Protherm electrical direct-heating convector User manual

INSTRUCTIONS
for installation and
operation
of electrical direct-heating
convector
PROTHERM
PROTHERM, s.r.o.[Ltd]
909 01 Skalica, Pplk Pljušťa 45 , Slovak Republic
phone: [phone]
fax: [phone]

1 Function of an Electrical Convector
A convector is a heating device the function of which is based on conversion
of electrical energy into heat and on the upward flow of warm air. It uses traditional
principles of electrical heating and the chimney effect in an advanced combination.
Thus, an electrical conveyor forms something like a small chimney fitted with
an electrical heating element in its bottom part. The element heats air which then
flows upwards inside the convector and into the room it is heating. Cooler air drops
down, the convector “takes it in”, reheats it and returns it back to into the room.
Therefore, we can call the convector a “chimney radiator”, which can function
without a fan, silently and efficiently. To achieve a pleasant temperature in a room,
only minimum consumption of 30 W per cu.m is required.
1 - cold air
2 - heat exchanger
3 - heating element
4 - wall
5 - thermostat sensor
6 - warm air
Fig. 1: Diagram of the chimney effect

Te convector is a modern version of the tried-and-tested hot-air heating.
The convector is equipped with a thermostat for controlling the required room
temperature between 5°C and 30°C. If more than one convectors are used connected
to an independent power supply, the temperature can be regulated by a central room
thermostat or a programmable regulator. The convector is fitted with a thermal fuse
which cuts out the power supply to the convector in case of overheating.
p
ower switch
thermostat control
Fig. 2: Convector control panel
2 Technical Specifications
Output (W): 500, 1000, 1500, 2000
The convector output is specified on the product labelling and also on the heating
element body for service purposes.
Regulation range: 5°C - 30°C
Nominal voltage: 230 V± 10 %, 50 Hz
Dimensions and weight
Type dimensions (mm) weight (kg)
0,5 kW 455 x 460 x 75 6,1
1 kW 455 x 460 x 75 6,1
1,5 kW 610 x 460 x 75 7,8
2 kW 765 x 460 x 75 9,6

3 Use
The electrical convector can be used:
-as an additional heating device to a current heating system (it can be easily plugged
into an electrical socket)
-for comprehensive heating of flats, houses, offices, etc. at the attractive electricity
rate BP.
4 Location and Installation
The convector is designed to be used in a normal environment AA5/AB5 as
per ČSN 33 2000-3 and ČSN 33 2000-5-51 (i.e. ambient temperature + 5°C to +
40°C, humidity – depending on temperature – up to max. 85%). The wall on which
the convector is mounted must be non-flammable (non-flammable materials classified
in group A as per ČSN 73 0832). The convector must not be installed in rooms with a
bath, bathrooms, wash rooms and showers, in zones 0, 1 and 2 as per ČSN 33 2000-7-
701. It may not be installed also in zones 3 if there is a possible occurrence of water
jets used for cleaning in municipal spas (municipal spas are baths and showers used in
schools, factories, sports clubs, etc., including any other such facilities for public use).
If used in zone 3, extra local interconnection must be done as per ČSN
33 2000-7-701.
Convector must not be installed directly under the mains plug !
Wiring to a power mains and electrical installation must be performed only by
an authorized person, qualified under Regulation No. 718/2002 Z.z.
Colour coding of conductors (to the fixed terminals in the preinstalled flush-
mounted wall conduit box):
protective conductor – yellow-green
central conductor – light blue
phase conductor - brown
Electrical convector control is designed to be operated by persons without any
electro-technical qualification. The person operating the convector may adjust only
the controls specified in these Operating Instructions!

Assembly – suspension on a wall is depicted in Fig. 3.
Fig. 3: Wall mounting
In order for the convector to function to your absolute satisfaction, the
following conditions must be met:
-it must be mounted (we recommend suspended on a wall) so that the bottom edge
is at least 15 cm above the floor,
-the convectors bottom and top openings must be free of obstacles to allow for
unobstructed circulation of air,
-foreign objects (furniture) must not obstruct air circulation, and must be located at
least 20 cm from the front, top and side walls of the convector.
5 Operation
Start the convector by switching on the power switch (see Fig.2). Set the
thermostat controller to the maximum temperature position. Heat the room until the
required temperature is achieved (check the room thermometer). Then turn the
thermostat controller back towards a lower temperature until the convector switches
off. Leave the thermostat in this position. The room temperature shall automatically
be maintained at the selected value.

Caution:
During the first start up of the convector a slight odour might be perceived,
which is caused by the burn-off of residues inside the convector. After longer time of
not using convector (summer, holiday ....) after restarting up it could appear slight
dour caused by the burn-off dust on the heating elements.
ATTENTION!
Topreventoverheating,donotcoveroverconvector!
o

Thermal Fuse 6
g. towel, etc.). After cooling the fuse is reset
nd the convector can be operated again.
Maintenance
The convector is fitted with a fuse that cuts out the power supply to the
heating element in case of convector overheating. This condition could arise only if
you prevent the free circulation of air through the convector (unsuitable location of
convector, covered convector air ducts, e.
a
7
must
e switched off before cleaning. Dust can be removed from slits by vacuuming.
Failure and Repair
The convector does not require any special maintenance. We recommend
normal cleaning of the surface with a moist cloth and detergent. The convector
b
8
elp, seek
authorized service centre. Service is provided by the dealer.
Delivery
In case of convector failure, first check that the convector switch is turned on,
and that the convector is plugged into a power socket. If it is, then check the
thermostat setting and free circulation of air. If these measures do not h
advice from an
9
ng, without
rminal. The delivery also contains a special bracket for wall mounting.
The convector is supplied with a connected cable, 150 cm lo
te

10 Warranty
Certificate and proof of purchase must be submitted when
aking a warranty claim.
1 Safety
The supplier provides a warranty as is set out in the Warranty Certificate and
the terms and conditions therein. Any defects subject to warranty must be reported to
the supplier. The Warranty
m
1
he PROTHERM convector is a class 1 product, protection cover IP 31.
Fig. 4: Wiring diagram
This product is approved under ŠS SKTC 101 .
