PROLiNK Hurricane 8800P User manual

USER'SManual
Version2.0
Hurricane8800P
ADSLBridge/Router

1
Contents
SectionOne-Introduction........................................................................ 3
1.1SystemRequirements................................................................................................................3
1.2FeaturesSummary.....................................................................................................................3
1.3EquipmentPerformance...........................................................................................................4
1.3.1ATMlayer...................................................................................................................4
1.3.2Protocols....................................................................................................................4
SectionTwo-ConnecttheBridge/Router................................................. 6
2.1ThisPackagecontents..............................................................................................................6
2.2ProductView............................................................................................................................7
2.3HardwareInstallation..............................................................................................................8
2.4NetworkConnections..............................................................................................................9
2.4.1forfourPCs............................................................................................................................9
2.4.2formorethanfourPCs.........................................................................................................9
SectionThree -ConfigurethePCs........................................................ 10
3.1specifyanstaticIPforyourcomputer. ................................................................................ 10
3.2VerifythelinkbetweenyourPCandRouter..................................................................... 12
SectionFour-ConfiguretheBridge/Router.......................................... 13
4.1.DescriptionofWebconfiguration. ...................................................................................... 13
4.2.HowtoConfigureyourrouter............................................................................................ 14
4.2.1PPPoARoutedConfiguration. ............................................................................ 16
4.2.2PPPoERoutedConfiguration. ............................................................................. 20
4.2.3RFC1483 RoutedConfiguration. ....................................................................... 23
4.2.4IPoARoutedConfiguration. ................................................................................. 26
4.3HowtoConfigureDHCPServer. ....................................................................................... 27
4.4HowtosetPortForwarding. .............................................................................................. 28
4.5HowtoletNetmeetingpass through. .............................................................................. 29
4.6HowtoConfigureBridgeMode. ........................................................................................ 30
4.7HowtoRestoretotheFactoryDefault. ........................................................................... 31
AppendixA-Troubleshooting................................................................. 32
AppendixB-HighProtocols................................................................... 34
AppendixC-Acronyms........................................................................... 37
AppendixD-EMCandSafety................................................................. 38
AppendixE-TelecomNotices.................................................................. 39

2
Theinformationcontainedinthismanualhasbeenverifiedatthetimeofthismanual's
printing.Themanufacturerreservestherighttomakeanychangesandimprovements
intheproductdescribedinthismanualatanytimeandwithoutnotice.
All registeredtrademarksarethepropertyoftheirrespectiveowners.
Copyright©2002Allrightsreserved.Noreproductionofthisdocumentinanyform
ispermittedwithoutpriorwrittenauthorizationfromthemanufacturer.

3
SectionOne-Introduction
TheHurricane8800PprovidesFull rate(ANSIandG.DMT)aswell asG.
liteADSLstandardslinesupport,andcanbeconnectedtoPCthrough
Ethernet.Thisproductsupportsbridgefeaturesetfortheintegrationof
ADSLserviceintocorporateorhomeLANandWAN.
1.1SystemRequirements
BeforeconnectingtheHurricane8800PtoyourPC,makesureyour
sysytemisequippedwiththeEthernetNICcardandTCP/IPprotocol.
1.2FeaturesSummary
ADSLSupport•ANSI(T1.413 Issue2)
•G.dmt(ITUG.992.1)
•G.lite(ITUG.992.2)
•G.hs(ITUG.994.1)
•Powercutback(G.liteonly)
LANSupport• IEEE 802.310/100 Base-TbandCSMA/CD
ATMSupport•ATMsignalingUNI3.1&4.0
•MultipleProtocoloverAAL5 (RFC1483 )
•AAL0,AAL2,AAL5
•VCandLLCbasedMultiplexing
•ATMServiceClass:UBR/VBR/CBR
•VCs
BridgingSupport•Transparentbridging(RFC1483)support
SectionOne:Introduction

4
SectionOne:Introduction
1.3EquipmentPerformance
1.3.1ATMlayer
Theequipmentwill befullycompatiblewiththeshowedonthefigure1of
theANSIT1.413-1998
1.Adaptationlayer
ThemodemwillimplementtheadaptationlayerAAL5,asrequestedbythe
recommendationITUI.363.5
2.VCs
Supportfornon-zeroVPIsislimittoPVCsonly.Thefull VPIrange(0~4095)
issupported.Thefull VCIrange(1~65536)issupported.Low-numbered
VCIsonVPI0arelookedup.
3.Serviceclass
Themodemwill support:CBR,UBR,rt-VBR,nrt-VBR
4.OAMstreams
ThemodemsupportsOAMF5stream.
5.ATMsignaling&ILMI
ThemodemsupportsATMFormun UNI3.0,3.1,UNI4.0&IISPsignaling
basedonUNI3.0orUNI3.1usingSSCOPasadatatransport.The
implementationofILMIisbasedontheATMForum'sILMIv4.0specification.
1.3.2Protocols
1.Bridge
Itprovidesatransparentandaspanning-tree bridge.
2.RFC1483 bridged
TheRFCinuseisthe2684,,the1483 and2684 areadmittedforLLC
encapsulationandVCmultiplexingforbridgedtraffic.

