Protech Systems BU-2509 User manual

USER’S
MANUAL
BU-2509
Micro ATX Motherboard
With Intel®6th Gen. CoreTM
i7/i5/i3 and Xeon E3 V5
Processor
BU-2509 M1

BU-2509
With Intel®6th Generation CoreTM
Micro ATX Motherboard
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the property of their
respective owners.
This manual is copyrighted in December 2016. You may not reproduce or transmit
in any form or by any means, electronic, or mechanical, including photocopying
and recording.
DISCLAIMER
This operation manual is meant to assist both Embedded Computer manufacturers
and end users in installing and setting up the system. The information contained in
this document is subject to change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case users will be required to correct the interference at his
own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void your
authority to operate such equipment.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of
used batteries according to the manufacturer’s instructions.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual…............................................................
1-2
1-2 System Specification…..........................................................
1-3
1-3 Safety Precautions….............................................................
1-7
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table…....................
2-2
2-2 Component Locations….…...................................................
2-3
2-3 How to Set Jumpers…...........................................................
2-6
2-4 COM Port and Connectors (COM1-COM6)………………
2-8
2-5 Clear CMOS Data Selection (JCMOS1)……………………
2-10
2-6 COM3 and COM4 Port RI / Voltage Selection (JPCOM3,
JPCOM4)…….…………………………………………….
2-11
2-7 Digital Input /Output Port Connector (JDIO1)…….……….
2-12
2-8 Keyboard and Mouse Port (KB_MS1)…………………......
2-13
2-9 DVI Port (DVI-D)...………………………..…….................
2-14
2-10 VGA Port (VGA)….………………………………………..
2-15
2-11 Front Panel Connector (FP1)…………...…………….........
2-16
2-12 LAN & USB Ports (LAN1_USB1, LAN2_USB1)…………
2-17
2-13 Line-In, Line-Out, MIC-In Port (AUDIO1)………………...
2-19
2-14 RS-232/422/485 (COM2) Selection (JP2)…………………
2-20
2-15 COM2 Auto Detection Selection (JP4)………………….…
2-21
2-16 Hardware Power Failure Selection (JP1)…………………...
2-22
2-17 Flash Descriptor Override Selection (JP3)…………………
2-23
2-18 LAN2 Enable/Disable Selection (JP5)………………...…...
2-24
2-19 Mini PCIE Voltage Selection (JP13)……………...………..
2-25
2-20 VCCIO Voltage Selection (JP10)……………...…………...
2-26
2-21 Mini PCI Express Slot (MPCIE1)……………...…………..
2-27
2-22 PCI Express Slots (PCI_E1 (X16), PCI_E2, PCI_E4 (X4),
PCI_E3 (X1))..……………………………………………...
2-28
2-23 CPU / System Fan Connectors (CPU_FAN1, SYS_FAN1,
SYS_FAN2)………..………………………………………
2-33

Contents
2-24 Serial ATA (SATA) Connectors (SATA1, SATA2,
SATA3, SATA4, SATA5, SATA6, SATA7, SATA8)…….
2-34
2-25 Internal USB 3.0 Connector (USB1)……………………….
2-35
2-26 Internal USB 2.0 Connectors (USB2, USB3)………………
2-35
2-27 Display Port Connector (DP1)…………………..…………
2-36
2-28 Power Input Connectors (ATX_PWR1, ATX_PWR2) ……
2-37
2-29 Speaker Connector (JSPEAKER)…………………..………
2-38
2-30 LPC Connector (JLPC1)…………………………..….........
2-38
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction……………..........................................….........
3-2
3-2 Intel®Chipset Software Installation Utility……..……..…...
3-3
3-3 Intel®Trusted Execution Engine Installation Utility……….
3-4
3-4 VGA Driver Utility………………………………….……...
3-5
3-5 LAN Driver Utility……...........................................….........
3-6
3-6 Sound Driver Utility………………………………………..
3-7
CHAPTER 4 BIOS SETUP
4-1 Introduction….......................................................................
4-2
4-2 Entering Setup Utility…........................................................
4-3
4-3 Main…………......................................................................
4-5
4-4 Advanced…...........................................................................
4-6
4-5 Chipset…...............................................................................
4-32
4-6 Security…..............................................................................
4-50
4-7 Boot….…..............................................................................
4-51
4-8 Save & Exit….......................................................................
4-56
APPENDIX A TECHNICAL SUMMARY
Block Diagram…..............................................................................
A-2
Interrupt Map…................................................................................
A-3
Memory Map….……………………………………………………
A-8
I/O Map…........................................................................................
A-10
Watchdog Timer Configuration….………………...………………
A-13
Flash BIOS Update…...............................................…....................
A-16

