Tsun mi™MP.11 Series
Capabilities of Fixed and Mobile WiMAX for
License-Free Frequency Bands Worldwide
The Next-Gener tion Bro db nd Wireless Access Solution
Adds WiMAX Function lity Tod y
Proxim Wireless is proud to introduce enhanced features to the field-proven Tsunami MP.11
point-to-multipoint product line. The MP.11 series has enabled municipalities and service providers
to bridge the digital divide, increase productivity, cut network costs, and create new business
opportunities – all through advanced broadband wireless networking. Advanced features include:
WiMAX Quality of Service (QoS); roaming with seamless handoffs at speeds up to 200 km/hour;
dynamic frequency selection (DFS), which has already received EN 301-893 v1.3.1 and FCC-DFS
(part 15) certification and extended range. Available in outdoor and indoor models, the MP.11
series is capable of supporting converged voice, video and data transmission in fixed and mobile
applications, bringing capabilities of the EEE 802.16e (mobile WiMAX) standard to market now,
for license-free frequency bands available globally. Existing MP.11 installations can even be
upgraded in the field.
• Frequency support for 2.4 GHz with 13 total channels, four 5 GHz bands (5.15, 5.25, 5.47,
and 5.725 GHz) with 80+ non-overlapping channels and 902-928 MHz with four channels
• Scalable performance from 6 to 54 Mbps – all selectable via simple user interfaces
• Advanced revenue-enhancing features are standard – including flexible bandwidth provisioning
for DSL, T1 or Ethernet-like tiered services as well as NAT and DHCP for P-based storage and
e-mail hosting
• Extended network coverage:
- High Power 5054-R-LR version provides extended range up to 20 miles
(Supports 5.15-6.08 GHz)
- Model MP.11 954-R reaches remote subscribers in rural areas where foliage and other
obstructions make line-of-sight impossible (Supports 902-928 MHz)
WiMAX QoS Provides New Revenue Opportunities for Service Providers
EEE 802.16 (WiMAX) QoS provides a higher level of prioritization than any available 802.1-based
schemes from currently existing products. As many as eight classes of service, with up to eight
service flows per class, are supported. This is especially important for emerging services like
Vo P and streaming video applications. As a result, service providers will have more options for
managing their bandwidth more effectively and can make better, more informed decisions
about their service management strategies and revenue-generating opportunities.
Mobile Ro ming En bles New Applic tions
Proxim innovation delivers another wireless industry first – mobile roaming of Subscriber Units (SU)
between Base Station Units (BSU). Public safety first responder networks, transportation system
monitoring and telemetry, and mobile security and surveillance are now all possible with
a low cost, robust system.
• Fast handoff at speeds up to 200 km per hour (120 miles per hour) with handoff times
as low as 40 ms
• Customizable roaming parameter maintains minimum bandwidth required for
application performance
Outdoor Bro db nd Wireless Access
Proxim Wireless offers the industry's
most complete suite of outdoor
broadband wireless access products.
This portfolio includes:
• Tsun mi™MP.11 –
Capabilities of fixed and mobile
WiMAX for U.S. and global markets
• Tsun mi™MP.16 –
WiMAX for the 3.5 GHz frequency band
• ORiNOCO®Wi-Fi Mesh –
Outdoor and indoor Wi-Fi®mesh for
service providers and municipalities
Proxim Wireless is a global pioneer in scalable
broadband wireless networking. From Wi-Fi to
wireless Gigabit Ethernet – our WLAN, mesh,
point-to-multipoint and point-to-point products
are available through our extensive global
channel network. 1Available for FCC only.
MP.11 Outdoor Base Station
MP.11 Subscriber Unit with Integrated Antenna

APPLICATIONS
•Security and Surveillance
Wireless solutions for
bandwidth-intensive and high-definition
P-surveillance cameras located at
important city and transportation
infrastructure such as airports,
bridges and trains
•Business and Residential
Last-Mile Access
Competitive broadband service
alternative to DSL or cable modems
for residences and T1 or Ethernet
for businesses
•Metropolitan Area Networks
Secure and reliable connectivity
between city buildings
•Emergency First Responders
Critical information delivery such as
medical data and video feeds during
in-progress events
•Enterprise Campus Connectivity
Extend main network to remote
branch offices, warehouses or other
out buildings without leased line
•Mobile Hot Spot
On-demand entertainment and
broadband access solutions for ferry,
transit buses and railway
system commuters
Ad ptive Wireless Network Optimizes Perform nce
Using advanced OFDM technology and Wireless Outdoor Routing Protocol (WORP), MP.11 networks
dynamically adapt to the ever-changing network load for optimum performance.
