1 Prerequisites
The pump can be enhanced with the PROFIBUS® functionality by means
of a plug-in module. To do this, insert the plug-in module into the front of
the pump (similar to a relay module). The operating menu then displays
the menu item
‘Field bus’ and the status bar shows the PROFIBUS®
symbol.
The pump must have the software version V01.01.00.00
or higher in order for the PROFIBUS® module to func‐
tion. If it is not working, the LED on the PROFIBUS®
module slowly flashes red and green.
Prerequisites
3

2 Adjusting the pump
2.1 General
The pump with the plugged-in PROFIBUS® module is adjusted in the
same way as the standard pump, with the addition of the bus functionality.
The pump interrupts the set-up process in the event of
pauses longer than 60 s.
2.2 Setting the slave address
The address is pre-set to “125”. If a master in the PROFIBUS® segment
assigns the slave addresses, manual setting of the slave address is can‐
celled.
1. Press the
[Menu] key.
2. Turn the
[Clickwheel] to ‘Fieldbus’ and press the [Clickwheel] .
3. Turn the
[Clickwheel] to ‘BUS Address’ and press the [Clickwheel] .
Always enter the PROFIBUS® address as 3 digits (addresses between
“002” and “125”):
1. Set the 1st number using the
[Clickwheel] and press the
[Priming] key.
ðThe 2nd number of the address is marked.
2. Set the 2nd number using the
[Clickwheel] and press the
[Priming] key.
ðThe 3rd number of the address is marked.
3. Set the 3rd number using the
[Clickwheel] and press the
[Clickwheel] .
2.3 Switch PROFIBUS® to active / inactive
In order for the pump to be controlled using the PROFIBUS®,
‘Fieldbus’
must be set to ‘Active’ in the operating menu:
1. Press the
[Menu] key.
2. Turn the [Clickwheel] to ‘BUS active’ and press the [Clickwheel] .
3. Turn the [Clickwheel] to ‘Active’ or ‘Inactive’ and press the
[Clickwheel] . You’re done!
All external inputs, such as level monitoring, metering monitor and external
control (pause, contact input, analogue input), will continue to function
while the PROFIBUS® is
‘active’ . They result in the reactions that would
be expected with the pump without the PROFIBUS® module being plugged
in - see “Operating instructions for diaphragm motor driven dosing pump
Sigma X Control type SxCb”. The pump transmits corresponding informa‐
tion via the PROFIBUS® to the master (PLC Programmable Logic Con‐
troller, PC etc.).
If the PROFIBUS® is set to
‘Inactive’ , the settings for the previously
selected operating mode are reloaded.
Adjusting the pump
4

If the pump is switched to another operating mode, it stops and can only
be restarted using the
[Stop/Start] key.
Adjusting the pump
5

3 Special features in active PROFIBUS® operation
3.1 General
The pump cannot be manually set or programmed in
PROFIBUS® operation! To do this, set the PROFIBUS®
to ‘Inactive’ .
nUsing the [Clickwheel] it is possible to switch between the continuous
displays at any time, as in the other operating modes. This does not
affect the operation of the pump.
nThe settings from other operating modes are carried over when
switching over to PROFIBUS® operation. However, settings made
using the PROFIBUS® are not saved! They only apply as long as the
pump is linked to the PROFIBUS®. Only the total number of strokes
and the total number of litres continue to be counted and saved.
nIf the pump is switched to PROFIBUS® operation, it stops and can
only be restarted using the PROFIBUS®.
3.2 Displays
There are additional identifiers in the operating display when PROFIBUS®
operation is running.
The current identifiers can be found in the "Control ele‐
ments" chapter in the "Operating instructions for dia‐
phragm motor driven dosing pump Sigma X Control
type ...”.
Stop PROFIBUS®: The pump has been stopped by the PROFIBUS®.
The master has sent the pump a corresponding telegram.
Connection error: If the pump loses its connection to the PROFIBUS®
(for instance as soon as the PROFIBUS® is stopped), an error message
with the symbol appears on the main display.
3.3 LEDs on the PROFIBUS® module
LEDs Cause
Flashing red and green at a slow
rhythm
Connection between the PRO‐
FIBUS® module and pump has
been disrupted;
the hardware or software version of
the pump may not be suitable for
PROFIBUS®
Lit red No connection to the PROFIBUS®
Lit green Pump in cyclic operation
Operating display
Status display
Main display
Special features in active PROFIBUS® operation
6

