ProLights ECLIPSEFRESNELJTW User manual

EN - IT
USER MANUAL
MANUALE UTENTE
LED FRESNEL PROIECTOR
ECLIPSEFRESNELJTW

All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be
reproduced in any form or by any means for any commercial use.
In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the
characteristics stated in this instruction manual at any time and without prior notice.
All revisions and updates are available in the ‘manuals’ section on site www.musiclights.it
REV.03-08/19

1
ECLIPSEFRESNELJTW
Packing content • ECLIPSEFRESNELJTW
• Power cable
• User manual
TABLE OF CONTENTS Safety
General instructions
Warnings and installation precautions
1 Introduction
1. 1 Description and specifications
1. 2 Technical specification
1. 3 Operating elements and connections
1. 4 ECLFRSJBP4
1. 5 operating elements and connections
2 Installation
2. 1 Mounting
3 Functions and settings
3. 1 Operation
3. 2 Basic
3. 3 Menu structure
3. 4 DMX mode
3. 5 DMX configuration
3. 6 Linking
3. 7 Screen
3. 8 Advanced
3. 9 Information
3. 10 Master/Slave
3. 11 Effects
3. 12 Static mode
3. 13 Manual mode
3. 14 Connection of the DMX line
3. 15 Construction of the DMX termination
3. 16 Channels DMX
4 Maintenance
4. 1 Maintenance and cleaning the unit
4. 2 Fuse replacement
4. 3 Trouble shooting
2
2
3
5
5
6
6
8
9
9
10
13
14
14
14
14
15
15
15
15
16
17
17
18
25
25
26

ECLIPSEFRESNELJTW
2
SAFETY
General instruction
• The products referred to in this manual conform to the European Community Directives and are there-
fore marked with .
• The unit is supplied with hazardous network voltage (230V~). Leave servicing to skilled personnel only.
Never make any modifications on the unit not described in this instruction manual, otherwise you will
risk an electric shock.
• Connection must be made to a power supply system fitted with efficient earthing (Class I appliance ac-
cording to standard EN 60598-1). It is, moreover, recommended to protect the supply lines of the units
from indirect contact and/or shorting to earth by using appropriately sized residual current devices.
• The connection to the main network of electric distribution must be carried out by a qualified electrical
installer. Check that the main frequency and voltage correspond to those for which the unit is designed
as given on the electrical data label.
• This unit is not for home use, only professional applications.
• Never use the fixture under the following conditions:
- in places wet;
- in places subject to vibrations or bumps;
- in places with a temperature of over 45 °C.
• Make certain that no inflammable liquids, water or metal objects enter the fixture.
• Do not dismantle or modify the fixture.
• All work must always be carried out by qualified technical personnel. Contact the nearest sales point for
an inspection or contact the manufacturer directly.
• If the unit is to be put out of operation definitively, take it to a local recycling
plant for a disposal which is not harmful to the environment.
Warnings and installation precautions
• If this device will be operated in any way different to the one described in this manual, it may suffer
damage and the guarantee becomes void. Furthermore, any other operation may lead to dangers like
short circuit, burns, electric shock, etc.
• Before starting any maintenance work or cleaning the projector, cut off power from the main supply.
• Always additionally secure the projector with the safety rope.When carrying out any work, always com-
ply scrupulously with all the regulations (particularly regarding safety) currently in force in the country
in which the fixture’s being used.
• Install the fixture in a well ventilated place.
• Keep any inflammable material at a safe distance from the fixture.
• Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent
that their effectiveness is impaired.
• The lamp (LED) shall be changed if it has become damaged or thermally deformed.
• Never look directly at the light beam. Please note that fast changes in lighting, e. g. flashing light, may
trigger epileptic seizures in photosensitive persons or persons with epilepsy.
• Do not touch the product’s housing when operating because it may be very hot.
• This product was designed and built strictly for the use indicated in this documentation. Any other use,
not expressly indicated here, could compromise the good condition/operation of the product and/or
be a source of danger.
• We decline any liability deriving from improper use of the product.
WARNING! Before carrying out any operations with the unit, carefully read this instruction
manual and keep it with cure for future reference. It contains important information about
the installation, usage and maintenance of the unit.

