Projecta INTELLI-CHARGE IC25 User manual

INTELLI-CHARGE
7 STAGE SWITCHMODE
BATTERY CHARGER
P/No.s IC25, IC25W, IC25RV, IC35, IC50, IC8-24

2
IMPORTANT SAFETY INFORMATION
Please read this manual thoroughly before use and store in a safe place for future reference.
WARNING
• Explosive gases may escape from the battery during charging. Prevent flames and
sparks. Provide adequate ventilation.
• Before charging, read the instructions.
• For indoor use. Do not expose to rain.
• For charging lead acid and lithium batteries ONLY (for the size and voltage specified in
the specifications table).
• Disconnect the 240V mains supply before making or breaking the connections
to the battery.
• The battery charger must be plugged into an earthed socket-outlet.
• Connection to supply mains is to be in accordance with National wiring rules.
• Do not attempt to charge non-rechargeable batteries.
• Never charge a frozen battery.
• If the AC cord is damaged do not attempt to use. It must be replaced or repaired by
a qualified person.
• Corrosive substances may escape from the battery during charging and damage delicate
surfaces. Store and charge in a suitable area.
• Ensure all vehicle accessories including lights, heaters, appliances etc are turned off
prior to charging.
• This charger is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Battery chargers for charging automobile batteries:
– the battery terminal not connected to the chassis has to be connected first. The other
connection is to be made to the chassis, remote from the battery and fuel line. The
battery charger is then to be connected to the supply mains
– after charging, disconnect the battery charger from the supply mains. Then remove the
chassis connection and then the battery connection.

3
7-STAGE AUTOMATIC CHARGING
(GEL, AGM, WET & Calcium)
Intelli-Charge incorporates the latest technology to deliver a 7-stage charge suitable for
automotive, calcium, marine and all types of deep cycle batteries (Gel and AGM). These
stages of charging ensure maximum battery life and performance are delivered with a
faster charging time and ensure a complete charge is achieved.
The 7 charge stages are:
Desulphation; Soft Start; Bulk; Absorption; Analysis; Recondition and Float.
1. DESULPHATION
Rejuvenates sulphated
batteries with a high
frequency pulse.
2. SOFT START
Increases battery life
by gently starting to
charge the battery.
3. BULK CHARGE
Reduces charging
time by delivering
maximum charge to
set voltage.
4. ABSORPTION
Ensures a full
charge to the
battery without
overcharging.
EQUALISATION
(Calcium mode only)
Returns a full
hydrometer reading
to calcium batteries
by removing acid
stratification.
5. ANALYSIS
Tests the battery to
ensure fully charged.
6. RECONDITION
Restores battery
health to deeply
discharged batteries
by equalising
the cells.
7. FLOAT
Float charge
maintains the
battery at 100%
charge.
VOLTAGE
CURRENT
(AMPS)
DESULPHATION
The Desulphation stage is designed to break down sulphation occurring in batteries
that have been left flat for extended periods of time, returning them back to full charge.
Sulphation occurs when lead-sulphate hardens and clogs up the battery cells.
SOFT START
This is a preliminary charge process that gently introduces power to the battery,
protecting the battery and increasing battery life.
BULK (CONSTANT CURRENT)
The Bulk stage reduces charging time by charging the battery at the maximum rate (constant
current) to a set voltage, at which point the battery is approximately 80% charged.
ABSORPTION (CONSTANT VOLTAGE)
The absorption stage charges the battery to 100% by adjusting the charge rate allowing
the battery to absorb more power.
EQUALISATION (CALCIUM MODE ONLY)
Designed especially for calcium batteries, this stage returns calcium batteries to full
service by removing acid stratification of the electrolyte.
ANALYSIS
The analysis mode tests the battery to ensure that it has taken the charge; if the
battery passes the test the charger will proceed to the float stage, but if the battery
fails the test, the charger will apply a recondition charge to try to return the battery
to full charge.

