Psyclone PSC01BK User manual

1
Website: www.psyclonegamer.com
PSC01BK
3
Component Source Selector
Product Information
Front
COMPONENT SOURCE SELECTOR
POWER
TM
TM
EDIT SELECT
PrecisionSignal Circuitry
-
1 32 4 5
1
2
3
4
5
On/Off Button
IR Sensor
LCD Display
Joystick - Edit Source name
Source Button
2
Precautions
Do not leave COMPONENT SOURCE SELECTOR in a dusty or humid
place.
Do not modify or disassemble COMPONENT SOURCE SELECTOR
under any circumstances.
Never get COMPONENT SOURCE SELECTOR wet.
Never stand on COMPONENT SOURCE SELECTOR.
USE a dry cloth to clean COMPONENT SOURCE SELECTOR, never
use chemicals to clean the product.
TM
＋
2
34
1
Power
SOURCE
Remote Control
Product Information
Table of Contents
Precautions
--------------------------------------------------------------------------------
---------------------------------------------------------------------
2
7
3
---------------------------------------------------------------------
9
Warranty
------------------------------------------------------------------------------------
FCC Certification
--------------------------------------------------------------------------8
Contact Information

4
Back
+
DC IN 7.5V
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 1
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 2
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 3
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 4
Y V L Optical
Ethernet S-Video
Pr Pb R
output
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 1
6
Some states do not allow limitations on how long an implied warranty lasts or
exclusion or limitation of incidental/consequential damages, so the above limitation
may not apply to you. This warranty gives you specific legal rights, and you may also
have other legal rights which vary from state to state.
Psyclone warrants to the original purchase of this product that it will be free from
defects in materials and/or workmanship for a lifetime from the date of purchase.
If a defect covered by this warranty is discovered, return the product, with your
original sales receipt, to the retailer of purchase. The retailer of purchase will replace
at its option, free of charge, any part determined to be defective, provided that a copy
of the original sales receipt is included with the product returned.
TM
Repair or replacement as provided under this warranty is Psyclone's exclusive
prerogative. Any applicable implied warranties, including warranties of merchantability
and fitness for a particular purpose, are hereby unlimited to a lifetime from the date of
purchase and are subject to the conditions set forth in this warranty. In no event shall
Psyclone or its affiliates be liable for consequential or incidental damages resulting
from the breach of any express or implied warranties.
This warranty is limited to the internal works of this product and the external housing.
It will not apply if your Psyclone product has been damaged by abuse, misuse,
negligence, accident, modification, tampering, or by any other causes unrelated to
defective materials and / or workmanship. Compensation or restoration of data loss
and software are not covered. Psyclone is not liable for loss of revenue or loss of use
of equipment.
Warranty
7
5
+
DC IN 7.5V
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 1
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 2
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 3
Y V L Optical
Ethernet S-Video
Pr Pb R
INPUT 4
Y V L Optical
Ethernet S-Video
Pr Pb R
output
Input 1 Input 2 Input 3 Input 4 Output to TV
This unit allows you to customize the names of the sources you have
connected. To edit the names of the sources, follow the instructions
below.
DVD
Push Joystick Push Joystick Push Joystick
Push Joystick
UP 2 times UP 1 times
RIGHT 1 time RIGHT 1 time
Press UP Press UP
Rename it to DVD then PUSH Joystick
NEW
A
A
DEFAULT
INPUT 1
INPUT 1
EDIT
INPUT 1
KNPUT 1
KNPUT 1
[e-mail]
1-800-315-0795

8
FCC Certification
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the
limits for a Class T digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.

2007 Psyclone Gaming
9
Any changes or modifications not expressly approved by the grantee of
this device could void the users authority to operate the equipment.
Contact Info: [email protected]
Website: www.psyclonegamer.com