3
ECLIPSEFRESNELJTW
- 1 - INTRODUCTION
1.1 DESCRIPTION
ECLIPSEFRESNELJTW is an advanced LED replacement of traditional 650W Fresnel lamps, featuring 6
colour mixing delivering high precision reproduction of the white spectrum from 2.800K to 10.000K with
high CRI and an extensive colour reproduction.
The optical system harnesses the power of a 130W custom LED with 6 colours to create an even projec-
tion, beautiful colours and precise white, with added ability to apply +/- green and magenta correction
to match other sources of light.
Featuring HD dimming and tuning from 2.800K to 10.000K version with external battery capabilities,
the ECLIPSEFRESNELTW delivers the performance and quality of output demanded from this level of
luminaire.
1.2 TECHNICAL DESCRIPTION
LIGHT SOURCE
• Source: 130W 6 colour custom LEDs source (red, orange, cyan, royal blue, green, lime)
• CT: 2.800 K - 10.000K
• CRI: > 90
• R9: > 90
• Luminous flux: (15°) 1’637 lm - (51°) 2’700lm
• Lux: (15°) 2’067lx @3 m
• Lux: (51°) 421lx @3 m
• Source life expectancy: >50.000 h
OPTICS
• Zoom: 15 ° - 51° manual
• Field angle: 26,7° - 75,6°°
• Lens diameter: 6’’- 150mm
• Lens type: fresnel zoom lens
COLOUR SYSTEM
• Colour mixing: tunable white + colour
• CTC: CTC control through independent DMX channel, + / - green and magenta correction and amber
shift activation by DMX
• White presets: 2.800 K - 10.000K
• Colour wheel: virtual colour wheel with presets
• Macros: several pre-build macros with adjustable speed
DYNAMIC EFFECTS
• Static colour mode: selection of static colour
• Manual colour mode: manual adjustment of intensity, CT, colour correction from knob
• Auto mode: built-in programs with execution speed adjustment
• Special features: linear crossfade from a white to any color and CTO applied on colours
BODY
• Hardware on-board: included filter frame, 8 doors barndoor, omega bracket spigot
• Body: sturdy die-cast aluminium body conceived for long-time durability
• Body colour: black
CONTROL
• Protocols: DMX512, RDM, local knob
• DMX channels: 1 / 2 / 5 - 1 / 5 - 2 / 7 / 9 / 12 / 13 / 16 / 19 / 21channel

ECLIPSEFRESNELJTW
4
• RDM: RDM ready for fixture remote monitor and settings
• Display: black OLED high resolution display
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Other: 16bit control of dimmer and colour
ELECTRONICS
• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 different dimming curves available
• Strobe / shutter: 1 - 30 Hz, electronic
• Flicker: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
• Power supply: 100-240 V – 50/60 Hz
• Power consumption (at 230 V): 107W
• Power consumption (at 120 V): 111W
• Output (at 230 V): 23 units on a single power line
• Output (at 120 V): 12 units on a single power line
• Power factor: pF 0,99 @120 V - pF 0,95 @230 V
BATTERY
• Battery: 24 - 34V 4400 mAh (optional) external battery
• Re-charge connection: XLR 4p
PHYSICAL
• Cooling: combination of heat pipe cooling system and low noise fan
• Sospension and fixing: hanging bracket suitable for safe hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• IP rating: 20
• Dimensions (WxHxD): 235x360x260mm
• Weight: 6kg
Fig.1 - Technical drawing
360
260235