3.4 Using the metering monitor
The "Metering monitor" socket must be assigned to use the metering mon‐
itor in PROFIBUS® operation. The pump then transmits
‘available’ for the
"Flow" status bit. The metering monitor can be switched on and off via the
PROFIBUS® using the
‘Flow control’ parameter - see “Operation” chapter.
Special features in active PROFIBUS® operation
7

4 Installation
All devices that are members of the bus system must be connected in a
line. There are up to 32 possible positions (master, slaves, repeaters).
At both the beginning and end of the cable, the bus must be terminated
with a terminating resistance.
For the PROFIBUS® cable, use a screened, twisted-pair cable in con‐
formity with EN 50170 (cable type A).
Use of shielding which is earthed at one end prevents
low-frequency ground loops. Shielding earthed at one
end has no effect in combating HF magnetic pick-up.
Shielding earthed at both ends as well as twisted con‐
ductors work to counter magnetic HF pick-up, but have
no effect against electrical HF pick-up.
For PROFIBUS®, it is recommended to establish a bilateral, low-induc‐
tance (i.e., large area and low-impedance) connection with the protective
earth.
The overall length of the bus cabling without repeaters varies according to
the desired data transmission rate:
Tab. 1: Data transmission rate and length of the bus cabling
Data transmission rate Maximum length of bus cabling
kBit/s m
1500 200
500 400
187.5 1000
93.75 1200
19.2 1200
9.6 1200
The PROFIBUS® module has a M12 industry socket for connection to the
PROFIBUS® cable. The pin configuration complies with the PROFIBUS®
standard - see below - which means that commercially available bus plugs
may be used. Please note that cable connections made with these plugs
generally only meet the requirements for protection against contact and
moisture according to IP 20!
An installation compliant with the protection against contact and moisture
according to IP 65 is possible, since the M12 industry socket of the PRO‐
FIBUS® module allows this. However, in this case the PROFIBUS® cable
must also be fitted with M12 industry plugs in conformity with IP 65.
In order to achieve the IP 65 degree of protection for the PROFIBUS®
cable installation, special Y-adapters or terminating adapters must be
installed (e.g. - see below).
Bus installation
Plugs and cables
Note for achieving IP 65 degree of protec‐
tion
Installation
8

CAUTION!
– Degree of protection IP 65 applies only to a plug/
socket combination that has been screwed together!
–In ambient conditions requiring protection against
contact and moisture according to IP 65, cables with
moulded M12 industry plugs must be used (e.g., see
below).
– Degree of protection IP 65 applies only to an
unwired pump (with PROFIBUS® module) if an IP
65-capable cover is placed over the M12 industry
socket! The cover included in the delivery does not
guarantee chemical resistance.
Socket on the PROFIBUS® module (M12 )
P_DE_0073_SW
1
5
4
3
2
1 5 V
2 A conductor (green)
3 GND
4 B conductor (red)
5 Shielding
.
Y-adapter (order no. 1040956)
The Y-adapter connects to the pump using a moulded M12 plug. The ends
are provided with an M12 plug and an M12 socket. The Y-adapter com‐
plies with the requirements for protection against contact and moisture
according to IP 65.
.
PROFIBUS® termination, complete (order no. 1040955)
If the pump is the last bus device connected to the PROFIBUS® cable, it
must be connected completely as a termination using the PROFIBUS® ter‐
mination - see EN 50170. The PROFIBUS® termination, complete, com‐
plies with the requirements for protection against contact and moisture
according to IP 65. (It consists of a Y-plug and terminating resistance.)
Installation
9

5 Operation
5.1 General
The plugged-in PROFIBUS® module make the PROFIBUS® pump a
device with slave functionality in conformity with DP-V1. This means that
the payload is transmitted both cyclically and acyclically.
5.2 GSD file
The GSD file must be used for configuring the master. It describes all fea‐
tures of the pump in PROFIBUS® operation (keywords, diagnosis, mod‐
ules, slots). The GSD file can be downloaded from the PROFIBUS® web‐
site and from the ProMinent website. The file name is clearly indicated:
PROM0B02.GSD
5.3 Description of the data objects
The initial parameters must be transmitted from the
master so that the pump can participate in cyclic data
transmission. Only standard parameterisation is needed
for this – there are no application-specific parameters.
Please note: Data is stored according to the "Big-
Endian" principle! This means that the byte with the
highest-value bits is stored first at the memory location
with the lowest storage address. For an example based
on “Status” - refer to the section below:
The pump status is stored as UINT32 type at the offset addresses +0 to
+3. Bytes are stored in this sequence:
Name Type Offset Byte Bits
Status UINT32 +0 0 24 ... 31
+1 1 16 ... 23
+2 2 8… 15
+3 3 0… 7
All the data objects that can be cyclically transmitted are described below.
Tab. 2: All data objects
Name No. Type Description
Device identi‐
fier
0 UINT32 Byte 0+1 = 0x0B02 Identification number
Byte 2 = 0x50 ProMinent- Identifier for Pumps
product group
Byte 3 = 3 "Sigma b” pump family
Status 1 UINT32 bit Name Function
Description of the data objects
Operation
10