5
3.PPPoErelay
ItisusedtotransportPPP trafficoverEthernet.
4.PPPoEthernetclient(RFC2516)
AuthentificationissupportedbyPAP&CHAPprotocols.TheRFC2516
supportsformultiplePVCs,witheachVCsupportingasinglePPPoEsession
(differentISPsoverdifferentPVCs)
5.BOOTP/TFTPclient
SystemscanbebootedoverEthernetusingBOOTP/TFTP.Oncethereis
arunningimageontheASSP,theimagesand/orconfigurationstoredinflash
canbeupdatedusingTFTP.
6.TELNETserver
Themodemprovidesasimpletelnetserverthatallowsadministrative
access totheplatformoverTCP/IP.Theimplementationsupportsonlya
singlesessionatatime.
SectionOne:Introduction

6
SectionTwo:ConnecttheBridge/Router
SectionTwo-ConnecttheBridge/Router
2.1ThisPackagecontents
1.ADSLBridge/Router
2.RJ-45 straightcable
3.RJ-11 telephonecable
4.RS-232 cable
5.5VDCPowerAdaptor
6.CDwithConfigurationTools
7.User'sManual
Foranymissingitems,Pleasecontactyourdealerimmediately.
1.
2
3
4
5.
6.&7.

7
PowerLED(Inredcolor)
LightONoncedetected.
ADSLLED(Ingreencolor)
LightONwhentheconnectionisON.
LANLEDx4(Ingreencolor)
Keepson,Lightblinksduringdatatransfer
LineJack
ForRJ-11,toconnecttoADSLLine
PowerConnector
LANConnectors
ForRJ-45,toconnecttoPCs/HUB
ConsolePort
ForRS-232,toconnecttoSerialPort
ResetButton
2.2ProductView
SectionTwo:ConnecttheBridge/Router

8
2.3HardwareInstallation
Thefollowingstepsinstructyoutoinstall theHurricane8800Pforone
computer.formorethanfourcomputers,pleasereferto2.4Network
Connection.
1.Turnoff thecomputer.
2.PlugtheendoftheEthernetcableintoanyoneconnectormarked12
34atthebackoftherouter.
3.PlugtheotherendoftheEthernetcableintoyourcomputer'sRJ45jack
ofEthernetcard.
4.ConnecttheACPoweradaptortotheJack.
5.Plugthetelephonecableintotheconnectormarkedatthebackof
therouter.
6.PlugtheotherendofthetelephonecableintoaPhoneSocket.
SectionTwo:ConnecttheBridge/Router
PowerAdaptor
Microfilter
RJ-11 Cable
StraightRJ-45 Cable
StraightRJ-45 Cable
MainPhoneSocket

9
2.4NetworkConnections
2.4.1forfourPCs
2.4.2formorethanfourPCs
SectionTwo:ConnecttheBridge/Router
ADSLRJ-11
RJ-45
RJ-45
RJ-45
RJ-45
StraightCabletoUplinkport
orCross Cabletonormalport
RJ-45
ADSL
RJ-11
RJ-45
HUB/SWITCH
RJ-45

10
SectionThree -ConfigurethePCs
Theinstructionsinthissectionwill helpyouconfigureeachofyour
computerstobeabletocommunicatewiththeRouter.
Todothis,youneedtoconfigureyourPC’snetworksettingstoobtainan
IPaddress orgetitautomaticallyfromtheDHCPoftherouter.Computers
useIPaddressestocommunicatewitheachotheracross anetwork,such
astheInternet.
3.1specifyanstaticIPforyourcomputer.
•SetIPAddress to192.168.101.X(X:2~254)
•SetSubnetMaskto255.255.255.0
•Add Gatewayto192.168.101.1
•DNSServertoLocalDNS(e.g.165.21.83.88)
ForWindows95/98/ME
ControlPanel>Network>TCP/IPofyourLANcard
SectionThree:ConfigurethePCs

11
ForWindowsXP
1.ClicktheStartbuttonandthenControlPanel.Fromthere,clickthe
NetworkandInternetConnectionsicon.ThenclicktheNetwork
Connectionsicon.
2.SelecttheLocalAreaConnectioniconfortheapplicableEthernet
adapterDouble-clicktheLocalAreaConnection.ClicktheProperties
button.
SectionThree:ConfigurethePCs