Fig.2
6
55
11
3
4
2
710
8
11
9
12 13
5
ECLIPSEFRESNELJTW
1.3 OPERATING ELEMENTS AND CONNECTIONS
1. AIR OPENING
2. LOCKING KNOB for mounting bracket
3. MOUNTING BRACKET
4. TRACK-ADAPTER(optional)
5. HANDLE
6. CONTROL PANEL with display and 4 button
used to access the control panel functions
and manage them
7. FOCUS AND ZOOM ADJUSTING SCREW to
zoom the projected image clearly
8. MAIN FUSE HOLDER: replace a burnt-out fuse
by one of the same type only
9. BATTERY 4 pin-in
10. POWER IN (PowerCON IN): for connection to a
socket (100-240V~/50-60Hz) via the supplied
mains cable.
11. DMX IN (5-pole XLR): 1 = ground, 2 = DMX-, 3
= DMX+, 4 N/C, 5 N/C
12. DMX OUT (5-pole XLR): 1 = ground, 2 = DMX-,
3 = DMX+, 4 N/C, 5 N/C
13. POWER OUT (PowerCON OUT): power output
for connection of multiple units in series.

ECLIPSEFRESNELJTW
6
Fig.4
1
3
8
5
47
4
3
2
10
9
6
442
175
368
Fig.3
1.4 ECLFRSJBP4
Battery pack kit for EclipseFresnelJ series, composed by ABS case, 4 pcs battery, 1 pc charger, 4 pcs male-
male cable and 4 pcs male-female cables.
BATTERY TECHNICAL SPECIFICATIONS
• Estimated battery life in single colour mode up to: (R) 8 h - (G) 8 h - (B) 7 h - (L) 3 h - (O) 4 h - (RB) 7h
• Estimated battery life in full-mode up to: (TW) 1,25 h - (TU, DY) 1,5h
• Re-charge time: 5h/max
1.5 OPERATING ELEMENTS AND CONNECTIONS
1. ABS case
2. CHARGER
3. CHARGER OUT
4. Button to start charging
5. MAIN FUSE HOLDER: replace a burnt-out
fuse by one of the same type only
6. POWER IN (PowerCON IN): for connection to
a socket (100-240V~/50-60Hz) via the supplied
mains cable.
7. SWITCH
8. Charger status LED: if it is red, the battery is
charging, if it is green, the battery is charged.
9. BATTERY
10. Battery status LED

7
ECLIPSEFRESNELJTW
Fig.5
Fig.6
MOUNTING
Holes
DMX cable male-female
DMX cable male-male
CORRECT WRONG
IMPORTANT: do not connect this charger directly to the ECLIPSEFESNELJ, please connect this charger only
with the battery as power charger.

Fig.7
A
B
ECLIPSEFRESNELJTW
8
- 2 - INSTALLATION
2.1 MOUNTING
ECLIPSEFRESNELJTW may be set up on a solid and even surface. The unit can also be mounted upside
down to a cross arm. For fixing, stable mounting clips are required. The mounting place must be of suffi-
cient stability and be able to support a weight of 10 times of the unit’s weight.
When carrying out any installation, always comply scrupulously with all the regulations (particularly re-
garding safety) currently in force in the country in which the fixture’s being used.
• Install the projector at a suitable location by means of the mounting bracket (1).
• Always additionally secure the projector with the safety rope from falling down. For this purpose, fas-
ten the safety rope at a suitable position so that the maximum fall of the projector will be 20 cm.
• Adjust the projector and use the knob (2) to slightly release or tighten the locking mechanism of the
bracket if is necessary.

9
ECLIPSEFRESNELJTW
- 3 - FUNCTIONS AND SETTINGS
3.1 OPERATION
Connect the supplied main cable to a socket (100-240 VAC-50/60 Hz). Then the unit is ready for operation
and can be operated via a DMX controller or it independently performs its show program in succession.
To switch off, disconnect the mains plug from the socket. For a more convenient operation it is recom-
mended to connect the unit to a socket which can be switched on and off via a light switch.
3.2 BASIC
Access control panel functions using the four panel buttons located directly underneath the LED Display
(fig.8).
MENU UP DOWN ENTER
Used to access the menu or
to return a previous menu
option
Navigates downwards through
the menu list and increases
the numeric value when in a
function
Navigates upwards through
the menu list and decreases
the numeric value when in
a function
Used to select and store the
current menu or confirm the
current function value or
option within a menu
Fig.8- Functions of the buttons

