy, Deezer, Tidal, Qobuz, iHeartRadio, TuneIn, Napster online streaming services integrated
to use in the app.
• PC streaming from iTunes.
• Analogue input for connecng external audio devices.
• EQ adjustment via app.
• Preset playlist available for quick access.

8
4. Specification
MAIN SPEAKER
Connections
Power Supply 21-24V / 4A
Audio Input AUX (mini-jack 3.5mm) Max 1V RMS input
Bluetooth 5.0 AAC FLAC
Audio Output Speaker out
Network WiFi 2.4G
LAN RJ45
Stereo / Mono Switch Stereo: Master speaker output Right channel, Slave speaker output Le channel
Mono: Le + Right Channel for both speakers
Mode Button Short press to switch input mode, Press twice to reset WiFi/BT, Press 3 mes to
restore factory sengs, Long press to standby, press again to wake up
Speaker
Bass 6.5” kevlar bass driver with rubber suspension
Tweeter 1” pivong aluminum dome tweeter EOS waveguide design
Sensitivity Bass: 86±3dB / Tweeter:89±3dB
Size Ø 23 cm x 10.5 cm (depth)
Amplier
Power LF 4Ω 50W *2 (Master + Slave)
HF 8Ω 15W *2 (Master + Slave)
Frequency Response LF: 60Hz-2500Hz
HF: 2500Hz-20000Hz
Signal Noise Ratio ≥85dB
THD+N <0.9%
Crosstalk >55dB
SLAVE SPEAKER
Connections
Audio Input Connect to Speaker Out of MAIN SPEAKER
Speaker
Bass 6.5” kevlar bass driver with rubber suspension
Tweeter 1” pivong aluminum dome tweeter EOS waveguide design
Sensitivity Bass: 86±3dB / Tweeter:89±3dB
Size Ø 23 cm x 10.5 cm (depth)

99
5. Interface
Main acve Loudspeaker:
Passive Slave Loudspeaker:
1. Aux in: Connecon to external audio source.
2. Mode buon:
SHORT PRESS: to switch input source.
SHORT PRESS TWICE: to reset WiFi/BT connecon.
SHORT PRESS THREE TIMES: to do factory reset.
LONG PRESS: to turn o the device, press again to turn on.
3. Stereo/Mono Switch: in MONO acve and passive speakers reproduce both LEFT and RIGHT channels, in STEREO acve speaker is
the RIGHT channel and the passive speaker is the LEFT channel.
4. DC in: for connecng the supplied power adapter.
5. Speaker connecon: Phoenix connector to connect slave speaker.
6. LAN: port for wired ethernet connecon.
1. Speaker connecon: phoenix connector to connect master speaker
AUX in
1
5
1
6
2 3 4
Mode
Stereo/Mono 24V DC IN

10
6. Installation
Tools needed for installaon
Quick installaon guide
STEP 1 STEP 2
Speaker wire
●Pencil
●Drill
●Tape Measure
●Ask yourself where is the best place to install the loudspeakers
in order to obtain the most uniform diusion in the area to be
sounded.
●Separate the speakers at least 2-3 meters apart.
●If you intend to re-paint the grilles it is best to do this prior to
installaon using an appropriate paint which will not block the
cracks.
We recommend to test the connecons and the sengs before
the actual installaon, as it is not very praccal to have to press
the mode buon or change the MONO/STEREO switch once the
speakers are inserted in their nal posion into a ceiling or a
wall.
Once the tests have been completed, it is possible to proceed
with the denive installaon, which is best not too far from
the place of the tests to ensure that WIFI and BT maintain the
connecons.
Using the included template, trace with the marker the shape
onto the panel to be carved. Using a drywall saw cut the hole
in the panel. Aenon: this is the most important part of the
whole installaon, because you must be sure that there are
no obstrucons behind the desired mounng area (you can
check with small holes and a pencil if the necessary space is
present). Use a piece of sandpaper to smooth the edges to get
a smoother outline. (See Diagram 1 and Diagram 2). Pass the
cables necessary for the installaon, leaving about half a meter
more to facilitate the connecon to the loudspeaker.
Diagram 1:
Cut-out tracing
Diagram 2:
Cut Out
To determine the length and gauge of speaker wire, you will
need:
●Measure the distance.
●Always consider a few meters more.
●Sound quality deteriorates when too thin a cable is used
over a long distance.
18AWG 1mm2- minimum for distances up to ............... 3 m
16AWG 1.5mm2 - from ........................................ 3 to 15 m
14AWG 2mm2- from .. ...................................... 15 to 30 m
● Wire cuer
●Philips-head
screwdriver
●Sandpaper
● Ulity knife
●Safety eye-wear
●Gloves

