ProMeister PT7704 User manual

User Guide
COB LED Inspection Hand Light
Produced in China for
Bileko Car Parts AB
P.O. Box 542
S-645 25 Strängnäs, Sweden
Tel: [phone]
www.promeister.com
Art. Nr: PT7704
RVNR-01

Operating Instructions Operating & Charging Procedure
With the following instructions, we would like to help you to get the best functions of your new light.
Keep this instruction manual for future reference or for subsequent possessors.
• Operating mode as below
- Press the Switch first time, top light switch on.
- Press the Switch second time, top light switch off.
- adjust the stepless switch to change brightness of the whole light.
• Switch lamp off and connect with USB charger when charging.
• The battery indicator will blink during charging.
• All the battery indicator will stay lighting up after finsihed charging.
• If the battery indicator did not light up, please remove the charger and try again.
• The use of a NON-recommended charger can lead to a fire and destroy the lamp.
• Before taking the hand lamp into service for the first time, charge it for 4-5 hours.
• Fully charge the hand lamp before it is stored for a longer period.
• Do not use the device if there is damage to the housing, plug or cable. Consult your local
authorized specialist.
• Do not open the device. Repair work and replacing the rechargeable battery pack may only be
carried out by electricians.
• Carry out cleaning tasks only when the main plug is removed from the main power.
• There is a risk of short-circuit. Repairs on the device may only be carried out by commissioned and
trained persons. Please contact your nearest authorized branch.
• Protect the battery against heat, e.g., against continuous intense sunlight, fire, water, and moisture.
Danger of explosion.
• If the battery is damaged or not used correctly, fluids can leak from it. Avoid contact with these.
Leaking battery fluids can lead to skin irritation or burns. Rinse off with water if you should come
into contact. If the fluid gets into your eyes, make sure you get medical help.
• The lamp is not allowed to be placed on the light surface while being used.
• The device should not be discarded in the normal household waste under any circumstances.
• Dispose of the device via an authorized disposal center or your communal waste disposal facility.
Observe the current applicable regulations. Contact your waste disposal facility in the event of
any doubt. Dispose of all packaging materials via an environmentally friendly disposal facility.
Rechargeable batteries must not be disposed of in the household waste. Return use rechargeable
batteries to your dealer or hand them into a battery collection facility.
• Do not open the device.
• Do not look directly into the light emitting lamp - Risk of eye injuries!
• Do not operate under direct sunlight or extreme temperature conditions.
• Keep away from children. Children should be supervised in order to insure that they do not play
with the device.
Light Source High Power COB LED - main light
High Power SMD LED - top light
Luminous Power ca. 60-700 lumen - main light (min-max)
ca. 120 lumen - top light
Operating Time ca. 16.5-1.4H - main light (full power mode)
ca. 10H - top light
Battery Specification Li-ion 3.7V, 2600 mAh, 9.62Wh
Charging Time ca. 4H 15Min
Charging Input DC 5V 1A
Degree of Protection IP 54, IK 07
Operating Temperature -10°C to +40°C
Technical Data
Safety Instruction
Environmental Protection
Warning