Page:1-1
INTRODUCTION
This chapter gives you the information for BU-2509. It also outlines
the system specifications.
The following sections are included:
About This Manual
System Specifications
Safety Precautions
Experienced users can jump to chapter 2 on page 2-1
for a quick start.
CHAPTER
1

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-2
1-1. ABOUT THIS MANUAL
Thank you for purchasing our BU-2509 Micro ATX Motherboard with Intel®6th
Generation CoreTM i7/i5/i3 Pentium® processor. The BU-2509 provides faster
processing speed, greater expandability and can handle more tasks than before.
This manual is designed to assist you how to install and set up the system. It
contains four chapters. The user can apply this manual for configuration according
to the following chapters:
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specifications for this system. The final page of this chapter will indicate how to
avoid damaging this board.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the end of
this chapter, you will learn how to set jumper and how to configure this card to
meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the VGA
utility, LAN utility, Sound utility, and Flash BIOS Update. It also describes the
Watchdog-timer configuration.
Chapter 4 BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This appendix introduces you the expansion bus for PCIe connectors.
Appendix B Technical Summary
This appendix gives you the information about the Technical maps.

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-3
1-2. SYSTEM SPECIFICATIONS
System
CPU
BU-2509RA-00P/11P/D0P/D1P: Intel®Skylake-S CPU
socket (LGA1151), supporting i7-6700(TE), i5-6500(TE),
i3-6100(TE), Pentium G4400(TE), Celeron G3900(TE)
BU-2509RA-06P/D6P: Intel®Skylake-S CPU socket
(LGA1151), supporting E3-1275 v5, E3-1225 v5, E3-
1268L v5, i3-6100TE, i7-6700(TE), i5-6500(TE), i3-
6100, Pentium G4400(TE), Celeron G3900(TE)
OS Support
Windows 7, Windows 8.1, Windows 10, Ubuntu14.4
Chipset
BU-2509RA-00P/D0P: Intel®Q170
BU-2509RA-11P/D1P: Intel®H110
BU-2509RA-06P/D6P: Intel®C236
Memory Support
BU-2509RA-00P/D0P: 4 x DDR4 DIMM 2133, supports
dual-channel and non-ECC
BU-2509RA-11P/D1P: 2 x DDR4 DIMM 2133, supports
dual-channel (location: JUDIMM2 / 4) and non-ECC
BU-2509RA-06P/D6P: 4 x DDR4 DIMM 2133, supports
dual-channel, ECC & non-ECC
ECC Compatibility
BU-2509RA-00P/11P/ D0P/D1P: Non-ECC
BU-2509RA-06P/D6P:
- E3-1275 v5, supports ECC
- E3-1225 v5, supports ECC
- E3-1268L v5, supports ECC
- i3-6100TE, supports ECC
- i7-6700(TE), non-ECC
- i5-6500(TE), non-ECC
- i3-6100, non-ECC
- Pentium G4400(TE), non-ECC
- Celeron G3900(TE), non-ECC
BIOS
AMI BIOS
Watchdog
1~255 seconds

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-4
Hardware Monitor
FAN, 12V, 5V, 5Vsb, Vcore
Speaker
Internal buzzer
Power Supply
ATX Power Supply (24 pins + 4 pins)
Dimension
229 mm x 191 mm
Certificate
CE/FCC Class A
I/O Ports
Serial Port
Total 6 COM ports:
*COM1-6: RS-232
*COM2: RS-232/422/485 auto flow control (Rear I/O)
*COM3, 4 support 5V/12V by jumper selection
USB Port
BU-2509RA-00P/06P/D0P/D6P:
Total 6 x USB 3.0, 4 x USB 2.0
4 x USB 3.0 on Rear I/O, others on board (internal wafer)
BU-2509RA-11P/D1P: Total 4 x USB 3.0, 4 x USB 2.0
4 x USB 3.0 on Rear I/O, others on board (internal wafer)
SATA Interface
BU-2509RA-00P/D0P:
6 x SATA III, supports RAID 0/1/5/10
BU-2509RA-11P/D1P: 4 x SATA III
BU-2509RA-06P/D6P:
8 x SATA III, supports RAID 0/1/5/10
LAN
Dual ports support 10/100/1000Mbps and Wake-on-LAN
LAN1: Intel®PHy 219 LM (10/100/1000Mbps)
LAN2: Intel®LAN 210 AT (10/100/1000Mbps)
Audio
Realtek ALC888S High Definition Audio,
line-out / line-in / MIC-in (Rear I/O)
DIO
8in/8out (internal connector)
API supporting
Keyboard/Mouse
2 x PS/2 (Rear I/O)
Expansion Bus
BU-2509RA-00P/D0P: 1 x PCIe (x16), 2 x PCIe (x4),
1 x PCIe (x1), 1 x mini-PCIe (PCIe, USB)