4
RECONDITION
If after charging, the battery is unable to hold the charge the battery reconditioning
function is initiated automatically. This is most likely to take place on batteries that
have been deeply discharged, prior to charging. The Recondition mode will then run
for 4 hours and at the end will retest the battery. The Intelli-Charge battery charger
will perform the recondition charge up to 3 times before switching the charging cycle
to Float with an error indication.
FLOAT
The Float stage maintains the battery at 100% charge without overcharging or
damaging the battery. This means the charger can be left connected to the battery
indefinitely.
5-STAGE LITHIUM AUTOMATIC CHARGING
When the Lithium Profile is selected, Intelli-Charge utilises a very specific and tailored
5 stage charging algorithm, engineered to get the best out of today’s Lithium (LiFePO4)
batteries. From the smallest 1 Amp unit up to the largest 50 Amp offering, world class
electronics guarantee the battery receives the ultimate charge to ensure maximum life
and performance over the life of the battery.
The 5 lithium charge stages are:
Soft Start 1; Soft Start 2; Bulk Charge; Absorption and Float.
VOLTAGE
CURRENT
(AMPS)
STAGE 1 2 4 53
SOFT START 1
Increases battery life
by gently starting to
charge the battery 5%
of bulk
SOFT START 2
Increases battery life
by gently starting to
charge the battery
25% of bulk
BULK CHARGE
Reduces charging
time by delivering
maximum charge to
set voltage
ABSORPTION
Ensures a full charge
to the battery
without overcharging
FLOAT
Float charge
maintains the battery
at 100% charge
Soft Start 1
Increases battery life by gently starting to charge the battery 5% of bulk.
Soft Start 2
Increases battery life by gently starting to charge the battery 25% of bulk.
Bulk Charge
Reduces charging time by delivering maximum charge to set voltage.
Absorption
Ensures a full charge to the battery without overcharging.
Float
Float charge maintains the battery at 100% charge.

5
BATTERY CHEMISTRY SELECTION
The Multi-Chem function allows you to set the charging profile to suit each battery’s
chemistry type (Lithium, GEL, AGM, WET and Calcium). This ensures correct and
thorough charging and maximises battery performance and battery life. The following
section describes the charge profiles for each chemistry type.
POWER SUPPLY (CONSTANT VOLTAGE OF 13.8 VOLTS)
This sets the charger in power supply mode giving a constant voltage of 13.8VDC.
This mode is best used where appliances are drawing power from the battery, for
example a Fridge.
LITHIUM (MAX VOLTAGE OF 14.2 VOLTS)
Charger will use a lithium-specific 5 stage charging algorithm.
GEL (MAX VOLTAGE OF 14.1 VOLTS)
This charge mode is designed for GEL batteries and has a maximum charge voltage
of 14.1V. Note that some GEL batteries require a higher charge voltage such as 14.4V.
The AGM mode can be used if this is required.
AGM (MAX VOLTAGE OF 14.4 VOLTS)
This charge mode is designed for AGM batteries and has a maximum charge voltage
of 14.4V.
WET (BULK AND ABSORPTION 14.7 VOLTS, RECONDITION UP TO 16 VOLTS)
This charge mode is designed for WET batteries and has a maximum charge voltage
of 14.7V during Bulk and Absorption stages and 16.0V during the Recondition stage.
CALCIUM (BULK AND ABSORPTION 14.7 VOLTS, EQUALISATION AND
RECONDITION UP TO 16 VOLTS)
This charge mode is best suited for Calcium batteries that have been deeply discharged
and require an equalisation charge to restore a full electrolyte reading. If the battery
requires a simple ‘top-up’, the WET charge mode can be used.

66
FEATURES
ADJUSTABLE CHARGE RATE
The charger’s output can be adjusted to suit the size of the battery for optimum
charging.
REMOTE CONTROL DISPLAY*
Control and monitor the charger’s performance from a remote control display, allowing
the charger to be flush or surface mounted out of the way and out of sight. The battery
charger and remote are synchronised for operation either locally or by remote.
RUBBER END CAPS (IC25W ONLY)
Protective rubber moulded end caps for the toughest workshop conditions.
DIRECT INSTALLATION
IC25RV supplied with 1.5M length terminated leads for permanent fitment to RV. All
other models can be hardwired by removing their battery clamps to access cable lugs
(see page 13).
TEMPERATURE COMPENSATION*
The temperature sensor monitors the battery temperature and adjusts (compensates)
the charger’s output to prevent overcharging. This is ideal for batteries used in warmer
climates or environments.
SWITCHMODE TECHNOLOGY
LCD SCREEN & LED INDICATORS
POLARITY PROTECTION
OVER TEMPERATURE PROTECTION
MOUNTING INSTRUCTIONS
MOUNTING BATTERY CHARGER
Intelli-Charge chargers are designed for indoor,
out of weather use only. Ensure that both
charger and battery are in a well-ventilated
space during charging.
The battery charger end plates include a mounting
flange for easy mounting. If permanently fixed the
charger should be mounted to a suitable horizontal
or vertical panel, with at least 10cm clearance from
the end plates to provide adequate ventilation for
the cooling fan.
ON
OFF
CHARGE
RATE
BATTERY
TYPE RECONDITION
VOLT/AMP
POWER ON
ABSORPTION
BULK
CHARGE
FULLY
CHARGED
IC35
12V 35A 7-STAGE
3.5mm
mounting hole
*Not included with IC25W
