pullman Ermator A1000 User manual

OPERATING INSTRUCTIONS
Air scrubber
A1000
A2000

Revision 1
1
Introduction
Dear Customer,
Thank you for choosing Pullman-Ermator as your supplier.
We hope that the Pullman-Ermator air cleaner will be to your satisfaction and meet your expectations.
Pullman-Ermator has been manufacturing professional dust extractors since 1967and has over the
years acquired a genuine technical knowledge in this area. We continuously strive to improve in our
product segment and will continue to supply the market with new equipment.
Please feel free to browse information about our product programme on our web site www.pullman-
ermator.se.
Notice!
These instructions are only for the air cleaner type Pullman-Ermator A1000/A2000.
The air cleaner, Pullman-Ermator A1000/A2000 can only be used with dry, non-explosive
materials.
Pullman-Ermator will not be held responsible if the air cleaner is used for other applications or
has been used in ways other than those outlined in this instruction manual.
Before using the machine, please read the safety regulations carefully.
Read the complete instruction manual before using the Pullman-Ermator A1000/A2000.
All spare parts used for the Pullman-Ermator A1000/A2000 must those specified by Pullman-
Ermator AB.

Revision 1
2
Unpacking
When unpacking the machine, please check that the air cleaner has not been damaged in transport.
Safety Instructions
Handling
Warning
•Cables damaged through crushing or splitting can be dangerous if used and should be replaced
immediately. Risk of personal injury.
Warning
•Do not connect the machine to an unearthed socket. Risk of personal injury.
Warning
•Make sure the assembly area is firm, so the air cleaner does not tip over. Risk of personal and
material injury.
Warning
•Risk of pinching when handling the toggle fastener.
Warning
•The machine must not be used in environments where explosive gases may be present. Serious
risk of explosion
Warning
•The machine should be turned off at the switch before releasing the power lead from the wall
outlet. If the switch is in the on position, a spark can occur between the contact on the power
lead contact.
Service
Warning
•Remove the plug from the wall socket when carrying out maintenance work. Risk of personal
injury.
Warning
•Dust that is hazardous to health can be spread when the coarse filter and the absolute filter are
replaced. Accordingly, the user should wear protective glasses, protective gloves, and a
breathing mask conforming to protection class FFP2
Warning
•Do not puncture the absolute filer. Risk of dust dispersion.

Revision 1
3
Function
Connect the lead to the power outlet, attach the outlet hose if available. Start the machine by pressing
the start knob. The air cleaner has two speeds.
The air cleaner separates material in two stages:
The first stage uses a coarse filter. This traps the bigger particles and acts as protection for the main
filter. The coarse filter should be changed on a daily basis.
The second absolute filter separates the unhealthy dust that is invisible to the eye.
Coarse filter characteristics
The coarse filter is strong and easy to change. It has low pressure drop and good separation capability.
The coarse filter takes care of big particles and acts as protection for the absolute filter.
Main filter characteristics
The main filter is an absolute filter with class HEPA H13 that is dimensioned for fine, dry dust and
should be preceded by a pre-filter.
Caution
•The operating life of the absolute filter decreases and can be completely destroyed if exposed
to water.
Caution
•The absolute filters cannot be cleaned and must be replaced when full.
Filter indicator
A1000/A2000 has two filter indicatorsconnected to a warning light which measures the pressure drop
over the filter. If the pressure drop is too high, a orange lamp light up, indicating that the absolute
filter should be changed. Using the air cleaner when light is showing will reduce the effectiveness of
the machine. When the pressuredrop is too low, a red lamp will light up, indicating that the Hepa filter
is leaking/damaged and needs to be replaced immediately.
Fan
The air cleaner is equipped with a single, 1 phase fan.
Risk of dust dispersion -Use of personal safety equipment
Unhealthy dust can be spread when cleaning the coarse filter and during filter change.
Accordingly, the user should wear protective glasses, protective gloves, and a breathing mask
conforming to protection class FFP2.