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-5
BU-2509RA-11P/D1P:
1 x PCIe (x16), 1 x PCIe (x2) with PCIe (x4) connector,
1 x PCIe (x1), 1 x mini-PCIe (PCIe)
BU-2509RA-06P/D6P: 1 x PCIe (x16), 2 x PCIe (x4),
1 x PCIe (x1), 1 x mini-PCIe (PCIe, USB)
LPC
1 x LPC (onboard pin-header)
TPM
Optional function via an additional LPC Daughter Board
FAN
1 x CPU FAN (4 pins), 1 x System FAN (4 pins),
1 x System FAN (3 pins)
I/O and others
Fintek 81866AD-I
Fintek 81216

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-6
Display
Display Interface
BU-2509RA-00P/11P/06P
1 x VGA up to 1920 x 1200 @60Hz, Rear I/O
1 x DVI-D up to 2560 x 1600 @60Hz, Rear I/O
1 Display Port up to 1920 x 1080 @60Hz, internal
connector
BU-2509RA-D0P/D1P/D6P
1 x VGA up to 1920 x 1200 @60Hz, Rear I/O
1 x DVI-D up to 2560 x 1600 @60Hz, Rear I/O
( no DP function )
Multi-Display
Supports 3 independent displays
Others
Shock
15G peak-to-peak, 11ms duration, non-operation
Vibration
Non-operation: 2G, 5-200Hz, X,Y,Z axis
Environment
Operating Temp.
0°C ~ 60°C (32°F ~ 140°F)
Storage Temp.
-40°C ~ 85°C (-40°F ~ 185°F)
Humidity
Operating: 5% - 95% (non-condensing)

Chapter 1 Introduction
BU-2509 USER  S MANUAL
Page: 1-7
1-3. SAFETY PRECAUTIONS
Follow the instructions below to avoid your systems from damages:
1. Keep your system away from static electricity on all occasions.
2. Prevent electric shock. Don’t touch any components of this board when it is
powered on. Always disconnect power when the system is not in use.
3. Disconnect power source when you change any hardware devices.
For instance, when you connect a jumper or install any cards, a surge of power
may damage the electronic components or the whole system.

Page 2-1
HARDWARE
CONFIGURATION
** QUICK START **
CHAPTER
2
Helpful information describes the jumper & connector settings, and
component locations.
The following sections are included:
Jumper & Connector Quick Reference Table
Component Locations
Configuration and Jumper Settings
Connector Pin Assignments

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-2
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
The jumpers and connectors are arranged alphabetically below:
JUMPER/CONNECTOR
NAME
Power Input Connectors
ATX_PWR1, ATX_PWR2
Line-In, Line-Out and MIC-In Port
AUDIO1
COM Port and Connectors
COM1, COM2, COM3, COM4,
COM5, COM6
CPU / System FAN Connectors
CPU_FAN1, SYS_FAN1,
SYS_FAN2
Display Port Connector
DP1
DVI (Digital Video Interface) Port
DVI-D
Front Panel Connector
FP1
Clear CMOS Data Selection
JCMOS1
Digital Input / Output Connector
JDIO1
LPC Connector
JLPC1
COM Port RI/Voltage Selection
JPCOM3, JPCOM4
Speaker Connector
JSPEAKER
Keyboard / Mouse Connector
KB_MS1
LAN + USB Connectors
LAN1_USB1, LAN2_USB1
Mini PCI Express Slot
MPCIE1
PCI Express Slots
PCI_E1, PCI_E2, PCI_E3, PCI_E4
SATA Connectors
SATA1, SAT2, SATA3, SATA4,
SATA5, SATA6, SATA7, SATA8
Universal Serial Bus 3.0 Connector
USB1
Universal Serial Bus 2.0 Connectors
USB2, USB3
VGA Port
VGA
RS-232/422/485 (COM2) Selection
JP2
COM2 Auto Detection Selection
JP4
Hardware Power Failure Selection
JP1
Flash Descriptor Override Selection
JP3
LAN2 Enable / Disable Selection
JP5
Mini PCI Express Voltage Selection
JP13
VCCIO Voltage Selection
JP10