Name No. Type Description
0 System 00 – Init 03 –Test
1 01 – Ready 04 - First run
2 02 – Diagnosis 05 - Power
down
3 Mode 00 – halt 03 –contact
4 01 – manual 04 - analogue
5 02 – batch
6 Error There are errors - see "Errors"
7 Warnings There are warnings - see
"Warnings"
8 Stop Pump has stopped
9 Priming Pump is in priming operation
(higher-level function)
10 Auxiliary Pump is in auxiliary operation
(higher-level function)
11 Pause Pump has been switched to
Pause (higher-level function)
12 Module Automatic operation
13 Flow Metering monitor activated
14 Batch Mem. Batch memory is activated
15 Calibrated Pump is calibrated
16 Relay 1 Relay 1 is physically present
17 Relay 2 Relay 2 is physically present
18 AnalogOut Module is physically present
19 Diaphragm
rupture
Diaphragm rupture option is
installed
21 - -
22 - -
24 Overpressure Drive control signals “back pres‐
sure too high”
27 - Always true
Start-Stop 2 BYTE Corresponds to Start-Stop switch; if Start-Stop = 0, then the pump
is stopped.
Reset 3 BYTE If the “Reset” value is switched from 1 to 0, the internal pump
memory is deleted (e.g., with batch metering) and - as far as pos‐
sible - existing errors are deleted.
Mode 4, 5 BYTE Value Name Description
0 Stop Pump is ready but not metering.
1 Manual Pump is metering continuously
at the set frequency.
2 Batch When triggered, the pump
meters the number of strokes
set in batch preselection.
3 Contact Pump is metering the number of
strokes calculated from the
product of “Number of triggers *
External factor”.
Operation
11

Name No. Type Description
4 Analogue Pump meters according to the
analogue signal and the
‘Analogue’ operating mode set
on the pump.
Frequency 6, 7 UINT16 Set metering frequency in strokes / hour ( 0.. “Maximum fre‐
quency”).
Actual fre‐
quency
8 UINT16 Actual metering frequency in strokes / hour ( 0.. ‘Maximum fre‐
quency’).
Maximum fre‐
quency
9 UINT16 Maximum metering frequency in strokes / hour (0...12000). The
maximum frequency can be significantly lower than in normal
mode according to the metering mode set.
Batch prese‐
lection
10, 11 UINT32 Number of strokes in batch operation per trigger. (0…99999).
Batch start 12 BYTE If the value changes from 1 to 0, batch metering is activated in
batch operation. Batches can also be activated via the contact
input.
Batch memory 13 BYTE If the batch memory is activated and a new batch is triggered
during batch metering already in progress, the remaining strokes
are increased by the number of the new batch.
If the memory is not activated, the remaining strokes of the batch
not yet processed are deleted and the new batch is processed.
Remaining
strokes
14 UINT32 The strokes still to be processed with batch metering
External factor 15, 16 UINT16 Factor by which the incoming pulses are multiplied. The factor is
given as a hundredth. Value range is 1…9999 - the factor is then
0.01…99.99.
External
memory
17 BYTE Analogue, like batch metering, is also added up here with high fac‐
tors or the remaining strokes are deleted.
Stroke length 18 BYTE Stroke length set on the pump (0...100%)
Metering mon‐
itor
19 BYTE If a metering monitor is installed, it can be switched on (1). Deacti‐
vation is (0).
Error 21 UINT16 bit Name Function
0 Minimum Metering liquid level too low
1 Batch Too many metering strokes >
100000
2 Analogue current is less than 4
mA
3 Analogue >
23mA
Analogue current is greater than
23 mA
4 Metering mon‐
itor
Metering monitor fault
5 Diaphragm
rupture
Faulty diaphragm in the dosing
head
7 Overpressure Overpressure in the hydraulic
system
8 - -
9 - -
11 Stroke length
changes
The stroke length was changed
in locked state.
13 Bus error Bus error reported by the
module
Operation
12

