promethean UST-P3 User manual

Promethean
720 Olive Way
Suite 1500
Seattle, WA 98101
1+ 888 652 2848
TP-3077-V01
Owner’s Manual
Multimedia Projector
Model: UST-P3

Promethean, Company Confidential i
Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without written consent of the author.
© Copyright 2020
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of
the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and
pending applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
All other product names used in this manual are the properties of their respective owners and are acknowledged.
Important Safety Information
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause
personal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
Ver.: 1

Promethean, Company Confidential ii
General Safety Information
Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
Follow all warnings and cautions in this manual and on the unit case.
The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
Do not place the unit on an unstable surface, cart, or stand.
Avoid using the system near water, in direct sunlight, or near a heating device.
Do not place heavy objects such as books or bags on the unit.
Projector Installation Notice
Place the projector in a horizontal position
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in
any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically.
Allow at least 50 cm clearance around the exhaust vent.
Ensure that the intake vents do not recycle hot air from the exhaust vent.
When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
All enclosures should pass a certified thermal evaluation to ensure that the projector does not
recycle exhaust air, as this may cause the device to shutdown even if the enclosure temperature is
with the acceptable operation temperature range.
Power Safety
Only use the supplied power cord.
Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
Remove the batteries from the remote control when storing or not in use for a prolonged period.
Note:
RG1 IEC 62471-5:2015

Promethean, Company Confidential iii
Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 44
for clear and safe instructions for this procedure. Before replacing the lamp:
Unplug the power cord.
Allow the lamp to cool for about one hour.
Cleaning the Projector
Unplug the power cord before cleaning. See Cleaning the Projector on page 46.
Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the Regulatory Compliance section
on page 59.
Important Recycle Instructions:
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that
can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal
Laws. For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp
specific disposal information check WWW.LAMPRECYCLE.ORG.
Symbol Explanations
DISPOSAL: Do not use household or municipal waste collection services for
disposal of electrical and electronic equipment. EU countries require the use
of separate recycling collection services.
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector.
Wherever possible, relevant information—such as an illustration and its description—has been kept on
one page. This printer-friendly format is both for your convenience and to help save paper, thereby
protecting the environment. It is suggested that you only print sections that are relevant to your needs.

Promethean, Company Confidential iv
Table of Contents
GETTING STARTED..............................................................................................................................................1
PACKING CHECKLIST .............................................................................................................................................1
VIEWS OF PROJECTOR PARTS................................................................................................................................2
Front-right View...............................................................................................................................................2
Rear view.........................................................................................................................................................3
Bottom view.....................................................................................................................................................4
REMOTE CONTROL PARTS.....................................................................................................................................5
REMOTE CONTROL OPERATING RANGE..................................................................................................................7
PROJECTOR AND REMOTE CONTROL BUTTONS.......................................................................................................7
SETUP AND OPERATION.....................................................................................................................................8
INSERTING THE REMOTE CONTROL BATTERIES .......................................................................................................8
STARTING AND SHUTTING DOWN THE PROJECTOR ..................................................................................................9
SETTING AN ACCESS PASSWORD (SECURITY LOCK)..............................................................................................10
ADJUSTING THE PROJECTOR LEVEL .....................................................................................................................12
ADJUSTING THE FOCUS AND KEYSTONE ...............................................................................................................13
ON-SCREEN DISPLAY (OSD) MENU SETTINGS..............................................................................................14
OSD MENU CONTROLS .......................................................................................................................................14
Navigating the OSD.......................................................................................................................................14
SETTING THE OSD LANGUAGE.............................................................................................................................15
OSD MENU OVERVIEW........................................................................................................................................16
IMAGE MENU.......................................................................................................................................................19
Computer Menu.............................................................................................................................................20
Advanced Feature.........................................................................................................................................21
White Balance ...............................................................................................................................................22
Color Manager...............................................................................................................................................23
SETTINGS 1MENU...............................................................................................................................................24
Audio..............................................................................................................................................................25
ActivBoard Installation...................................................................................................................................26
Advanced 1 Feature......................................................................................................................................27
Advanced 2 Feature......................................................................................................................................29
SETTINGS 2MENU...............................................................................................................................................30
Status.............................................................................................................................................................31
Advanced 1 Feature......................................................................................................................................32
Advanced 2 Feature......................................................................................................................................42
MAINTENANCE AND SECURITY.......................................................................................................................44
REPLACING THE PROJECTION LAMP .....................................................................................................................44
Resetting the Lamp .......................................................................................................................................46
CLEANING THE PROJECTOR .................................................................................................................................47
Cleaning the Projector Mirror: .......................................................................................................................47
Cleaning the Case.........................................................................................................................................48
USING THE PHYSICAL LOCK .................................................................................................................................49
Using the Kensington®Lock..........................................................................................................................49
Using the Security Bar...................................................................................................................................49
TROUBLESHOOTING.........................................................................................................................................50
COMMON PROBLEMS AND SOLUTIONS...................................................................................................................50
TIPS FOR TROUBLESHOOTING ..............................................................................................................................50
LED ERROR MESSAGES......................................................................................................................................51
IMAGE PROBLEMS ...............................................................................................................................................51
LAMP PROBLEMS.................................................................................................................................................52
REMOTE CONTROL PROBLEMS.............................................................................................................................52
HAVING THE PROJECTOR SERVICED.....................................................................................................................52
HDMI Q&A.......................................................................................................................................................53
SPECIFICATIONS................................................................................................................................................54
SPECIFICATIONS..................................................................................................................................................54
PROJECTION DISTANCE VS.PROJECTION SIZE......................................................................................................55

