ProScan PLT9602G User manual

User Manual
0

User Manual
1
Key points：
This manual includes security measures and correct operating methods. For personal safety, please make sure to read this
manual before using. Thank you!
The machine adopts capacitive touch screen, you can just touch it by finger or click with capacitive pen for operation. (Never use
the sharp objects to click the screen, or the touch screen may be damaged).
Do not put the device at any high temperature, high humidity or dusty place.
Do not drop or crash the device to prevent the violent impacting between the display and the capacitive touch screen. Or the
customers have to take the consequence by themselves.
Please choose the suitable volume and never make the too loud volume .If you feel uncomfortable please turn down the volume
or stop to use the device soon.
Please charge if you meet those situations as below:
A、Low battery on the battery icon. B、The system turns off automatically.
C、The keys do not work. D、“ ” is battery charging.
【Note】:Don’t use the different type charger or it may make the device burned. We assume no liability for the damage.
Please contact with our agent if you need the original adaptor.
In the charging process，the device may be warning up a little (not too hot), this is normal, and it won’t effect functions.
Do not disconnect the device while formatting, downloading or uploading, or it may make the error.
Our company won’t bear the duty for the loss of the memory erasing on account of the damage, repair or some other reason.
Please operate the device according to the user manual rightly and backup the important data in time.
Do not dismantle this device by yourself, and do not polish it with alcohol, dilution, or benzene.
Do not use this device where electronics is forbidden, such as on the airplane.
Do not use this device while walking and driving, avoiding traffic accident.
USB is for transferring data.
Virus can damage this device. So please use proper computer antivirus and keep it updated.
For any support needed for this device please contact the company or the authorized distributor. Any unauthorized dismantling of
the device will make the warranty null and void.
We reserve the right to keep the change of the products, the specification and design is subject to change without notice!

User Manual
2
Packing List: ：
Please check box for the following items
1. Device
2. User Manual
3. Product Warranty
4. Power Adaptor (Note that this unit is meant to be charged by using the adapter. USB charging is an option but charging time will
be increased greatly. And please use the adaptor for recharge if battery of device is gone and cannot be powered on.)
5. USB Cable
6. Keyboard Case (Optional) (Note: Please plug in USB cable of Keyboard Case in the tablet before powering on the unit)
Other accessories can be purchased at local retailers
The accessories may not be compatible with other devices
Power Adaptor Specification:
MODEL: WRP2U-050200C
(Optional) STC-A520B-D
INPUT: AC 100-240V 50/60Hz 0.35A MAX
OUTPUT: 5.0V 2.0A

User Manual
3
Device description
①Touch screen：You can click and drag in the touch screen.
★②Camera：You can take photos and videos etc..
③Volume-：Turn down the volume.
④Volume+：Turn up the volume.
⑤POWER：Keep pressing button over 2 seconds for power on/ off, press
button once to turn on screen from sleep mode .
⑥：Earphone jack: 3.5mm standard earphone jack.
⑦MIC：Microphone jack
⑧：Micro USB, Micro-5 pin connector.
⑨：DC jack: Connect the power cable to charge to the device.
⑩Speaker holes：Output sound.
⑪Micro SD/TF card：Micro SD/TF card slot.
⑫RESET：Reset the device.
【TIPS 】：1. When the battery is low, it will power off automatically.
2. Shutdown illegally, when you restart, device would scan
and repair the disk. The screen will stay at the progress bar
for a long time .
【Note】： The pictures in the user manual are just for your reference, about the “★” item, please according to the real products.

User Manual
4
Setting up for the first time
Charging your device：
For first-time use, you need to charge the device for ten hours.
After that you can recharge the device as needed.
Connect the DC-in jack to your device and plug the AC adapter into
any AC outlet.
【TIPS】:
1. This device adopts built-in polymer battery. Only the specified
charger
should be used.
2. It is normal for the device’s surface to become warm during charging
or long
periods of use. All devices are factory tested before release.
3. If you do not use this set for a long time, please charge/release it once
one month to avoid deep discharge. The damage caused by battery over-consuming is not included in the warranty.
Battery Saving
To save battery running life, please see below key points. With below suggestions, battery can run longer time after fully charged
each time.
1. When device is not in use, press power button once to go to sleep mode.
2. Shut down the applications when not in use.
3. Turn off WLAN when not in use
4. Shut off application sync selection
5. Set a shorter time for display backlight
6. Reduce brightness of display

User Manual
5
Power On
Keep pressing power button over 2 seconds, device will start up opening screen, Android system is activating and enter the main
screen.
Sleep Mode
After devise is on, press power button once and it goes to sleep mode. The screen is now on standby and under low battery
consumption. To wake up device, press one more time power button.
Power off and Forced Shut down
When you are not using the device, keep pressing power button over 2 seconds,
the screen will display “shut down”, select “Yes”to power off unit completely.
If device is hanging, use a small pin to press Reset hole, it will forced shut down
and the device will power on again.
Operation of Touch Panel
Click -- Use finger or capacity panel pen to touch once, so as to select or activate function, or select menu or turn on applications.

User Manual
6
Tap and hold -- Tap over 2 seconds, it will turn on option list
Slide -- Slide up, down, left or right for fast scrolling browsing page and display screen
Drag –drag an icon and relocate the position

User Manual
7
Double Click –Double click to enlarge or shrink the display size of picture or under browsing webpage.
Shut --Use two fingers at same time on touch panel, to enlarge or to shrink the display scale.

User Manual
8
Home Screen
①Google Search
②Click to turn on voice search, it will search according to voice input ( Make sure WIFI is on )
③Back to previous screen
④Back to Home screen
⑤List of last running applications
⑥Shortcut to application
⑦Enter applications page
⑧Display of icons and device status, click to turn on notification screen

User Manual
9
Home screen with a set of 5 screens, slide left/ right to view individual screen
Change of Wallpaper
1. Tag home screen, it will pop-up wallpaper selection
2. Select preloaded wallpapers or picture as wallpaper
3. Click “setup”to confirm
Add shortcut on Home screen
1. Enter in application page, tag the icon of application
2. Locate the icon to designated position or locate it in another screen
Add Widget in Home Screen
1. Enter application page and slide to Widget page
2. Slide left / right to select widget
3. Tag designated widget and locate it in home screen
Remark：Some widgets is linked to internet service, be careful it will occur data cost
Some widgets might only be used in certain countries or under assigned service providers
Relocate the shortcut on Home screen
1. Tag the application icon and move
2. Move icon to the designated position
Cancel shortcut on Home screen
1. Tag the application icon, recycle bin displays on upper screen
2. Drag icon to recycle bin
3. When icon changes to red, let go
