Puhui T-8120 User manual

Preheating Oven User Manual
Http://www.tech168.cn
1
Preheating Oven User Manual
Model: T-8120
Tai’an Puhui Technology Co., Ltd.
http://www.tech168.cn

Preheating Oven User Manual
Http://www.tech168.cn
2
CATALOGUE
Products Features …………………………………………….3
Main Parameter…………………………………………….....3
Main Component……………………………………………...3
Main component function explanation………………………..4
1. Preheating oven body……………………………………..4
2. Front panel………………………………………………. .4
3. Back panel……………………………………………….. 5
4. Circuit board (PCB) rack………………………………….5
Operation instructions …………………………………………6
1. Starting and inspects before starting………………………6
2. Operation of preheating PCB board……………………….6
3. Machine installation and adjustment………………………7
Caution! ………………………………………………………..8
Guarantee acceptance…………………………………………..8

Preheating Oven User Manual
Http://www.tech168.cn
3
Products Features:
1. The machine selects the infrared highly effective component to
give off heat which independent exploration, adopt advanced PID
intelligent controlling warm heating technology, controls warm precisely.
2. Can achieve to heat PCB board and component which contains
lead or not，especially suit to BGA、SMD.
3. Use infrared heat, easy to cut through, heat proportion, don’t have
sirocco flow. Don’t shift the small component on the PCB board，ensure
the welding quality.
4. This machine has 600W heating system, widely to
120x120mm.Can use with the handhold infrared welder T-835.
5. Easily operate, can operate it through easy training.
Main Parameter：
Work floor size
200x240mm
Rated voltage and frequency
AC220-230V/AC110V 60/50Hz
Complete machine power
500W
Preheating chassis power
450W
Preheating chassis size
120x120mm
Preheating chassis temperature
adjustable
0-450℃
Main Component：
Preheating oven main body
1
Temperature sensor
1
Board support of the circuit
1
Power line
1
User manual (compact disc)
1

Preheating Oven User Manual
Http://www.tech168.cn
4
Main component function explanation：
1.Welding table main body：
2.Front panel
Preheat display screen of temperature
Preheat dish switch
Preheating chassis
Front panel
Fan
Board support of
the circuit
Set the temperature button
Preheating temperature sensor
Power source switch
Board support
of the circuit

Preheating Oven User Manual
Http://www.tech168.cn
5
3. Back panel
5.Circuit board (PCB) rack：
Fuse
Power connecting wire
Die-pin support
Board support of the circuit
Sliding support die-pin
Temperature sensor socket

Preheating Oven User Manual
Http://www.tech168.cn
6
Operation instructions：
1. Starting and inspects before starting:
①Check the temperature sensor and the power line.
②Turn on the power line. Don’t use until passing check. (The nixie
tube displays the indoor temperature.)
③The black switch on the front panel use to control the infrared
preheating chassis; press “▲”up，“▼”down，can be at 0-450℃,adjust
the infrared preheating chassis’s temperature. Press the button“WARM”，
the infrared preheating chassis starts to work, press“COOL”，it stops
working.
2.Operation of preheating PCB board：
(1) PCB board’s placement and adjustment：
①According to the PCB board’s size, adjust the location of the
board support, put the PCB board on the support and fix the screw
tightly with hands. Make the temperature measurement head fixed on
the PCB board which needs to preheating, use aluminum-foil paper or
adhesive paper to stick tightly.
②According to the size of PCB board and welding technological
requirement, press “▲”and “▼”button, between 0℃and 450℃, regulate
the output temperature of preheating chassis.
(2) Preheating opening and closure:
①Press the “WARM”button，open the preheating chassis about 3-5
minutes, make the temperature be about the setting value then carry on
the step operation.

Preheating Oven User Manual
Http://www.tech168.cn
7
②After finishing ,press “COOL”, the preheating chassis stop
working.
Attention：This time can’t close the power switch, after the machine
full cooling then close the power source.
③General preheating temperature establishment suggestion：when
PCB board has lead ,may adjust the infrared preheating chassis
temperature to 100-120℃; When PCB board has non-lead, may adjust
to 120-140℃; Also may set the different preheating temperature
voluntarily according to user's use craft and experience.
3. Machine installation and adjustment:
This infrared preheating chassis heating way includes: The total
pressure flow-through heating way and the PID percentage adjustment
way, you may adjust voluntarily according to the PCB board’s preheating
allowance. preheating temperature is lower than 250℃, selects the PID
percentage adjustment method; The preheating temperature is higher than
250℃, use the total pressure flow-through heating way.
Caution!
1. After finishing, don’t turn off the power immediately; make the
infrared preheating chassis full cooling.
2. Keep the ventilation free-flowing, the infrared preheating chassis pure;
use the dehydrated alcohol to be clean regularly!
3. Careful, the high temperature operation, pay attention, avoids scalding.

Preheating Oven User Manual
Http://www.tech168.cn
8
4. Long-time doesn’t use, should cramp out the power source plug!
Guarantee acceptance
The complete machine maintains for one year and lifelong service.
Long-term factory price supply .Provides the immediate network online
Q/A and the technical advisory work service.
Statement
Between user operating manual and actual product different place, take
actual product as！
