Projecta IC700 User manual

INTELLI-CHARGE
12 VOLT, 7 STAGE SWITCHMODE
BATTERY CHARGER
P/No.s IC700, IC700W, IC1000, IC1500

2
IMPORTANT SAFETY INFORMATION
Please read this manual thoroughly before use and store in a safe place for future
reference.
WARNING
• Explosive gases may escape from the battery during charging. Prevent flames and
sparks. Provide adequate ventilation.
• Before charging, read the instructions.
• For indoor use. Do not expose to rain.
• For charging 12 Volt lead acid batteries ONLY.
• Disconnect the 240V mains supply before making or breaking the connections
to the battery.
• The battery charger must be plugged into an earthed socket-outlet.
• Connection to supply mains is to be in accordance with National wiring rules.
• Do not attempt to charge non-rechargeable batteries.
• Never charge a frozen battery.
• If the AC cord is damaged do not attempt to use. It must be replaced or repaired by
a qualified person.
• Corrosive substances may escape from the battery during charging and damage delicate
surfaces. Store and charge in a suitable area.
• Ensure all vehicle accessories including lights, heaters, appliances etc are turned off
prior to charging.
• This charger is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Young children should be supervised to ensure that they do not play with the appliance.

3
FEATURES
7-STAGE AUTOMATIC CHARGING
This is a fully automatic battery charger with 7 charge stages.
Automatic charging protects your battery from being overcharged so you can leave the
charger connected to the battery indefinitely.
7-stage charging is a very comprehensive and accurate charging technique that gives
your battery longer life and better performance compared to using traditional chargers.
Projecta’s Intelli-Charge chargers can be adjusted to suit a number of different battery
types including GEL, AGM, WET and Calcium. The chargers can also help restore drained
and sulphated batteries.
The 7 charge stages are:
Desulphation; Soft Start; Bulk; Absorption; Analysis; Recondition and Float.
1. DESULPHATION
Rejuvenates sulphated
batteries with a high
frequency pulse.
2. SOFT START
Increases battery life
by gently starting to
charge the battery.
3. BULK CHARGE
Reduces charging
time by delivering
maximum charge to
set voltage.
4. ABSORPTION
Ensures a full
charge to the
battery without
overcharging.
EQUALISATION
(Calcium mode only)
Returns a full
hydrometer reading
to calcium batteries
by removing acid
stratification.
5. ANALYSIS
Tests the battery to
ensure fully charged.
6. RECONDITION
Restores battery
health to deeply
discharged batteries
by equalising
the cells.
7. FLOAT
Float charge
maintains the
battery at 100%
charge.
VOLTAGE
CURRENT
(AMPS)
Desulphation
The Desulphation stage is designed to break down sulphation occurring in batteries that
have been left flat for extended periods of time, returning them back to full charge.
Sulphation occurs when lead-sulphate hardens and clogs up the battery cells.
Soft Start
This is a preliminary charge process that gently introduces power to the battery,
protecting the battery and increasing battery life.
Bulk (Constant Current)
The Bulk stage reduces charging time by charging the battery at the maximum rate
(constant current) to a set voltage, at which point the battery is approximately
80% charged.

4
Absorption (Constant Voltage)
The absorption stage charges the battery to 100% by adjusting the charge rate allowing
the battery to absorb more power.
Equalisation (Calcium mode only)
Designed especially for calcium batteries, this stage returns calcium batteries to full
service by removing acid stratification of the electrolyte.
Analysis
The analysis mode tests the battery to ensure that it has taken the charge; if the battery
passes the test the charger will proceed to the float stage, but if the battery fails the test,
the charger will apply a recondition charge to try to return the battery to full charge.
Recondition
If after charging, the battery is unable to hold the charge the battery reconditioning
function is initiated automatically. This is most likely to take place on batteries that
have been deeply discharged, prior to charging. The Recondition mode will then run
for 4 hours and at the end will retest the battery. The Intelli-Charge battery charger will
perform the recondition charge up to 3 times before switching the charging cycle
to Float with an error indication.
Float
The Float stage maintains the battery at 100% charge without overcharging or
damaging the battery. This means the charger can be left connected to the battery
indefinitely.
ADJUSTABLE CHARGE RATE
The charger’s output can be adjusted to suit the size of the battery for optimum
charging.
MULTI CHEMISTRY
The Multi-Chem function allows you to set the charging profile to suit each battery’s
chemistry type (GEL, AGM, WET and Calcium). This ensures correct and thorough
charging and maximises battery performance and battery life.
POWER SUPPLY
When Power Supply mode is selected, you can safely run an appliance or load from
your battery. An appliance can also be run directly from the battery clamps if required,
for example using the charger as a memory saver when disconnecting the battery
from the vehicle.
WIRING HARNESS (IC700 ONLY)
The wiring harness allows for easy connection to vehicles that have hard to reach
batteries. Includes an inline fuse to protect the harness from accidental short circuits.
RUBBER END CAPS (IC700W ONLY)
Rubber end caps provide added durability and protection.

