Proton InteliTHERM HTG400 Manual

Page 1of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
Instruction Manual
Proton Products
InteliTHERM HTG400
Handheld Temperature Gauge
Issue 1a
25 April 2017
Proton Products Co. Ltd.
10 Aylesbury End
Beaconsfield
Buckinghamshire HP9 1LW
England
www.protonproducts.com

Page 2of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
Table of Contents
DECLARATION OF CONFORMITY (CE)..........................................................3
INTRODUCTION..........................................................................................4
SPECIFICATIONS........................................................................................4
DISPLAY AND OPERATION...........................................................................5
CHARGING................................................................................................6
DIMENSIONAL DRAWINGS ...........................................................................7
CONTACT DETAILS FOR ENQUIRIES,SALES AND SERVICE ...............................8
WEB SITE..............................................................................................................................................8
ENQUIRIES AND SALES...........................................................................................................................8
SERVICE ENQUIRIES ..............................................................................................................................8
MANUAL FEEDBACK AND COPYRIGHT ..........................................................8

Page 3of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
DECLARATION OF CONFORMITY (CE)
This is to certify that the following equipment conforms to the requirements of
CE including EMC to the heavy industrial standard Class A.
Equipment Covered
Product name
Description
Part number
InteliTHERM HTG400
Handheld temperature gauge
00055MC004
The manufacturer of the above named equipment is:
Proton Products International Limited
10 Aylesbury End
Beaconsfield
Bucks
HP9 1LW
ENGLAND
Proton Products is an ISO9001:2008 registered company.
The declaration is signed by:
Paul Sives ………………………

Page 4of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
INTRODUCTION
The Proton Products InteliTHERM HTG400 handheld temperature gauge is a portal contact
(thermometer) temperature instrument designed for use on continuous cable production lines for bare
metal wire temperature measurement.
The temperature gauge is designed with a V-shaped wire slot which consists of one copper flange
and one constantan flange separated by a thin insulator on a rotary wheel. When the heated wire is
put on the V-shaped slot, a thermos electric voltage is generated between both flanges during the
contact and the temperature is determined by measuring the voltage.
Note:DO NOT use electrically-conductive detergent to clean the flanges and the rotary wheel.
Please use a dry soft brush to clean it if necessary.
SPECIFICATIONS
Temperature measurement range: ambient temperature to +400°C (752F)
Error: ±0.5°C ± 0.2% of reading
Display: Segment LCD.
Battery type: 18650 Li-ion
Battery capacity: 3500mAh.
Battery life: >1000 measurements.
Charging interface: USB-C
Charging voltage: 4.7V~5.2V
Charging current: ≥500mA
Rotary wheel
V-shaped wire slot
Constantan flange
Copper flange

Page 5of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
DISPLAY AND OPERATION
Display
GDC8310-1 segment LCD display with green LED back light
Temperature display format
If the measured temperature is lower than 100°C/°F, the temperature reading keeps one digit after the
decimal point, otherwise no digit after the decimal point.
Keyboard
Press the button to power on the temperature gauge. During the gauge power on, press the
button to reset the current temperature reading to the measured maximum temperature reading.
The gauge will be automatically switched off one minute after the last pressing on the button.
Press the button to switch the temperature display unit between centigrade degree and
Fahrenheit degree (°C/°F).

Page 6of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
CHARGING
The temperature gauge uses Li-ion battery as the power source. It usually takes 8 hours to have the
battery fully charged. The temperature gauge can be continuously used around 50 hours with a full
charge.
It’s recommended to use the specified charger or USB cable to charge the temperature gauge. The
charging voltage range should be 4.7V~5.2V and the charging current should be equal or greater than
500mA.
Charging via the USB cable
Unwind the USB cable, plug one end to the USB port on the bottom of the temperature gauge and the
other end to a PC or other standard USB port.
Charging via the specified charger
The temperature gauge can also be charged by the specified charger which includes 4 worldwide
adaptors: Australia/China, Europe, UK, and US/Japan. A micro USB to USB type-C converter is
provided since the cable end of the charger is not standard USB interface.
To charge the temperature gauge, plug one end with the required adaptor to the power supply and
the other end with the converter connected to the USB port of the temperature gauge.

Page 7of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
DIMENSIONAL DRAWINGS

Page 8of 8
InteliTHERM HTG400 Instruction Manual, issue 1a
CONTACT DETAILS FOR ENQUIRIES,SALES AND SERVICE
WEB SITE www.protonproducts.com
ENQUIRIES AND SALES
USA head office:
European head office:
Weber and Scher,
P.O. Box 366,
1231 U.S. Highway 22 East,
Lebanon Borough,
New Jersey,
U.S.A.
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Proton Products Europe N.V.,
Nieuwbaan 81,
B-1785,
Merchtem-Peizegem,
BELGIUM
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Asia head office:
Global head office:
Proton Products Chengdu Ltd.,
Building G3 (TianFu Software Park Zone
G), No.1800 Central YiZhou Avenue,
Chengdu, 610041
CHINA
Tel. [phone]
Fax: [phone]
Email: [e-mail]
Proton Products International Ltd.,
10 Aylesbury End,
Beaconsfield,
Buckinghamshire,
ENGLAND
Email: [e-mail]
SERVICE ENQUIRIES
Please contact your local Proton Products agent for service enquiries (please see
www.protonproducts.com for agent contact details) or email:
America:
[e-mail]
Asia:
[e-mail]
Europe:
[e-mail]
MANUAL FEEDBACK AND COPYRIGHT
Please email feedback on this manual to: [e-mail]
•This manual contains details of equipment and software manufactured and supplied by Proton Products.
•Equipment, products and related features made or introduced before or after the issue of this manual may not
be included in this manual.
•Specifications and information contained within this publication are subject to change without notice.
•Proton Products is not responsible for any errors or omissions contained within this manual.
•Proton Products is not responsible for consequential or incidental damage related to the provision or use of
the information contained in this manual.
•The information contained in this manual is the property of Proton Products and may not be circulated or
distributed to third parties.
•This manual may be copied in accordance with the following conditions:
Printed manual: no part of the manual may be reproduced or converted to electronic format (such as by
scanning) without the prior express written permission of Proton Products.
Manual in electronic format (e.g. CD-ROM): one electronic copy and one printout may be made for storage
and use at the site of product use.