MENU
1CONNECT ðDMX Address ðValue (001-512) Default: 001
DMX Mode ð
1CH ðAmber Shift on
Default: 19CH
Color
Temperature ðCTO 2800 - 10000K
Hue (025~025)
Default: 2800K
Color Picker ð3200K
71
97
100
...
777
Default: 3200K
Customization ðRed (000~255)
Orange (000~255)
Green (000~255)
Royal Blue (000~255)
Blue (000~255)
Lime (000~255)
Default: 255
2CH ðAmber Shift on
Color
Temperature ðCTO 2800 - 10000K
Hue (025~025)
Default: 2800K
Color Picker ð3200K
71
97
100
...
777
Default: 3200K
Customization ðRed (000~255)
Orange (000~255)
Green (000~255)
Royal Blue (000~255)
Blue (000~255)
Lime (000~255)
Default: 255
5CH1
5CH2
7CH1
7CH2 ðColor Picker ðNo Action
3200K
71
97
100
...
777
8CH
9CH
12CH
13CH
16CH
19CH
21CH
2SETUP ðScreen ðBack Light ðOn
10 s
20 s
30 s
Default: 10 s
Flip Display ðNo-Yes Default: No
Key Lock ðNo-Yes Default: No
ECLIPSEFRESNELJTW
10
3.3 MENU STRUCTURE

3ADVANCED ðFull On Mode ðHB
Studio
Default: Studio
Dimmer Mode ðOff
Dimmer 1
Dimmer 2
Dimmer 3
Default: Off
White Balance ðOff
Adjust ðRed (125~255)
Orange (125~255)
Green (125~255)
Royal Blue (125~255)
Blue (125~255)
Lime (125~255)
Default: Off
Led Frequency ð 600Hz
1200 Hz
2000 Hz
4000 Hz
6000Hz
25kHZ
Default: 1200Hz
Fan Mode ðAuto
On
Off
Silent
Default : Auto
Factory Reload ðNo-Yes No-Yes Default: No
4INFORMATION ðFixture TIme ð0-9999
Version ðV1.0
UID ð15D0021F****
5STAND ALONE ðMaster/Slave ðMaster
Slave
Default : Slave
Effects ðEffect1
Effect2
Effect3
Effect4
ð(1~100) Default: Effect4
Speed=100
CCT
HSI
Color Tempera-
ture ð2800K
3000K
3200K
3400K
3600K
3800K
4000K
4200K
4400K
4600K
4800K
5000K
5200K
5400K
5600K
5800K
6000K
6200K
6400K
6800K
7000K
7200K
7400K
7600K
7800K
8000K
8200K
8400K
8600K
8800K
9000K
9200K
9400K
9600K
9800K
10000K
ðDimmer (000~255)
Hue (025~025)
Default : 6000K
Dimmer=255
Hue=0
11
ECLIPSEFRESNELJTW

Fixed Color ð R
O
G
RB
B
L
R.0
R.G
R.RB
R.B
R.L
O.G
O.RB
O.B
O.L
G.RB
G.B
G.L
RB.B
RB.L
B.L
R.O.G
R.O.RB
R.O.B
R.O.L
R.G.RB
R.G.B
R.G.L
R.RB.B
R.RB.L
R.B.L
O.G.RB
O.G.B
O.G.L
O.RB.B
O.RB.L
O.B.L
G.RB.B
G.RB.L
G.B.L
RB.B.L
R.O.G.RB
R.O.G.B
R.O.G.L
R.O.RB.B
R.O.RB.L
R.O.B.L
R.G.RB.B
R.G.RB.L
R.G.B.L
R.RB.B.L
O.G.RB.B
O.G.RB.L
O.G.B.L
O.RB.B.L
G.RB.B.L
R.O.G.RB.B
R.O.G.RB.L
R.O.G.B.L
R.O.RB.B.L
R.G.RB.B.L
O.G.RB.B.L
R.O.G.RB.B.L
ðDimmer (000~255) Default:
R.O.G.RB.B.L
Dimmer=255
Color Picker ð 3200K
71
97
100
101
102
103
104
105
106
107
110
111
113
115
116
117
118
119
120
121
122
124
126
128
130
132
134
135
136
137
138
139
141
144
147
151
152
156
157
158
161
164
165
166
170
174
179
180
181
182
195
197
198
200
201
202
203
204
205
206
702
730
777
ðDimmer (000~255) Default: 3200K
Manual Color ð Red
Orange
Green
Royal Blue
Blue
Lime
ð(000~255) Default:
RGBW=255
ECLIPSEFRESNELJTW
12