Revision 1
4
Accessories
PART NO. DESCRIPTION No./machine Machine
200900275 Coarse filter 1 pc A1000
200700532 Hepafilter 1 pc A1000
200900224 Coarse filter 1 pc A2000
10085 Hepafilter 1 pc A2000
Contact your local representative for other spare parts.
Warranty
All Pullman-Ermator devices and accessories have a 12-month factory warranty for material and
manufacturing defects. When returning the attached warranty slip, the warranty extends to 36 months.
Do not attempt to repair the suction apparatus without the consent of the manufacturer.
The warranty does not cover defects which are the result of normal wear and tear, negligence,
defective use, unauthorised repair or the suction apparatus being connected to the incorrect voltage.
In the event of any complaint, the suction apparatus or an agreed part of it must be returned to us or
our authorised representative for warranty examination and for any warranty repair or replacement.

Revision 1
5
PROBLEM SOLVING
The A1000/A2000 is designed and manufactured for a severe environments and tasks, but the user
must note that the machine components must be protected from knocks and blows. Filter and sealing
connections are carefully chosen to serve the operator. Therefore, the machine must be handled with
care if it is to work correctly for many years.
Problem Cause Procedure
The fan does not start No power Connect the machine
Cable defective Change
Switch defective Change
The fan stops immediately Wrong fuse Connect the correct fuse
The fan runs, Blocked filter Change filter
but suction is poor Cover loose Adjust
Sealing defect Change current seal
Dust blows from unit Defective or loose filter Adjust or change
Abnormal noise Order service
Keep these instructions!

Revision 1
6
TEKNISK DATA
TECHNICAL DATA
Luftrenare / Air cleaner A1000 A2000
Voltage 230 VAC (1-phase) 230 VAC (1-phase)
Max power output 285 W (full speed) 600 W (full speed)
Max Airflow 2 speed 1000 m3/h 2000 m3/h
Pre filter size 0,16 m20,64 m2
HEPA FILTER
Filter classification H13 H13
Filter Area 3,5 m210,5 m2
Sound level 2 speed 58 / 65 dB(A) 60 / 68 dB(A)
Sound level LxBxH (mm) 465x385x466 724x424x810
Weight 19 kg 38 kg

Revision 1
7
OM ÖVERENSSTÄMMELSE
DECLARATION OF CONFORMITY
DECLARATION DE CONFORMITÉ
ERKLÄRUNG DER ÜBERSTIMMUNG
SAMSVARSERKL∅RING
Pullman Ermator AB
Industrivägen 10
S-777 34 SMEDJEBACKEN
Försäkrar under eget ansvar att maskinen
Declare under our sole responsibility that the machine
Certifie sous sa propre responsabilité que le produit ciaprès
Versichern auf eigener verantwortung, dass das Produkt
Forsikrer under eget ansvar at maskinen
A1000 Nr./No:00900061 0001-xxxx
A2000 Nr./No:00900062 0001-xxxx
Tillv.år/Manufact.year/Baujahr: 2010-
som omfattas av denna försäkring är i överensstämmelse med standarder:
included in this declaration, follows the provisions of the:
est conforme aux aux normes suivantes:
den folgenden Normen entspricht:
er i overensstemmelse med standarder:
SS-EN 292-1, SS-EN 60 204-1 (1993.11.30)
SS-EN 55011:1989
SS-EN 50082-1
SS-EN 60335-1, SS-EN 60335-2-69 & A1
enligt villkoren i/according to/selon/laut/i henhold til vilkårene i
Machine Directive 98/37/EEG
Low Voltage Directive 73/23/EEG
EMC Directive 89/336/EEG
SMEDJEBACKEN 2006.01.01 Torbjörn Bengtsson
VD
General Manager

Revision 1
8

Revision 1
9
A100 0

Revision 1
10

Revision 1
11
A2 00 0

Revision 1
12
