PROPELLA PRO 9S User manual

USER GUIDE
P
R
O
P
E
L
L
A
E
L
E
C
T
R
I
C
B
I
K
E
w
w
w
.
p
r
o
p
e
l
l
a
.
b
i
k
e
9S PRO
Updated: 2022.09.14

IMPORTANT SAFETY WARNING!
READ THIS USER GUIDE AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS
BEFORE USING YOUR PROPELLA ELECTRIC BIKE. FAILURE TO FOLLOW THESE SAFETY
INSTRUCTIONS COULD RESULT IN SERIOUS PERSONAL INJURY, DEATH, OR DAMAGE TO THE
PRODUCT ITSELF OR NEARBY PROPERTY.
1. Always wear a well-fitting helmet while riding your Propella Bike. A helmet is necessary to protect your head in
the event of a fall or collision. Failure to wear a helmet could result in serious personal injury or death.
2. Turn off the Propella Bike and disconnect the battery before doing any repair or maintenance work. When the
Propella Bike is turned on, rotating the pedals will activate the motor and spin the wheel. Failing to turn off
the Propella Bike before any repair or maintenance, could result in serious personal injury or death, or damage to
nearby property.
3. Ensure the battery pack is locked and secure before riding. An unlocked battery may detach from the bike
during ride which could result in personal injury, death, or damage to nearby property.
4. Use only the battery, battery charger unit, and charging cable provided with your Propella Bike. Do not use any
other adapter cables with your Propella Bike, unless you purchase it from Propella and you confirm that it is
intended for use specifically with your bike. Use of another battery charger unit or charging cable may lead your
battery to overheat or catch fire, which could result in serious personal injury, death, or damage to nearby property.
5. Do not burn, break, gouge, puncture, crush, drop, or otherwise damage your Propella Bike, battery, battery
charger unit, or charging cable. Damaging your Propella Bike or its battery, battery charger unit, or charging cable
may cause overheating, fire, explosion, or smoking, which could result in serious personal injury or death. or damage
to nearby property.
6. Do not immerse your Propella Electric Bike battery in liquid of any kind. Your Propella Bike’s battery is water
resistant and can be used to ride your bike outside in the rain, but the battery should not be immersed in water or
any other liquid. Dry your battery before storing and store your dry battery in a clean, dry environment. Immersing
your battery in liquid or storing it while wet could result in an electrical short circuit, and may cause fire, explosion,
or smoking, which could result in serious personal injury or death, or damage to nearby property.
7. Do not attempt to repair or modify the battery, charger unit, or any other electrical components of your Propella
Bike (except as described in warranty service instructions). Do not attempt to open or tamper with the battery pack,
or other electronic components (except as described in warranty service instructions), which could cause
overheating, fire, explosion, or smoking and could result in serious personal injury, death, or damage to nearby
property.
8. Keep small metal objects away from the battery pack. Small metal objects can come in contact with the battery
terminals and create a short circuit which will damage the battery, or may cause fire, explosion, or smoking, which
could result in serious personal injury or death, or damage to nearby property.
9. Do not get your battery charger unit or charging cable wet. The battery charger unit and charging cable are not
waterproof and are designed for indoor use only. Do not get them wet. Clean with a dry cloth only. If your battery
charger unit or charging cable gets wet, it could damage the battery pack, or result in an electrical short circuite.