• WORP adapts to avoid collisions and maximizes data content with each transmission
• Dynamic Data Rate Selection automatically compensates for temporary link degradation,
maintaining robust connectivity and mitigating service calls
Adv nced Security Protects Priv cy
Multiple security mechanisms protect operator, residential customer and enterprise privacy.
• Weatherized enclosure allows colocation on rooftops – limiting physical access
• Proxim’s Wireless Outdoor Routing Protocol (WORP) prevents snooping common
to Wi-Fi systems
• Advanced encryption protects over-the-air transmission
• ntracell blocking forbids direct communication between Subscriber Units
• BSU and SU mutual authentication eliminates unauthorized use of system by rogue SUs
and man-in-the middle attacks
• Password protection of all remote management methods
Designed for F st Inst ll tion nd Lower M inten nce Cost
MP.11 radios incorporate hardware and software features that reduce labor costs associated
with initial deployment and post-sales maintenance.
• With Peltier heating and cooling technology inside a ruggedized enclosure, the
MP.11 products can be deployed in extreme weather conditions
• Decrease Subscriber Unit configuration time with integrated and vertical/horizontal
polarized antennas
• Eliminate guess work in locating the remote antennas with audible tone and real-time
signal strength measurements
• Support for both local and remote management, removing the need for expensive
on-site supports
Investment Protection for Current Tsun mi MP.11 Model 5054 (MP.11 ) customers
Customers of earlier versions of MP.11 can upgrade their products in the field with
enhancements including WiMAX QoS and fast roaming (v2.3) and DFS compliant with
EN 301-893 v1.3.1.
Please visit http://support.proxim.com/ to obtain upgrade details.
Tsunami™MP.11 Series

PERFORMANCE AND SCALABILITY
Best-in-class Performance with WORP By eliminating in-the-air collisions and maximizing data content for each transmission, Wireless Outdoor
Router Protocol (WORP) significantly improves performance
Near Line of Sight Capable Line of sight and near line of sight connectivity extends deployment flexibility in rural as well
as high-density urban areas
Highest Performance Per Cell Supports 6 sectors per cell with an aggregate data rate of 324 Mbps
Dense Subscriber Support Per Cell Supports up to 1,500 subscribers with 6 sectors
Guaranteed Data Rate While Roaming Allows bandwidth-intensive applications, such as high-definition video streaming,
in mobile environments
Q ALITY OF SERVICE (QoS)
WiMAX 802.16 QoS Supports up to 8 QoS Classes; Supports up to 8 Service Flows per class
Traffic Prioritization Parameters Supported P ToS (Layer 3 QoS identification), P Protocol List, 802.1p tag (Layer 2 QoS identification), Source
P Address+Mask, Destination P Address+Mask, Source TCP/UDP port ranges, Destination
TCP/UDP port ranges, Source MAC addresses, Destination MAC address, VLAN D, Ethertype
Committed nformation Rate (C R) Users can set C R for each Subscriber Unit
Minimum nformation Rate (M R) Support User defined M R
SEC RITY
Unicast, Multicast and Broadcast Storm User definable threshold levels prevent excessive bandwidth consumptions from degrading
network control performance
