PSB M4U 9 User manual

WIRELESS ACTIVE NOISE CANCELLING HD HEADPHONES
OWNER’S MANUAL
M4U 9

INTRODUCTION
Thank you for purchasing a pair of PSB Speakers M4U 9 Headphones. Producing natural musical dynamics and precisely
imaged sound, these high-fidelity headphones bring you closer to the music you love.
Engineered with 50 years of audio excellence and research, the M4U 9 delivers unmatched sound quality, all-day comfort
and fold-and-go portability, for music enthusiasts and professionals. PSB’s true-to-nature sound quality and stylish
ergonomic design allow you to escape to a personal concert experience that travels anywhere with you.
REGULATORY INFORMATION
Operating Temperature Range: 5°C – 40°C
Operating Frequency Range: Bluetooth 2.4G
Maximum Output Power: 5.5mW
Input Rating: 5VDC, 1A
Battery Rating: 1.2V, 1000mAh
Battery Charging Time: 4 hours
Weight: 332 grams
M4U 9 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.
Date of Manufacture: The second and third digits in the serial number indicates the year of manufacture; “21” is 2021.
Responsible Party: Lenbrook Industries Limited. 633 Granite Court, Pickering, Ontario, Canada L1W 3K1.
Phone: [phone], Facsimile: [phone]
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks
by PSB Speakers is under license.
The N-Mark is a trademark or registered trademark of the NFC Forum, Inc. in the United States and in other countries.
To prevent possible hearing damage, do not listen at high volume levels for long periods.
OSHA Guidelines for Noise Exposure Limits
The Occupational Safety Health Administration (OSHA) has issued headphone usage recommendations for maximum daily
exposure and sound pressure levels [measured in decibels (dB)]. A decibel is a unit of sound measurement that increases
exponentially with volume. For example, conversational speech is typically around 60dB, and a rock concert in a stadium is
often about 110dB.
90dB 8 hours
95dB 4 hours
100dB 2 hours
105dB 1 Hour
110dB 30 minutes
115dB 15 minutes
120dB Avoid as damage may occur
SAFETY INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC ID: SVC-PSBM4U9

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Radio Frequency Exposure Statement for IC
The device has been evaluated to meet general RF exposure requirements. The device can be used in mobile exposure
conditions. The minimum separation distance is 25mm.
WARNING
Warnings or announcements may be unnoticed when you are using the headphones. Please be aware of ambient sounds
while wearing the headphones and recognize them as needed.
• To prevent possible hearing damage, do not listen at high volume levels for long periods.
• These headphones should only be connected to a USB interface of version USB2.0 or higher.
• Risk of explosion if the battery is replaced by an incorrect type, dispose of used batteries according to the instructions.
• Be sure to read the Owner’s Manual of the device that you want to connect to these headphones.
• Check the volume settings when using the headphones when in public places and ensure that you do not disturb
people around you.
• These headphones are not guaranteed to work with all combinations of Bluetooth devices/mobile phones.
• These headphones do not support a connection with all Bluetooth devices/mobile phones.
• Bluetooth wireless technology can communicate up to approximately 10 m. Obstructions (people, metallic objects,
walls, etc.) and radio wave conditions affect the actual range.
• The Bluetooth device that you want to connect with must support the same profile as these headphones in order to
use the Bluetooth function. For details on profiles that the Bluetooth device is compatible with, see the Bluetooth
device Owner’s Manual.
• Due to features of Bluetooth wireless technology, playback of audio on the headphones is slightly delayed compared
to the playback on the transmitting device.
• Do not use your headphones while driving.
• Remove the headphones immediately if you experience a warming sensation or loss of audio.
• Do not use mobile phone adaptors to connect these headphones to airplane seat jacks, as this could cause
overheating and result in injury or property damage.
• The headphones and accessories contain small parts which may be a choking hazard. Not suitable for children under
age 3.
• This product contains magnetic material. Consult your physician on whether this might affect your implanted medical
device
• Use this product only with an agency approved power supply which meets local regulatory requirements (e.g., UL,
CSA, VDE, CCC).
• Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight, fire or the like).
• Long-term exposure to loud music may cause permanent hearing damage. To avoid personal injury when using the
headphones for extended periods, the volume should be kept at the described levels in the OSHA Guidelines above.
• Fire or shock may occur should water or other foreign substances permeate inside the device.
• Do not attempt to modify this product as it could result in personal injury and/or product failure.
• Keep batteries out of reach of children