5
CHARGE STATUS INDICATOR
The CHARGING and FULLY CHARGED LEDs will illuminate and flash in various patterns
to indicate the different stages of charging. See below for flash patterns.
CHARGING LED: blue LED illuminates and flashes during charging process.
FULLY CHARGED LED: green LED illuminates (solid) when fully charged.
POLARITY PROTECTION
Prevents the output leads from sparking due to accidental reverse connection or short
circuit making the charger safer to use around batteries.
OVER TEMPERATURE PROTECTION
If the temperature within the charger rises too high, the charger will begin to cool down
by turning on the fan, and if the temperature continues to rise it will begin reducing the
power output. If still unsuccessful, the charger will shutdown until it cools down.
SWITCHMODE TECHNOLOGY
Using the latest technology in battery chargers, switchmode chargers convert 240VAC
power to 12VDC power using electronic components unlike traditional battery chargers
that rely on heavy transformers. This allows the charger to be lightweight and compact
without sacrificing on performance.
COOLING FAN
The charger is fitted with a thermostatically controlled fan to cool onboard electronics
and maintain charging performance. The cooling fan will engage automatically when
there is a high load on the battery or there is sufficient heat build up.
REMOTE CONTROL DISPLAY*
Control and monitor the charger’s performance from a remote control display, allowing
the charger to be flush or surface mounted out of the way and out of sight. The battery
charger and remote are synchronised for operation either locally or by remote.
*Available as optional extra for P/No. IC1500 only, not supplied with unit but can be
purchased separately (P/No. ICREMOTE)
Absorption/
Desulphation Soft Start Bulk Equalisation Analyse Recondition Float
Red LED Power
Blue LED Charging
Green LED Full
(Fast Flash) (Slow Flash)

66
SPECIFICATIONS
P/No. IC700 & IC700W IC1000 IC1500
Type 7 stage 7 stage 7 stage
Input (Nominal) 240VAC, 50Hz 240VAC, 50Hz 240VAC, 50Hz
Input Power 110W 160W 240W
Output Voltage 12V 12V 12V
Output Current 7A, 4A, 2A, 1A 10A, 6A, 4A, 2A 15A, 8A, 4A, 2A
Minimum Start Voltage 2.5V 2.5V 2.5V
Back Drain 1mA 1mA 1mA (with remote 2mA)
CHARGE CONTROL
Desulphation High Frequency Pulse charge up to 11V
Soft Start Half the rated set current up to 12V
Bulk Set current up to: Set current up to: Set current up to:
14.1V (GEL) 14.1V (GEL) 14.1V (GEL)
14.4V (AGM) 14.4V (AGM) 14.4V (AGM)
14.7V (WET) 14.7V (WET) 14.7V (WET)
14.7V (CALCIUM) 14.7V (CALCIUM) 14.7V (CALCIUM)
Absorption Constant voltage until Constant voltage until Constant voltage until
current drops to: current drops to: current drops to:
1A – 0.15A 2A – 0.3A 2A – 0.3A
2A – 0.3A 4A – 0.6A 4A – 0.6A
4A – 0.6A 6A – 0.9A 8A – 1.2A
7A – 1.05A 10A – 1.5A 15A – 2.25A
Equalization Constant current (1.0–2.0A) Constant current (2.0A) up Constant current (2.0–2.2A)
(Calcium mode only) up to 16V then hold for 1 hour to 16V then hold for 1 hour up to 16V then hold for
or 12 hour timeout or 12 hour timeout 1 hour or 12 hour timeout
Analysis Monitors battery for 90 sec
Recondition Constant current Constant current Constant current
(0.15A – 1.05A) for (0.3A – 1.5A) for (0.3A – 2.25A) for
4 hours limited to: 4 hours limited to: 4 hours limited to:
14.1V (GEL) 14.1V (GEL) 14.1V (GEL)
14.4V (AGM) 14.4V (AGM) 14.4V (AGM)
16V (WET) 16V (WET) 16V (WET)
16V (CALCIUM) 16V (CALCIUM) 16V (CALCIUM)
Float 13.7V 13.7V 13.7V
POWER SUPPLY
Set Voltage 13.8VDC 13.8VDC 13.8VDC
Maximum Current 7A 10A 15A
BATTERY RANGE
Deep Cycle 7–140Ah 14–200Ah 14–300Ah
Automotive 40–800CCA 80–1000CCA 80–2000CCA
Marine 55–900MCA 110–1200MCA 110–2500MCA
Types of Batteries Most types of lead acid batteries including GEL, AGM, WET CELL and CALCIUM
Size (mm) IC700: 182 x 61 x 108 202 x 61 x 108 222 x 61 x 108
IC700W: 193 x 65 x 112
Weight IC700: 1.02Kg 1.15Kg 1.54Kg
IC700W: 1.08Kg