1111
Download the 4 Stream applicaon from App Store for iOS based devices and Google Play Store for Android based devices.
The applicaon supports English, Spanish, French, German, Italian, Portuguese, Korean, Simplied Chinese, Tradional Chinese and
Japanese.
4STREAM
7.1 APP Download
7. How to Use
STEP 3 STEP 4
The ceiling speakers come from the factory with the tweeter
facing straight out from the bae. This will result in the overall
smoothest response. However, you can adjust the tweeter to
focus the sound at your listening locaon. In order to do this,
remove the grill and gently press on tweeter plasc border (see
Diagram 3). Cauon: do not touch the tweeter dome while
adjusng it (see Diagram 3).
Retract the dog-ear brackets by turning slowly clockwise the
four screws accessible from the speaker’s front bae, using a
Phillips head screwdriver.
Connect all the wires and insert the speaker into the hole in
the panel. Then, keeping the speaker in posion, turn the four
levers on the front of the speaker one by one in the direcon
of the arrow. The quick-turn mounng system and frame will
"sandwich" or clamp around the panel to hold the speaker
securely in place (see Diagram 4).
Reposion the grille.
Diagram 3:
Adjust the tweeter here
Tweeter
Diagram 4:
Mounng Dog Ear
Dog Ear
Closed
Closed
Loose
Loose

12
7.2 Connection
7.2.1 First time usage & BLE WiFi Setup
1) Make sure your mobile phone or tablet is connected to your WIFI network using 2.4G
and your GPS and BLUETOOTH is on.
2) Download the 4Stream APP from Google Play Store or Apple App Store.
3) Move the CS602WIFI device in the WIFI range of the router. In places with many WIFI
networks we suggest to get close to the router of your network for the rst conguraon.
4) Plug in the power cable.
5) The LED light will start ashing quickly, if it is not a white LED, press the MODE buon
to change mode ll the LED will be white and ashing quickly.
6) Place your mobile phone at a distance of less than 15m (BLUETOOTH range) from the
CS602WIFI device, then open 4STREAM APP.
Note: only for Android device, the system will ask for permission to use GPS data & File
storage, please click accept to connue. This GPS permission is setup by Google for
BLE usage, once setup is nish you can go to system sengs and disable it, le storage
permission is to let 4Stream access your mp3 les store in your mobile.
7) Press "Add Device" buon, wait ll the indicator of the CS602WIFI is blinking slowly,
then press "indicator is blinking".
8) The 4STREAM APP will list out all the CS602WIFI_XXXX devices available for setup,
choose one.
9) The 4STREAM APP will then ask you to choose the network you want the device to be
connected to: choose the one you want to connect.
10) Now type password for your network. Press "Next" buon.

1313
11) Then you can change the name of the device. You can select a preset one or enter your
own.
12) Aer you dene the name of the device, you will see it appear in the device list in
4stream app and now you can start streaming music.
SOME TIPS:
* To carry out the WIFI inializaon procedure, the BLUETOOTH on the mobile device must
be acve.
* If you change the WIFI network, the procedure must be repeated.
* If the router or the password of the connected router has been changed, the procedure
must be repeated. Press MODE buon for 5 secs in WiFi mode to shut o, then press
MODE again to reset the connecon.
* If you have setup router connecon before, the device will auto connect to that router.
1) Plug in the power cable while pressing the MODE buon.
2) The LED light will start ashing, release the buon and wait ll the LED ashes slowly.
3) Go to your mobile WIFI sengs and search for CS602WIFI_XXXX WiFi and connect.
4) Open 4STREAM APP and you should see the CS602WIFI_XXXX list in the device list.
*Your mobile might ask if you want to stay using this WIFI connecon, click yes.
6) Click on the “+” icon on the top right corner to add device. The app will prompt you to
select the router SSID you want your device to connect to: enter password, if required, and
select connue.
7) Once connected, you can change the name of the device. You can select a preset one or
enter your own.
8) Aer you dene the name of the device, you will see it appears in the device list in
4STREAM app and now you can start streaming music.
There is another way to setup the CS602WIFI
* Aenon for Android users: dierent brand mobile phones may ask you to allow to
use CS602WIFI_XXXX WiFi network. Please choose yes, if not, you may not able to set up
successfully. It may also ask you to authorize other things, please choose yes or it may
aect your use.

