promethean Promethean PRM-25 User manual

Multimedia Projector
MODEL PRM-25
PROJECTOR
Owner’s Manual

Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright
laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be
reproduced without written consent of the author.
© Copyright 2009
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
repre sentations or warranties with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the
right to revise this publication and to make changes from time to time in the content hereof without obligation
of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pending
applications in other countries throughout the world.
All other product names used in this manual are the properties of their respective owners and are
ac knowledged.
Promethean, Company Confidential i

Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
General Safety Information
Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
Follow all warnings and cautions in this manual and on the unit case.
The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
Do not place the unit on an unstable surface, cart, or stand.
Avoid using the system near water, in direct sunlight, or near a heating device.
Do not place heavy objects such as books or bags on the unit.
Promethean, Company Confidential ii

Projector Installation Notice
Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in
any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically.
Allow at least 50 cm clearance around the exhaust vent.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed 5 - 35°C while the projector is running, and the air intake and
exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable 5 - 35°C range.
Power Safety
Only use the supplied power cord.
Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
Remove the batteries from the remote control when storing or not in use for a prolonged period.
Promethean, Company Confidential iii

Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 39 for
clear and safe instructions for this procedure. Before replacing the lamp:
Unplug the power cord.
Allow the lamp to cool for about one hour.
Cleaning the Projector
Unplug the power cord before cleaning. See Cleaning the Projector on page 42.
Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the Regulatory Compliance section on
page 53.
Important Recycle Instructions:
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can
be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws.
For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp specific
disposal information check WWW.LAMPRECYCLE.ORG.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use of
separate recycling collection services.
Main Features
• Lightweight unit, easy to pack away and transport.
• Compatible with all major video standards including NTSC, PAL, and SECAM.
• A high brightness rating allows for presentations in daylight or in lit rooms.
• Supports resolutions up to SXGA+ at 16.7 million colors to deliver crisp, clear images.
• Flexible setup allows for front, rear projections.
• Line-of-vision projections remain square, with advanced keystone correction for angled
projections.
• Input source automatically detected.
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector. Wher ever
possible, relevant information—such as an illustration and its description—has been kept on one page.
This printer-friendly format is both for your convenience and to help save paper, thereby protecting the
environment. It is suggested that you only print sections that are relevant to your needs.
Promethean, Company Confidential iv