Intelli-Power
Intelli-Power
Intelli-Power
FOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIES
Intelli-Power
Intelli-Power
Intelli-Power
FOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIES
222
108
Thermostatically
Controlled Cooling Fan
LED Charge Status Display
Indicates Power, Charging
and Fully Charged
Mounting
Flange
Adjustable
Charge Rate
Battery Chemistry
Selection (Mode)
Button
LED Battery
Chemistry Display
Indicates selected
battery chemistry type
Power
Cord
DC Leads
Intelli-Power
Intelli-Power
Intelli-Power
FOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIESFOR LEAD ACID CELL BATTERIES
IC700
182
108
IC1500
202
108
IC1000
7
61
61
61
AC Cord
15A Inline
Blade Fuse
1.15m
Output Lead
Battery Clips
Battery Clips
Ring
Terminals
AC Cord
Intelli-Power
FOR LEAD ACID CELL BATTERIES
IC700W
193
112
65
AC Cord
Battery Clips
Battery Clips
Vehicle Harness
AC Cord

8
CHARGING INSTRUCTIONS
STEP 1 – CHECK THE ELECTROLYTE LEVEL
Prior to charging the battery, remove the vent caps and check the electrolyte level (not
required on sealed & maintenance free batteries). The electrolyte should be 6mm (1/4”)
above the battery’s plates. If low, top up with distilled water to the correct level and
refit the vent caps.
STEP 2A – CONNECTION OUT OF THE VEHICLE
Connect the RED lead (battery clip) from the charger to the Positive (+) battery post.
Connect the BLACK lead (battery clip) from the charger to the Negative (-) battery post.
STEP 2B – CONNECTION IN VEHICLE
Determine if the vehicle is Positively (+) or Negatively (-) earthed. Negatively earthed
vehicles have a cable (usually black) from the Negative battery terminal to the vehicle’s
chassis.
Negatively earthed (most vehicles)
Connect the RED lead (battery clip) from the charger to the Positive (+) battery terminal.
Connect the BLACK lead (battery clip) from the charger to the vehicle’s chassis away
from the fuel line or moving parts.
12V 7A 7-Stage
PWR SUPPLY
GEL
AGM
WET
CALCIUM
MODE
POWER ON
CHARGING
FULLY CHARGED
1A
2A
4A
7A
CHARGE
RATE
Connection out of vehicle
12V 7A 7-Stage
PWR SUPPLY
GEL
AGM
WET
CALCIUM
MODE
POWER ON
CHARGING
FULLY CHARGED
1A
2A
4A
7A
CHARGE
RATE
Connection in vehicle
(negatively earthed)

12V 7A 7-Stage
PWR SUPPLY
GEL
AGM
WET
CALCIUM
MODE
POWER ON
CHARGING
FULLY CHARGED
1A
2A
4A
7A
CHARGE
RATE
Positively earthed
Connect the BLACK lead (battery clip) from the charger to the Negative (-) battery terminal.
Connect the RED lead (battery clip) from the charger to the vehicle’s chassis away from
the fuel line or moving parts.
STEP 2C – CONNECTION IN VEHICLE WITH HARNESS (IC700 ONLY)
Connect the RED ring terminal of the harness to the Positive (+) battery terminal.
Connect the BLACK ring terminal of the harness to the Negative (-) battery terminal.
Connect the plug on the harness to the charger’s output lead socket.
STEP 3 – CONNECT TO 240V MAINS POWER
Connect the battery charger to the 240V mains powered socket and turn on the mains
power.
STEP 4 – SET CHARGE RATE
The charge rate should be set according to the size of the battery. See the recommended
charge rates for various battery sizes in the table on the following page.
a. Press the CHARGE RATE or MODE button to enter setting mode.
b. Press the CHARGE RATE button until the desired setting is achieved.
9
Connection in vehicle
(positively earthed)
12V 7A 7-Stage
PWR SUPPLY
GEL
AGM
WET
CALCIUM
MODE
POWER ON
CHARGING
FULLY CHARGED
1A
2A
4A
7A
CHARGE
RATE
Vehicle harness

