Projecta HDBC20 User manual

6/12/24 VOLT AUTOMATIC/MANUAL
WORKSHOP
BATTERY CHARGER
P/No.s HDBC20, HDBC35
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 2

WARNING
• Explosive gases. Prevent flames and sparks. Provide adequate ventilation during charging.
• Before charging, read the instructions.
• For indoor use. Do not expose to rain.
• For charging lead acid batteries ON Y (of the size & voltage specified in the specifications table).
• Always charge the battery on the correct voltage setting. Never set the charger to a higher voltage
than the battery.
• Disconnect the 240V mains supply before making or breaking the connections to the battery.
• Do not attempt to charge non-rechargeable batteries.
• Never charge a frozen battery.
• This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
• Young children should be supervised to ensure that they do not play with the appliance.
• Charge the battery in a suitable area, as the battery may give off corrosive fumes which could
damage delicate surfaces.
• Ensure all vehicle accessories and lights are turned off prior to charging.
• If the AC cord is damaged, it must be returned to an authorized Service Center.
2
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 3

3
FEATURES
Automatic Charging
When in automatic mode the charger will stop charging the battery when the battery is fully charged.
You can leave the charger connected to the battery without risk of overcharging. Once the battery is full,
the battery charger will automatically start to maintain the battery. The charger monitors the battery voltage
and continues to top up the battery, keeping it fully charged and ready for use.
Manual Charging
The charger in this mode will continue to charge the battery until the timer finishes or is turned off and
requires the user to monitor the charging battery. When used by experienced users it can deliver an
equalization charge to balance the voltage in the battery’s cells.
LED Indication
OVER OAD (Red ED Flashing): The ED will flash when the transformer or the current regulators (SCR’s)
have got too hot
POWER ON (Red ED ON): The ED comes on when connected to power and the charger is switched on
POWER ON (Red ED Flashing): Indicates that the battery clamps have been connected in reverse polarity
Charging (Orange ED on): The ED comes on indicating charging
Fully charged (Green ED on): The ED comes on when the battery is charged
VO T (Red ED ON): The ED indicates that Voltage is being displayed
AMP (Red ED ON): The ED indicates that Amps or current is being displayed
LED Voltage/Amp Display
The charger has a VO T and AMP meter built in. When the charger is initially powered up the display will
show voltage. When the VO T / AMP button is pressed the Amps will be displayed, press the button again
the display will go back to Volts. When Volts is displayed this indicates the state of charge of the battery,
when Amps is displayed this indicates how much charge is being accepted by the battery.
verride Button
The battery charger measures the battery voltage at the clamps to determine if the battery is correctly
connected. A reading above 3V will activate the battery charger. In some instances where the battery is
extremely flat, it is possible to have correct connection and the battery to be below the 3V limit. In this
instance check the battery leads to ensure they are connected correctly and press the OVERRIDE button
to activate the battery charger.
Multi Voltage
Suitable for charging 6V, 12V & 24V batteries.
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 4

Engine Start
If you need to get going and the battery is flat then the engine start will help you out. Connect
the charger to the battery, set it to engine start mode for 5 minutes, then start your engine.
0–14 Hour timer
Automatically turns the battery charger off after a set time. The timer has 1 hour intervals with
a maximum of 14 hours. This switch can also be set to permanently ON.
Toroidal Transformer
Using the latest technology in transformer design, toroidal transformers don’t use a solid iron
core (like traditional transformers) making them lighter and more compact. They deliver more
power than a traditional transformer charger of the same size.
Protection features
The charger is fitted with the following protection features:
1. Reverse polarity protection – Where the battery leads are connected incorrectly the charger will
flash the power ED and not charge the battery.
2. Short circuit protection – There is no voltage at the leads until the battery clamps are connected
to the battery.
3. Overload protection – To prevent damage to the electronics the charger will switch off when
overloaded, it will automatically reset when safe. The overload ED will flash in these times.
4
6/12/24 VOLT 12 AMP AUTOMATIC BATTERY CHARGER WITH ENGINE START
WORKSHOP 1200
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 5

SPECIFICATIONS
PART N . HDBC20 HDBC35
Type: Manual and Automatic Manual and Automatic
Input: 240VAC 50HZ 240VAC 50HZ
Input power: 1.35A (324W) 2.65A (636W)
Output Voltage: (Nominal) 6VDC/12VDC/24VDC 6VDC/12VDC/24VDC
Output Current: 12A @ 6VDC 21A @ 6VDC
(Continuous) 12A @ 12VDC 21A @ 12.5VDC
7.7A @ 26VDC 13.5A @ 26VDC
Suitable for charging 6V, 12V, 24V, lead acid batteries
Battery Range: (CCA) 450–1200 550–2000
(MCA) 600–1400 700–2500
(Ah) 65–160 75–250
Minium Start Voltage: 0V 0V
Charge control:
Cut Out 6V 7.1V 7.1V
12V 14.2V 14.2V
24V 28.4V 28.4V
Cut In 6V 6.7V 6.7V
12V 13.4V 13.4V
24V 26.8V 26.8V
Output lead specifications: 6mm2cable 6mm2cable
183cm 183cm
Size: 301x264x161mm 301x264x161mm
Weight: 8.6kg 11.5kg
5
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 6

