ProLights DIAMOND7 User manual

USER MANUAL
MANUALE UTENTE
DIAMOND7
MOVING HEAD
EN - IT

All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be
reproduced in any form or by any means for any commercial use.
In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the
characteristics stated in this instruction manual at any time and without prior notice.
All revisions and updates are available in the ‘manuals’ section on site www.musiclights.it
REV.004-03/18

1
DIAMOND7
Packing content • DIAMOND7
• Mount bracket
• User manual
TABLE OF CONTENTS Safety
General instructions
Warnings and installation precautions
1 Introduction
1. 1 Description
1. 2 Technical specications
1. 3 Operating elements and connections
2 Installation
2. 1 Mounting
3 Functions and settings
3. 1 Operation
3. 2 Basic
3. 3 Menu structure
3. 4 Slave Receive mode
3. 5 Operation in automatic mode
3. 6 Scenes Record mode
3. 7 Music mode
3. 8 Sensitivity microphone
3. 9 Linking
3. 10 DMX mode
3. 11 DMX conguration
3. 12 DMX addressing
3. 13 Connection of the DMX line
3. 14 Construction of the DMX termination
3. 15 DMX control
3. 16 Wireless control settings
3. 17 Fixture settings
3. 18 Lamp settings
3. 19 Display settings
3. 20 Fixture information
3. 21 Reset functions
3. 22 Special functions
4 Maintenance
4. 1 Maintenance and cleaning the unit
4. 2 Fuse replacement
4. 3 Trouble shooting
2
2
3
3
6
7
8
8
9
11
12
13
13
14
14
14
14
15
16
16
17
22
22
22
23
23
24
24
27
27
28

DIAMOND7
2
WARNING! Before carrying out any operations with the unit, carefully read this instruction
manual and keep it with cure for future reference. It contains important information about
the installation, usage and maintenance of the unit.
SAFETY
General instruction
• The products referred to in this manual conform to the European Community Directives and are there-
fore marked with .
• The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.
Never make any modications on the unit not described in this instruction manual, otherwise you will
risk an electric shock.
• Connection must be made to a power supply system tted with ecient earthing (Class I appliance ac-
cording to standard EN 60598-1). It is, moreover, recommended to protect the supply lines of the units
from indirect contact and/or shorting to earth by using appropriately sized residual current devices.
• The connection to the main network of electric distribution must be carried out by a qualied electrical
installer. Check that the main frequency and voltage correspond to those for which the unit is designed
as given on the electrical data label.
• This unit is not for home use, only professional applications.
• Never use the xture under the following conditions:
- in places wet;
- in places subject to vibrations or bumps;
- in places with an ambient temperature of over 45°C.
• Make certain that no inammable liquids, water or metal objects enter the xture.
• Do not dismantle or modify the xture.
• All work must always be carried out by qualied technical personnel. Contact the nearest sales point for
an inspection or contact the manufacturer directly.
• If the unit is to be put out of operation denitively, take it to a local recycling
plant for a disposal which is not harmful to the environment.
Warnings and installation precautions
• If this device will be operated in any way dierent to the one described in this manual, it may suer
damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like
short circuit, burns, electric shock, etc.
• Before starting any maintenance work or cleaning the projector, cut o power from the main supply.
• Always additionally secure the projector with the safety rope.When carrying out any work, always com-
ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country
in which the xture’s being used.
• For inside use only. Not designed for outside use.
• The minimum distance between the xture and surrounding walls must be more than 50 cm and the
air vents at the housing must not be covered in any case.
• Install the xture in a well ventilated place.
• Keep any inammable material at a safe distance from the xture.
• The maximum temperature that can be reached on the external surface of the tting, in a thermally
steady state, is high. After power o, please cool down over 15 minutes.
• Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent
that their eectiveness is impaired.
• The lamp (LED) shall be changed if it has become damaged or thermally deformed.
• Never look directly at the light beam. Please note that fast changes in lighting, e. g. ashing light, may
trigger epileptic seizures in photosensitive persons or persons with epilepsy.