LED STATUS INDICATORS
PART/SETTING LED STATUS INDICATOR DESCRIPTION
Active Noise Cancelling Mode (ANC) Solid green Active Noise Cancelling (ANC) mode setting is
selected and activated
Pulsing “breathing” green Standby mode
Active Mode (ON) Solid blue Active Mode (ON) mode setting is selected
and activated
Pulsing “breathing” blue Standby mode
Flashing blue Ongoing firmware update
Bluetooth Pairing Solid blue Bluetooth connection, paired device
Alternately flashing red and blue Unpaired, ready to be paired
No light Bluetooth connection disabled or unpaired
Flashing red Mute Call Microphones is engaged
ANC/ON Flashing red Headphone being charged
Solid red Headphone fully charged
Flashing red fast (three times normal speed) Faulty internal battery charging
Alternately flashing blue and green Active Monitor/Transparency Mode enabled
CONNECTING…
Wired Connections
Before connecting your headphones, ensure your audio source is powered off, as severe damage to equipment and/or
your ears could result.
To connect your headphones, plug the 1/8-inch (3.5mm) straight connector into one of the inputs located at the base of
the left (L) or right (R) ear cup. This allows you to pick a preferred side for a more comfortable listening setup as shown
in Figure 1 below.
Figure 1
1/8-inch (3.5mm) Straight Connector

The Controls are used as follows:
Volume, Active Monitor and Transparency
Mode
Volume (- VOL +)
Slide up towards the + sign to increase the volume.
Slide down towards the – sign to lower the volume.
Volume Control button function can be configured
to be either Active Monitor or Transparency
Mode. This can be configured via the connected PSB
Headphone App (Settings – Control – Button Functions
– Volume Control – Active Monitor/Transparency
Mode).
Bluetooth Pairing button function can also be
configured as Transparency Mode button (Settings – Control – Button Functions – Bluetooth Pairing –
Bluetooth Pairing/Transparency Mode/Mute Call Microphones)
Active Monitor
With Volume Control button function configured as Active Monitor, press the VOL button to engage Active
Monitor. Active Monitor will reduce your current audio track by 30dB. This will enable you to hear your
surroundings without leaving your personal space. When activated, the surroundings will be amplified through
the headphones.
Active Monitor only works in either ANC or ON Listening Mode. If Active Monitor is engaged, the Listening
Mode Switch indicator will be alternately flashing BLUE and GREEN.
If your audio equipment uses a 1/4-inch (6.3mm) output jack, use the included 1/4-inch adaptor.
USB Cable
Use the supplied USB cable to listen to music from your computer (audio only). This cable is also used to charge your
M4U 9 headphones.
NOTES
• With the USB cable connected to your M4U 9 and USB power, the Listening Mode Switch indicator will be flashing
RED to indicate it is being charged. The M4U 9 is fully charged when the Listening Mode Switch indicator turns into
solid RED.
• When M4U 9 is connected to USB power and the Listening Mode Switch indicator is flashing RED fast (three times
normal speed), this indicates that it is not charging correctly. When this happens, undertake the following:
• Disconnect from USB power and reconnect.
• Disconnect from USB Power, remove the battery cover and “roll” the batteries in place for a couple of seconds.
Battery contact oxidation may have occurred.
EARPHONE MOUNTED CONTROLS…
The main controls are located on the rear part of the right ear cup.
They are used to control Volume, Noise Cancelling, and your smart
device (tablet, iPod) as needed.