10. Before riding, ensure all components of your Propella Bike are in good working order and all connections are
tight. Make sure the pedals and the front wheel quick-release are tight. Check the tire pressure and make sure the brakes
are in good working order. Riding a Propella Bike with loose wheels, connections, or brakes could result in serious
personal injury or death.
11. Do not over-inflate the tires on your Propella Electric Bike. The maximum tire pressure is shown on the tire
sidewalls. Overinflating the tires can result in tire puncture during ride which could result in serious personal injury or
death.
12. Stop using and turn off immediately if you suspect any part of your Propella Bike, battery, battery charger unit,
or charging cable is damaged. Inspect your Propella Bike, battery, battery charger unit, and charging cable regularly. If
you notice any damage, punctures, deformation, leakage, discoloration, or other abnormalities, do not use your Propella
Bike or any of its accessories. Store damaged batteries outside. Contact Propella immediately. Continuing to use your
Propella Bike if any part is damaged may cause overheating, fire, explosion, electric shock, or smoking, which could result
in serious personal injury or death. It could also result in other damage to your Propella Bike, battery, battery charger unit,
or charging cable, or nearby property.
13. Do not operate, charge, or store your Propella Bike, battery, battery charger unit, or charging cable in locations
where the temperature may reach over 120°F (48°C). (See “Battery Safety Tips' ' section of this User Guide for
recommended operating and storage temperatures). Do not leave your Propella Bike battery in direct sunlight or inside of
a car in direct sunlight. Do not leave your battery near an open flame or heater. Do not cover your battery while charging.
Allowing your Propella Bike, battery, battery charger unit, or charging cable to become too hot may cause overheating,
fire, explosion, electric shock, or smoking, which could result in serious personal injury or death. It could also result in
damage to your Propella Bike, battery, battery charger unit, charging cable, or nearby property.
14. Keep your Propella Bike and all its components out of reach of children and pets. Your Propella Bike is not a toy.
Never allow children to play with or use your Propella Bike, battery, battery charger unit, or charging cable, or
accessories. Your Propella Bike and its accessories contain small parts that may present a choking hazard. Allowing
children to access or play with your Propella Bike, battery, battery charger unit, or charging cable could result in serious
personal injury to or death of the child. Failure to keep pets away from your Propella Bike, battery, battery charger unit, or
charging cable could result in the pet suffering serious injury or death.
15. Keep cords out of reach of children. Children can get tangled in charging cables, risking serious personal injury
or death by strangulation. Place cables at least three feet away from any crib, bassinet, play yard, or other safe sleep
environment.
16. Do not use a Propella Electric Bike if you have a pacemaker or other implanted medical device. Propella Bike
batteries and other electrical components emit electromagnetic waves that could interfere with pacemakers or other
implanted medical devices. Interference with a pacemaker or other implanted medical device could cause the device to
malfunction and result in serious personal injury or death.
CONTAINS LITHIUM ION BATTERY
DO NOT DISPOSE OF BATTERY IN HOUSEHOLD WASTE.
CONTACT YOUR LOCAL RECYCLING FACILITY AND DISPOSE OF PROPERLY.
SAVE THESE WARNINGS

HOW TO GET STARTED …………………………….............................................................……….………... 2
BATTERY SAFETY TIPS ………………………………………...............................................................…...…. 5
BATTERY STORAGE TIPS ………………….............................................................……………….……....... 7
GENERAL MAINTENANCE TIPS …….............................................................…………….…………....... 8
WARRANTY & CUSTOMER SUPPORT ……….............................................................……...…...…. 9
POWER ADAPTER
LI-ION BATTERY CHARGER
INPUT: AC100-240V
OUTPUT: DC 42V 3A
BATTERY
36 VOLT LITHIUM-ION (360 WATT-HOUR)
CHARGING TEMPERATURE: 40-112° F (5-45° C)
OPERATING TEMP: -4 - 122° F (-20 - 50° C)
MOTOR
DC HUB MOTOR
350W NOMINAL (500W PEAK)
PACKAGE CONTENT
ELECTRIC BIKE
BATTERY PACK
CHARGER & PARTS
USER GUIDE
MULTI-TOOL
ASSEMBLY
WATCH THE BIKE ASSEMBLY VIDEO AT www.propella.bike/assemble
ELECTRICAL SPECS

●WHEN INSTALLING THE BATTERY, APPLY ENOUGH PRESSURE UNTIL YOU HEAR
A CLICK.
●ENSURE THAT THE BATTERY IS LOCKED AND SECURE BEFORE RIDING.
●REMOVE THE BATTERY WHEN THE BIKE IS MOUNTED ON A BUS OR CAR RACK.
●READ THE BATTERY SAFETY TIPS TO ENSURE SAFE AND PROPER USE OF YOUR
E-BIKE BATTERY. THIS DOCUMENT IS INCLUDED IN THE USER GUIDE (PAGE 5)
AND AVAILABLE ONLINE AT: www.propella.bike/userguide
2
BATTERY INSTALLATION
SAFETY TIPS:
NOTE: BATTERY LOCK KEYS ARE UNIQUE TO EACH CUSTOMER AND PROPELLA
DOES NOT STORE ANY EXTRAS. IF NEEDED, PLEASE MAKE EXTRA COPIES OF
YOUR KEYS.