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-3
2-2. COMPONENT LOCATIONS
BU-2509 Connector, Jumper and Component Locations (Front Side)
Note: C236 SKU has SATA1~8, JDIMM1~4, PCI_E1~4 available. Q170 SKU
only has SATA1~6, JDIMM1~4, PCI_E1~4 available. H110 SKU only
has SATA1~4, JDIMM2/4, PCI_E1~3 available. USB1 is not available
for H110 SKU. DP1 is not available for BU-2509RA-D0P/D1P/D6P.
C P U 1
JUD IM M1
LAN1
JUD IM M2
JUD IM M3
JUD IM M4
LAN2_USB1 LAN1_USB1
AUDIO1/
JOUT1
VGA
DVI COM2
COM1 KB_MS1
JP4
JP2
CPU_FAN1
ATX_PWR2
JP5
JP1
JP3
DP1
JP10
PCI_E2
PCI_E3
PCI_E4 PCI_E1
USB1
USB3
USB2
FP1
BAT1
SATA8
SATA7
SATA6
SATA5
SATA4
SATA3
SATA2
SATA1
ATX_PWR1
SYS_FAN1
SYS_FAN2
COM3
COM6
COM5 COM4
JLPC1 JP14
JPCOM4
JP15
JDIO1
JSPEAKER
MPCIE1
JPCOM3
DIMM1
DIMM2
DIMM3
DIMM4
JCMOS1
JP13

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-4
BU-2509 Connector, Jumper and Component Locations (Rear Side)

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-5
BU-2509 I/O View
VGA PortPS/2 Mouse
PS/2 Keyboard
COM Port
COM Port DVI-D Port
LAN1 LAN2
2 x USB 3.0 2 x USB 3.0
LINE-IN/
LINE-OUT
MIC-IN

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-6
2-3. HOW TO SET JUMPERS
You can configure your board by setting jumpers. Jumper is consists of two or three metal
pins with a plastic base mounted on the card, and by using a small plastic "cap", Also
known as the jumper cap (with a metal contact inside), you are able to connect the pins.
So you can set-up your hardware configuration by "open"or "close"pins.
The jumper can be combined into sets that called jumper blocks. When the jumpers are all
in the block, you have to put them together to set up the hardware configuration. The
figure below shows how this looks like.
JUMPERS AND CAPS
If a jumper has three pins (for examples, labelled PIN1, PIN2, and PIN3), you can connect
PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to
create another setting. The same jumper diagrams are applied all through this manual. The
figure below shows what the manual diagrams look and what they represent.

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-7
Jumper Diagrams
2 pin Jumper
looks like this
Jumper Cap
looks like this
3 pin Jumper
looks like this
Jumper Block
looks like this
Jumper Settings
Looks like this
3 pin Jumper
2-3 pin close(enabled)
Looks like this
Jumper Block
1-2 pin close(enabled)
2 pin Jumper close(enabled)
1
1
121 2
1
1
Looks like this

Chapter 2 Hardware Configuration
BU-2509 USER  S MANUAL
Page: 2-8
2-4. COM PORT and CONNECTORS
COM1: COM1 Connector, fixed as RS-232.
PIN
ASSIGNMENT
1
DCD#
2
RX
3
TX
4
DTR#
5
GND
6
DSR#
7
RTS#
8
CTS#
9
RI#
COM2: COM2 Connector selectable as RS-232/422/485.
The pin assignments are as follows:
PIN
Signal
RS-232
RS-422
RS-485
10
DCD#
TX-
RS-485-
11
RX
TX+
RS-485+
12
TX
RX+
NC
13
DTR#
RX-
NC
14
GND
GND
GND
15
DSR#
NC
NC
16
RTS#
NC
NC
17
CTS#
NC
NC
18
RI#
NC
NC
COM2/
COM1