Name No. Type Description
14 System error System components faulty - see
LCD screen
15 Module error Fault in module handling
Warnings 22 UINT16 bit Name Function
0 Minimum Metering liquid level too low
1 Calibration Stroke length set outside the
calibration tolerance
2 Metering mon‐
itor
Metering monitor fault
3 Diaphragm
rupture
Faulty diaphragm in the dosing
head
4 Airlock Air in the dosing head
5 - -
6 - -
7 Overpressure Overpressure in the hydraulic
system
8 Low pressure Pressure too low in the
hydraulic system
Stroke counter 23 UINT32 Counts the number of strokes since the last reset
Delete stroke
counter
24 BYTE If the value changes from 1 to 0, the stroke counter is deleted
Quantity
counter
25 FLOAT Counts the capacity since the last reset in litres
Litres per
stroke
26 FLOAT Litres per stroke. Depending on the frequency and stroke length
adjustment
Delete quantity
counter
27 BYTE If the value changes from 1 to 0, the volume counter is deleted
Identity code 28 STRING Pump identity code (pump specification)
Serial number 29 STRING Pump serial number
Name 30 STRING Pump name, freely determinable (max. 32 characters)
Installation site 31 STRING Installation site, freely determinable. (max. 32 characters)
5.4 Cyclic data transmission
DP-V0 describes the cyclic data transmission in the PROFIBUS®.
5.4.1 Overview of the data objects
The data objects are summarised into modules and their configuration
identifier – see following table. The configuration identifier allows modules
to be excluded from cyclic data transmission during configuration to avoid
unnecessarily burdening the cyclic data transmission.
Operation
13

Tab. 3: Modular construction
Module no. Output Length Input Length Module name Configuration
identifier (hex)
1 - - Status 4 byte Status 40.83
2 Start-Stop
Reset
1 byte
1 byte
- - Control 80.81
3 Mode 1 byte Mode 1 byte Operating
mode
C0,80,80
4 Frequency 2 byte Frequency
Actual fre‐
quency
2 byte
2 byte
Frequency C0,81,83
5 - - Maximum fre‐
quency
2 byte Maximum fre‐
quency
40.81
6 Batch prese‐
lection
Batch start
Batch memory
4 byte
1 byte
1 byte
Batch prese‐
lection
4 byte Batching C0,85,83
7 - - Remaining
strokes
4 byte Remaining
strokes
40.83
8 External factor
External
memory
2 byte
1 byte
External factor 2 byte Transmission
multiplier
C0,82,81
9 - - Stroke length 1 byte Stroke length 40.80
10 Metering mon‐
itor
1 byte - - Flow Control 80.80
12 - - Error
Warnings
2 byte
2 byte
Error / Warning 40.83
13 Delete stroke
counter
1 byte Stroke counter 4 byte Stroke number C0,80,83
14 Delete quantity
counter
1 byte Quantity
counter
Litres per
stroke
4 byte
4 byte
Quantity C0,80,87
Tab. 4: Pump data (output data)
Offset Value Type Name Range Module name Module no.
+0 - BYTE Start-Stop 0.1 Control 2
+1 - BYTE Reset 0.1↓ -
+2 - BYTE Mode see Operating
mode
3
+3
+4
high
low
UINT16 Frequency 0..max. Freq. Frequency 4
+5
+6
+7
+8
high
↓
low
UINT32 Batch prese‐
lection
1..99999 Batching 6
+9 - BYTE Batch start 0.1↓ -
+10 - BYTE Batch memory 0.1 -
Operation
14

Offset Value Type Name Range Module name Module no.
+11
+12
high
low
UINT16 External factor 0..9999 Transmission
multiplier
8
+13 - BYTE External
memory
0.1 -
+14 - BYTE Metering mon‐
itor
0.1 Flow Control 10
+15 - BYTE Delete stroke
counter
0.1↓ Stroke number 13
+16 - BYTE Delete quantity
counter
0.1↓ Quantity 14
Tab. 5: Pump data (input data)
Offset Value Type Name Range Module name Module no.
+0
+1
+2
+3
high
↓
low
UINT32 Status see Status 1
+4 - BYTE Mode see Operating
mode
3
+5
+6
high
low
UINT16 Frequency 0..max. Freq. Frequency 4
+7
+8
high
low
UINT16 Actual fre‐
quency
0..max. Freq.
+9
+10
high
low
UINT16 Maximum fre‐
quency
0..12000↓ Maximum fre‐
quency
5
+11
+12
+13
+14
high
↓
low
UINT32 Batch prese‐
lection
1..99999 Batching 6
+15
+16
+17
+18
high
↓
low
UINT32 Remaining
strokes
1..99999 Remaining
strokes
7
+19
+20
high
low
UINT16 External factor 0..99999 Transmission
multiplier
8
+21 - BYTE Stroke length 0..100↓ Stroke length 9
+26
+27
high
low
UINT16 Error see Error / Warning 12
+28
+29
high
low
UINT16 Warnings see
+30
+31
+32
+33
high
↓
low
UINT32 Stroke counter 0..(232)-1 Stroke number 13
Operation
15