1. PRESS AND HOLD THE POWER BUTTON TO TURN ON THE SYSTEM.
[SEE ILLUSTRATION ABOVE]
WARNING : ONCE THE DISPLAY IS TURNED ON, ROTATING THE PEDALS WILL ACTIVATE
THE MOTOR. MAKE SURE YOU ARE MOUNTED ON THE BIKE AND READY TO RIDE.
WARNING:  NEVER RIDE WITHOUT A HELMET, OR AT NIGHT WITHOUT LIGHTS.
2. THE MOTOR ASSIST TURNS ON WHEN YOU START PEDALLING .
3. THE MOTOR ASSIST AUTOMATICALLY TURNS OFF WHEN YOU STOP PEDALLING OR 
PRESS THE BRAKE LEVERS.
4. YOU CAN CONTROL THE LEVEL OF ASSIST BY USING THE +/- BUTTONS.
LEVEL “1” IS THE MINIMUM ASSIST, AND LEVEL “5” PROVIDES THE MAXIMUM POWER
AND SPEED.
THE MOTOR TOP SPEED IS ABOUT 20 MPH (32 KPH) AT FULL BATTERY LEVEL. YOU CAN
STILL PEDAL FASTER TO REACH A HIGHER SPEED.
5. TO TURN OFF PEDAL-ASSIST, LOWER THE ASSIST LEVEL TO “0”.
6. TO TURN OFF THE SYSTEM COMPLETELY, PRESS AND HOLD THE DISPLAY POWER
BUTTON. NOTE: THE SYSTEM WILL AUTOMATICALLY SHUT DOWN AFTER 3 MINUTES
OF INACTIVITY.
3
LCD DISPLAY
WHAT IS PEDAL-ASSIST ?
PEDAL-ASSIST (PASS) PROVIDES SEAMLESS ELECTRIC POWER ASSIST AS YOU PEDAL. YOU
CAN USE IT TO CLIMB HILLS, GO FARTHER AND FASTER, OR SIMPLY ENJOY A BOOST OF
POWER WHILE YOU RIDE!
POWER / MODE
BUTTON
+
BUTTON
–
BUTTON
MOTOR POWER INDICATOR
SPEED
INDICATOR
BACKLIGHT
DISPLAY
PEDAL - ASSIST
LEVEL INDICATOR
0 TO 5
ODOMETER INDICATOR
BATTERY
STATUS

4
LCD DISPLAY FUNCTIONS AND SETTINGS
1. PLUG THE BATTERY CHARGER UNIT INTO A STANDARD WALL OUTLET
AND CONNECT THE CABLE TO THE BATTERY. [SEE ILLUSTRATION]
2. PLUG THE BATTERY CHARGER UNIT INTO A STANDARD
WALL OUTLET AND CONNECT THE CABLE TO THE BATTERY.
[SEE ILLUSTRATION]
3. A FULLY DRAINED BATTERY TAKES ABOUT 2.5 - 3 HOURS
TO RECHARGE. A GREEN LED LIGHT ON THE CHARGER WILL
ILLUMINATE ONCE THE BATTERY IS FULLY CHARGED. YOU CAN
CHECK THE BATTERY LEVEL BY TAPPING ON THE ROUND
BUTTON ON TOP OF THE BATTERY.
SAFETY TIP : UNPLUG THE CHARGER ONCE THE BATTERY IS
FULLY CHARGED.
NOTES:
PUSH THE CHARGER PLUG IN FIRMLY TO ENSURE CONNECTION.
A RED LED LIGHT ON THE CHARGER INDICATES THAT CHARGING
IS IN PROGRESS.
YOU CAN CHARGE YOUR BATTERY ON OR OFF THE BIKE.
●PRESS THE “ ON/OFF ” BUTTON ONCE TO SWITCH BETWEEN: ODO(mil) → M AX. SPEED(mph)
→AVG. SPEED (mph) → TRIP TIME (Min.)
●PRESS AND HOLD THE “ + “ BUTTON FOR 1 SECOND TO ACTIVATE THE DISPLAY BACKLIGHT.
LIKEWISE, HOLD THE “ + “ BUTTON TO TURN IT OFF.
●IN TRIP MODE, PRESS THE " UP" AND "DOWN" BUTTONS AT THE SAME TIME FOR MORE THAN
1 SECOND TO RESET THE TRIP DATA INFORMATION.
●SHORT PRESS THE POWER BUTTON AND THEN HOLD THE “ – “ BUTTON TO ACTIVATE THE
WALK MODE. THE SCREEN DISPLAY WILL SHOW . THIS WILL GENTLY ENGAGE THE
MOTOR AND PUSH THE BIKE FORWARD AT A LOW SPEED OF 3 MPH. THIS FEATURE IS
USEFUL WHEN WALKING YOUR BIKE UP A VERY STEEP HILL.
●TO ACCESS SETTING MODE, PRESS AND HOLD THE POWER AND THE “ – ”BUTTON
SIMULTANEOUSLY FOR 1 SECOND. PRESS THE " + " OR " – " BUTTON TO CHOOSE THE
DISIRED SETTING , AND THEN PRESS THE POWER BUTTON TO CONFIRM AND STORE A
CHANGED SETTING .