Promethean, Company Confidential v
Projection Distance and Size Table ..............................................................................................................55
TIMING MODE TABLE ...........................................................................................................................................56
PROJECTOR DIMENSIONS ....................................................................................................................................58
REGULATORY COMPLIANCE ...........................................................................................................................59
FCC WARNING ...................................................................................................................................................59
CANADA..............................................................................................................................................................59
SAFETY CERTIFICATIONS .....................................................................................................................................59

Promethean, Company Confidential 1
GETTING STARTED
Packing Checklist
Carefully unpack the projector and check that the following items are included:
DLPPROJECTOR
REMOTE CONTROL
(WITH TWO AAA BATTERIES)
QUICK INSTALL GUIDE
VGACABLE
REGIONAL POWER CORD
HDMICABLE
Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It
is recommend that you keep the original packing material should you ever need to return the equipment
for warranty service.
Caution:
Avoid using the projector in dusty environments.

Promethean, Company Confidential 2
Views of Projector Parts
Front-right View
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Lamp cover
Removes cover to replace lamp or color wheel
2.
IR receiver
Receives IR signal from remote control
3.
Aspheric mirror
Reflects images
4.
Lens
Projection Lens
5.
Focus ring
Focuses the projected image
6.
TEMP LED
Red
Error code
51
LAMP LED
Amber
Lamp Error
Flashing
Error code
POWER LED
Flashing
Error code , System warm up,
Cooling
Green
Power On, Ready to power on
(Standby)
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.

Promethean, Company Confidential 3
Rear view
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Security bar
For security and authorized usage
49
2.
Kensington lock
Secure to permanent object with a Kensington Lock
system
3.
USB-B(Service)
Connect the USB cable from a computer
4.
AUDIO L/R
(For VIDEO/ S-VIDEO)
Connect an AUDIO cable from the audio device
5.
RS-232
Connect RS-232 serial port cable for remote control
6.
AUDIO IN
Connect an AUDIO cable from the audio device
7.
AUDIO OUT
Connect an AUDIO cable to an audio amplifier
8.
AC IN
Connect the POWER cable
9
9.
HDMI 1
Connect the HDMI cable from a HDMI device
10.
HDMI 2
Connect the HDMI cable from a HDMI device
11.
MONITOR OUT
Connect the RGB cable to a display
12.
COMPUTER
Connect the RGB cable from a computer or components device
13.
VIDEO
Connect the composite cable from a video device
14.
USB (1.5A)
Connect the USB cable for power supply.
15.
RJ –45
Connect a LAN cable from Ethernet
Note:
If your video equipment has various input sources, it is recommended to connect in priority of
HDMI/DVI, component (thru VGA), Composite for better picture quality.
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
1 2 345 6 78
9101112131415

Promethean, Company Confidential 4
Bottom view
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Tilt adjustor
Rotate adjuster lever to adjust angle position
10
2.
Ceiling support holes
Contact your dealer for information on mounting the projector on a
ceiling
Note:
When installing, ensure that you use only UL Listed ceiling mounts.
For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw
depth of 12 mm (0.47 inch).
The construction of the ceiling mount must be of a suitable shape and strength. The ceiling mount
load capacity must exceed the weight of the installed equipment, and as an additional precaution
be capable of withstanding three times the weight of the equipment (not less than 5.15 kg) over a
period of 60 seconds.
247.01
135.51
1222
1
1

Promethean, Company Confidential 5
Remote Control Parts
Important:
1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency
fluorescent lights can disrupt remote control operation.
2. Be sure nothing obstructs the path between the remote control and the projector. If the path
between the remote control and the projector is obstructed, you can bounce the signal off certain
reflective surfaces such as projector screens.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

Promethean, Company Confidential 6
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
IR transmitter
Transmits signals to projector
2.
Status LED
Lights when the remote control is used
3.
Up
Up arrow when connected through USB to a PC
4.
Right
Right arrow when connected through USB to a PC
5.
Down
Down arrow when connected through USB to a PC
6.
Page Down
Page down when connected through USB to a PC
7.
Up cursor
Navigates and changes settings in the OSD
8.
Right cursor
9.
Down cursor
10.
Zoom+
Zoom in
11.
Zoom-
Zoom out
12.
Freeze
Freeze/unfreezes the on-screen picture
13.
Blank
Makes the screen blank
14.
Source
Detects the input device
15.
Auto
Auto adjustment for phase, tracking, size, position
16.
Menu
Opens the OSD
17.
Status
Opens the OSD Status menu (the menu only opens
when an input device is detected)
31
18.
Keystone
top/bottom
Corrects image-trapezoid (wider top/bottom) effect
10
19.
Left cursor
Navigates and changes settings in the OSD
20.
Enter
Changes settings in the OSD
21.
Page Up
Page up when connected through USB to a PC
22.
Left
Left arrow when connected through USB to a PC
23.
Enter
Enter key when connected through USB to a PC
24.
Power
Turns the projector on or off
9