10
ADJUSTABLE CHARGE RATES: 12 VOLT BATTERIES
STEP 5 – SET BATTERY CHEMISTRY TYPE
Battery Chemistry should be selected by the type of battery being charged (refer to
the battery manufacturer’s specifications for battery type). Refer to page 12 for a
detailed explanation.
For example if you are charging an AGM battery, then AGM mode will need to be
selected. This can be done by the following procedure:
a. Press the Mode or Charge Rate button.
b. Press the Mode button repeatedly until the correct battery type is selected.
STEP 6 – CHARGING
During the charge process, the CHARGING and FULLY CHARGED LED will flash various
patterns. This is normal and indicates the various charge stages. Refer to “How can I tell
what stage the battery charger is in” in the FAQ section, page 14.
When the FULLY CHARGED LED remains on, this is known as the float stage and the
charger can be left connected to the battery without over charging.
If the POWER LED is flashing, there is a fault; refer to “Fault Codes” explanation on
page 13 of this manual.
STEP 7 – DISCONNECTION
Ensure the 240V mains switch is turned off and the charger is disconnected from the
240V mains power.
Battery out of vehicle
Remove the BLACK lead (battery clip) from the battery.
Remove the RED lead (battery clip) from battery.
Battery in vehicle
Remove the chassis connection.
Remove the battery terminal connection.
Battery in vehicle using harness (IC700 only)
Unplug the harness from the charger’s output lead.
Current AH CCA MCA
setting C-7 C-20 C-7 C-20 C-7 C-20 Time
1A 7 20 40 120 55 170 7 – 24h
2A 14 40 80 240 110 330 7 – 24h
4A 30 80 180 480 250 650 7 – 24h
6A 40 120 240 720 330 1000 7 – 24h
7A 50 140 300 800 350 900 7 – 24h
8A 60 160 360 1000 500 1300 7 – 24h
10A 70 200 450 1000 500 1200 6 – 20h
15A 85 300 465 2000 600 2500 6 – 20h

11
STEP 8 – CHECK THE ELECTROLYTE LEVEL (CALCIUM MODE ONLY)
Check the electrolyte level and top up if required.
MOUNTING INSTRUCTIONS
INTELLI-CHARGE Chargers are designed for indoor,
out of weather use only. Ensure that both charger
and battery are in a well-ventilated space during
charging.
The battery charger end plates include a mounting
flange for easy mounting. If permanently fixed the
charger should be mounted to a suitable horizontal
or vertical panel, with at least 10cm clearance from
the end plates to provide adequate ventilation for
the cooling fan.
PERMANENT WIRING TO BATTERY
It is possible to hard wire the DC charging leads to the battery for permanent
installations.
You will need 2 x ring terminals, an inline fuse holder and a fuse with a rating equal
to or greater than twice the chargers output. (See below)
IC700 = use supplied wiring harness (15 Amp fuse)
IC700W = 15 Amp fuse
IC1000 = 20 Amp fuse
IC1500 = 30 Amp fuse
Connection:
1. Cut off the supplied battery clips; ensure you leave sufficient cable to reach the
battery terminals. (DO NOT extend the battery charger DC cables, as the added
voltage drop will cause incorrect charging).
2. Fit a ring terminal to the BLACK Negative (-) wire.
3. Connect the inline fuse to the RED Positive (+) wire.
4. Connect a ring terminal to the other end of the inline fuse.
5. Connect the RED lead (with inline fuse and ring terminal) to the Positive (+)
battery post.
6. Connect the BLACK lead (with ring terminal) to the Negative (-) battery post.
12V 7A 7-Stage
PWR SUPPLY
GEL
AGM
WET
CALCIUM
MODE
POWER ON
CHARGING
FULLY CHARGED
1A
2A
4A
7A
CHARGE
RATE
3.5mm
mounting hole