(
PROPELLA E-BIKE BATTERY SAFTY TIPS
CHARGING
• DO NOT CHARGE THE BATTERY WITH UNAUTHORIZED CHARGERS.
• ONLY USE THE CHARGER PROVIDED BY PROPELLA.
• AVOID LEAVING THE CHARGER PLUGGED IN FOR MORE THAN NEEDED.
• DO NOT USE OR CHARGE THE BATTERY AND CONTACT PROPELLA IF THERE ARE
NOTICEABLE ABNORMALITIES SUCH AS DAMAGE, PUNCTURE, DEFORMATION, LEAKAGE,
DISCOLORATION, ETC.
• THE CHARGING PROCESS ON A FULLY DRAINED BATTERY SHOULD TAKE NO MORE
THAN 3 HOURS
• IT IS RECOMMENDED TO UNPLUG THE CHARGER WHEN THE BATTERY IS FULLY
CHARGED. THE LED LIGHT ON THE BATTERY CHARGER TURNS GREEN WHEN THE
BATTERY IS FULLY CHARGED.
• AVOID RUNNING THE BATTERY UNTIL IT IS COMPLETELY OUT OF CHARGE. MONITOR
THE CHARGE LEVEL AND TURN IT OFF BEFORE IT GETS TOO LOW.
5
DURABILITY
•THE BATTERY IS RESISTANT AGAINST SPLASH AND RAIN. IF THE E-BIKE IS PARKED
OUTSIDE UNDER HEAVY RAIN OR SEVERE WEATHER, IT IS BEST TO REMOVE THE
BATTERY AND STORE IT INDOOR.
•DO NOT DISASSEMBLE, MODIFY, OR REPAIR THE BATTERY.
•DO NOT INSERT METAL PARTS INTO THE BATTERY TERMINAL.
•DO NOT IMMERSE BATTERY IN WATER OR OTHER TYPES OF LIQUID.

•DO NOT USE, CHARGE, OR STORE THE BATTERY IN HIGH-TEMPERATURE ENVIRONMENTS.
•AVOID LONG EXPOSURE TO DIRECT SUNLIGHT.
•DO NOT LEAVE THE BATTERY FOR LONG PERIODS INSIDE A PARKED CAR IN DIRECT
SUNLIGHT.
•DO NOT PLACE NEAR OPEN FLAME OR HEATER.
SHIPPING
6
TEMPERATURE WARNING
•USE GROUND TRANSPORTATION WITH PROPER
PACKAGING AND LABELING.
•PACKAGING SHALL BE COMPLIANT WITH THE D.O.T
AND SHIPPING CARRIER REGULATIONS.
•REMOVE THE BATTERY WHEN THE BIKE IS MOUNTED ON A BUS OR CAR BIKE RACK.
•BATTERY PACK FORBIDDEN FOR TRANSIT ABROAD PASSENGER AIRCRAFT OR VESSEL.

• STORE THE BATTERY IN A COOL AND DRY ENVIRONMENT.
• REFER TO THE TABLE ABOVE FOR RECOMMENDED STORAGE TEMPERATURES.
• DO NOT STORE THE BATTERY WITH THE CHARGER PLUGGED IN.
• KEEP AWAY FROM FLAMMABLE OR OTHER HAZARDOUS MATERIAL.
• PRIOR TO STORING THE BATTERY, MAKE SURE IT HAS A HEALTHY STATE-OF-
CHARGE (SOC) OF 50-100%.
• FOR LONG-TERM STORAGE (3-12 MONTHS), RECHARGE THE BATTERY EVERY
2 - 3 MONTHS TO MAINTAIN A HEALTHY STATE-OF-CHARGE (SOC).
STORAGE TEMPERATURE
1-3 MONTHS
3-12 MONTHS
-20°C to 40°C
-20°C to 20°C
-4°F to 104°F
-4°F to 68°F
Celsius Fahrenheit
LITHIUM-ION BATTERY STORAGE TIPS
7
THE FOLLOWING IS A LIST OF TIPS THAT WILL HELP INCREASE THE LIFESPAN OF
YOUR E-BIKE BATTERY PACK WHILE STORING THEM.
IN ADDITION, FOLLOWING THESE TIPS WILL REDUCE THE RISK OF DAMAGE TO
THE BATTERY AS WELL AS POTENTIAL SAFETY HAZARDS.