Transparency Mode
With Volume Control button function configured as Transparency Mode, press the VOL button to engage
Transparency Mode. Transparency Mode mixes outside environment noise with your audio playback to
keep you aware of your surroundings. A good example for selecting Transparency Mode is when you are
out for a walk or run and hearing car horns or sirens. If Transparency Mode is engaged, the Listening Mode
Switch indicator will be alternately flashing BLUE and GREEN.
Note that ANC function will not work when Transparency Mode is active.
Active Noise Cancellation and Amplifier
The Listening modes use the internal (rechargeable) batteries. There are three Listening modes – Active Noise
Cancelling, Active, and Passive.
1 Active Noise Cancelling Mode (ANC)
In Active Noise Cancelling mode, the “Noise Cancelling” feature is activated with the internal headphone
amplifier. The 3-position Listening Mode Switch indicator will be GREEN.
2 Active Mode (ON)
In Active mode, the internal headphone amplifier is active. The 3-position Listening Mode Switch indicator
will be BLUE.
3 Passive Mode (OFF)
In Passive mode (OFF), noise cancelling and amplifier are turned off. No power is required as the
headphones are powered by your audio source.
NOTE
Bluetooth connection will not work in Passive mode.
Standby Mode
By default, the M4U 9 will go into standby to save power if audio playback has stopped for 20 minutes. This
time length can be adjusted or bypassed in the Standby Timer option in PSB Headphone app (Settings –
Control – Standby Timer).
The M4U 9 will be at a “breathing” state as indicated by the Listening Mode Switch indicator slowly fading
or flashing intermittently. The Bluetooth indicator at the top will also turn off to show that the M4U 9 has
already unpaired from the Source device.
NOTE
At “breathing” state, press a button or switch to ANC or ON mode to once again activate or power up your
M4U 9 from standby mode.

Phone Function
If you receive a phone call during a listening session, press the Phone button to answer the incoming
call and pause your audio track. Once the call is completed, a single button press will end the call
and resume audio play.
To activate Siri or Google Assistant, hold down the phone button for five seconds.
NOTE
Phone function only works when connected by Bluetooth.
Playback Function
When listening to a handheld music device, this button can be used to change to the previous track, the next
track or pause and resume music without reverting to the controls of the handheld device.
Toggle to pause or resume music playback
Slide the button up for previous track or beginning of current track
Slide the button down for the next track
Wireless Pairing
Pairing is the process required to create a link between Bluetooth devices to allow wireless connection. You
must pair a device with the PSB M4U 9 to be able to make a BLUETOOTH connection for the first time.
Before you start pairing operation, make sure that:
The Bluetooth device is placed within 1 m (3 feet) of the headset.
The M4U 9 is charged sufficiently.
To pair your device
1 Turn on the Bluetooth feature on your source device.
2 Open the Bluetooth settings on the source device.
3 Switch the M4U 9 to a Listening mode (ANC or ON). The Bluetooth pairing LED will alternately flash
RED and BLUE.
4 Select your M4U 9 headphones from the source device list.
5 Once the M4U 9’s link has been established with the source device, the Bluetooth pairing LED will turn
solid BLUE.
6 If pairing fails, the pairing LED will turn solid RED.
To unpair your device
1 Press the Bluetooth Pairing button twice to disconnect currently paired device.
2 The Bluetooth Pairing LED will alternately flash RED and BLUE. Your M4U 9 is ready again to be paired.
Mute Call Microphones
Aside from the Bluetooth Pairing button function being configured as Bluetooth Pairing or Transparency Mode
button, it can also be assigned as Mute Call Microphones button (Settings – Control – Button Functions –
Bluetooth Pairing – Bluetooth Pairing/Transparency Mode/Mute Call Microphones).
With Bluetooth Pairing button function configured as Mute Call Microphones button, press Bluetooth Pairing
button once to mute microphone during a call and press again to unmute microphone.

NFC Wireless Pairing
M4U 9 supports Near Field Communication (NFC) so you can easily pair your headphones.
For pairing, follow the instructions below.
To pair your device using NFC:
1 Turn on NFC and Bluetooth on the device you are pairing.
2 With the M4U 9 turned on to one of the Listening modes (ANC or ON), place your
Bluetooth enabled device against the opposite side of the right ear cup where the
controls are located.
3 Accept the pairing on your device when prompted.
NOTE
NFC is a short-range wireless communication. Pairing devices are required to be within a
few centimeters of the headphones to communicate. If pairing is unsuccessful, refer to the
device’s manual to find its NFC touchpoint. Repeat the steps shown and ensure the located
touchpoint is placed against the right ear cup as directed in Step 2.
Top Right Bottom Right
Bluetooth Pairing
button
Call Microphones
for the phone
USB-C plug, used to charge
the internal battery and as a
PC connection for audio
3.5mm jack for optional
audio equipment