12
3.2VerifythelinkbetweenyourPCandRouter
a)Fromstart>Run
b)Enterping192.168.101.1–tandclickOK
c)Iftheconnectionhasbeenestablished,Youwill receivereplyfrom
therouter.
d)Ifyoureceive“Requesttimedout”,thatmeansthelinkhasnotbeen
established,pls.checkthenetworkcableandIPaddress.
NOTES:
1.YoumayhavetodisabletheproxysettingsonyourInternetbrowser
.Tools>InternetOptions>Connection>LANsettings>DisableProxy
Server
2.Makesurethatyourbrowserissettoconnectdirectly.
ForInternetExplorer,clickTools,InternetOptions,andthenthe
Connectiontab.MakesurethatInternetExplorerissettoNeverdiala
connection.
ForNetscapeNavigator,clickEdit,Preferences,Advanced,andProxy
MakesurethatNetscapeNavigatorissettoDirectconnectiontothe
Internet.
SectionThree:ConfigurethePCs

13
SectionFour:ConfiguretheBridge/Router
SectionFour-ConfiguretheBridge/Router
4.1.DescriptionofWebconfiguration.
1)OpenInternetExplorer,typehttp://192.168.101.1
2)Thesystemwill remindyoutoenteradministrator’susernameand
passwordwhenrestartingorconfiguring.Itisillustratedinthefollowing
figure.
Defaultusername:admin
password:admin

14
3)Therearefourmainmenusintheleftcolumn:
“Status”tothecurrentstatusofeverysetting,includingIPofport,
connectionstatusofport,andstatusofWANport,LANport,
hardwareanddefinitionport.
“System”toshowinformationoftheADSLRouter,including
ErrorLog,UpgradeandRestart(tofactorydefault)
“Configuration”tosettheparametersaccordingtoyouroperating
system.
•SaveConfigtoclickSavebuttonandwaituntilitfinishes.
•Authenticationtocheckcurrentuserinformationandcreate
newuser.
•LANConnectiontochangedefaultLANportaddress.
•WANConnectiontocheck,editanddeletecurrentWAN
portconfigurationorcreatenewroutingmodeandbridging
mode.
•SNTPClienttosetSNTP(SimpleNetworkTimeProtocol)
•SecuritytosetNAT,Portforwarding,DMZandfirewall .
“ADSL”tochecktheattributionofADSLlevel.
4.2.HowtoConfigureyourrouter
Youcanconfigureyourrouteraseitheroneofthefollowingmodes:
Routingmode
üRFC1483 Routed
üPPPoERouted
üIPoARouted
üPPPoARouted
SectionFour:ConfiguretheBridge/Router

15
Bridgingmode
üRFC1483 Bridged
üPPPoERelayBridged
PleasekindlycheckwithyourlocalISP,selectoneoftheabovemodesto
configureit.
TheInformationinthescreenshotsinthismanualisasexamples
only,youarerequiredtoreplacethesevalueswiththoseprovided
byyourADSLInternetServiceProvideroryourSystem
Administrator!
NOTE:Youhavetodeletetheexistentwanconnectionbefore
configuringanewone.
1)SingNetandPacificInternet:PPPoAorPPPoE
2)MagixATMplan(StaticIP):RFC1483 Routed
SectionFour:ConfiguretheBridge/Router

16
4.2.1PPPoARoutedConfiguration.
A.ClickRoutermodeunderConfigurationandchoosePPPOArouted.
ClickConfigureandtheinterfaceshowsasbelow.
SectionFour:ConfiguretheBridge/Router

17
•Description:NameoftheWANconnection.(e.g.SingNet
•VPI/VCI:ATMVCoflocalISP(remote)
(e.g.forSingapore,VPI=0,VCI=100)
•WANIPAddress/WANSubnetMask:IPandSubnetMask
dynamicallyallocatedbyyourISP.
0.0.0.0(Default)
255.255.255.0(Default)
•LLCHeaderMode:off (Default)
•HDLCHeaderMode:off (Default)
•ChooseCHAP
•UsernameandPassword:Theusernameandpasswordwill
beprovidedbyyourISPwhenapplyingforADSLservice.(e.g.
prolink@singnet)
ClickConfiguretocomplete
B.NATConfiguration.
ClickSecurityandtheinterfaceshowsasbelow.ChooseEnableunderSecurity
StateandclickChangeState
SectionFour:ConfiguretheBridge/Router

18
Clickadd InterfaceunderSecurityInterface
Add WANInterface
•Name:selectthenameofWANPort(e.g.ppp-0)
•InterfaceType:Chooseexternal
ClickApplyandWANInterfaceisadded.
Add LANInterface
•Name:SelectthenameofLANport(e.g.eth0orip1)
•InterfaceType:Chooseinternal
ClickApplyandLANInterfaceisadded.Thescreenwill showthefollowing
interface.
SectionFour:ConfiguretheBridge/Router

19
ClickEnableNATtointernalinterfacesandtheconfigurationofPPPoARouter
modehasbeendone.
NOTE:Pleaseremembertosavetheconfigurationafterfinishingthe
settings.
SectionFour:ConfiguretheBridge/Router