PERIODIC INSPECTION AND MAINTENANCE SERVICE ON YOUR E-BIKE IS HIGHLY
RECOMMENDED FOR SAFETY , RELIABILITY , AND OPTIMUM PERFORMANCE.
NOTE: IF YOU’RE NOTICING ISSUES OR ABNORMALITIES WITH ANY OF THE BICYCLE
COMPONENTS
(BRAKES, PEDALS, ETC.), PLEASE VISIT A BIKE SHOP OR MECHANIC FOR PROPER
DIAGNOSIS AND REPAIR.
NOTE: IF YOU’RE NOTICING ISSUES OR ABNORMALITIES WITH ANY OF THE ELECTRICAL
COMPONENTS (BATTERY, MOTOR, ETC.) PLEASE CONTACT US AT www.propella.bike /support
WATCH OUR VIDEO AT www.propella.bike/service OR SCAN THE QR CODE BELOW:
8
BASIC MAINTENANCE TIPS
WARNING: MAKE SURE YOUR ELECTRIC BIKE IS TURNED OFF BEFORE DOING ANY REPAIR
OR MAINTENANCE WORK.
FOR MORE INFORMATION ON:
•CHAIN LUBRICATION
•TIRE PRESSURE AND PUMPING AIR
•BOLT CHECKS
•FRONT WHEEL QUICK-RELEASE CHECK
•BRAKE ADJUSTMENT
•GEAR SHIFTER ADJUSTMENT
•BATTERY LOCK CHECK

9
IF THE E-BIKE FAILS IN NORMAL USE WITHIN THE FIRST 12 MONTHS OF OWNERSHIP,
PROPELLA WILLREPAIR OR REPLACE THE PRODUCT. AFTER 12 MONTHS, PROPELLA CAN
PROVIDE TECHNICAL SUPPORT SERVICE ON ELECTRICAL COMPONENTS AND OFFERS
AVAILABLE REPLACEMENT PARTS AT RETAIL PRICE.
WARRANTY COVERAGE IS VALID STARTING THE DATE OF DELIVERY WITH THE FOLLOWING
CONDITIONS:
WEAR AND TEAR AND DAMAGE TO BICYCLE COMPONENTS SUCH AS TIRES, TUBES, BRAKE
PADS, CHAINS, CABLES, GEARS, ETC. ARE NOT COVERED BY THIS POLICY.
WARRANTY POLICY DOES NOT COVER DAMAGE DUE TO NEGLECT, ABUSE, IMPROPER
ASSEMBLY, IMPROPER OR INADEQUATE MAINTENANCE, MODIFICATIONS, ACCIDENTS, OR
NONCOMPLIANT WITH THE USER GUIDE OR PRODUCT WARNING LABELS.
DAMAGE DUE TO EXTREME TEMPERATURE, OR WATER IMMERSION ARE NOT COVERED BY THIS
POLICY.
TAMPERING WITH THE BATTERY OR OTHER ELECTRICAL COMPONENTS WILL RESULT IN A
VOIDEDWARRANTY.
WARRANTY SERVICE ONLY APPLIES TO COUNTRIES/REGIONS WHERE PROPELLA OFFERS SALE
ANDDISTRIBUTION.
SERIAL NUMBER
PLEASE KEEP TRACK OF YOUR BIKE UNIQUE SERIAL NUMBER IN CASE YOU MAY NEED IT.
THE SERIAL NUMBER IS PRINTED ON THE UNDERSIDE OF THE FRAME, UNDERNEATH THE
BOTTOM BRACKET HOUSING.
THE DIGITS OF THE SERIAL NUMBER ARE UNIQUE TO YOUR BIKE AND PROPELLA DOES NOT
KEEP A RECORD OF THIS INFORMATION.
WRITE YOUR SERIAL NUMBER DOWN BELOW:
--------------------------------------------
CUSTOMER SUPPORT
IF YOU ENCOUNTER ANY ISSUES WITH YOUR PRODUCT OR HAVE ANY QUESTIONS, FEEL FREE
TO CONTACT US ON OUR WEBSITE: www.propella.bike /support
WARRANTY POLICY

JOIN US!
#PropellaBikes
instagram.com/propella.bike
facebook.com/PropellaBikes
www.propella.bike