Offset Value Type Name Range Module name Module no.
+34
+35
+36
+37
high
↓
low
FLOAT Quantity
counter
... (litre) Quantity 14
+38
+39
+40
+41
high
↓
low
FLOAT Litres per
stroke
... (litre)
5.4.2 Configure
It is possible to select on the master which modules are to be involved in
cyclic data transmission. Modules and slots always relate to each other.
Empty spaces (empty modules) therefore have to be configured for mod‐
ules to be excluded.
The target configuration is defined in the form of identifiers. The identifier
is stated in the last column in for every defined module.
The identifiers of the modules have to be listed successively in ascending
order. If the data of a module is not to be involved in cyclic data transmis‐
sion, then an empty module must be configured at this point.
Operation
16

Tab. 6: Configuration for the transmission of all cyclic modules (42 byte input, 17 byte output)
Module 1 Module 2 Module 3 Module 4 Module 5 Module 6 Module 7 Module 8
40, 83 80, 81 C0, 80, 80 C0, 81, 83 80, 81 C0, 85, 83 40, 83 C0, 82, 81
Module 9 Module 10 Module 11 Module 12 Module 13 Module 14
40, 83 80, 80 80, 80 40, 83 C0, 80, 83 C0, 80, 87
The following table shows an example for a target configuration in which
the modules 8, 10, 11 and 14 are excluded from the cyclic data transmis‐
sion.
INFO
The data objects can still be reached acyclically.
Tab. 7: Target configuration
Module 1 Module 2 Module 3 Module 4 Module 5 Module 6 Module 7 Module 8
40 83 80 81 C0 80 80 C0 81 83 80 81 C0 85 83 40 83 0
Module 9 Module 10 Module 11 Module 12 Module 13 Module 14
40 80 0 0 40 83 C0 80 83 0
The pump checks whether the target configuration corresponds to the
actual configuration. If this is not the case, the pump reacts and sends a
configuration error in the standard diagnostics.
In order for the target configuration to function, the options for the crea‐
tion of the identifier formats must be limited and the followings rules must
be observed.
nAlways use the special identifier format for the coding.
nAlways use the byte structure as the format.
nDo not state any manufacturer-specific data (e.g., data types).
nModules must always be replaced with empty modules to remove
them from the cyclic data transmission.
By excluding individual modules from the cyclic data transmission, the
offset addresses of the transmitted data objects will shift - see and :
Tab. 8: Pump data (reduced output data)
Offset Value Type Name Range Module name Module no.
+0 - BYTE Start-Stop 0.1 Control 2
+1 - BYTE Reset 0.1↓
+2 - BYTE Mode see Operating
mode
3
+3
+4
high
low
UINT16 Frequency 0..max. Freq. Frequency 4
+5
+6
+7
+8
high
↓
low
UINT32 Batch prese‐
lection
1..99999 Batching 6
+9 - BYTE Batch start 0.1↓
Example configurations
Operation
17

Offset Value Type Name Range Module name Module no.
+10 - BYTE Batch
memory
0.1
+11 - BYTE Delete stroke
counter
0.1↓ Stroke
number
13
Tab. 9: Pump data (reduced input data)
Offset Value Type Name Range Module name Module no.
+0
+1
+2
+3
high
↓
low
UINT32 Status see Status 1
+4 - BYTE Mode see Operating
mode
3
+5
+6
high
low
UINT16 Frequency 0..max. Freq. Frequency 4
+7
+8
high
low
UINT16 Actual fre‐
quency
0..max. Freq.
+9
+10
high
low
UINT16 Maximum fre‐
quency
0..12000↓ Maximum fre‐
quency
5
+11
+12
+13
+14
high
↓
low
UINT32 Batch prese‐
lection
1..99999 Batching 6
+15
+16
+17
+18
high
↓
low
UINT32 Remaining
strokes
1..99999 Remaining
strokes
7
+19 - BYTE Stroke length 0..100↓ Stroke length 9
+20
+21
high
low
UINT16 Error see Error /
Warning
12
+22
+23
high
low
UINT16 Warnings see
+24
+25
+26
+27
high
↓
low
UINT32 Stroke
counter
0..(232)-1 Stroke
number
13
5.5 Acyclic data transmission
(from DP-V1)
The acyclically transmitted data are addressed via slot and index. All data
summarised under one slot can then be addressed individually via the
index and be transmitted acyclically.
Operation
18