Packet Filtering MAC, Ethertype, P address filtering provides very granular network security
ntracell Blocking Allows the BSU to act as the central policy enforcer for SU to SU communications, further
enhancing subscriber units’ privacy
WORP as a Secure Protocol Un-snoopable by wireless decryptors, WORP provides critical feature support for secure long-range
wireless deployments in unlicensed frequency spectrum
Secure Encryption and Authentication Supports for WEP, WEP+ and AES over the air encryption and RADIUS for user authentication
nterference Mitigation Tool Variable Receive Threshold, Transmit Power Control and Dynamic Frequency Selection
LOWER COST OF OWNERSHIP
Dynamic Data Rate Selection (DDRS) Automatically optimizes throughput as link conditions change or as subscribers roam;
connectivity is automatically maintained when link quality degrades
Flexible and Secure Remote Management Supports remote management via Telnet, SNMP and web interfaces with password protections
Antenna Alignment Tool Audible tone and CL with running statistics displaying real-time signal strength ease antenna
system installation
Comprehensive Station Statistics Unit and group statistics are available for monitoring, planning and management of a wireless network
Lower Recurring Lease Cost Co-locating unit on rooftops with plenty of available space lowers lease cost
Antenna Flexibility Subscriber unit with type-N connector supports a broad selection of standard-based external antennas;
subscriber unit with integrated antennas supports dual polarizations, vertical and horizontal, to minimize
installation time
Remote Reboot System reboot or reset to factory default can be performed remotely via a power injector button

954-BSUR-US
Tsunami MP.11 954-R Base Station Unit with Type-N Connector
954-SUA-US
Tsunami MP.11 954-R Subscriber Unit with Type-N Connector
OFDM
Americas (FCC) 902-928 MHz (4 channels)
N/A
54, 48, 36, 24, 18, 12, 9, 6 Mbps
10/100Base-TX Ethernet (RJ-45)
WORP
Standard Type-N Female
14.6 x 13.7 x 8.2 in (370 x 348 x 208 mm)
9.2 lbs (4.2 kg)
-33° to 60°C (Operating)
-55° to 80°C (Storage)
Max 100% relative humidity (non-condensing)
110/250 VAC
Current 420mA at 48V
Maximum 20 Watt
Via RJ-45 Ethernet interface port
RS-232 Serial Port (RJ11 to DB-9)
Telnet, Web GU , TFTP
SNMPv1/v2c; M B- ; Ethernet-like M B; 802.3MAU; 802.11M B; Private M B;
ORiNOCO M B; RFC 1157; RFC 1213; RFC 1643; RFC 1493; RFC 2668
100,000 hours; 1-year on parts and labor
• One (1) Tsunami MP.11 954-BSUR with N-connector, or One (1) 954-SUA Unit
with N-connector
•One (1) wall/pole mounting bracket
•One (1) power injector and country specific power cord
•One (1) Ethernet cable water-proof plug
•One (1) Documentation
• Software CD-ROM
MP.11 5054-R-LR, 5054-R, 2454-R products, Quickbridge.11 (2454-QB, 5054-QB,
5054-QB-LR), AP-4000MR(-LR) Mesh AP, AP-4900MR-LR Mesh AP, PoE Surge
Arrestor (70251), Spare Power DC njector for MP.11 or QB.11 (69823), Surge
Arrestor 5 GHz (5054-SURGE), ProximVision™ Network Management System,
ServPak (US/CAN Only), Worldwide Extended Warranty
DESCRIPTION
RADIO & TRANSMISSION
SPECIFICATIONS
MODULATION METHOD
UNLICENSED
FREQUENCIES
LICENSED FREQUENCIES
DATA RATE
INTERFACES
IRED ETHERNET
IRELESS PROTOCOL
ANTENNA CONNECTOR
PHYSICAL
SPECIFICATIONS
DIMENSIONS: (Packaged)
EIGHT: (Packaged)