13
ECLIPSEFRESNELJTW
3.4 DMX MODE
• To set the DMX address, press the button MENU so many times until the display shows Connect, then
select throught the buttons UP/DOWN Dmx Address, then press the button ENTER.
• Press UP/DOWN button to select the desired value (001-512). Press and hold to scroll quickly.
• Press ENTER button to store.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.
To operate the ECLIPSEFRESNELJTW with a light controller, adjust the DMX start address for the first a
DMX channel. For example, If the controller is provided with to command the function of the first DMX
channel, adjust the start address 33 on the ECLIPSEFRESNELJTW. The other functions of the light effect
panel are then automatically assigned to the following addresses.
An example with the start address 33 is shown below:
DMX Address: 48DMX Address: 38DMX Address: 33 DMX Address: 43
Fig.9 - Example 5 DMX channels configuration
DMX512 Controller
Number of
DMX channels
Start address
(example)
DMX Address
occupied
Next possible start
address for unit No. 1
Next possible start
address for unit No. 2
Next possible start
address for unit No. 3
1 33 33 34 35 36
2 33 33-34 35 37 39
5 33 33 - 37 38 43 48
7 33 33 - 39 40 47 54
8 33 33 - 40 41 49 57
9 33 33 - 41 42 51 60
12 33 33 - 44 45 57 69
13 33 33 - 45 46 59 72
16 33 33 - 48 49 65 81
19 33 33 - 51 52 71 90
21 33 33 - 53 54 75 96
. . . . . . . . . . . .

ECLIPSEFRESNELJTW
14
3.5 DMX CONFIGURATION
ECLIPSEFRESNELJTW has several DMX channel configurations that can be accessed from the control panel.
• Press the button MENU so many times until the display shows Connect, then select throught the buttons
UP/DOWN DMX Channel, then press the button ENTER.
• Select the desired DMX configuration (1CH, 2CH, 5CH1, 5CH2, 7CH1, 7CH2, 9CH, 12CH, 13CH, 16CH, 19CH, 21CH)
through the buttons UP/DOWN.
3.6 LINKING
1. Connect the DMX OUT output of the main unit to the DMX IN input of the first secondary unit using a
5-pin XLR cable.
2. Connect the DMX OUT output of the first secondary unit to the DMX IN input of the second secondary
unit, etc.
3.7 SCREEN
It is possible to modify the following parameters, related to the display, following the same procedure:
• Press the button MENU to enter the menu mode.
• Press UP/DOWN button to scroll through the menu, select Set Up, then press the ENTER button to access
the next menu.
• Press UP/DOWN button to select Screen and press the ENTER button to proceed.
• Select the proposed option and press the ENTER button to confirm.
-Backlight - Auto Off display backlight. This function allows you to switch off automatically the back-
lighting of the display after a certain time which can be set using the directional keys. To have the
display always on select On or set a value between those shown (10s, 20s, 30s) to turn off the display
once the chosen time has elapsed, after exiting the menu.
-Flip Display - Display orientation. This feature allows you to rotate the display by 180 ° to get a better
view of the display when the unit is hanging upside down. Select Yes to activate the function, No to
deactivate it.
-Key lock - With this function, you can lock the keys on the control panel to prevent, for example, tam-
pering with the settings. If this function is activated, the keys are locked automatically. To disable or
temporarily disable or disable the key lock function, press the keys in the following order to regain
access to the menu commands: UP, DOWN, UP, DOWN, ENTER. Select Yes to activate the function or
No to deactivate it.
• Press the ENTER button to confirm the selection.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.
3.8 ADVANCED
You can change the parameters for the device by following these steps:
• Press the button MENU to enter the menu mode.
• Press UP/DOWN button to select the Advanced. Press the ENTER button to confirm.
• Press UP/DOWN button to select the desired option and press the ENTER button to confirm:
- Full On Mode - Select the Full on Mode function to set the HB mode (High Brightness Mode, with the
- maximum value of the colours) or Studio mode with a automatic white balance.
- Dimmer Mode - Adjusting the dimmer. Enter in Dimmer Mode to select specific dimming curve.
Particularly when set:
• Off: The increase in light intensity is linear.
• Dimmer 1: dimmer curve with low fade.
• Dimmer 2: dimmer curve with medium fade.

