PT W85033 User manual

OWNER'S MANUAL
WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY
RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL
VOID WARRANTY.
BIG TOP PNEUMATIC
ROLLING SHOP STOOL
Item Number W85033

2
1. DO NOT exceed rated capacity. Overloading the stool
can cause damage to or failure of the stool.
2. Use only on hard, level surface capable of sustaining
the load. Use of stool on other than hard level surfaces
can result in stool instability.
3. DO NOT stand on stool. Serious injury can result if the
tool tips over or you accidentally come in contact with
the stool.
4. DO NOT expose to heat. Parts of the unit are under
pressure.
5. Do not alter this product in any way.
6. Keep your work area clean and well lit. Cluttered work
areas invite accidents.
7. Keep bystanders, children, and visitors away while
operating stool. Distractions can cause you to lose
control.
8. Stay alert. Watch what you are doing, and use common
sense when operating a stool. Do not use a stool while
tired or under the inuence of drugs, alcohol or medica-
tion. A moment of inattention while operating stool may
result in serious personal injury.
9. Store idle stool out of reach of children and other
untrained persons. Stools are dangerous in the hands
of untrained users.
10. Stool service must be performed only by qualied
repair personnel. Service or maintenance performed by
unqualied personnel could result in a risk of injury.
11. When servicing a stool, use only identical replacement
parts - refer to attached, product-specic parts list and
diagram. Follow instructions in the Care & Maintenance
section of this manual. Use of unauthorized parts or
failure to follow maintenance instructions may create a
risk of injury and may void any applicable warranty.
12.Maintain labels and nameplates on the stool. These
carry important information. If unreadable or missing,
contact Performance Tool for a replacement.
13.The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are fac-
tors, which cannot be built into this product, but must
be supplied by the operator.
After opening the box, unpack your stool and related parts & accessories. Please inspect it carefully for
any damage that may have occurred during transit and check it against the photograph on box. If any
parts are missing, call customer service at 1-800-426-1262 between 6 a.m. and 5 p.m. Pacific time.
WARNING DO NOT operate this stool if damaged during shipment, handling or misuse. Do not operate the stool until
the parts have been replaced or the fault rectified. Failure to do so may result in serious personal injury or property
damage. All damaged parts must be repaired or replaced as needed prior to operating this stool. Check to see that all
nuts, bolts and fittings are secure before putting this stool into service. If you have any questions, or require assistance
with damaged or missing parts, contact our factory customer service department at: 1-800-426-1262. Please be sure to
have the serial number, model number, and date of purchase available for reference when calling.
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting
steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest
product information available at the time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
SAFETY GUIDELINES / DEFINITIONS

WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate or maintain
this product. Failure to comply with the instructions may result in serious personal injury and/or property damage!
The following signal words are used to emphasize safety warnings that must be followed when using this product:
DANGER:
Indicates an imminently hazardous situation
that, if not avoided, WILL result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation that,
if not avoided, COULD result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation that,
if not avoided, MAY result in minor or moderate injury.
NOTE: Indicates important information, which if not
followed, MAY cause damage to equipment.
UNPACKING AND INSPECTION
WARNING. READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS
BEFORE OPERATING THIS PRODUCT. FAILURE TO DO SO MAY
RESULT IN FIRE, ELECTRICAL
SHOCK, PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
Capacity:.........................................................................................300 lbs.
Ram Extension: ................................................................................... 5 in.
Seat Height:................................................................................ 19 - 24 in.
Seat: ................................................... 12-1/2 in. diameter x 3-1/2 in. deep
Casters: ............................................................................................... 2 in.
Specifications are subject to change without notice.
SPECIFICATIONS:

3
1. Place the Seat Bracket (2) on the underside of the Padded Seat (1). Align the holes in
the Seat Bracket with the 4 holes in the center of the Padded Seat and hand tighten with
the 4 machine screws (3). Use a #2 phillips screwdriver for nal tightening.
2. Hand thread the 5 Casters (6) onto Base Frame (7). Tighten with a 14 mm open end or
adjustable wrench.
3. Place the Base Cover (5) over the center of the Base Frame (7).
4. Insert the Pneumatic Cylinder (4) into the center opening in the Base Frame (7), then
place the Seat assembly from step 1 onto the thinner end of the Pneumatic Cylinder.
Press down to ensure a tight and secure t.
CONTENTS
1 Padded Seat ....................... 1
2 Seat Bracket/Handle........... 1
3 Machine Screws ................. 4
4 Pneumatic Cylinder............. 1
5 Base Cover ......................... 1
6 Casters................................ 5
7 Base Frame......................... 1
No. Description Qty.
1
2
3
4
5
6
7
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
1. 14 mm open end or adjustable wrench
2. #2 phillips screwdriver

1 YEAR LIMITED WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These
warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington
governs all warranties and all exclusions and limitations of warranties and remedies. There may be other rights
which vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and workmanship under normal
use and service. A defective product may be returned for a free replacement within 90 days from the date of
purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90
days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which
our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a sales
receipt showing the date of purchase accompanies the defective product or defective part (s) being returned. For
part (s) after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other consumables which must be
replaced under normal use and service. These warranties shall not apply to any product or part which is used for a
purpose for which it is not designed, or which has been repaired or altered in any way so as to affect adversely its
performance or reliability, nor shall these warranties apply to any product or part which has been subject to misuse,
neglect, accident or wear and tear incident to normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or to assume any liability in
connection with its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL® makes no
express or implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL® makes
no implied warranty of merchantability and no implied warranty of fitness for any particular purpose, except that for
goods purchased primarily for personal, family or household use and not for commercial or business use,
PERFORMANCE TOOL® makes an implied warranty of merchantability (and, if otherwise applicable, an implied
warranty of fitness for a particular purpose), but only for the particular qualities or characteristics, and for the
duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the above limitations may not apply in
all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special damages resulting from or in any
manner related to any product, or to the design, use, or any inability to use the product. The sole and exclusive
remedy for a defective product or part shall be the repair, or replacement thereof as provided above. The laws on
limitation of remedies or on consequential, incidental or special damages may vary from state to state, so the above
limitations may not apply in all cases.
© Copyright 2020 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
TO RAISE SEAT:
Stand next to stool. Lift handle, and release when seat is at the desired height.
TO LOWER SEAT:
Sit on the stool. Lift handle, and release when the seat is at the desired height.
OPERATION