LISTENING…
With the volume set to low, turn on your audio source, find a comfortable listening level, and drift into a personal space
filled with the sounds of your favorite audio/video collections.
Headphone Placement
Each ear cup is marked with “L” and “R” to indicate the left and right sides of the headphones. Be sure to put them on
correctly to enjoy your audio as originally intended and your personal music experience.
PERSONAL SOUND…
Audiodo Personal Sound is a unique feature that corrects for your own personal hearing.
You must download the PSB Headphones app for your device in order to calibrate your headphones with Audiodo.
Personal Sound calibration will not be possible without the PSB Headphones app.
Once you have the PSB Headphones app downloaded and your M4U 9 paired to that device, you are ready to set up your
Audiodo profile.
In the PSB Headphones app…
Calibration
The hearing calibration is meant to assess your hearing characteristics. To produce the most accurate results, we advise
you to complete the calibration in a quiet place - the quieter, the better. If you’re unsure whether you hear a tone or not, it
is best to select NO.
Tap START CALIBRATION button to begin the hearing calibration.
The hearing calibration has now commenced. Select YES if you hear a tone or NO if you do not hear a tone. If you feel you
cannot hear any tones during the calibration, make sure that you are connected to the headphones.
To quit the hearing calibration, tap the X Calibration in the top-left corner. If you choose to quit you will be redirected to
the start page. You can redo the calibration at a later time, but no data will be saved.
psbspeakers.com/headphones-app

NOTES
• If you happen to connect the application to headphones that already have a profile stored on them, you will see
the following Profile message - Save the Personal Sound “xxxxx”? The Personal Sound “xxxxx” was found in the
connected headphones. Do you want to save it?. This means that a profile exists on the headphones you are now
using but not on the app.
• To download/save the profile that is on headphones to your mobile application, select YES. If you select NO, the profile
will not be downloaded to the app and cannot be accessed again unless the previous app and headphones are paired
again.
• If for some reason your device gets disconnected, select TRY AGAIN to reconnect to it. To connect to a different
device, select ADD HEADPHONES.
Profile Name
After completing the hearing calibration, you can name your profile. The name must be at least one character long. You
must create a name to proceed.
To rename or delete your profile, select Personal Sound from Settings menu. Then, from Manage Profiles, select the
Profile to rename or delete.
Age
Select your age by dragging the cursor. Age affects how we hear, so its beneficial for us to collect this information in order
to optimize the test process and the algorithms behind Audiodo Personal Sound.
You must select an age to proceed. This information is not used for marketing purposes.
Gender
Select the icon that best describes your gender. Since gender affects how we hear, its beneficial for us to collect this
information in order to optimize the test process and the algorithms behind Audiodo Personal Sound.
You must select a Gender icon to proceed. If you wish to decline answering, choose the icon in the middle. This
information is not used for marketing purposes.
Main Menu
Tapping the menu icon in the top-left corner will take you to the Main Menu. Selecting your calibrated PSB M4U 9 from
the Main menu will take you to the Settings menu.
Personal Sound
Under Settings menu, select Personal Sound to open your Profile List. At Profile section, there is an option to Enable
Personal Sound - drag or swipe the slider icon to the right or to the left to enable or disable Personal Sound respectively.
On your visual hearing profile, the y-axis represents Sound Pressure Level while the x-axis represents Frequencies or Tone
levels. Where the curves dip lowest is where the algorithm will compensate most.
To redo the hearing calibration or to add a new profile, tap the + in the top-left corner. This will take you to the screen
where you can complete a new hearing calibration.
Restoring M4U 9 to Factory Default settings
At Active Mode (ON) setting, press and hold together PLAY (4) and VOL buttons for more than 5 seconds or until you
hear a beep sound and Active Mode (ON) LED indicator flashes once. Bluetooth Pairing button will also alternately flash
RED and BLUE to indicate that your M4U 9 is ready again to be paired.
NOTES
• Restoring M4U 9 to factory default settings will delete all Audiodo profiles and user settings in the headphone and the
headphone unpaired.
• Factory reset can also be initiated via the connected PSB Headphone App (Settings-Control-Reset Headphones).

