protech KPD-M Series User manual

MPEG4
STAND-ALONE
DVR
M
User’s Manual
■Some system menu can be different from each model
■Some system menu is subject to change by firmware upgrade
■Please read this manual carefully before running DVR system
MP PE EG G4 S 4 ST TA AN ND D- -A AL LO ON NE D E DV VR R
K
K
KP
P
PD
D
D-
-
-M
M
M
S
S
Se
e
er
r
ri
i
ie
e
es
s
s

CAUTION
TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS.
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Please beware of the following precautions before installing the DVR.
Avoid any place with moisture, dust, or soot.
Avoid any place with direct sunlight or heating appliances.
Keep the product away from electric shock or magnetic substances.
Avoid high or low temperature.
(Recommended operation temperature is between 0°C ~ 40°C).
Do not place any conductive material through the ventilation.
Turn off the system before installation.
Ensure enough space for cable connections.
Place the system on a solid surface with sufficient air ventilation.
Avoid any surface that vibrates.
Placing the system near electronic devices such as radio or TV may cause
breakdown to the product.
Do not disassemble the product without assistance from the manufacturer.
Do not place any heavy object on the system.
NOTE
This equipment had been tested and found to comply with the limits for a CLASS A digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.
PLEASE READ THIS MANUAL THOROUGHLY FOR EFFECTIVE AND SAFE USAGE OF
THE DEVICE.
2

CONTENTS
I. KEY FEATURES ------------------------------------------------------------------- 5~6
II. UNIT PACKAGE ------------------------------------------------------------------ 7
III. BUTTON AND CONNECTION ----------------------------------------------- 8~11
IV. REMOTE CONTROLLER ----------------------------------------------------- 12
V. OPERATION ---------------------------------------------------------------------------------------- 13~20
1. POWER ON -------------------------------------------------------------------------------------- 13
2. LOG IN SYSTEM ------------------------------------------------------------------------------- 13
3. RECORD ------------------------------------------------------------------------------------------ 13
4. LIVE MODE -------------------------------------------------------------------------------------- 14~15
5. SEARCH MODE ---------------------------------------------------------------------------- 16~17
6. FUNCTION --------------------------------------------------------------------------------------- 18~20
VI. SYSTEM SETUP ---------------------------------------------------------------------------------- 21~40
zTHE TABLE OF MENU --------------------------------------------------------------------- 21~22
1. SYSTEM ---------------------------------------------------------------------------------------- 23~26
1-1 PASSWORD ------------------------------------------------------------------------------ 23
1-2 TIME -------------------------------------------------------------------------------------- 24~25
1-3 PTZF PROTOCOL -------------------------------------------------------------------------- 25
1-4 STORAGE ------------------------------------------------------------------------------------- 25~26
1-5 CHANGE LANGUAGE ------------------------------------------------------------------- 26
1-6 SOFTWARE UPDATE ------------------------------------------------------------------ 26~27
1-7 SETUP DATA ----------------------------------------------------------------------- 27~28
2. DISPLAY ------------------------------------------------------------------------------------------ 28~30
2-1 SEQUENCE DWELL (SINGLE) ----------------------------------------------------------- 28
2-2 SEQUENCE DWELL (GROUP) ----------------------------------------------------------- 28
2-3 CAMERA NAME ---------------------------------------------------------------------------- 28
2-4 CAMERA STATUS ------------------------------------------------------------------------- 29
2-5 CAMERA COLOR -------------------------------------------------------------------------- 29
2-6 SPOT DWELL (SINGLE) --------------------------------------------------------------------- 29
2-7 SPOT DWELL (GROUP) -------------------------------------------------------------------- 30
2-8 VGA FREQUENCY CHANGE ------------------------------------------------------------ 30
2-9 VIDEO STANDARD ------------------------------------------------------------------------- 30
3. RECORD -------------------------------------------------------------------------------------------- 31~35
3-1 REC PROPERTY ---------------------------------------------------------------------------- 31
3-2 REC OPTIONS ------------------------------------------------------------------------------- 31~32
3-3 EVENT REC ----------------------------------------------------------------------------------- 32~34
3

3-4 SCHEDULE REC ---------------------------------------------------------------------------- 34
3-5 DELETE REC --------------------------------------------------------------------------------- 35
3-6 LOCK/UNLOCK ------------------------------------------------------------------------------ 35
3-7 DELETE ALL REC -------------------------------------------------------------------------- 35
4. NETWORK ------------------------------------------------------------------------------------------ 36~38
4-1 NETWORK TYPE ---------------------------------------------------------------------------- 36
4-2 DDNS ------------------------------------------------------------------------------------------- 37
4-3 NET PASSWORD --------------------------------------------------------------------------- 37
4-4 NET CLIENT PORT ------------------------------------------------------------------------- 37
4-5 NET CLIENT ID ------------------------------------------------------------------------------ 38
4-6 NET DVR ID -------------------------------------------------------------------------------------- 38
4-7 NET CLIENT ADDR ------------------------------------------------------------------------- 38
4-8 NETWORK THROUGHPUT -------------------------------------------------------------- 38
4-9 WEB PORT ---------------------------------------------------------------------------------
5. SENSOR / AUDIO -------------------------------------------------------------------------------- 39~40
5-1 SENSOR TYPE ------------------------------------------------------------------------------ 39
5-2 ALARM MOTION MANAGER ------------------------------------------------------------ 39
5-3 ALARM SENSOR MANAGER ----------------------------------------------------------- 39
5-4 ALARM BUZZER ---------------------------------------------------------------------------- 40
5-5 ALARM OUTPUT ---------------------------------------------------------------------------- 40
5-6 ALARM OUT PERIOD ---------------------------------------------------------------------- 40
5-7 AUDIO ------------------------------------------------------------------------------------------ 40
* HDD INSTALLATION ------------------------------------------------------------------------------- 41
* TROUBLE SHOOTING ------------------------------------------------------------------------------- 42
4

