ANT-121-M22
Vandal Resistant 4G/LTE MIMO Omni Antenna
- 1 of 8 -
Data Sheet: Rev A 03/01/20
© Proxicast, LLC. All rights reserved.
Disclaimer: Subject to change without notice
www.proxicast.com •1-877-777-7694
•
Kiosks
•
Vending Machines
•
Digital Signage
•
Video Surveillance
•
Point-of-Sale Terminals
•
SCADA / Telemetry / PLCs
•
Vandal Resistant
•
Low Profile ~ 3 inches Tall
•
Weatherproof
•
Compatible with all 3G & 4G/LTE Networks
•
Compatible with most Cellular Modems/Routers
•
3 –5 dBi Peak Gain
•
Omni-Directional MIMO
•
SMA Male Connector on 10 ft Low-Loss Coax
Part No. Description
ANT-121-M22
VandalResistant MIMO Low
Profile4G/LTEOmni-
Directional Screw Mount
Antenna- 10 ft Coax Lead
This low profile (~ 3 inches tall) fixed screw mount omni-directional antenna provides 3 to 5 dBi of gain and
supports all cellular frequency bands for AT&T, Verizon, Sprint, T-Mobile, Bell, Rogers, Telus and other cellular
carriers worldwide.
Connect this antenna to existing MIMO-capable cellular modems, routers or other 3G/4G/LTE enabled devices
which have 2 SMA external antenna connectors.
Ideal for use in vending machines, meter housings, equipment sheds, NEMA enclosures or other locations
requiring a low-profile vandal resistant external antenna. Also suitable for vehicle mounting on buses, vans,
trucks or other mobile installations.
Permanently mounts via a 5/8 in. (16 mm) hole with locking internal nut. Resists vandalism with no exposed
coax cable, high impact ABS radome shell and an extra thick threaded mounting post. Includes 10 ft of low-loss
paired RG174 coax fed through center mounting post. Includes "L" bracket for optional wall mounting.
Integrated SMA male plug connectors mates with SMA female jacks found on most cellular modems and
routers.
Completely waterproof (IP67) when properly installed with post extending into a water-tight enclosure. Not
waterproof when used exclusively with wall bracket.
For optimum performance this antenna should be mounted on a flat, horizontal metal surface at least 8 inches in
diameter.
General Description
Ordering Information
Product Features
Applications
ANT-121-M22
Vandal Resistant 4G/LTE MIMO Omni Antenna
- 2 of 8 -
Data Sheet: Rev B 03/01/20
© Copyright Proxicast, LLC. All rights reserved.
Disclaimer: Subject to change without notice
www.proxicast.com •1-877-777-7694
Parameter Rating
Frequency Range
698-960 / 1710-2700 MHz
includes all 2G, 3G, 4G, LTE Bands
Gain
3 –5 dBi
VSWR
≤ 2.0:1
Input Impedance
Input Impedance
Polarization Type
Max Input power
Ground Plane
Input Impedance
50 Ohm
Polarization Type
Vertical
Max Input power
50 W
Ground Plane 8 inch (20 cm)
diameter min. unless wall
mounted using included bracket.
50 Ohm
Polarization
Vertical
Max Input Power
50 W
DC Grounded
No
Ground Plane
8 inch (20 cm) diameter min
Parameter Rating
Connector Type
2x SMA Male (plug)
Cable Length
10 ft (3 m) of RB174 low-loss coax
Height
Radome: 3.2 inches (82 mm) above mounting surface
Overall: 4.0 inches (102 mm)
Diameter
Radome: 1.9 inches (48 mm) at base
Mounting post: 0.55 inches (14 mm)
Weight
6.2 oz (176 g excluding mounting bracket)
Materials
Radome: UV stabilized ABS plastic
Connector: Brass with Nickel plating
Mounting Bracket: Aluminum
Adhesive Pad: Urethane Foam
Antenna Color
Black
Operating Temperature
-40°C to +70°C
Environmental Rating
IP67 (waterproof)
Operation of this device outside the parameter ranges given above may cause permanent damage.
Mechanical Specifications
Electrical Specifications
ANT-121-M22
Vandal Resistant 4G/LTE MIMO Omni Antenna
- 8 of 8 -
Data Sheet: Rev B 03/01/20
© Copyright Proxicast, LLC. All rights reserved.
Disclaimer: Subject to change without notice
www.proxicast.com •1-877-777-7694
•Position away from:
▪CRT/TVs
▪Lighting fixtures & motors
▪Other antennas & wireless devices
▪Low-E or tinted/coated windows
▪Large vertical metal or concrete objects
•Drill a 5/8” (16mm) hole in flat horizontal surface
•Remove mounting nut & washer and feed coax cable through hole
•Remove bottom plastic liner to expose adhesive
•Press antenna into hole and tighten nut & washer from underneath
•Optionally apply a thin bead of silicone caulk around the antenna rim
•Keep coax lead cable as short as possible & weatherproof all outdoor connectors