ENVIRONMENTAL
SPECIFICATIONS
TEMPERATURE
HUMIDITY
ELECTRICAL
INPUT
OUTPUT
PO ER CONSUMPTION
PO ER OVER ETHERNET
MANAGEMENT
LOCAL
REMOTE
SNMP
MTBF & WARRANTY
PACKAGE CONTENTS
RELATED PROD CTS
PROD CT MODELS MP.11 954-R MP.11 2454-R
Tsunami™MP.11 Series Technical Specifications
2454-BSUR-XX
Tsunami MP.11 2454-R Base Station Unit with Type-N Connector
2454-SUA-XX
Tsunami MP.11 2454-R Subscriber Unit with Type-N Connector
2454-SUR-XX
Tsunami MP.11 2454-R Subscriber Unit with ntegrated 18 dBi Antenna
OFDM
Americas (FCC) 2.4-2.4835 GHz (13 channels)
Europe (ETS ) 2.4-2.4835 GHz (13 channels)
Japan (MKK) 2.4-2.4835 GHz (14 channels)
N/A
54, 48, 36, 24, 18, 12, 9, 6, 4.5, 3, 2.25, 1.5 Mbps
10/100Base-TX Ethernet (RJ-45)
WORP
Standard Type-N Female (BSUR & SUA)
14.6 x 13.7 x 8.2 in (370 x 348 x 208 mm)
BSUR, SUA: 9.2 lbs (4.2 kg)
SUR: 10.1 lbs (4.6 kg)
-33º to 60ºC (Operating)
-55º to 80ºC (Storage)
Max 100% relative humidity (non-condensing)
110/250 VAC
Current 420mA at 48V
Maximum 20 Watt
Via RJ-45 Ethernet interface port
RS-232 Serial Port (RJ11 and DB-9)
Telnet, Web GU , TFTP
SNMPv1/v2c; M B- ; Ethernet-like M B; 802.3MAU; 802.11M B; Private M B;
ORiNOCO M B; RFC 1157; RFC 1213; RFC 1643; RFC 1493; RFC 2668
100,000 hours; 1-year on parts and labor
• One (1) Tsunami MP.11 2454-BSUR with N-connector, One (1) 2454-SUA Unit
with N-connector, or one (1) 2454-SUR with 18 dBi antenna
•One (1) wall/pole mounting bracket
•One (1) power injector and country specific power cord
• One (1) Ethernet cable water-proof plug
•One (1) Documentation
• Software CD-ROM
MP.11 5012 Subscriber Units, Quickbridge.11 (2454-QB, 5054-QB,
5054-QB-LR), AP-4000MR(-LR) Mesh AP, AP-4900MR-LR Mesh AP, PoE Surge
Arrestor (70251), Spare Power DC njector for MP.11 or QB.11 (69823), Surge
Arrestor 5 GHz (5054-SURGE), 2.4 GHz Antennas, 5 GHz Antennas,
ProximVision™ Network Management System,ServPak (US/CAN Only),
Worldwide Extended Warranty

5054-BSUR-XX
Tsunami MP.11 5054-R Base Station Unit with Type-N Connector
5054-SUA-XX
Tsunami MP.11 5054-R Subscriber Unit with Type-N Connector
5054-SUR-XX
Tsunami MP.11 5054-R Subscriber Unit with ntegrated 23 dBi Antenna
OFDM
Americas (FCC) 5.25-5.35 GHz (15 channels)
Americas (FCC) 5.47-5.725 GHz (46 channels)
Americas (FCC) 5.725-5.850 GHz (21 channels)
Europe (ETS ) 5.47-5.725 GHz (46 channels)
Europe (Russia) 5.15 - 6.08 GHz (185 channels)
Europe (UK only) 5.725 – 5.850 GHz (21 channels)
Asia ( ndia only) 5.8 – 5.850 GHz (9 channels)
Transportation ( TS) 5.85 - 5.95 GHz (19 channels)
54, 48, 36, 24, 18, 12, 9, 6, 4.5, 3, 2.25, 1.5 Mbps
10/100Base-TX Ethernet (RJ-45)
WORP
Standard Type-N Female (BSUR & SUA)
14.6 x 13.7 x 8.2 in
(370 x 348 x 208 mm)
BSUR, SUA: 9.2 lbs (4.2 kg)
SUR: 10.1 lbs (4.6 kg)
-33º to 60ºC (Operating)
-55º to 80ºC (Storage)
Max 100% relative humidity (non-condensing)
110/250 VAC
Current 420mA at 48V
Maximum 20 Watt
Via RJ-45 Ethernet interface port
RS-232 Serial Port (RJ11 and DB-9)
Telnet, Web GU , TFTP
SNMPv1/v2c; M B- ; Ethernet-like M B; 802.3MAU; 802.11M B; Private M B;
ORiNOCO M B; RFC 1157; RFC 1213; RFC 1643; RFC 1493; RFC 2668
100,000 hours; 1-year on parts and labor
• One (1) Tsunami MP.11 5054-BSUR with N-connector, One (1) 5054-SUA Unit
with N-connector, or one (1) 5054-SUR with 23 dBi antenna