15
ECLIPSEFRESNELJTW
• Dimmer 3: dimmer curve with high fade.
- White Balance - To balance the white on each colour. Select the colour (Red, Orange, Green, Royal Blue,
Blue and Lime) and the value (125 ~ 255) using the UP / DOWN button and press the ENTER button to
confirm.
- LED Frequency - To adjust the frequency of the LEDs. Select the frequency 600 Hz ~ 25 KHz using the UP /
DOWN button and press ENTER to confirm the selection.
- Fan Mode - Fan Speed. Select the fan speed (Auto, On, Off, Silent) using the UP / DOWN button.
- Factory Reload - To reset the unit. Select Yes or No and select the UP / DOWN button to confirm.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.
3.9 INFORMATION
To view all the information on the device, proceed as follows:
• Press the button MENU to enter the menu mode.
• Press UP/DOWN button to select Information, then press the ENTER button to access the next menu.
• Press UP/DOWN button to scroll through the menu, then select one of the following informationa and
press the ENTER button to display it.
- Fixture Time - To view the operating time of the projector.
- Software Version - To view the firmware version will show on the display.
- UID - To view the identification ID for the RDM control.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.
3.10 MASTER/SLAVE MODE
This mode will allow you to link up the units together without a controller. The first unit will be set as mas-
ter and other units will work as slave with the same effect.
• Press the button MENU so many times until the display shows Stand Alone, then select throught the
buttons UP/DOWN Master/Slave, then press the button ENTER.
• Press UP/DOWN and select the Master/Slave mode to set the unit as master or slave (Master, Slave).
• Use the ECLIPSEFRESNELJTW DMX connectors and an XLR cable to form a drive chain. In certain condi-
tions and lengths, it is recommended to terminate as shown on page 18.
3.11 EFFECTS
This fixture has a built-in automatic program. To access this, please see the below instructions:
• To enter the Effects mode, press the ENTER button to access the menu.
• Press UP/DOWN button to select Stand Alone, then select Effect. Press ENTER to confirm
• Press UP/DOWN button to select the desired program Effect 1, Effect 2, Effect 3, Effect 4, Effect 5 then press
ENTER to confirm.
• Set the value (1 - 100), then press the ENTER button to confirm.
3.12 STATIC MODE
This fixture has the ability to accept custom static color settings. Access these chases via the control panel
on the back of the fixture.
• Press the MENU button so many times until the display shows Stand Alone, then press the ENTER button.
• Select Fixed Color through the UP/DOWN buttons, then press the ENTER button.
• Set the colors R , O, G, W, RB, B, L, R.O.G.RB.B.L... R.G.RB.B.L, O.G.RB.B.L, R.O.G.RB.B.L through the UP/DOWN but-
tons, then press the ENTER button.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.

ECLIPSEFRESNELJTW
16
3.13 MANUAL MODE
To set the customized balance of red, orange, green, royal blue, blue and lime colors, refer to the following
procedure:
• Press the button MENU so many times until the display shows Stand Alone, then select throught the
buttons UP/DOWN Static, then press the button ENTER.
• Select Manual Color Mixer through the buttons UP/DOWN, then press the button ENTER.
• Select the color Red, Orange, Green, Royal Blue, Blue, Lime through the buttons UP/DOWN, then press the
button ENTER.
• Using UP/DOWN button, select the desired color value 000 ~ 255.
• Press ENTER button to continue to the next color Red, Orange, Green, Royal Blue, Blue, Lime.
• Continue until the desired mix is obtained.
• Press the MENU button to go back or to meet the waiting time to exit the setup menu.

