Projecta INTELLI-RV PM300 User manual

INTELLI-RV
12V POWER MANAGEMENT SYSTEM
P/No. PM300
INSTALLATION GUIDE

2
WARNINGS
• Explosive gases. Prevent flames and sparks. Provide adequate ventilation during charging
• Before charging, read the instructions
• For indoor use. Do not expose to rain
• For charging lead acid and LiFePO4batteries ONLY (of the size & voltage specified in the specifications table)
• Always charge the battery on the correct voltage setting. Never set the charger to a higher voltage than
the battery
• Disconnect the 240V mains supply before making or breaking the connections to the battery
• The battery charger must be plugged into an earthed socket outlet
• Connection to supply mains is to be in accordance with National wiring rules
• Do not attempt to charge non-rechargeable batteries
• Never charge a frozen battery
• If the AC cord is damaged, do not attempt to use. It must be replaced or repaired by a qualified person
• Corrosive substances may escape from the battery during charging and damage delicate surfaces.
Store and charge in a suitable area
• This charger is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety
• Young children should be supervised to ensure that they do not play with the appliance
• If the recreational vehicle is to be put in to storage without power, please turn off the BATTERY MASTER
SWITCH. If the recreational vehicle is to be put into long term storage without power, disconnect ALL
cabling from the battery.

3

4
Code Name Model Qty Part No. on
drawing
112V 30A Charger and 35Amp Power supply,
30A MPPT Solar controller
PM335 1 1
2LCD DisplayT/S PM335 PMLCD 1 2
3200mm water sensor with 4.5m cable PMWS200 (not supplied) 0 4
4400mm water sensor with 4.5m cable PMWS400 (not supplied) 0 4
Code Description Qty Length
PMLCDC 5m Cable to suit PMLCD 15m
PMBS Battery sensor with 3m cable 13m
PMTS Temperature sensor with 5m cable 15m
PMSW200 4.5m Cable to suit PMWS200 (not supplied) 04.5m
PMAC AC power cord, 1.5m,AUS 11.5m

5
(15A)
(15A)
(10A)
(15A)
(10A)
(10A)
(15A)
(10A)
(10A)
(10A)
(10A)
(10A)
(10A)
(10A)
1 PM335

6
1 PM335

7
2 PMLCD

8
4 Water tank level sensor
(Not supplied)

9
4 PMWS200

10
4 Water tank level sensor
(Not supplied)

11
4 PMWS400

12