CONNECTING TO IN-FLIGHT ENTERTAINMENT SYSTEMS…
To connect to in-flight entertainment systems equipped with dual output connectors, use the supplied dual 3.5mm airline
adaptor and the standard analogue cable.
NOTES
• Audio output jack configurations may vary on airplanes. Airline audio quality may not equal what your home audio
equipment, or portable sources provide.
• The supplied conversion plug may not be usable depending on the type of aircraft.
• Do not use these headphones when the use of electric devices on the aircraft is prohibited, or when the use of
personal headphones to listen to on-board music service is prohibited.
WARNING
PSB Speakers recommends you do not use these headphones as aviation communication equipment. They are not
engineered for many environmental conditions common in commercial or non-commercial aircraft (including, but not
limited to: altitude, temperature, noise conditions, unpressurized aircraft) and could result in possible interference to
critical communications.
WARNING
Liquids or cleaning solvents can cause irreparable damage to the electronics inside your headphones. The M4U warranty
does not cover such damage.
M4U 9 HEADPHONE CARE
For safe, sanitary use, it is essential to maintain and clean your M4U Headphones periodically. However, excessive
cleaning may cause damage and jeopardize the longevity of the product. When not in use, always store headphones in the
supplied protective case, and store in a clean and dry environment. Avoid storing in extreme heat or cold temperatures and
humidity, and avoid exposure to liquids.
Cleaning…
For regular cleaning, use a slightly damp cloth and gently clean each ear cup cushion, then use a dry cloth to remove any
residual moisture.
If heavy cleaning is necessary after extended listening and use, follow these directions:
• Remove the ear cup cushions according to the Cushion Attachment/Detachment instruction section below.
• Clean the ear cup cushions by hand, using cold water.
• Add a very small amount of dish or laundry soap and gently clean the cushions.
• After cleaning the cushions, rinse with clean water.
• To dry the ear cup cushions, place them on a towel with the pads facing up.
• Fold the towel over top of the cushions and press down to remove any excess water in the foam padding.
• Air-dry completely before reattaching.

Cushion Attachment/Detachment
1 To detach the ear cup cushion, grasp the headband over the ear cup cushion
that needs to be removed.
2 Using your other hand, grip the leather ear cup cushion and carefully stretch
and pull the ear pad away from the ear cup. Repeat on the other ear cup if
necessary.
3 To reattach the ear cup cushion, grip the headband and cushion as
described above, and clip the lip of the ear cup cushion back in place. The
right side should be installed back on the ear cup with the controls.
NOTE
Be careful not to press down on or remove any other components inside the
earcup as this could damage the headphones.
Storage in the protective case
Remove the cable from the headphones, fold and insert them into the
protective case.
NOTE
Do not force them into the protective case. Doing so may damage the
headphones.
WARNING
When disconnecting your M4U Headphones, hold the plug at the end of the
cable and pull to disconnect. Do not pull on the headphone cable to disconnect the headphones from your music player.
PROTECTING YOUR INVESTMENT….
For long lasting enjoyment of your headphones, you should respect their limits and avoid excessive volume levels for music
or movie playback. Excessive volume levels can damage all headphones.
If your headphones are pushed to excessive volume levels, they could be driven into “clipping”. This could result in severe
or permanent injury. When using your headphones at loud levels, listen carefully for any sign of harsh, garbled midrange
and diminishing intelligibility. If detected, turn the volume down immediately.
NEVER TEST PEAK LISTENING LEVELS OF THE HEADPHONES BY TURNING THE VOLUME UP ALL THE WAY!

At the end of its useful life, this product should not be disposed of with regular household waste. It should be returned to
a collection point for the recycling of electrical and electronic equipment.
The materials can be reused in accordance with their markings. Through re-use, recycling of raw materials,
or other forms of recycling of old products, you are making an important contribution to the protection of our
environment. The following symbols on the packaging indicate the recycling mandate.
Your local administrative office can advise you of the responsible waste disposal location.
PSB and the PSB logo are trademarks of PSB Speakers, a division of Lenbrook Industries Limited. All rights reserved. No part of this publication may be reproduced,
stored or transmitted in any form whatsoever without the written permission of PSB Speakers. While every effort has been made to ensure the contents are accurate at
the time of publication, features and specifications may be subject to change without prior notice.
© 2023 PSB Speakers. Designed in Canada, Made in China
www.psbspeakers.com