Table of Contents
GETTING STARTED... ............................................................................................................................................................. . 1
PACKING CHECKLIST................................................................................................................................................................. .. 1
VIEWS OF PROJECTOR PARTS.................................................................................................................................................... .. 2
PRM-25 Front-right View... ................................................................................................................................................. .. 2
Rear view ... ......................................................................................................................................................................... ... 3
Bottom view... ...................................................................................................................................................................... ... 4
REMOTE CONTROL PARTS ....................................................................................................................................................... ... 5
REMOTE CONTROL OPERATING RANGE..................................................................................................................................... . 7
PROJECTOR AND REMOTE CONTROL BUTTONS... ..................................................................................................................... .. 7
SETUP AND OPERATION... .................................................................................................................................................... . 8
INSERTING THE REMOTE CONTROL BATTERIES ........................................................................................................................ . 8
CONNECTING INPUT DEVICES... ................................................................................................................................................. . 9
STARTING AND SHUTTING DOWN THE PROJECTOR... ............................................................................................................... . 10
SETTING AN ACCESS PASSWORD (SECURITY LOCK)... ............................................................................................................ . 12
ADJUSTING THE PROJECTOR LEVEL........................................................................................................................................ .. 14
ADJUSTING THE FOCUS AND KEYSTONE ................................................................................................................................. . 15
ADJUSTING THE VOLUME ....................................................................................................................................................... .. 16
ON-SCREEN DISPLAY (OSD) MENU SETTINGS............................................................................................................ . 17
OSD MENU CONTROLS .......................................................................................................................................................... .. 17
Navigating the OSD........................................................................................................................................................... ... 17
SETTING THE OSD LANGUAGE.............................................................................................................................................. ... 18
OSD MENU OVERVIEW... ....................................................................................................................................................... .. 19
OSD SUB-MENU OVERVIEW ... ............................................................................................................................................. ... 20
IMAGE MENU.......................................................................................................................................................................... ... 21
Advanced Feature.............................................................................................................................................................. ... 22
Color Manager... ................................................................................................................................................................ .. 23
COMPUTER MENU... ................................................................................................................................................................ .. 24
VIDEO/AUDIO MENU ............................................................................................................................................................. ... 25
Audio................................................................................................................................................................................... .. 26
INSTALLATION I MENU... ....................................................................................................................................................... ... 27
INSTALLATION II MENU .......................................................................................................................................................... . 28
Advanced Feature.............................................................................................................................................................. ... 29
OSD Menu Setting... .......................................................................................................................................................... ... 30
Peripheral Test... ................................................................................................................................................................ .. 30
Lamp Hour Reset ................................................................................................................................................................ . 31
Network................................................................................................................................................................................ . 31
3D ...................................................................................................................................................................................... ... 32
Factory Reset... .................................................................................................................................................................... . 38
Status................................................................................................................................................................................... .. 38
MAINTENANCE AND SECURITY... ................................................................................................................................. ... 39
REPLACING THE PROJECTION LAMP........................................................................................................................................ .. 39
Resetting the Lamp... .......................................................................................................................................................... .. 41
CLEANING THE PROJECTOR.................................................................................................................................................... ... 42
Cleaning the Lens ... .......................................................................................................................................................... ... 42
Cleaning the Case.............................................................................................................................................................. ... 42
USING THE KENSINGTON®LOCK ........................................................................................................................................... ... 43
TROUBLESHOOTING .......................................................................................................................................................... .. 44
COMMON PROBLEMS AND SOLUTIONS ... ................................................................................................................................. . 44
TIPS FOR TROUBLESHOOTING ... ............................................................................................................................................. .. 44
LED ERROR MESSAGES .......................................................................................................................................................... . 45
IMAGE PROBLEMS... ................................................................................................................................................................ .. 45
LAMP PROBLEMS.................................................................................................................................................................... ... 46
REMOTE CONTROL PROBLEMS .............................................................................................................................................. ... 46
AUDIO PROBLEMS ... ................................................................................................................................................................ . 47
HAVING THE PROJECTOR SERVICED ... .................................................................................................................................... . 47
SPECIFICATIONS... ................................................................................................................................................................ . 48
Promethean, Company Confidential v

SPECIFICATIONS... ................................................................................................................................................................... .. 48
PROJECTION DISTANCE VS. PROJECTION SIZE ... ..................................................................................................................... . 49
PRM-25 Projection Distance and Size Table... ....................................................................................................................... 49
PRM-25 TIMING MODE TABLE ... .......................................................................................................................................... .. 50
PROJECTOR DIMENSIONS ....................................................................................................................................................... ... 52
REGULATORY COMPLIANCE ............................................................................................................................................... 53
FCC WARNING....................................................................................................................................................................... ... 53
CANADA ... ............................................................................................................................................................................... . 53
SAFETY CERTIFICATIONS... .................................................................................................................................................... ... 53
EN 55022 WARNING..................................................................................................................................................................... 53
Promethean, Company Confidential vi

GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
PRM-25 DLP PROJECTOR
REMOTE CONTROL POWER CORD (EU) POWER CORD (UK) POWER CORD (US)
(WITH TWO AAA BATTERIES)
RGB CABLE RGB TO COMPONENT CARRYING CASE CD-ROM
ADAPTER (OPTIONAL) (THIS USER’S MANUAL)
WARRANTY CARD QUICK START CARD
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is
recommend that you keep the original packing material should you ever need to return the equipment for
warranty service.
Caution:
Avoid using the projector in dusty environments.
Promethean, Company Confidential 1