12
7. Fit the correctly rated fuse.
If the charger is used in a Permanent/Hard Wired application and the vehicle will not
be used for some time, it is best to leave the charger connected to mains power (turned
‘On’) so that it can maintain the battery fully charged.
Ensure any modification to the 240V mains lead is carried out by a qualified person and
that connection to supply mains is in accordance with National wiring rules.
BATTERY CHEMISTRY SELECTION
The Multi-Chem function allows you to set the charging profile to suit each battery’s
chemistry type (GEL, AGM, WET and Calcium). This ensures correct and thorough
charging and maximizes battery performance and battery life.
1. Press the Mode button; all the lights will come on. Wait for the lights to turn off.
2. Press the Mode button repeatedly until the correct battery type is selected.
POWER SUPPLY (CONSTANT VOLTAGE OF 13.8 VOLTS)
This sets the charger in power supply mode giving a constant voltage of 13.8VDC.
This mode is best used where appliances are drawing power from the battery, for
example like a Fridge. Although the charger is designed to work with a battery
connected, it can also work without a battery.
GEL (MAX VOLTAGE OF 14.1 VOLTS)
This charge mode is designed for GEL batteries and has a maximum charge voltage
of 14.1V. Note that some GEL batteries require a higher charge voltage such as 14.4V.
The AGM mode can be used if this is required.
AGM (MAX VOLTAGE OF 14.4 VOLTS)
This charge mode is designed for AGM batteries and has a maximum charge voltage
of 14.4V.
WET (BULK AND ABSORPTION 14.7 VOLTS, RECONDITION UP TO 16 VOLTS)
This charge mode is designed for WET batteries and has a maximum charge voltage
of 14.7V during Bulk and Absorption stages and 16.0V during the Recondition stage.
Inline fuse Ring terminal
FOR LEAD ACID CELL BATTERIES

13
CALCIUM (BULK AND ABSORPTION 14.7 VOLTS, EQUALISATION AND
RECONDITION UP TO 16 VOLTS)
This charge mode is best suited for Calcium batteries that have been deeply discharged
and require an equalization charge to restore a full electrolyte reading. If the battery
requires a simple ‘top-up’, the WET charge mode can be used.
LOCKING THE BATTERY CHARGER SETTINGS
Locking the battery charger settings will disable the CHARGE RATE & MODE keys from
use. This function is ideal for hire vehicles etc as it prevents the chargers settings from
being altered if the keys are touched.
To lock; press and hold the ‘CHARGE RATE’ and ‘MODE’ keys for 3 seconds until all the
LEDs illuminate. This indicates the keys are now locked.
To unlock; press and hold and ‘CHARGE RATE’ and ‘MODE’ keys for 3 seconds until all
the LEDs illuminate. This indicates the keys are now unlocked.
FAULT CODES
There are three error codes that may be displayed. These will be displayed in the
following way:
Power Charging Full Fault Remedy
(Red LED) (Blue LED) (Green LED)
___ ___ ___
(Slow Flash) OFF OFF
– – – – – – –
(Fast Flash) OFF OFF
___ ___ ___
(Slow Flash) OFF ON
Check clips are not
touching each other
OR
Check the clips are
correctly connected
to the battery
Battery may
be faulty
Battery may be
faulty and may
need replacing
OR
There is a load
on the battery
causing the battery
to fail Analysis
The charger
has entered
recondition mode
3 times and has
timed out
Bulk charging
has timed out
and stopped
after 22 hours
Short circuit
or reverse
connection
of the clips

FREQUENTLY ASKED QUESTIONS
Q. How do I know if the battery is charged?
A. The charger’s FULLY CHARGED LED will illuminate (solid). Alternatively use a Battery
Hydrometer (Projecta Part No. BH100). A reading of 1.250 or more in each cell indicates
a fully charged battery.
Q. I have connected the charger properly but the ‘CHARGING LED’ does not
come on?
A. In some cases batteries can be flattened to the point where they have very little or no
voltage. This can occur if a small amount of power is used for a long time, for example
a map reading light is left on for a week or more. Projecta 7 Stage chargers are
designed to charge from as little as 2.5 Volts.
If the voltage is lower than 2.5 Volts use a pair of booster cables to connect between
two batteries to provide more than 2.5 Volts to the battery being charged. The charger
can then start to charge the battery and the booster cables can be removed.
Q. Can I use the charger as a power supply
A. Yes, by selecting Power Supply mode you are able to use the charger as a power supply
to run an appliance. Ensure the appliance being run is not greater than the charger’s
output current and where possible connect the charger to a battery, and the battery
to the appliance.
The charger may also be used to connect to a vehicle while changing the battery
to maintain the vehicles computer and radio settings.
Q. Why does the charger reset when I connect a load directly to the battery
charger in Power Supply mode.
A. The charger will reset when in Power Supply mode if the load exceeds the chargers
capacity. Some appliances when turned on or first connected to the charger will cause
the charger to reset and it will re-try by slowly ramping up its output.
Q. How can I tell what stage the battery charger is in?
A. Below are the conditions that are displayed by the LEDs for each of the charge stages.
14
Absorption/
Desulphation Soft Start Bulk Equalisation Analyse Recondition Float
Red LED Power
Blue LED Charging
Green LED Full
(Fast Flash) (Slow Flash)

