Protech Systems KF-7330 User manual

If you discover any item below damaged or lost,
please contact your vendor.
KF-7130 Kiosk Main Unit x1
This Quick Reference Guide x1
KF-7330
Quick
Reference
Guide
This Quick Reference Guide x1
Ver. Q1
All Rights Reserved. Copyright 2016
Packing Checklist
KF-7330
KF-7330 KF-7330
Specifications
System View
KF-7330 Kiosk Main Unit X1
This Quick Reference Guide X1
Manual / Driver CD X1
Key X7
System
CPU Type Intel®Celeron J1900
Chipset Intel platform Bay Trail SoC
Memory Support 1 x DDR3 SO-DIMM socket on board (Default: 4GB)
HDD 500GB 2.5" SATA HDD
Speaker 2W speaker
O.S. Support POS Ready 7 / Windows 7
Dimension (WxHxD) 420 mm x 1464 mm x 405mm (with 2nd display)
System Weight About 110 kg (with package materials)
Power 120 W 100-240V , 7.2A , 50-60HZ
Display
LCD Panel Main Display: 17” 4:3 LED backlight
Second Display (optional):18.5” 16:9 LED backlight
Max. Resolution Main Display: 1280x1024 dots SXGA
Second Display (optional): 1366x768 dots WXGA
Touch Screen Projected Capacitive Touch
Integrated Devices
MSR ISO Track 1/2/3 and JIS II
RFID Reader Read/Write ISO 14443A Mifare
Barcode scanner 1D/2D Bardcode Scanner
Smart Card Reader Read/Write ISO 7816 Smart Card
Pin Pad PCI 3.x certified PAD
Camera 2.1M fixed focus CCD camera module
Thermal Printer Paper width: 79.5 ± 0.5mm/Printing speed: 250 mm/s maximum
Contactless Payment Visa payWave qVSDC, Master Paypass M/Chip
Coin Acceptor Acceptance Rate: 96% or greater
Coin Hopper About €1 x 1500pcs, up to 12 coins per second for payout speed
I/O Ports
LAN Port 1 x RJ-45, 10/100/1000 Base-T Fast Ethernet
Environment
Operating Temp. 5°C~ 35°C (41°F ~ 95°F)
Storage Temp. -20°C~ 60°C (-4°F~ 140°F)
Humidity 20%~ 85%
Desktop KIOSK
Top side only. It could put on
the desk for your convenience.
Barcode Scanner
Contact/Contactless/
MagStrip
PinPad
Printer
18.5” Secondary screen
17” Main operation touch screen
Trim Panel
Camera
Coin Acceptor
Bill Acceptor /
Receiver
Coin Withdrawal Cabinet
Trim Panel
If you discover any item below are damaged
or lost, please contact your vendor immediately.
AC Power Cord Cable X1

Quick Setup
KF-7330
All Rights Reserved. Copyright 2016
17” Projected Capacitive Touch Kiosk
Step 1. Connect the AC power cord to the AC power jack and connect the Ethernet cable to
the LAN port.
Power On and Connect KF-7330 to Network
Step 2. Insert Key#11089 to unlock the Stand.
Step 3. Pull down the knob of the sliding rod to open the Stand door.
Step 4. Switch on the power of the multi socket extension cord located on the bottom of the
inside of the stand.
Step 5. Insert Key#11001 to unlock the Panel.
Step 6. Pull down the knob of the sliding rod to open up the panel.
Step 7. Press the Power button to turn on the system.
Install Paper Roll Onto Printer
Step 1. Insert Key#10001 to unlock the Printer.
Step 2. Move the Printer module outwards.
Step 3. Insert the paper roll onto the paper roll axis.
Step 4. Install the paper roll axis onto the paper holder.
Step 5. Push the paper roll into the printer module.
The paper roll will be then automatically loaded into the
printer module after the printer sensor detects the
paper.
See Figure 3.
See Figure 1 and Figure 2.
Safety Precaution
AC Power
Jack
LAN Port
1
Figure 1 Figure 2 Figure 3
Key#11089
2
4 & 5
Push
Printer
module
outwards.
Paper Roll
Axis
1
2
Sliding rod
3
4Power switch of
Extension Cord
Power Button
3
Key#10001
• Don’t allow foreign objects to fall into this product.
• If water or other liquid spills into this product, unplug the power cord immediately.
4. Good Care
• When the outside of the case is stained, remove the stain with a neutral washing agent with a dry
cloth.
• Never use strong agents such as benzene and thinner to clean the system.
If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and
then wipe thoroughly with a dry cloth.
• If dust has been accumulated on the outside, remove it by using a special made vacuum cleaner
for computers.
• Don’t contact the surface of capacitive touch before entering your operation system, or capacitive
touch may have position problems for electrostatics interface.
• Don't exchange the M/B battery by yourself or serious damage may incur.
The following messages are reminders for safety on how to protect your systems from damages and to
extend a long life of the system.
1. Check the Cable Voltage
• Make sure the range of operating voltage between AC 100~240V. Otherwise, the system could be
damaged.
2. Environmental Conditions
• Place your KF-7130 on a sturdy, level surface. Be sure to allow enough space to have easy
access around the system.
• Avoid extremely hot or cold place to install the system.
• Avoid exposure to sunlight for a long period of time or in an airtight space.
• Avoid the system from any heating device or using it outdoors in a cold winter day.
• Bear in mind that the operating ambient temperature is from 0~35°C (32~95°F).
• Avoid moving the system rapidly from a hot place to a cold one and vice versa for condensation
may come from inside of the system.
• Place KF-7130 in strong vibration(s) may cause hard disk failure.
• Don’t place the system close to any radio active device in case of signal interference.
3. Handling
• If the system isn’t fully in DOS mode, adjust BIOS setting as the instruction:
Advanced Chipset Feature →Boot display →choose “LFP”.
• Avoid putting heavy objects on top of the system.
• Don’t turn the system upside down. This may cause the hard drive to malfunction.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And therefore we strongly
recommend that qualified engineers can open and disassemble the system. The LCD and Touchscreen are
easily breakable, please handle them with extra care.
7
5Key#11001
6Sliding Rod
Key#11031
Key#11009
Key#11039
Key#11053