3
DIAMOND7
- 1 - INTRODUCTION
1.1 DESCRIPTION
DIAMOND7 is the smallest luminaire in the DIAMOND family oering all the advantages of WBFX tech-
nology. WBFX technology establishes a new concept of versatility oering three operating modes: high
performance Washlight with advanced color calibration , punchy Beam light and amazing FX graphic gen-
erator, revealing itself as a true creative tool for the LDs.
DIAMOND7 is equipped with 7x15W RGBW/Full Color Osram Ostar LED driven to 1A and it is the brightest
LED xture in its category oering one of the highest lumen/W ratio in the industry, through the combi-
nation of high-end LED source, new optic design ,and the most advanced liquid-cooling system and PSU
managment on the maket. A 1:11 Fast-Zoom system oers a fully variable beam of 6°-66°, remaining even
in the whole range and making this xture useful in both indoor venues as TV studios and music hall and
outdoor large environments as stadium and arenas.
The“Wash-mode”features a perfect color calibration system and homogeneous light distribution through
the application of reex-technique where color are pre-mixed in the internal optical channels. The “Beam-
mode” enters in action when DIAMOND7 is zoomed to 6° featuring a parallel beam and the xture be-
comes an ultra-bright mid-air eect light. The “FX-mode” is obtained through a state of the art com-
bination between the honey-comb gapless optic design, pixel control of every individual LED and the
advanced rmware features.
DIAMOND7 oers several DMX mode with mltiple pre-built static and dynamic patterns which can be con-
trolled on dierent layers and variable in speed and position also in the basic DMX mode with low chan-
nels requirements. Extreme speed and precision of movements is guaranteed by the ultra-lightweight
chassis and by usage of special motors, allowing DIAMOND to be fast, reactive and precise in its move-
ments. SHINE series electronic design oers advanced features as colorful high-denition LCD display with
multi-language Menu, battery backup, RDM, hibernation, color bounce, advanced diagnostic, dimmer
control and color managment system.
1.2 TECHNICAL SPECIFICATIONS
LIGHT SOURCE
• Source: 7x15W RGBW Osram Ostar LED
• Lux: (6°) 10980 - (66°) 745lux @3m Full
• Source Life Expectancy: >50.000 h
OPTICS
• Zoom: 6-66° Motorised linear zoom
• Lens Diameter: 126mm
• Lens Type: Honey-Comb gapless plano convex optics
COLOR SYSTEM
• Color Mixing: RGBW/FC
• CTC: CTC control through independent DMX channel
• White Presets: 2000~10000K
• Color Wheel: Virtual color wheel with presets
DYNAMIC EFFECTS
• Pixel Patterns: Preprogrammed dynamic and static patterns
• FX Generator: Adjustable foreground/background color, index, speed, direction

DIAMOND7
4
BODY
• Pan Angle: 630°
• Tilt Angle: 265°
• Pan/Tilt Resolution: 8/16 bit
• Feedback: Automatic repositioning after accidental movement
• Body: Aluminium structure with hi-resistance polycarbonate cover
• Body Color: Black, White nishing available
CONTROL
• Protocols: DMX512, RDM
• DMX Channels: 19/26/50/18/20ch
• Pixel Control: Pixel2Pixel control
• W-DMX: Optional, Wireless Solution receiver
• RDM: RDM ready for xture remote monitor and settings
• Display: LCD high resolution color display
• Firmware Upgrade: Yes, via USB-DMX interface (UPBOX2) not included
• Hibernation: Power Safe Mode when lost DMX
• Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
• Dimmer: Linear 0~100% electronic dimmer
• Strobe/Shutter: 1-25 Hz, electronic
• Battery Backup: Battery backup for user operation without connecting to the main power
• Operating Temperature: -10° ~ +45°
• Flicker: Flicker free operation
ELECTRICAL
• Power Supply: 100-240V – 50/60Hz
• Power Consumption (at 230V): 125W
• Power Consumption (at 120V): 125W
• Output (at 230V): 12 units on a single power line
PHYSICAL
• Cooling: Combination of heat pipe cooling system and low noise fan
• Suspension And Fixing: Any position with“quick-lock” omega brackets
• Signal Connection: 3p+5p in/out
• Power Connection: PowerCON in/out
• IP: 20
• Dimensions (WxHxD): 278x348x200mm
• Weight: 6,4kg

