protech Prox-1720 User manual

USER’S
MANUAL
Pentium®4
Full-size CPU Card
With VGA/Sound/LAN
ProX-1720
Prox-1720 M0

Copyright Notice
Prox-1720 Pentium® 4
Full-size CPU Card
With VGA/Sound/LAN
OPERATION MANUAL
COPYRIGHT NOTICE
This operation manual is meant to assist both Embedded Computer
manufacturers and end users in installing and setting up the system. The
information contained in this document is subject to change without any
notice.
This manual is copyrighted in February 26, 2003. (Revised Edition:
September 8, 2003). You may not reproduce or transmit in any form or by
any means, electronic, or mechanical, including photocopying and
recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the
property of their respective owners.
CE NOTICE
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.

Copyright Notice
FCC NOTICE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void
your authority to operate such equipment.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ........................................................ 1-2
1-2 System Specification ...................................................... 1-3
1-3 Safety Precautions ......................................................... 1-6
CHAPTER 2 HARDWARE CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ................ 2-2
2-2 Component Locations .................................................... 2-3
2-3 How to Set the Jumpers ................................................. 2-4
2-4 COM Port Connector ……..…………………………... 2-6
2-5 RS232/422/485 (COM2) Selection ............................... 2-7
2-6 Solid-State Disk Socket ..................................………... 2-8
2-7 SSD Memory Mapping Selection .................................. 2-9
2-8 Keyboard or PS/2 Mouse Connector .....................….... 2-10
2-9 Keyboard or PS/2 Mouse Selection .......................….... 2-10
2-10 External Keyboard Connector ....................................... 2-11
2-11 Reset Connector ............................................................ 2-11
2-12 Hard Disk Drive LED Connector .................................. 2-12
2-13 ATX Power Button ….................................................... 2-12
2-14 External Speaker Connector .......................................... 2-13
2-15 Power Led Connector ……............................................ 2-13
2-16 KeyLock Connector ..………………………………… 2-14
2-17 Clear CMOS Data Selection ………………………….. 2-14
2-18 CPU Fan Connector ………………………………….. 2-15
2-19 System Fan Connector ………………………………… 2-15
2-20 VGA CRT Connector ………………………………… 2-16
2-21 DVO Connector ……………………………………... 2-17
2-22 Hard Disk Drive Connector ........................................... 2-19
2-23 Floppy Disk Drive Connector ....................................... 2-21
2-24 Printer Connector .......................................................... 2-22
2-25 Universal Serial Bus Connector ……………………… 2-23
2-26 IrDA Connector …..………………………………….. 2-24
2-27 LAN Connector ………………………………………. 2-24
2-28 ATX Power Connector ……………………………….. 2-25
2-29 ATX Power Signal Connector ……….……………… 2-25

Contents
2-30 ATX +12V Power Connector ......................................... 2-26
2-31 Memory Installation …..……………………….………. 2-26
2-32 Reset / NMI / Clear Watchdog Selection ……….…….. 2-27
2-33 Sound Connector ………………………………………. 2-28
2-34 CD-IN Connector ……………………………………… 2-28
2-35 PPCI Connector ……………….……………….………. 2-29
2-36 Compact Flash Card Master/Slave Selection ………….. 2-30
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction …………..........................................…....... 3-2
3-2 VGA Driver Utility ……………………………….…… 3-3
3-3 Flash BIOS Update ..............................................…....... 3-4
3-4 LAN Driver Utility …...........................................…...... 3-6
3-5 Sound Driver Utility …...........................................….... 3-7
3-6 Intel Chipset Software Installation Utility …..……..….. 3-8
3-7 USB2.0 Software Installation Utility ………………….. 3-9
3-8 SCSI and STORAGE_ATA Software Installation ……. 3-10
3-9 Watchdog Timer Configuration .................................... 3-12
CHAPTER 4 AWARD BIOS SETUP
4-1 Introduction ................................................................... 4-2
4-2 Entering Setup ............................................................... 4-3
4-3 The Standard CMOS Features ………............................ 4-4
4-4 The Advanced BIOS Features ....................................... 4-8
4-5 Advanced Chipset Features ........................................... 4-11
4-6 Integrated Peripherals …............................................... 4-14
4-7 Power Management Setup ............................................. 4-18
4-8 PNP/PCI Configuration …............................................. 4-20
4-9 PC Health Status …….................................................... 4-22
4-10 Frequency Control ....................................…………...... 4-23
4-11 Load Fail-Safe Defaults ................................................. 4-24
4-12 Load Optimized Defaults .........................................…. 4-24
4-13 Password Setting ……………………………………… 4-25
4-14 Save & Exit Setup ......................................................... 4-26
4-15 Exit Without Saving ………………………………… 4-27