Views of Projector Parts
PRM-25 Front-right View
ITEM LABEL DESCRIPTION SEE PAGE:
1. Height-adjuster button Push to release height adjuster
14
2. Height adjuster Adjusts level of projector
3. Lens cap Protect lens when not in use
4. Lens Projection Lens
5. IR receiver Receive IR signal from remote control 5
6. Focus ring Focuses the projected image 15
READY LED
7.
Red
Flashing
Lamp is ready to be powered-on.
Lamp not ready (Warm-up/shutting down/cooling)
(see LED Error Messages on page 45)
POWER LED Flashing
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
Promethean, Company Confidential 2

Rear view
ITEM LABEL DESCRIPTION SEE PAGE:
1. AC IN Connect the POWER CABLE 10
2. (USB) Connect the USB CABLE from a computer
3. VGA OUT Connect the RGB CABLE to a display
(Loop Thru only for VGA IN-1)
4. LAN Connect a LAN CABLE from Ethernet
5. VGA IN - 1
Connect the RGB CABLE from a computer and
components
9
6. VGA IN - 2
Connect the RGB CABLE from a computer and
components
7. HDMI Connect the HDMI CABLE from a HDMI device
8. S-VIDEO IN Connect the S-VIDEO CABLE from a video device
9. VIDEO IN Connect the COMPOSITE CABLE from a video device
10. Kensington Lock Secure to permanent object with a Kensington® Lock
system 43
11. AUDIO IN (L and R) Connect the AUDIO CABLES from a audio device
12. RS-232 Connect RS-232 serial port cable for remote control 9
13.
Note:
AUDIO IN
AUDIO OUT
Connect an AUDIO CABLE from the input device
Connect an AUDIO CABLE for audio loop through
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI/DVI, component (thru VGA), S-Video, Composite for better picture quality.
Promethean, Company Confidential 3

Bottom view
ITEM LABEL DESCRIPTION SEE PAGE:
1. Tilt adjustor Rotate adjuster lever to adjust angle position. 14
2. Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling
3. Height adjustor Adjuster drops down when adjuster button is pushed.
14
4. Height adjustor button Push to release adjustor.
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 6 mm (0.23 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution be
capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a period
of 60 seconds.
Promethean, Company Confidential 4

Remote Control Parts
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency
fluorescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off certain
reflective surfaces such as projector screens.
3. The buttons and keys on the projector have the same functions as the corresponding buttons on the
remote control. This user’s manual describes the functions based on the remote control.
Promethean, Company Confidential 5

ITEM LABEL DESCRIPTION SEE PAGE:
1. IR transmitter Transmits signals to projector
2. Status LED Lights when the remote control is used
3. Laser Press to operate the on-screen pointer
4. Up Up arrow when connected through USB to a PC
5. Right Right arrow when connected through USB to a PC
6. Down Down arrow when connected through USB to a PC
7. Page Down Page down when connected through USB to a PC
8. Up cursor
9. Right cursor Navigates and changes settings in the OSD 17
10. Down cursor
11. Volume +/- Adjusts volume 16
12. Mute Mutes the built-in speaker
13. Zoom+ Zoom in
15
14. Zoom- Zoom out
15. Freeze Freeze/unfreezes the on-screen picture
16. Blank Makes the screen blank
17. Source Detects the input device
18. Auto Auto adjustment for phase, tracking, size, position
19. Menu Opens the OSD 17
20. Status Opens the OSD Status menu (the menu only opens when an
input device is detected)
38
21. Keystone top/bottom Corrects image-trapezoid (wider top/bottom) effect 15
22. Left cursor Navigates and changes settings in the OSD
23. Enter Changes settings in the OSD
24. Page Up Page up when connected through USB to a PC 17
25. Left Left arrow when connected through USB to a PC
26. Enter Enter key when connected through USB to a PC
27. Power Turns the projector on or off 10
28. Laser Use as on-screen pointer. DO NOT POINT IN EYES.
Promethean, Company Confidential 6

Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and
15 degrees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.
Projector and Remote Control Buttons
The projector can be operated using the remote control or the buttons on the top of the projector. All
operations can be carried out with the remote control; however, the buttons on the projector are lim-
ited in use.
Promethean, Company Confidential 7

SETUP AND OPERATION
Inserting the Remote Control Batteries
1. Remove the battery compartment cover
by sliding the cover in the direction of
the arrow.
2. Insert the battery with the positive side
facing up.
3. Replace the cover.
Caution:
1. Only use AAA batteries (Alkaline batteries are recommended).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.
Promethean, Company Confidential 8

Connecting Input Devices
A PC or notebook computer and video devices can be connected to the projector at the same time. Video
devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras.
Check the user manual of the connecting device to confirm it has the appropriate output connector.
ITEM LABEL DESCRIPTION
(USB) Connect the USB CABLE from a computer
VGA OUT Connect the RGB CABLE to a display (Loop Thru only for VGA IN-1)
LAN Connect a LAN CABLE from Ethernet
VGA IN - 1 Connect the RGB CABLE from a computer and components
VGA IN - 2 Connect the RGB CABLE from a computer and components
AUDIO IN Connect an AUDIO CABLE from the input device
AUDIO OUT Connect an AUDIO CABLE for audio loop through
HDMI Connect the HDMI CABLE from a HDMI device
S-VIDEO IN Connect the S-VIDEO CABLE from a video device
VIDEO IN Connect the COMPOSITE CABLE from a video device
AUDIO IN (L and R) Connect the AUDIO CABLES from a audio device
RS-232C Connect the RS-232 serial cable for remote control
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
Promethean, Company Confidential 9

Starting and Shutting down the Projector
1. Connect the power cord to the projector.
Connect the other end to a wall outlet.
The POWER and READY LEDs
on the projector light.
2. Turn on the connected devices.
3. Ensure the READY LED displays a
solid red and not a flashing red. Then
press the POWER button to turn on
the projector.
The projector splash screen displays and
connected devices are detected.
See Setting an Access Password
(Security Lock) on page 12 if security
lock is enabled.
4. If more than one input device is con-
nected, press the SOURCE button and
use ▲▼ to scroll among devices.
(Component is supported through the
RGB to COMPONENT ADAPTER.)
• VGA 1/VGA 2: Analog RGB
Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr via HD15 connector
•Composite Video: Traditional composite video
• S-Video: Super video (Y/C separated)
• HDMI: HDMI, DVI
Promethean, Company Confidential 10

5. When the “Power Off? /Press Power
again” message appears, press the
POWER button. The projector turns
off.
Caution:
1. Be sure to remove the lens cap before starting projector.
2. Do not unplug the power cord until the READY LED stops flashing-indicating the projector has
cooled down.
Promethean, Company Confidential 11

4. diess the cursor ◄► button to enable or
Setting an Access Password (Security Lock)
You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projec-
tor. When enabled, the password must be entered after you power on the projector. (See Navigating
the OSD on page 17 and Setting the OSD Language on page 18 for help on using OSD menus.)
Important:
Keep the password in a safe place. Without the password, you will not be able to use the projector. If
you lose the password, contact your reseller for information on clearing the password.
1. Press the MENU button to open the OSD
menu.
2. Press the cursor ◄► button to move to
the Installation I menu.
3. Press the cursor ▲▼ button to select
Security Lock.
sable security lock function.
A password dialog box automatically
appears.
Promethean, Company Confidential 12

5. You can use the cursor buttons ▲▼◄►
on IR remote control for password entry.
You can use any combination including
the same arrow five times, but not less
than five.
Press the cursor buttons in any order to set
the password. Push the MENU button to
exit the dialog box.
6. The password confirm menu appears when
user presses the power-on key in case the
Security Lock is enabled.
Enter the password in the order you set it at
step 5. In case you forget the password,
please contact the service center.
Service center will validate the owner and
help reset the password.
Promethean, Company Confidential 13