Promethean, Company Confidential 7
Remote Control Operating Range
The remote control uses infrared transmission to control the projector. It is not necessary to point the
remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or
the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and
15 degrees above or below the projector level. If the projector does not respond to the remote control,
move a little closer.
Projector and Remote Control Buttons
The projector can only be operated using the remote control. All operations can be carried out with
the remote control.

Promethean, Company Confidential 8
SETUP AND OPERATION
Inserting the Remote Control Batteries
1.
Remove the battery compartment
cover by sliding the cover in the
direction of the arrow.
2.
Insert the battery with the positive
side facing up.
3.
Replace the cover.
Caution:
1. Only use AAA batteries (Alkaline batteries are recommended).
2. Dispose of used batteries according to local ordinance regulations.
3. Remove the batteries when not using the projector for prolonged periods.

Promethean, Company Confidential 9
Starting and Shutting down the Projector
1.
Connect the power cord to the
projector. Connect the other end to
a wall outlet.
2.
Turn on the connected devices.
3.
Ensure the POWER LED displays a
solid green. Then press the POWER
button of the remote to turn on the
projector.
The projector splash screen displays
and connected devices are
detected.
See Setting an Access Password
(Security Lock) on page 10 if
security lock is enabled.
4.
If more than one input device is
connected, press the SOURCE
button of the remote and use ▲▼ to
scroll among devices.
(Component is supported through
the RGB to COMPONENT
ADAPTER.)
HDMI1/HDMI2: HDMI, DVI
VGA: Analog RGB
Component: DVD input YCbCr / YPbPr, or
HDTV input YPbPr via HD15 connector
Composite Video: Traditional composite video
5.
When the “Power Off? /Press Power
again” message appears, press the
POWER button. The projector turns
off.
Caution:
Do not unplug the power cord until the POWER LED change to green–indicating the projector has
cooled down.

Promethean, Company Confidential 10
Setting an Access Password (Security Lock)
You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector.
When enabled, the password must be entered after you power on the projector. (See Navigating the
OSD on page 14 and Setting the OSD Language on page 15 for help on using OSD menus.)
Important:
Keep the password in a safe place. Without the password, you will not be able to use the projector.
If you lose the password, contact your reseller for information on clearing the password.
1.
Press the MENU button to open the
OSD menu.
2.
Press the cursor ◄► button to move
to the Settings 1 menu, press the
cursor ▲▼ button to select Advanced
1.
3.
Press (Enter) / ►to enter the
Advanced 1 sub menu. Press the
cursor ▲▼ button to select Security
Lock.
4.
Press the cursor ◄► button to enter
and enable or disable security lock
function.
A password dialog box automatically
appears.

Promethean, Company Confidential 11
5.
You can use the cursor buttons
▲▼◄►
either on keypad or IR remote control
for password entry. You can use any
combination including the same arrow
five times, but not less than five.
Press the cursor buttons in any order
to set the password. Push the MENU
button to exit the dialog box.
6.
The password confirm menu appears
when user presses the power-on key
in case the Security Lock is enabled.
Enter the password in the order you
set it at step 5. In case you forget the
password, please contact the service
center.
The service center will validate the
owner and help reset the password.

Promethean, Company Confidential 12
Adjusting the Projector Level
Take note of the following when setting up the projector:
The projector table or stand should be level and sturdy.
Position the projector so that it is perpendicular to the screen.
Ensure the cables are in a safe location. You could trip over them.
To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle
has been achieved.

Promethean, Company Confidential 13
Adjusting the Focus and Keystone
1.
Use the Image-focus
control (on the projector
only) to sharpen the
projected image
2.
Use the KEYSTONE
buttons on the remote
control to correct
image-trapezoid (wider
top or bottom)
effect.
3.
The keystone control
appears on the display.

Promethean, Company Confidential 14
ON-SCREEN DISPLAY (OSD) MENU SETTINGS
OSD Menu Controls
The projector has an OSD that lets you make image adjustments and change various settings.
Navigating the OSD
You can use the remote control cursor buttons to navigate and make changes to the OSD.
1. To enter the OSD, press the
MENU button.
2. There are three menus.
Press the cursor ◄► button
to move through the menus.
3. Press the cursor ▲▼ button
to move up and down in a
menu.
4. Press ◄► to change values
for settings.
5. Press MENU to close the
OSD or leave a submenu.
Note:
Depending on the video source, not all items in the OSD are available. For example, the
Horizontal/Vertical Position items in the Computer menu can only be modified when connected
to a PC. Items that are not available cannot be accessed and are grayed out.