5
DIAMOND7
Fig.1
Photometric data
Technical drawing
200mm
7,87in
278mm
10,94in
348mm
13.7in
Illuminance at a Distance
6°- 66°
3m
5.0m
7.5m
0m
0.44/3.95m
0.65/6.50m
Lux Center Beam Angle: 6°- 66° Beam Width
9700/745lx
3263/302lx
0.91/9.68m
1494/141lx

DIAMOND7
6
1. MOVING HEAD
2. ROTARY ARM
3. HANDLE
4. LED INDICATOR "WDMX"
5. MICROPHONE
6. CONTROL PANEL with LCD display
and 5 button used to access
the control panel functions and
manage them.
7. DMX OUT ( 3-pole XLR):
1 = ground, 2 = DMX -, 3 = DMX +
8. DMX IN (3-pole XLR):
1 = ground, 2 = DMX -, 3 = DMX +
9. DMX OUT (5-pole XLR):
1 = ground, 2 = DMX-, 3 = DMX+,
4 N/C, 5 N/C
10. DMX IN (5-pole XLR):
1 = ground, 2 = DMX-, 3 = DMX+,
4 N/C, 5 N/C
11. POWER IN (PowerCON IN):
for connection to a socket
(100-240V~/50-60Hz) via the
supplied mains cable.
12. POWER OUT (PowerCON OUT):
power output for connection of
multiple units in series.
13. MAIN FUSE HOLDER: replace a
burnt-out fuse by one of the same
type only.
1.3 OPERATING ELEMENTS AND CONNECTIONS
Fig.2
View A
View B
4
A
B
1
2
3
5 6
7 9 11 12
8 10 13

7
DIAMOND7
- 2 - INSTALLATION
2.1 MOUNTING
The DIAMOND7 may be set up on a solid and even surface. By means of the xing facilities of the base-
plate, the unit can also be mounted upside down to a cross arm. The base plate is shown in g.3. For xing,
stable mounting clips are required. According to the gure, the bolts of the brackets are placed into the
openings provided in the base plate and turned clockwise until they lock (to the stop). Always ensure that
the unit is rmly xed to avoid vibration and slipping while operating. The mounting place must be of
sucient stability and be able to support a weight of 10 times of the unit’s weight. When carrying out any
installation, always comply scrupulously with all the regulations (particularly regarding safety) currently
in force in the country in which the xture’s being used. Always additionally secure the projector with the
safety rope from falling down. For this purpose, fasten the safety rope at a suitable position so that the
maximum fall of the projector will be 20 cm.
Fig.3
CLAMP
SAFETY
CABLE
OMEGA
BRACKETS

DIAMOND7
8
- 3 - FUNCTIONS AND SETTINGS
3.1 OPERATION
Connect the supplied main cable to a socket (100-240V~/50-60Hz). The unit will run built-in program to
reset all motors to their home position. Shortly after that the DIAMOND7 is ready for operation. To switch
o, disconnect the mains plug from the socket. For a more convenient operation it is recommended to
connect the unit to a socket which can be switched on and o via light switch.
3.2 BASIC
The DIAMOND7 has a LCD display and 5 button used to access the control panel functions and manage
them (g.4).
Fig.4 - Functions of the buttons and display icons
CONNECT LIGHT INFORMATION SET PROGRAM
LEFT RIGHT UP DOWN ENTER BATTERY
Return to the top
level
Commute from
units, tens, hundred
in the menu
Increases the value
displayed or passes
to the previous item
in a menu
Decreases the value
displayed or passes
to the next item in
the menu
Conrms the
displayed value,
or activates the
displayed function,
or enters the
successive menu
Used to activate the
backup battery. It
allows to switching
display interface
without main power
Battery