6
CHARGING & ENGINE START INSTRUCTIONS
STEP 1 – CHECK THE ELECTR LYTE LEVEL
Prior to charging the battery, remove the vent caps and check the electrolyte level. (Not required on
sealed & maintenance free batteries). The electrolyte should be 6mm (1/4”) above the battery’s plates.
If low, top up the electrolyte with distilled water to the correct level and refit the vent caps.
STEP 2A – C NNECTI N UT F VEHICLE
Connect the RED lead (battery clip) from the charger to the Positive (+) battery post.
Connect the B ACK lead (battery clip) from the charger to the Negative (-) battery post.
C NNECTI N UT F VEHICLE
6/12/24 VOLT 12 AMP AUTOMATIC BATTERY CHARGER WITH ENGINE START
WORKSHOP 1200
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 7

7
STEP 2B – C NNECTI N IN VEHICLE
Determine if the vehicle is Positively (+) or Negatively (-) earthed. Negatively earthed vehicles have a cable
(usually black) from the Negative battery terminal to the vehicle’s chassis.
Negatively earthed (Most Vehicles)
Connect the RED lead (battery clip) from the charger to the Positive (+) battery terminal.
Connect the B ACK lead (battery clip) from the charger to the vehicle’s chassis away from the fuel line or
moving parts.
C NNECTI N IN VEHICLE (NEGATIVELY EARTHED)
Positively earthed
Connect the B ACK lead (battery clip) from the charger to the Negative (-) battery terminal.
Connect the RED lead (battery clip) from the charger to the vehicle’s chassis away from the fuel line or
moving parts.
C NNECTI N IN VEHICLE (P SITIVELY EARTHED)
6/12/24 VOLT 12 AMP AUTOMATIC BATTERY CHARGER WITH ENGINE START
WORKSHOP 1200
6/12/24 VOLT 12 AMP AUTOMATIC BATTERY CHARGER WITH ENGINE START
WORKSHOP 1200
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 8

8
STEP 3 – C NNECT T 240V MAINS P WER
Connect the battery charger to the 240V mains power (ensure the battery charger POWER ON/OFF TIMER is
set to the OFF position).
STEP 4 – SET BATTERY V LTAGE
Set BATTERY VO TAGE switch to either 6V, 12V or 24V.
STEP 5 – SET CHARGE C NTR L
AUTO
It is recommended to run AUTO mode when the battery is in the vehicle.
MANUA
In this mode the charger continues to operate and may in time overcharge and damage the battery.
It is recommended to use the timer with this mode.
ENGINE START
Use this mode to provide a rapid charge. Constant Supervision is recommended.
STEP 6 – SET the P WER N/ FF TIMER switch
ON
The charger will remain on. It is recommended using in AUTOMATIC mode.
TIMER
Can be used in any charging mode.
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 9

9
STEP 7A – CHARGING
The POWER and CHARGING ED’s will illuminate.
When the FU Y CHARGED ED illuminates charging is complete.
Manual mode
Note: Charging will continue until the timer finishes or the power is turned off to the charger. The battery
needs to be monitored to ensure is does not overcharge.
STEP 7B – ENGINE START
a. Allow the charger to boost charge the battery for 5 minutes.
b. Turn the cars ignition key to start the engine.
c. If engine fails to start after 3 seconds, wait 5 minutes before attempting to start the engine again.
NOTE: Do not repeat this operation more than 5 times.
STEP 8 – DISC NNECTI N.
Ensure the power selection switch is set to the OFF position and disconnect from the 240V supply.
Battery out of vehicle
Remove the B ACK lead (battery clip) from the battery. Remove the RED lead (battery clip) from the battery.
Battery in vehicle
Remove the chassis connection. Remove the battery terminal connection.
CALCIUM BATTERY CHARGING OR EQUALIZATION CHARGE
Calcium batteries are becoming more commonly sold as they have a longer shelf life (4 times longer than
a lead antimony battery), they also have a better ability to withstand higher engine bay temperatures, and
have increased cranking output. They also require a different charging technique when left flat or when
deeply discharged.
STEP 1 to 3
Follow STEPS 1 to 3 of the Charging instructions of this booklet. Ensure that the battery is removed from
the vehicle to prevent the batteries electrolyte from spilling over and damaging the car or engine bay.
STEP 4 – SET BATTERY V LTAGE
Set switch to either 6V or 12V depending on what battery voltage you are charging. For 24V vehicles the
batteries should be disconnected and the two 12Volt batteries need to be charged separately.
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 10