14
7.2.2 First time usage, WIRED NETWORK Setup
1) Make sure your mobile phone or tablet is connected to your WIFI network using 2.4G.
2) Download the 4STREAM APP from Google Play Store or Apple App Store.
3) Plug in the wired cable to the RJ45 Ethernet. Note: the mobile device and the STRWIFI must be in the same network.
4) Plug in the power cable.
5) The LED light will start ashing quickly, then it will ash slowly and nally will stay on.
6) Open 4STREAM APP.
7) You will see the device appear in the applicaon's device list: now you can start streaming music.
SOME TIPS:
* WIRED connecon and WIFI connecon can coexist but WIRED connecon has priority over WIFI, so if you want to congure both
connecons leave the cable unconnected and congure CS602WIFI for WiFi connecon as specied in the previous paragraph, then
connect the WIRED network.
7.2.3 Bluethooth
To use Bluetooth, please switch to bluetooth via app or by remote controller, then nd bluetooth device CS602WIFI_XXXX from your
phone bluetooth seng and pair it .

1515
7.3 App Features
7.3.1 Device setting
7.3.2 To play local storage music
In the applicaon, choose “Browse” on boom, then scroll on “My
library” “My Music” and choose the songs you want to play from your
Phone, Tablet or USB Disk.
Rename: changes the device name.
Speaker info: displays device informaon like IP
address, Mac address, SSID, rmware version,
factory reset, etc.
Alarm Clock: setups up to 4 dierent alarm clocks with music of your
choice.
Preset Content: 10 Preset content buons.
Sleep Timer: countdown to turn o the device.
EQ: Bass and Treble control.

16
7.3.3 To play music from a NAS home server using DLNA
In the applicaon choose "Browse" on boom, then scroll on "My library" "My Music" "Home Music Share", then choose the
server available on your network, nally choose the songs you want to play. Please note that our system only support NAS with DLNA
feature.
Some notes about the playlist:
• You can make playlists from the music contained in the library of your phone, tablet or DLNA servers.
• The Playlists are stored in the app for phone or tablet you currently use to make them.
• We suggest you to create your playlists with song from the same source, phone, tablet, DLNA server, because if the source device is
acve all the songs contained in this device will be in the playlist, while if a source device is not acve all the playlists that contain
songs from that device would be corrupted.
7.3.4 To use Line in Mode
Connect the AUX in to the TV or other audio source.
Choose Line In mode in the applicaon or using MODE buon: the LED will
change to green.
Play audio from the connected source.

1717
7.4 Streaming Services
To use the online streaming services iHeartRadio, Spofy, Tidal, Qobuz and Deezer you may need to register an account at the service
provider plaorm.
With “Manage Music Services” you can show or hide the services from the list.
7.3.5 To use Bluetooth Mode
Choose the BLUETOOTH mode in the applicaon or using RESET buon: the LED
will change to blue.
Open the BLUETOOTH menu in your mobile device and pair it to the CS602WIFI
(see 7.2.3).
Play audio from your mobile device.

18
The CS602WIFI supports AirPlay. From the iOS device you can choose the AirPlay "CS602WIFI_XXXX" to listen your music.
7.4.2 AirPlay
To use Spofy directly you must own a Spofy premium account, you can also play via Airplay or Bluetooth.
You will nd the CS602WIFI_XXXX in the device list on the Spofy applicaon and choose the device you want to play.
* Note: one Spofy account can only stream to one device at a me.
7.4.1 Spotify

1919
Users can group mulple rooms and zones on the applicaon. For example, you can group devices 1, 2 and 3 to play the same music
in sync, or group device 1 as zone A and devices 2 and 3 as zone B, and play dierent music in zones A and B.
7.5 Multiroom and Multizone
1. Connect your device to your wi network
2. Open up the Tidal app on your phone, tablet using the same
wi network
3. Select a song and select Devices Available.
4. Select your device and start listening.
7.4.3 Tidal
1Zone A
Zone B
2
3

20
In order to add a device to mulroom funcon, click on the mark of the device you want to be the master device.
A list of available devices will pop out and you can select the device you want to add as slave device. Click the DONE buon when
nished.
The grey ck icon represents the master device and green ck icon represent the slave device.
To remove a device from mulroom funcon, click on the mark again to bring up the device list and unselect any slave device
you want to remove. Then click on the DONE buon to conrm.
If all the slave device are removed, mulroom funcon will be disabled.
7.5.1 Add / Remove Device to Multiroom
Users can choose the right channel or le channel or stereo mode on the applicaon, or choose le channel on device A and choose
right channel on device B, and group them together and play in sync to make stereo.
7.6 Left and Right channel assignment