9
DIAMOND7
3.3 MENU STRUCTURE
MENU
1Connect ðDMX Address ðValue (1-512)
Wireless DMX ðValue (1-512)
2Light ðMax Temperature ðValue (80°-139° C)
Lamp Adjust ðControl ðValue (000-255)
Pan ðValue (000-255)
Pan Fine ðValue (000-255)
Tilt ðValue (000-255)
Tilt Fine ðValue (000-255)
Pan&Tilt Speed ðValue (000-255)
Pan&Tilt Fun ðValue (000-255)
Shutter Fun ðValue (000-255)
Shutter ðValue (000-255)
Dimmer ðValue (000-255)
Color Function ðValue (000-255)
Virtual Color1 ðValue (000-255)
Virtual Color2 ðValue (000-255)
Red-All ðValue (000-255)
Green-All ðValue (000-255)
Blue-All ðValue (000-255)
White-All ðValue (000-255)
Zoom ðValue (000-255)
Pattern ðValue (000-255)
Pattern Speed ðValue (000-255)
Pattern Byte 1 ðValue (000-255)
Pattern Byte 2 ðValue (000-255)
Pattern Byte 3 ðValue (000-255)
Pattern Byte 4 ðValue (000-255)
Fade Time ðValue (000-255)
Scene Time ðValue (000-255)
3Information ðTime Info.
Temperature
Fans Speed
Channel Value
Error Message

DIAMOND7
10
Fixture Model
Software Ver.
4Set ðReset ðAll
Pan & Tilt
Others
Movement ðPan Reverse ðON/OFF
Tilt Reverse ðON/OFF
Pan Degree ð540/630
Encoders ðON/OFF
Pan/Tilt Mode ðStandard/Smooth
UI Set ðMic Sens. ðValue (00-99%)
No Signal ðClose/Hold/Auto/Music
Temperature C/F ðCelsius/Fahrenheit
Fans Mode ðAuto Speed/High Speed
Hibernation ðNot Hibernation/Min (01-99)
Backlight ðAlways On/Min (01-99)
Flip Display ðON/OFF
Display Bright ðValue (00-31)
Brand Show ðON/OFF
Key Lock ðON/OFF
Language ðEN/FR/SP...
Fixture Set ðTheater Mode ðON/OFF
Frequency ð600/1200/2000/2400/4000 Hz/25 kHz
Users ðUser Mode ðStandard/Extended1/Extended2/Basic-8bit/...
Edit User ðMax Channel/Control/Pan/Pan Fine/Tilt/Tilt Fine...
Calibration ðPassword ð050 (insert to unlock the following settings)
Pan ðValue (-128-127)
Tilt ðValue (-128-127)
Fixture ID ðName ðFixture ID Name
Password ð050 (insert to unlock the following settings)
PID Code ð00001
Wireless Set ðDMX On Cable ðON/OFF
Reset Connect ðON/OFF
Reload Default ðBasic Reload ðON/OFF
Program Reload ðON/OFF

11
DIAMOND7
3.4 SLAVE RECEIVE MODE
This mode will allow you to link up the units together without a controller. Choose a unit to function as the
Master. The unit must be the rst unit in line; other units will work as slave with the same eect.
A Master unit can send up to 3 dierent data groups to the Slave units, i.e. a Master unit can start 3 dier-
ent Slave units, which run 3 dierent programs. The Master unit sends the 3 program parts in a continuous
loop.
The Slave unit receives data from the Master unit according to the group which the Slave unit was as-
signed to.
For example, if a slave device is set to Receive Part 1, the Master unit Slave unit will send the automated
Chase Part 1; if set to Receive Part 2, the Chase Part 2 Slave units will receive from the Master.
To set the drive as a slave, proceed as follows:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, and then select Play and press the ENTER
button to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, and select Slave Receive and press ENTER to
conrm.
• Press the UP/DOWN button to select the dierent modes of operation Part 1 Receive/Receive Part 2/Part 3
Receive, and then press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
Password ð050 (insert to unlock the following settings)
Private Reload ðON/OFF
All Reload ðON/OFF
5Program ðPlay ðDMX Receive
Slave Receive ðPart 1 Receive/Part 2 Receive/Part 3 Receive
Sequence ðAlone/Master
Music ðAlone/Master
Select Chase ðChase Part 1 ðChase 1 - Chase 8
Chase Part 2 ðChase 1 - Chase 8
Chase Part 3 ðChase 1 - Chase 8
Edit Chases ðEdit Chase 1 ðChase Test/ Step 1 - Step 64
Edit Chase 2 ðChase Test/ Step 1 - Step 64
Edit Chase ... ðChase Test/ Step 1 - Step 64
Edit Chase 8 ðChase Test/ Step 1 - Step 64
Edit Scenes ðEdit Scenes 001 ðControl/.../Fade Time/Scene Time/External Input
Edit Scenes 002 ðControl/Pan/Pan Fine/Tilt/Tilt Fine...
Edit Scenes ... ðControl/Pan/Pan Fine/Tilt/Tilt Fine...
Edit Scenes 250 ðControl/Pan/Pan Fine/Tilt/Tilt Fine...
Scenes Record ðSc XX - Sc XX