10
STEP 5 – SET CHARGE C NTR L T AUT
STEP 6 – SET the P WER N/ FF TIMER switch to N
STEP 7 – WAIT for the ‘FULLY CHARGED’ LED to illuminate.
STEP 8 – SET CHARGE C NTR L to MANUAL
STEP 9 – SET DISPLAY T READ V LTAGE
STEP 10 – CHECK THE BATTERY
Set the POWER TIMER to 2 hours and check the battery every 30 minutes to ensure it does not get
too warm and the batteries electrolyte is not bubbling profusely. You may need to may need to reset
the timer after 2 hours.
STEP 10A – CHARGING 6 VO T BATTERIES
Wait for the voltage to reach 8.0 Volts and then turn the charger off.
STEP 10B – CHARGING 12 VO T BATTERIES
Wait for the voltage to reach 16.0 Volts and then turn the charger off.
STEP 11 – DISC NNECT THE CHARGER FR M THE BATTERY
a. Ensure the battery charger is off and is disconnected from the 240V supply.
b. Remove the leads from the battery.
c. Check the electrolyte if possible. The electrolyte may need to be topped up after charging.
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 11

11
FREQUENTLY ASKED QUESTIONS
Q. How do I know if the battery is charged?
A. The battery charger’s GREEN ‘FU Y CHARGED’ ED will illuminate to indicate when the battery is fully
charged. Alternatively use a Battery Hydrometer (Projecta Part No. BH100). A reading of 1.250 or more
in each cell indicates a fully charged battery.
Q. Why does the battery charger have two ratings?
A. Battery chargers for automotive use have traditionally been given an RMS rating in the past. This rating
is now used as an industry reference only. Australian Standards now require all battery chargers to be rated
at the charger’s continuous output at a nominated voltage, we express this as mA (milliamps) rather than
A (Amps) to avoid confusion.
Q. Why does the ‘FULLY CHARGED’ LED come on straight away?
A. There are four possible reasons why the ‘FU Y CHARGED’ ED may come on straight away.
1. The battery is fully charged.
2. The battery has taken a surface charge.
3. The battery has a faulty cell.
4. The BATTERY VO TAGE setting on the charger is set lower than the battery voltage.
Q. What is Surface Charge?
A. Batteries unused or left flat for some time build up a resistance to being recharged. When the charger is
first connected, these batteries will take a surface charge, and the ‘FU Y CHARGED’ ED will illuminate
within a short while. The battery however is not fully charged, the charger is voltage sensitive and cannot
differentiate between a surface charge and a fully charged battery. After a few hours the battery may start
to accept some charge but most batteries with this condition will not recover.
Q. What is a Faulty Cell?
A. 12 Volt batteries contain 6 cells and one faulty cell is enough to ruin your battery. If after eight hours of
charging your battery is still flat, you should test the cells using a hydrometer. If one reading is lower than
the rest it indicates a faulty cell. It is pointless to continue charging, as the battery needs replacing.
Q. I have connected the charger properly but the ‘ range’ charging light does not come on?
A. In some cases batteries can be flattened to the point where they have very little or no Voltage. This can
occur if a small amount of power is used for a long time, for example a map reading light is left on for a
week or more. Projecta automatic chargers are designed to charge from as little as 3 Volts. If the voltage
is lower than 3.0V press the override button to start the charger.
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 12

Q. Can I use the charger as a power supply?
A. Projecta automatic chargers are designed to only supply power to the battery clips when they are correctly
connected to a battery, this is to prevent sparks or damage to the charger or battery if connected incorrectly by
mistake. This safety feature prevents the charger from being used as a ‘Power Supply’. No Voltage will be
present at the clips.
Q. In maintenance mode why does the current go high then low again?
A. While in maintenance mode it is normal for the current to go high and then low. The charger is maintaining the
battery voltage between the Cut-In and Cut-Out voltages. The pulses of power are topping up the battery to
maintain it fully charged.
12
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 13

Q. What are Volts and Amps?
VO TS
The term voltage refers to the electrical force or electric potential to do work between two terminals or a good
analogy is water pressure in a pipe. For example a battery has 12 Volts between the positive and negative
terminals, or a 6 Volt battery has 6 Volts between the positive and negative terminals.
AMPS
The term AMPS is the unit of measure used for current. Which can be described as the flow of electric charge in
a circuit. Again if you use the water analogy this would refer to how much water is flowing through the pipe.
For example if the current is reading 12 Amps then this is the amount of energy going into the battery.
Q. How does a typical battery charge?
A. A typical flat battery has a low internal resistance, when first connected to a charger the battery will accept a
high current. As the battery slowly charges, the voltage and internal resistance will rise causing the battery to
accept less and less current.
13
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 14

14
N TES:
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 15

15
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 16

Distributed by
AUSTRALIAN FFICE
Brown & Watson International Pty Ltd
Knoxfield, Victoria 3180
Telephone [phone]
Facsimile [phone]
National Toll Free 1800 113 443
NEW ZEALAND FFICE
Narva New Zealand Ltd
22–24 Olive Road
PO Box 12556 Penrose
Auckland, New Zealand
Telephone [phone]
Facsimile [phone] IS151
Issue 1 18.3.11
HDBC20 I structio Ma ual NEW_Layout 1 28/07/11 4:33 PM Page 1
