PTF PEPPER PTF 4 User manual
Assembly manual
PEPPER PTF 4
Foil tunnel
Scan to see the assembly video
Information on the foil tunnel
Follow the OHS Rules
2
Wear protective gloves
during the assembly
Wear protective glasses
during the assembly
Provide help from the
assistant during the assembly
The temperature
in the tunnel is high
Perform assembly
on days which are not windy
It is prohibited to have
the structure assembled
by drunk and intoxicated personnel
Thank you that you have chosen PTF Polska tunnel. We believe that it will help you in growing your flowers and vegetables and that you will be satisfied a lot.
We did our best so that the design and modern technical solutions are helpful in the cultivation and so that the assembly is simple and easy.
WARNING!
PTF POLSKA foil tunnels are not suitable for assembly in open spaces or locations where the structure will be exposed to strong winds. They must be assembled
in a place protected against wind and not exposed to it directly – this will prevent its damage.
Do not leave the foil on the tunnel in the winter period because it may be damaged due to the pressure of snow.
Do not tie up the shrubs with crops to the framework (e.g. tomatoes) – this may impair the structure greatly.
Safe use rules:
1. The tunnel is dedicated only to plant growing.
2. Dig the foil excess in the ground – this will prevent the tunnel from being caught by the wind.
3. Mount the structure in the place not exposed to strong wind blows; avoid slopes and open spaces.
4. Do not assemble the tunnel in strong winds and in other adverse weather conditions.
5. Keep children away from the assembly site because the set includes small elements and foil bags which may lead to choking or suffocating.
6. Check the stability of the tunnel regularly, especially after storm winds. If you notice any damage, replace a damaged element or disassemble the structure.
7. Use assembly tools specified in the manual and wear protective gloves and glasses during the tunnel assembly and maintenance.
8. Avoid using mowers and mechanical scythes near the structure.
9. Do not keep hot objects, especially hot barbecue equipment, etc. in the tunnel.
10. Remove the foil from the tunnel for the winter season and secure the structure so that it is not caught by the wind.
11. Do not climb the structure roof.
12. Do not leave children unattended in the tunnel because the door may close and prevent children from exiting the structure.
13. Do not use open flame in or near the structure.
14. Do not load roof panels additionally (with the exception of tied-up plants).
15. The tunnel cannot be used in the public space.
P-01
x6 -680mm
P-07
x4 -570mm
Z-05
x14
Z-07
x2
Z-06
x2
Z-03
x8
Z-11
x4
Z-09
x2
Z-10
x3
Z-01
x4
Z-08
x6
P-02
x8 -720mm
P-05
x4 -750mm
P-08
x26 -980mm
P-04
x10 -1050mm
P-06
x4 -1550mm
P-03
x10 -1300mm
SZ-1
x8
Z-11A
x12
List of elements
CHECK WHETHER THE PACKAGING INCLUDES ALL THE ELEMENTS.
We recommend elements sorting before their assembly. This will facilitate assembly works.
Z-14
x72
ZMC
x4
W1
x256 W2
x8
x4
x4
List of elements
CHECK WHETHER THE PACKAGING INCLUDES ALL THE ELEMENTS.
We recommend elements sorting before their assembly. This will facilitate assembly works.
HINGE
x4
FOIL 2
x2
FOIL 1
FOR THE
DOOR
x2
FOIL 3
x1
BIT
x1
DRILL DRIVER
x1
MEASURING
TAPE
x1
SCISSORS
x1
RUBBER
HAMMER
x1
SCREWDRIVER
x1
12mm DRILL
x1
SPANNER 8
x1
The DIY assembly foil tunnel lacks some tools.
Provide necessary tools before starting work.
Tools
P-08
x8 -980mm
Z-05
x6 Z-01
x4
elements
1
Hammer in the
profiles with a rubber
hammer
(not a steel one)
Z-05
x4
P-05
x2 -750mm
elements
2
P-07
x4 -570mm
elements
3
SZ-1
x8
HAMMER IN
THE ANCHORING
ELEMENT SZ-1
INTO THE GROUND
P-03
x10 -1300mm
elements
4
5
elements
Z-11A
x6
About 710 mm
from the ground to
the connector Z-11A
6
Z-08
x6
elements
7
elements
Z-06
x2
Z-07
x2
A
B
A
A
B
B
8
P-06
x4 -1550mm
elements
9
elements
Z-11
x4
10
P-05
x2 -750mm
elements
elements
11
P-08
x8 -980mm
12
P-04
x4 -1050mm
elements
13
elements
Z-09
x2
14
x3
P-04
x6 -1050mm Z-11A
x6
Z-10
x3
elements
15
elements
x3