DIAMOND7
12
Select the desired program on the master unit (described in section 3.5).
Use the DMX connectors of the DIAMOND7 and an XLR cable to form a chain of units. Under certain
conditions and lengths you want to make a termination as shown on page 17.
3.5 OPERATIONS IN AUTOMATIC MODE
The unit independently runs through its show. Before you send an automatic program you need to set the
drive as Master/Alone:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Play and press the ENTER button to enter
the next menu.
• Press the UP/DOWN button to scroll through the menu, select Sequence and press ENTER to conrm
your choice.
• Press the UP/DOWN button to select the mode of operation:
- Master, if the unit is connected in series with other units and it acts as the Master;
- Alone, if the unit is not connected to other units.
• Press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
The unit will go into automatic mode by executing the program automatically.
Select Chase
The function Select Chase lets you choose the automatic program to actually run.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Select Chase and press the ENTER button
to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, then select Chase Part 1/Chase Part 2/Chase Part 3
and press ENTER to conrm.
• Press the UP/DOWN button to select Chase1-Chase8, and press the ENTER button to conrm.
• Press the LEFT button repeatedly to exit the menu and save changes.
Edit Chases
The function Edit Chases allows you to create automatic pre-programmed show.
The automatic programs Chase Part1/2/3 are each divided into Chase1-Chase8. Each Chase can be composed
of 1-64 step that can be congured through the following procedure:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Edit Chases and press the ENTER button
to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Edit Chase 1 - Edit Chase 8, then press the
ENTER button to conrm.
• Press the UP/DOWN button to select the Step 01 - Step 64, and press ENTER to conrm.
• Press the UP/DOWN button to select the Scene you want to set for the Step chosen, and then press
ENTER to conrm.
• Press the LEFT button repeatedly to exit the menu and save changes.

13
DIAMOND7
Edit Scenes
The function Edit Scenes allows you to create individual scenes to be included in the Chase Step.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Edit Scenes and press the ENTER button
to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Edit Scene 001 - Edit Scene 250, then press the
ENTER button to conrm.
• Press the UP/DOWN button to select the desired function you want to edit (Control, Pan,Tilt, etc..), Then
press the ENTER button to conrm.
• Press the UP/DOWN button to change the value of the function, then press the ENTER button to
conrm. Press the LEFT button repeatedly to exit the menu and save changes.
3.6 SCENES RECORD MODE
DIAMOND7 is equipped with a built-in DMX recorder by which you can transmit the programmed scenes
from your DMX-controller to the device. Proceed as follows to store the sequence of scenes in the unit.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll through the menu, select the Program icon, then press the ENTER
button to enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Scenes Record and press the ENTER button
to enter the next menu.
• Press the UP/DOWN button to adjust the scene at the beginning and end to be inserted in the auto-
matic program, then press the ENTER button to conrm.
• Press the LEFT button repeatedly to exit the menu and save changes.
When recalling scenes from the controller will automatically be transmitted to the device.
3.7 MUSIC MODE
In music mode, via its integrated microphone, the unit can be controlled by music with a clear rhythm in
the bass range. If the music control should not work optimally, increase the volume or reduce the distance
between the sound source and the light eect unit or alternatively increase the sensitivity of the micro-
phone.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Program icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select Play and press the ENTER button to enter
the next menu.
• Press the UP/DOWN button to scroll through the menu, select Music and press ENTER to conrm.
• Press the UP/DOWN button to select the mode of operation:
- Master, if the mobile head is connected in series to other units, and it performs the Master function;
- Alone, if the xture is not connected to other units.
• Press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
The unit will go into music mode by executing an automatic program to the rhythm of music.
3.8 SENSITIVITY MICROPHONE
Select this function to set the value of the sensitivity of the microphone for use with a music control:

DIAMOND7
14
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Set icon, then press the ENTER button to enter
the next menu.
• Press the UP/DOWN button to scroll through the menu, select UI Set, and press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, then select Mic Sens. and press ENTER to conrm.
• Press the UP/DOWN button to adjust the level of sensitivity of the microphone, and then press the
ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
3.9 LINKING
Several units may be interconnected in order to control all further slave units to the same eect of the
master unit.
1. Connect the DMX OUT of the master unit via 3/5-pole XLR cable to the DMX IN of the rst slave unit.
2. Connect the DMX OUT of the rst slave unit to the DMX IN of the second slave unit, etc. until all units
are connected in a chain.
3.10 DMX MODE
To enter the DMX mode, follow these steps:
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Connect icon, then press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select the DMX Address and press the ENTER key.
• Press the arrow keys to select the desired value (001-512).
• Press the ENTER key to conrm the setting.
• Press the LEFT button repeatedly to exit the menu and save changes.
3.11 DMX CONFIGURATION
The DIAMOND7 has 5 DMX channel congurations which can be accessed from the control panel.
• Press the ENTER button to access the main menu.
• Press the UP/DOWN button to scroll the menu, select the Set icon, then press the ENTER button to enter
the next menu.
• Press the UP/DOWN button to scroll through the menu, select Users and press the ENTER button to
enter the next menu.
• Press the UP/DOWN button to scroll through the menu, select User Mode and press ENTER to conrm
your choice.
• Use the UP/DOWN button to select the desired DMX channel conguration (Standard, Extended1,
Extended2, Basic-8bit, Basic-16bit, User), then press the ENTER button to conrm your choice.
• Press the LEFT button repeatedly to exit the menu and save changes.
The tables on page 18 show the mode of operation and their values DMX.
The unit is equipped with 3/5-pole XLR connections.
Edit User
The Edit User, in the same menu, allows you to create a prole of personalized functions. You can change
the parameters of the various functions (Control, Pan, Tilt, etc.). Once you’ve created your custom prole,
you can use it by selecting the USER mode as described above.

15
DIAMOND7
Number of
DMX channels
Start address
(example)
DMX Address
occupied
Next possible start
address for unit No. 1
Next possible start
address for unit No. 2
Next possible start
address for unit No. 3
19 33 33-51 52 71 90
26 33 33-58 59 85 111
50 33 33-82 83 133 183
18 33 33-50 51 69 87
20 33 33-52 53 73 93
3.12 DMX ADDRESSING
For operation via light control unit with DMX512 protocol, is sucient connect the controller to DIA-
MOND7. To able to operate the DIAMOND7 with a light controller, adjust the DMX start address for the
rst a DMX channel. If e. g. address 33 on the controller is provided for controlling the function of the rst
DMX channel, adjust the start address 33 on the DIAMOND7. The other functions of the light eect panel
are then automatically assigned to the following addresses.
An example with the start address 33 is shown below:
Fig.5 - Example 19 DMX channels conguration
DMX Address: 90DMX Address: 52DMX Address: 33 DMX Address: 71
. . . . . . . . . . . .
DMX512 Controller

