PROLED PAD300 User manual

For Your Own Or Other Person's Safety, Please Read The Manual Before
Use And Save For Future Reference

Safety Notice
To prevent damage to your product or injury to yourself or to others, read the
following safety precautions in their entirety before using this equipment.
Keep these safety instructions where all those who use this equipment will
read them.
Do not disassemble or modify
Failure to observe this precaution could result in electric shock or product
malfunction. Should the product break open as the result of a fall or other
accident, remove the batties.
Keep dry
Do not handle with wet hands or immerse in or expose to water or rain.
Failure to observe this precaution could result in fire or electric shock.
Do not use in the presence of flammable gas. Failure to observe this
precaution could result in explosion or fire.accident, remove the batties.
Keep out of reach of childen
This device contains small parts which may pose a choking hazard.Consult
a physician immediately if a child swallows any part of this device.
Do not expose to high temperatures
Keep away from strong sunlight or other high temperatures or it may explode.
Be careful when handling batteries
Use only batteries listed in this manual.
Turn off device before removing batteries.
Keep batteries away from fire
Be careful when handling battery charger
Don't touch the charger with wet hands in case of electric shock.
Don't damage, disassemble or drag the power cable. Repair or replace
when necessary.
Don't place heavy things on the device.
Clean the plug with a dry cloth.
1

Front:
1. LED Bulbs
2. Locking Frame
Back:
3. Battery Release Button
4. Li-ion Battery compartment
Accessories
10. Light Stand Adapter
11. Angle Adjustment Knob
5. White Light Control (5600K)
6. USB Output Port (5V 2A)
12. Hot Shoe Mount
13. NP-F750 Li-ion Battery
7. Power Switch
8. Warm Light Control (3200K)
9. Hot Shoe Mounting Hole
14. Battery Charger
15. Soft Diffuser
(Fully decoded)
1
2
3
4
10
11
12
13 14 15
Safety Notice
2
5
6
7
8
9

Set Up And Basic Operatio
LED Panel Installation
Rotate the light stand adapter(10) to the bottom of the panel( ), then insert 7
the hot-shoe mount to camera or light stand(not included).
Soft Diffuser Installation
Mount the diffuser on the front side of light panel and match the bayonet on
each side of the diffuser.
3

Battery Indicator
The battery indicator LED shows current battery power level.
Battery indicator LED lights red when power is low. Time to recharge or
replace the batteries.
75%
Power
Two battery types FN-750(included) and FN-550(not included) are acceptable.
direction to power the light panel.
Insert one of them or both to battery compartment according to the diagram's
Available Battery
*
*
Panasonic Series Batteries
Sony NP-F Series Batteries
100%
50%
The LED panel is compatible with below batteries:
4
25% or less

Function And Operation
Brightness Control
The light output can be adjusted by rotating the brightness wheel. Turn
clockwise to increase brightness from 0%-100%. Turn counter clockwise
brightness from 100%-0%.
Color Temperature Control
Adjust color temperature by rotating the color temperature wheel. Turn
clockwise to increase temperature. Turn counterclockwise to decrease
temperature.
5
Brightness Control
Color Temperature Control

Angle Adjustment
Adjust light panel angle by rotating the light stand adapter. Loosen the light
stand adapter lock and adjust LED light panel angel then tighten the light
stand adapter lock.
Specification
Model
LED Quantity
MAX Output
Color temperature
Luminous Flux
Color Rendering index(Ra)
Beam Angle
Battery Type
Battery Charger Input
Battery Charger Output
PAD300
360PCS
24W
5600/3200K
2820Lm
>90%
120°
NP-F750(fully decoded)
AC 100~240V 50/60HZ
DC 8.4V 600mAH
6

Attention
1. Please do not face to the LED directly when it's on.
2. Never block the ventilation grill by covering it with paper or clothes.
3. Do not place the LED light near alcohol or other flammable objects.
4. Keep all liquids away from LED panel.
5. When the LED light is on or against the other items above, please
turn it off, lest they cause fire or damage to the light.
6. Do not make LED light face down when move the light stand.6. Do not make LED light face down when move the light stand.
7. Use a clean, dry , soft cloth to clean LED panel. Use only neutral
detergents to remove the dirt and stains. Do not use strong cleaning
agents such as thinner, gasoline, or alcohol.
Our Guarantee
This product is guaranteed for 1 year against all defects of workmanship
and materials. Within this warranty period, CROLED will repair or replace,
at its discretion, defective parts at no charge.This warranty does not apply
if the warranty period expired; the product has been modified by any
unauthorized service center or personnel;the defect was subject to
abuse, improper use not conforming to product manual instructions,or
environment conditions more severe than those specified in the manual
and specification, neglect of the owner or improper installation; the
defect was subject to Force Majeure such as flood, lightning, earthquake,
other natural calamities, war, vandalism or theft.
Service & Support
In the event of a warranty claim, or if service is required for this product,
please contact CROLED customer service at: [e-mail]
Made In China
7