15
Q. What happens if my battery charger is in Desulphation mode or Soft Start
mode, but I want to start bulk charging?
A. Desulphation mode is time limited to 6 hours and Soft Start is limited to 1 hour. If you
can not wait for the battery charger to move through these stages you can select Power
Supply mode to charge the battery. After an hour of charging in Power Supply mode,
there should be sufficient charge in the battery to bypass both Desulphation and Soft
Start. Select the correct battery chemistry type to continue charging the battery. Whilst
in Power Supply mode the charger will output a full current up to 13.8V.
Q. What if I have an appliance connected to the battery whilst charging?
A. Powering an appliance while charging your battery will impact on the battery chargers
ability to accurately measure the battery’s response to the charge being applied.
The battery charger has been designed to accommodate this situation although not
recommended.
For optimum charging it is recommended to charge without any appliance load on
the battery. Power Supply mode is recommended when an appliance is connected to
a battery and is drawing power.
Q. Can I select a different battery chemistry for charging my battery?
A. Yes the battery chemistry selection can be different to your battery type if the charge
voltages match the battery manufacture’s recommendations.
Q. Why does CALCIUM mode take so long to charge?
A. To fully charge a Calcium battery, the battery requires an extra charging stage called
‘Equalization’. This consists of a constant current being fed into the battery until 16V is
reached. This rejuvenates the battery cells. This charging stage can take up to 12 hours.
Q. Why do I need a special Calcium mode?
A. Because of the different chemistry used to make a Calcium battery, a different charging
algorithm (or technique) is required. Calcium batteries are also affected when deeply
discharged or used heavily. They need to be recharged by a Calcium charger to fully
recharge the battery and to maximize the battery’s life and performance.
Q. What is a Calcium battery?
A. Calcium batteries are lead acid batteries that have had calcium added to the
lead plates, either to one plate (called Calcium Hybrid) or to both plates (called
Calcium–Calcium).
The added calcium provides a number of benefits:
i. Lower internal resistance which provides a small increase in CCA performance.
ii. The ability to withstand higher engine bay temperatures.
iii. Low self discharge rate, which increases the shelf life, typically 4 times longer
than a Lead–Lead battery.

WARRANTY STATEMENT
Applicable only to product sold in Australia
Brown & Watson International Pty Ltd of 1500 Ferntree Gully Road, Knoxfield, Vic.,
telephone [phone], fax [phone], warrants that all products described in
its current catalogue (save and except for all bulbs and lenses whether made of glass or
some other substance) will under normal use and service be free of failures in material and
workmanship for a period of one (1) year (unless this period has been extended as indicated
elsewhere) from the date of the original purchase by the consumer as marked on the
invoice. This warranty does not cover ordinary wear and tear, abuse, alteration of products
or damage caused by the consumer.
To make a warranty claim the consumer must deliver the product at their cost to the
original place of purchase or to any other place which may be nominated by either BWI or
the retailer from where the product was bought in order that a warranty assessment may
be performed. The consumer must also deliver the original invoice evidencing the date and
place of purchase together with an explanation in writing as to the nature of the claim.
In the event that the claim is determined to be for a minor failure of the product then
BWI reserves the right to repair or replace it at its discretion. In the event that a major
failure is determined the consumer will be entitled to a replacement or a refund as well as
compensation for any other reasonably foreseeable loss or damage.
This warranty is in addition to any other rights or remedies that the consumer may have
under State or Federal legislation.
IMPORTANT NOTE
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure.
Distributed by
AUSTRALIA
Brown & Watson International Pty Ltd
Knoxfield, Victoria 3180
Telephone [phone]
Facsimile [phone]
National Toll Free 1800 113 443
NEW ZEALAND
Narva New Zealand Ltd
22–24 Olive Road
PO Box 12556 Penrose
Auckland, New Zealand
Telephone [phone]
Facsimile [phone] IS154
Issue 3: 25.06.14