Contents
APPENDIX A EXPANSION BUS
ISA Bus Pin Assignment ..............................................…......... A-2
PCI Bus Pin Assignment ..............................................….......... A-3
APPENDIX B TECHNICAL SUMMARY
Block Diagram ........................................................................... B-2
Interrupt Map ............................................................................ B-3
RTC & CMOS RAM Map ........................................................ B-4
Timer & DMA Channels Map .................................................. B-5
I/O & Memory Map ...............................................…................ B-6
APPENDIX C TROUBLE SHOOTING
Trouble Shooting for Error Messages ........................…............ C-2
Trouble Shooting for POST Codes ............................................ C-8

Contents

Page:1-1
INTRODUCTION
This chapter gives you the information for Prox-1720. It also
outlines the System specification.
Section includes:
zAbout This Manual
zSystem Specifications
zSafety precautions
Experienced users can skip to chapter 2 on page 2-1
for Quick Start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 Prox-1720 USER
′ S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our Prox-1720 Socket 478 Embedded Card
enhanced with VGA / Sound / LAN, which is fully PC / AT compatible. Prox-
1720 provides faster processing speed, greater expandability and can handle
more task than before. This manual is designed to assist you how to install and
set up the system. It contains four chapters. The user can apply this manual for
configuration according to the following chapters :
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the
specification for this system. Final part of this chapter will indicate you how
to avoid damaging this Embedded Card.
Chapter 2 Hardware Configuration
This chapter outlines the component location and their functions. In the end of
this chapter, you will learn how to set jumper and how to configure this card
to meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the VGA
utility, LAN utility, sound utility, and BIOS update. It also describes the
Watchdog timer configuration.
Chapter 4 Award BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A Expansion Bus
This Appendix introduces you the expansion bus for ISA Bus and PCI Bus.
Appendix B Technical Summary
This section gives you the information about the Technical maps.
Appendix C Trouble Shooting
This section outlines the error messages and offers you the methods to solve
the problems.

Chapter 1 Introduction
Prox-1720 USER ′ S MANUAL Page: 1-3
1-2. SYSTEM SPECIFICATION
zCPU (mPGA 478) :
Intel® Pentium® 4 in mPGA478 socket
Available at 1.4, 1.5, 1.6, 1.7, 1.8, 1.9, 2.0, 2.2, 2.4,2.8, 3.06GHz
System bus frequency at 400MHz/533MHz
Auto detect voltage regulator
zSYSTEM CHIPSET :
Intel® 845GV chipset
zMEMORY :
Supports up to 2GB DDR SDRAM.
Two 184-pin DDR DIMM sockets on board
zCACHE :
Built-in CPU
zREAL-TIME CLOCK / CALENDAR :
256-byte battery backed CMOS RAM.
Hardware implementation to indicate century rollover
zBIOS :
Phoenix-AwardBIOS™ for plug & play function
Memory size with 2 MB, with VGA BIOS
zKEYBOARD/MOUSE CONNECTOR :
Mini DIN connector, selectable for Keyboard, PS/2 Mouse, or Y-Cable
One additional 5-pin External keyboard connector
zUNIVERSAL SERIAL BUS :
Universal Serial Bus Connector on board
Supports up to four USB 2.0 ports.
zDISK-ON-CHIPS SOCKET :
One 32-pin socket supports up to 288MB disk-on-chip.