DIAMOND7
16
Fig.6
Fig.7
3.13 CONNECTION OF THE DMX LINE
DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped-
ance and low capacity.
The following diagram shows the connection mode:
ATTENTION
The screened parts of the cable (sleeve) must never be connected to the system’s earth, as this would
cause faulty xture and controller operation.
Over long runs can be necessary to insert a DMX level matching amplier.
For those connections the use of balanced microphone cable is not recommended because it cannot
transmit control DMX data reliably.
• Connect the controller DMX input to the DMX output of the rst unit.
• Connect the DMX output to the DMX input of the following unit. Connect again the output to the input
of the following unit until all the units are connected in chain.
• When the signal cable has to run longer distance is recommended to insert a DMX termination on the
last unit.
3.14 CONSTRUCTION OF THE DMX TERMINATION
The termination avoids the risk of DMX 512 signals being reected back along the cable when they reach-
es the end of the line: under certain conditions and with certain cable lengths, this could cause them to
cancel the original signals.
The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the 5-pin male XLR
connector, as shown in gure.
DMX - OUTPUT
XLR socket
DMX - INPUT
XLR plug
Pin1 : GND - Shield
Pin2 : - Negative
Pin3 : + Positive
Pin4 : N/C
Pin5 : N/C
Example:
3 pin XLR connector

17
DIAMOND7
3.15 DMX CONTROL
STAND EXT-1 EXT-2 BAS-8 BAS-16 FUNCTION DMX
Value
19 Ch 26 Ch 50Ch 18 Ch 20 Ch
11111PAN
0~100% 000 - 255
2 2 2 PAN FINE
0~100% 000 - 255
23323TILT
0~100% 000 - 255
4 4 4 TILT FINE
0~100% 000 - 255
35535MOVEMENT SPEED
Fast to slow 000 - 255
6 6
MOVEMENT FUNCTION
Normal
Movement with backout
TBD
000 - 015
016 - 031
032 - 255
477
SHUTTER FUNCTION
Normal Shutter Functions
Pulse-eect Forward
Pulse-eect Reverse
Random strobe
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 255
588
SHUTTER
Normal Shutter Functions
Close
Strobe Rate (slow to fast)
Open
Pulse-eect Forward
Close
Strobe Rate (slow to fast)
Open
Pulse-eect Reverse
Close
Strobe Rate (slow to fast)
Open
Random Strobe
Close
Strobe Rate (slow to fast)
Open
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
000 - 031
032 - 223
224 - 255
4 6
SHUTTER
Shutter closed
No function (shutter open)
Strobe eect slow to fast
000 - 031
032 - 063
064 - 095

DIAMOND7
18
STAND EXT-1 EXT-2 BAS-8 BAS-16 FUNCTION DMX
Value
19 Ch 26 Ch 50 Ch 18 Ch 20 Ch
4 6
No function (shutter open)
Pulse-eect in sequences
No function (shutter open)
Random strobe eect slow to fast
No function (shutter open)
096 - 127
128 - 159
160 - 191
192 - 223
224 - 255
69957DIMMER
Dimmer (close to open) 000 - 255
7 10 10 6 8
VIRTUAL COLOR FUNCTION
On Function
CTC Function
Forward Spin
Reverse Spin
Continuous
Color Bounce
TBD
000 - 015
016 - 031
032 - 047
048 - 063
064 - 079
080 - 111
112 - 255
8 11 11 7 9
VIRTUAL COLOR 1
CTC Function
ColorTemperature Correction 2000K->2700K
White 3200K
White 4200K
White 5600K
White 8000K
Forward Spin
Rainbow Eect (Slow to Fast)
Reverse Spin
Rainbow Eect (Slow to Fast)
Continuous & Color Bounce
Black
Red
Green
Blue
White
Red=0, Green->up, Blue=full,White=0
Red=0, Green=full, Blue->down,White=0
Red->up, Green=full, Blue=0,White=0
Red=full, Green->down, Blue=0, White=0
Red=full, Green=0, Blue->up, White=0
Red->down, Green=0, Blue=full, White=0
000 - 223
224 - 231
232 - 239
240 - 247
248 - 255
000 - 255
000 - 255
000 - 000
001 - 001
002 - 002
003 - 003
004 - 004
005 - 046
047 - 088
089 - 130
131 - 172
173 - 214
215 - 255
9 12 12 8 10
VIRTUAL COLOR 2 (Only on Color Bounce)
Color Bounce
Black
Red
000 - 000
001 - 001