Slots are identical to the modules of the cyclical trans‐
mission.
Tab. 10: Slots of the acyclic data objects
No. Slot Index Data object Type Length Channel Channel Read /
write
0 Slot 0 1 Device identifier UINT32 4 byte MS1 MS2 read
1 Slot 1 1 Status UINT32 4 byte MS1 MS2 read
2 Slot 2 1 Start-Stop BYTE 1 byte MS1 MS2 write
3 2 Reset BYTE 1 byte MS1 MS2 write
4 Slot 3 1 Mode BYTE 1 byte MS1 MS2 write
5 2 Mode BYTE 1 byte MS1 MS2 read
6 Slot 4 1 Frequency UINT16 2 byte MS1 MS2 write
7 2 Frequency UINT16 2 byte MS1 MS2 read
8 3 Actual frequency UINT16 2 byte MS1 MS2 read
9 Slot 5 1 Maximum frequency WORD 2 byte MS1 MS2 read
10 Slot 6 1 Batch preselection UINT32 4 byte MS1 MS2 write
11 2 Batch preselection UINT32 4 byte MS1 MS2 read
12 3 Batch start BYTE 1 byte MS1 MS2 write
13 4 Batch memory BYTE 1 byte MS1 MS2 write
14 Slot 7 1 Remaining strokes UINT32 4 byte MS1 MS2 read
15 Slot 8 1 External factor UINT16 2 byte MS1 MS2 write
16 2 External factor UINT16 2 byte MS1 MS2 read
17 4 External factor BYTE 1 byte MS1 MS2 write
18 Slot 9 1 Stroke length BYTE 1 byte MS1 MS2 read
19 Slot 10 1 Metering monitor BYTE 1 byte MS1 MS2 write
21 Slot 12 1 Error UINT16 2 byte MS1 MS2 read
22 2 Warnings UINT16 2 byte MS1 MS2 read
23 Slot 13 1 Stroke counter UINT32 4 byte MS1 MS2 read
24 3 Delete stroke
counter
BYTE 1 byte MS1 MS2 write
25 Slot 14 1 Quantity counter FLOAT 4 byte MS1 MS2 read
26 2 Litres per stroke FLOAT 4 byte MS1 MS2 read
27 3 Delete quantity
counter
BYTE 1 byte MS1 MS2 write
28 Slot 15 1 Identity code STRING 32 byte MS1 MS2 read
29 2 Serial number STRING 16 byte MS1 MS2 read
30 3 Device names STRING 32 byte MS1 MS2 Read /
write
31 4 Installation place STRING 16 byte MS1 MS2 Read /
write
Operation
19

5.6 Extended diagnostics
(from the 7th byte)
The pump uses the mechanism of the extended PROFIBUS® diagnostics
to report error statuses to the master. The extended diagnostics can be
found in the diagnostics telegram. The extended diagnostics include the
device-related "Alarm_Type (48)" and the "Diagnostic_User_Data".
Tab. 11: Construction of the extended PROFIBUS® diagnostics telegram
Header_Byte Alarm_Type Slot_Number Alarm_Specifier Diag‐
nostic_User_Data
Bit 1-6: Length of the status message,
including Header_Byte
48 1 1 see Table
Ä Tab. 12 ‘Diag‐
nostic_User_Data’
on page 20
Bit 7-8: 0
Diagnostic_User_Data consists of a minimum of one group of 3 bytes with
error information. Diagnostic_User_Data consists of a maximum of 19
groups. The error information of a group is coded as follows:
Tab. 12: Diagnostic_User_Data
Service no.
(1st byte)
(2nd byte)
Error type
Type of data access
(3rd byte)
No. – see Table
Ä Chapter 5 ‘Operation’
on page 10
0x30 OK
0x31 Date outside of limits
0x32 Date protected
0x34 Option not installed
0x35 Service not defined
0x36 Value cannot be changed
0x37 Update completed
0x55 Communication error
0xD3 Write access
0xE5 Read access
Operation
20