KEY FEATURES
Operation
Embedded LINUX OS
Enhanced MPEG4 compression
Display, Playback, Recording, Network transmission
Real time single or multi-screen display
Easy operation by IR remote controller
Hidden camera option (covert)
Easy firmware update by network and USB 2.0
Playback
Multi-screen playback
Search by time, event and calendar with go first/last function
Simple playback – automatic download of viewer software at backup
Recording
Recording resolution and quality level adjustable
Recording frame rate can be set by user
The recording speed of max. 120/100 images per second (NTSC/PAL)
Continuous, manual, schedule and event (motion, alarm) recording
Pre-alarm/post alarm recording
Delete and lock/unlock recording video available
4 channel audio recording
Alarm pop-up
Event log view
Network
Live, playback with viewer software and IE(Internet Explorer)
Remote control via networked PC with the exclusive client viewer
Supporting Static, DHCP, DDNS, PPPoE
Multi-user connection available
Live and Recording audio File play in network
5

KEY FEATURES
Audio
4 channel audio recording in real time
1 channel audio output
Backup
Remote backup on network PC with the exclusive client viewer
CD-RW (DVD-RW) backup
USB 2.0 backup( Both USB stick and USB connection HDD available)
General
Auto detection of video frequency(NTSC/PAL)
Built-in hardware Watchdog
S-Video output
Alarm In/Out, RS-485, RS-232 Connections
Loop-through connections
Multiple Languages
VGA output for PC monitor
6

UNIT PACKAGE
MPEG4DVRSystem
Viewer Program/Manual Install Guide Remotecontroller
LANcable Powercord
Battery HDD screws DC adaptor
(DC12V5A)
7

BUTTON AND CONNECTION
1-1 FRONT PANEL
2
3
4
5
6
7
8
9
16
10
11
12
15
1
14
13
1. Channel Selection
You select a channel as full-size screen during live display or playback. When the number is
above 10, please press the ‘+10’ button at first and press other number.
2. USB 2.0 slot
It is used when you upgrade firmware update and backup video files.
3. MULTI
When you press the button repeatedly, you can change the screen display mode as you want
from PIP to multi channel to single channel view.
4. AUTO
The function allows users to watch individual channels by rotating every channel in turn
automatically. Please press the button again to stop it
5. PIP (Picture in Picture)
If you press the button, you can see a master channel and a slave channel on the master
simultaneously. Press the button again, and master becomes slave and vise versa.
6. MUTE
You can turn off the audio.
7. INFO
INFO key shows system information of DVR only in live display mode.
8. OSD
If you do not need OSD, press the button. Pressing one more time retrieve the OSD.
9. BACKUP
You can backup video in CD-RW (DVD-RW) or USB (Memory stick and exterior HDD) in
playback mode.
10. LED Lights
You can identify how power, record, HDD and network(NET) are.
11. MENU
You can change DVR settings. When you want to return to the previous step, press the button
again.
8

BUTTON AND CONNECTION
12. SEARCH
You can choose the video file you want to find through this key.
13. REC
You can manually record by pressing the button. Press it once more, and you can stop
recording.
14. Playback
REW (◀◀): Rewind the video (up to 128x)
PLAY/PAUSE (▶/II): Play and Pause the video
FAST (▶▶): Fast forward the video (up to 128)
STOP (■): Stop the video.
15. PTZ
When you want to control speed dome cameras, please press the button.
16. Control keys
You can shift up, down, right and left and select what you want to.
9

BUTTON AND CONNECTION
1-2 REAR PANEL
KPD-M1601
1
2
3
4
KPD-M901
KPD-M401
1. Audio In
RCA 4 channel audio inputs
2. Video Input
Max 16 channel video inputs
3. Loop out
Max 16 channel video loop outputs
4. Power switch
5. Power Input
Input: 100V~240VAC 50/60Hz 1.5A
Output: DC 12V, 5A
6. SEN. IN/AL/485
Sensor In:16Ch(1~16), 9Ch(1~9), 4Ch(1~4)
17-20: Alarm Out, 21: 485+, 22: 485-, 23-25: GND
5
6
7
8
9
10
11
12
14
13
10