•One (1) wall/pole mounting bracket
•One (1) power injector and country specific power cord
• One (1) Ethernet cable water-proof plug
•One (1) Documentation
• Software CD-ROM
MP.11 5054-SU ndoor subscriber2, MP.11 5012 Subscriber Units,
Quickbridge.11 (2454-QB, 5054-QB, 5054-QB-LR), AP-4000MR(-LR) Mesh AP,
AP-4900MR-LR Mesh AP, PoE Surge Arrestor (70251), Spare Power DC njector
for MP.11 or QB.11 (69823), Surge Arrestor 5 GHz (5054-SURGE), 2.4 GHz
Antennas, 5 GHz Antennas, ProximVision™ Network Management System,
ServPak (US/CAN Only), Worldwide Extended Warranty
Tsunami™MP.11 Series Technical Specifications
2See MP.11 5054 Technical Specs for more information on the 5054-SUI
5054-BSUR-LR-XX
Tsunami MP.11 5054-R-LR Base Station Unit for extended range with Type-N
Connector
5054-SUA-LR-XX
Tsunami MP.11 5054-R-LR Subscriber Unit for extended range with Type-N
Connector
5054-SUR-LR-XX
Tsunami MP.11 5054-R-LR Subscriber Unit for extended range with ntegrated
23 dBi Antenna
OFDM
Americas (FCC) 5.725-5.850 GHz (21 channels)
Europe (Russia) 5.15 - 6.08 GHz (185 channels)
54, 48, 36, 24, 18, 12, 9, 6, 4.5, 3, 2.25, 1.5 Mbps
10/100Base-TX Ethernet (RJ-45)
WORP
Standard Type-N Female (BSUR & SUA)
14.6 x 13.7 x 8.2 in
(370 x 348 x 208 mm)
BSUR, SUA: 9.2 lbs (4.2 kg)
SUR: 10.1 lbs (4.6 kg)
-33° to 60°C (Operating)
-55° to 80°C (Storage)
Max 100% relative humidity (non-condensing)
110/250 VAC
Current 420mA at 48V
Maximum 20 Watt
Via RJ-45 Ethernet interface port
RS-232 Serial Port (RJ11 and DB-9)
RS-232 Serial Port (RJ11 and DB-9)
SNMPv1/v2c; M B- ; Ethernet-like M B; 802.3MAU; 802.11M B; Private M B;
ORiNOCO M B; RFC 1157; RFC 1213; RFC 1643; RFC 1493; RFC 2668
100,000 hours; 1-year on parts and labor
• One (1) Tsunami MP.11 5054-BSUR-LR with N-connector, One (1) 5054-SUA-LR
Unit with N-connector, or one (1) 5054-SUR-LR with 23 dBi antenna
• One (1) wall/pole mounting bracket
• One (1) power injector and US power cord
• One (1) Ethernet cable water-proof plug
• One (1) Documentation
• Software CD-ROM
MP.11 5012 Subscriber Units, Quickbridge.11 (2454-QB, 5054-QB,
5054-QB-LR), AP-4000MR(-LR) Mesh AP, AP-4900MR-LR Mesh AP, PoE Surge
Arrestor (70251), Spare Power DC njector for MP.11 or QB.11 (69823), Surge
Arrestor 5 GHz (5054-SURGE), 2.4 GHz Antennas, 5 GHz Antennas,
ProximVision™ Network Management System, ServPak (US/CAN Only),
Worldwide Extended Warranty
PROD CT MODELS MP.11 5054-R MP.11 5054-R-LR
DESCRIPTION
RADIO & TRANSMISSION
SPECIFICATIONS
MODULATION METHOD
UNLICENSED
FREQUENCIES
LICENSED FREQUENCIES
DATA RATE
INTERFACES
IRED ETHERNET
IRELESS PROTOCOL
ANTENNA CONNECTOR
PHYSICAL
SPECIFICATIONS
DIMENSIONS: (Packaged)
EIGHT: (Packaged)
ENVIRONMENTAL
SPECIFICATIONS
TEMPERATURE
HUMIDITY
ELECTRICAL
INPUT
OUTPUT
PO ER CONSUMPTION
PO ER OVER ETHERNET
MANAGEMENT
LOCAL
REMOTE
SNMP
MTBF & WARRANTY
PACKAGE CONTENTS
RELATED PROD CTS

Proxim ireless Corporation
www.proxim.com
For detailed technical specifications, please go to http://www.proxim.com/
©2008 Proxim Wireless Corporation. All rights reserved. Proxim is a registered trademark and the Proxim logo and Tsunami are trademarks of Proxim Wireless
Corporation. All other trademarks mentioned herein are property of their respective owners. Specifications are subject to change without notice.
DS_0408_MP11S_US