17
ECLIPSEFRESNELJTW
Fig.10
Fig.11
3.14 CONNECTION OF THE DMX LINE
DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω imped-
ance and low capacity.
The following diagram shows the connection mode:
ATTENTION
The screened parts of the cable (sleeve) must never be connected to the system’s earth, as this would
cause faulty fixture and controller operation.
Over long runs can be necessary to insert a DMX level matching amplifier.
For those connections the use of balanced microphone cable is not recommended because it cannot
transmit control DMX data reliably.
• Connect the controller DMX input to the DMX output of the first unit.
• Connect the DMX output to the DMX input of the following unit. Connect again the output to the input
of the following unit until all the units are connected in chain.
• When the signal cable has to run longer distance is recommended to insert a DMX termination on the
last unit.
3.15 CONSTRUCTION OF THE DMX TERMINATION
The termination avoids the risk of DMX 512 signals being reflected back along the cable when they reach-
es the end of the line: under certain conditions and with certain cable lengths, this could cause them to
cancel the original signals.
The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the 5-pin male XLR
connector, as shown in figure.
DMX - OUTPUT
XLR socket
DMX - INPUT
XLR plug
Pin1 : GND - Shield
Pin2 : - Negative
Pin3 : + Positive
Pin4 : N/C
Pin5 : N/C
Example:
5 pin XLR connector

1 CHANNEL
MODE FUNCTION DMX
Value
1 Ch
1DIMMER
0~100% 000 - 255
2 CHANNELS
MODE FUNCTION DMX
Value
2 Ch
1DIMMER
0~100% 000 - 255
2
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer speed mode off
Dimmer speed mode1 (fast speed)
Dimmer speed mode2 (middle speed)
Dimmer speed mode3 (slow speed)
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
5 CHANNELS 1
MODE FUNCTION DMX
Value
5 Ch1
1DIMMER
0~100% 000 - 255
2
CTO
2800K - 3000K
3000K - 3200K
3200K - 3400K
3400K - 3600K
3600K - 3800K
3800K - 4000K
4000K - 4200K
4200K - 4400K
4400K - 4600K
4600K - 4800K
4800K - 5000K
5000K - 5200K
5200K - 5400K
5400K - 5600K
5600K - 5800K
5800K - 6000K
6000K - 6200K
6200K - 6400K
6400K - 6600K
6600K - 6800K
6800K - 7000K
7000K - 7200K
7200K - 7400K
7400K - 7600K
7600K - 7800K
7800K - 8000K
8000K - 8200K
8200K - 8400K
8400K - 8600K
8600K - 8800K
8800K - 9000K
9000K - 9200K
9200K - 9400K
9400K - 9600K
9600K - 9800K
9800K - 10000K
000 - 007
007 - 014
014 - 021
021 - 028
028 - 035
035 - 042
042 - 049
049 - 056
056 - 063
063 - 070
070 - 077
077 - 084
084 - 091
091 - 098
098 - 105
105 - 112
112 - 119
119 - 126
126 - 133
133 - 140
140 - 147
147 - 154
154 - 161
161 - 168
168 - 175
175 - 182
182 - 189
189 - 196
196 - 203
203 - 210
210 - 217
217 - 224
224 - 231
231 - 238
238 - 245
245 - 255
3
HUE
0
-25°~25°
000 - 000
001 - 255
4
COLOR MACRO
No Function
Amber Shift on
Color Macro
000 - 002
003 - 005
006 - 255
5
DIMMER SPEED MODE
Preset dimmer speed from display menu
Dimmer speed mode off
Dimmer speed mode1 (fast speed)
Dimmer speed mode2 (middle speed)
Dimmer speed mode3 (slow speed)
000 - 051
052 - 101
102 - 152
153 - 203
204 - 255
ECLIPSEFRESNELJTW
18
3.16 DMX CHANNELS
