Protech Systems KF-7130 User manual

If you discover any item below damaged or lost,
please contact your vendor.
KF-7130 Kiosk Main Unit x1
This Quick Reference Guide x1
KF-7130
Quick
Reference
Guide
This Quick Reference Guide x1
Ver. Q1
All Rights Reserved. Copyright 2015
Packing Checklist
KF-7130
KF-7130 KF-7130
Specifications
System View
18.5” Secondary screen
17” Main operation touch screen
Barcode Scanner
Media Card Reader
Motion Sensor
Thermal Printer
RFID Card Dispenser + RFID Module
KF-7130 Kiosk Main Unit X1
This Quick Reference Guide X1
Manual / Driver CD X1
MSR + IC Card + RFID Reader
Full Page Passport Reader
MRZ Password Reader
RFID Module
System
CPU Type Intel®Celeron J1900
Chipset Intel platform Bay Trail SoC
Memory Support 1 x 240-pin DDR3L-1600 SODIMM socket on board, up to 4GB
HDD 500GB 2.5" SATA ⅢHDD 5,400rpm,8MB cache
Speaker 2 x 5W HD speaker
IP54 Front End of PPC only
Dimension (WxHxD) 500 mm x 1775 mm x 540mm (with 2nd display)
System Weight 85 kg
Power 120 W 100-240V , 7.2A , 50-60HZ
Display
LCD Panel Main Display: 17” 4:3 LED backlight
Second Display (optional):18.5” 16:9 LED backlight
Max. Resolution Main Display: 280x1024 dots SXGA
Second Display (optional): 66x768 dots WXGA
Integrated Devices (optional)
MSR + IC Card + RFID SYSKING IMI301-Series
MRZ Passport Reader 3M CR-100 Document Reader
Full Page Passport Reader 3M KR-9000 Full Page Reader
RFID Reader UIC 680TG RFID Reader
Barcode scanner Riotec FS5022J Barcode Scanner
Media Card Reader AFT PRO-37U Media Card Reader
Thermal Printer Epson M-T532II AP / HP Thermal Printer
BA-T500II Control Board
NE-500II Paper near end Sensor
Card dispenser EWT EWTK-2234C1
RFID Module EWTJ-680A-I
Motion Sensor Pro-Wave 400EP14D-NBPN Ultrasonic sensor
I/O Ports
LAN Port 1 x RJ-45, 10/100/1000 Mbps
Phone Port 1x RJ-11
Environment
Operating Temp. 5°C~ 35°C (41°F ~ 95°F)
Storage Temp. 0°C~ 60°C (32°F~ 140°F)
Humidity 20%~ 85%
If you discover any item below are damaged
or lost, please contact your vendor.
AC Power Cord Cable X1

Quick Setup
KF-7130
All Rights Reserved. Copyright 2015
Safety Precaution
17” Projected Capacitive Touch Kiosk
Step 1.
Connect the AC power cord to the AC power jack and
connect the Ethernet cable to the LAN port.
Step 2.
Install the paper roll onto the paper roll axis, and then unlock and open the front door,
and install the paper roll axis onto the paper holder.
• Don’t allow foreign objects to fall into this product.
• If water or other liquid spills into this product, unplug the power cord immediately.
4. Good Care
• When the outside of the case is stained, remove the stain with a neutral washing agent with a dry
cloth.
• Never use strong agents such as benzene and thinner to clean the system.
If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and
then wipe thoroughly with a dry cloth.
• If dust has been accumulated on the outside, remove it by using a special made vacuum cleaner
for computers.
• Don’t contact the surface of capacitive touch before entering your operation system, or capacitive
touch may have position problems for electrostatics interface.
• Don't exchange the M/B battery by yourself or serious damage may incur.
The following messages are reminders for safety on how to protect your systems from damages and to
extend a long life of the system.
1. Check the Cable Voltage
• Make sure the range of operating voltage between AC 100~240V. Otherwise, the system could be
damaged.
2. Environmental Conditions
• Place your KF-7130 on a sturdy, level surface. Be sure to allow enough space to have easy
access around the system.
• Avoid extremely hot or cold place to install the system.
• Avoid exposure to sunlight for a long period of time or in an airtight space.
• Avoid the system from any heating device or using it outdoors in a cold winter day.
• Bear in mind that the operating ambient temperature is from 0~35°C (32~95°F).
• Avoid moving the system rapidly from a hot place to a cold one and vice versa for condensation
may come from inside of the system.
• Place KF-7130 in strong vibration(s) may cause hard disk failure.
• Don’t place the system close to any radio active device in case of signal interference.
3. Handling
• If the system isn’t fully in DOS mode, adjust BIOS setting as the instruction:
Advanced Chipset Feature →Boot display →choose “LFP”.
• Avoid putting heavy objects on top of the system.
• Don’t turn the system upside down. This may cause the hard drive to malfunction.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And therefore we strongly
recommend that qualified engineers can open and disassemble the system. The LCD and Touchscreen are
easily breakable, please handle them with extra care.
Ethernet Cable
Power Cord
AC Power
Jack
LAN Port
Power Button
Paper Roll Axis
Thermal Printer
