Surround Air Intelli-Pro 3 XJ-3100A User manual

“Intelli-Pro 3” Air Purifier
(Model: XJ-3100A)
Instruction Manual
(Please read before using air purifier)
Surround Air Division
Indoor Purification Systems, Inc.
334 Marshall Way, Suite C
Layton, Utah 84041
Toll Free: 888.812.1516
PH: 801.444.0606
FX: 801.991.4838
Web: www.surroundair.com
Email: [e-mail]

zPlug Type US: 120V (120VAC/60HZ)
zPower: 55W
zCleanable HEPA Cleaning Efficiency: 99.97%
zDimensions: 19 x 15.75 x 6.5 (in)
zWeight: 12 lbs.
zMaximum Air Volume: 180 cfm
zCleanable HEPA (High-Efficiency Particulate Arrestor) Filter to remove airborne particles such as dust and
other allergens.
zActivated Carbon Filter to adsorb chemicals, cigarette smoke and odors.
zPhotocatalytic Filter (TiO2) to remove airborne chemicals and bacteria.
zGermicidal UV (Ultraviolet) Lamp to destroy micro-organisms.
zNegative Ion Generator to circulate air-cleaning negative ions throughout the room.
zPollutant Sensors for automatic air quality control.
zFilter Replacement Sensors.
zBrushless DC Motor: quiet, powerful and smooth operation.
zSince the Intelli-Pro 3 uses a fan, and blows a strong current of air out the top of the unit, it is not necessary
to place the unit at a high elevation. It can be placed on the floor, on a table, a countertop, or on a shelf.
zThe back of the Intelli-Pro 3 should be at least 8 inches away from the wall to prevent discoloration of the the
wall. Also, there should not be any obstructions above the air outlet on top of the unit. There should be at least 2
feet of space between the top of the air purifier and any object or surface above it.
zKeep the Intelli-Pro 3 at least 3 feet away from computers, televisions, and sensitive electrical equipment,
and two feet from occupants in the room while in operation.
zTo the extent possible, it is optimal to place the Intelli-Pro 3 in areas: 1) nearest the source of airborne
pollutants, 2) where airborne pollution is strongest, and 3) where affected persons spend most of their time.
1. To prevent electric shock, do not dismantle, repair or modify this product beyond the instructions given in this
manual. In case of malfunction, please contact Surround Air.
2. Do not use in places where flammable and explosive materials are stored.
3. Do not allow foreign objects into this device. High voltage inside the device may cause electric shock.
4. To avoid interference, this device should be placed at least 3 feet away from computers, televisions or radios.
5. Do not cover this device with fabrics or any other materials.
6. Do not block the air inlet or outlet.
7. Do not move the device while it is in operation.
8. Make sure that all filters are in place before operating.
9. To prevent short-circuit or electric shock hazard, do not place the device in places that are wet or where
water may potentially enter the unit.
10. Before unplugging the device, turn the power off, along with all control functions.
11. Do not operate if the power cord is damaged.
12. To prevent fire or electric shock, unplug the machine from the electrical outlet under the following conditions:
when it is not operated for long periods, while cleaning or replacing filters or UV bulbs, or when the machine is
being moved.
Specifications
Functions
Cautions
Placement

Diagram - External

Diagram - Internal
Combination Filter:
The air first passes through
the large, combination filter
of the Intelli-Pro 3, which
features an activated carbon
filter on one side, and a high-
efficiency HEPA filter on the
other.

How to Operate
Properly Setting the Sensor for Automatic Mode:
1. Turn the air purifier on and enter Manual Mode by pressing the Air Flow button. Operate on High until
you are confident that the air is reasonably clean, whether it be minutes, hours or days.
2. Turn the air purifer “off”, unplug it, and then immediately plug it back in and turn it on again. This will
reset the sensor. The air purifier will register the existing air quality condition as Clean.
3. The Clean Air LED will blink for 3 minutes to establish a baseline reading. Leave the air purifier in
Auto mode (the Auto LED will be lit).
1. Press the Power Button Once for Automatic Mode. The Auto LED will light up and the Clean Air
LED at the bottom left of the control panel will blink for three minutes to establish a baseline reading (see
“Properly Setting the Sensor for Automatic Mode” below). In Automatic mode, the air purifier will run in
High operation when the air quality registers as Unclean, Low operation when the air quality registers as
Between, and Quiet mode when it registers as Clean.
2. Press the Power Button Twice for Sleep Mode. In Sleep Mode, the LED lights are dimmed, and
the fan will operate in Quiet Mode.
3. Press the Air Flow Button to enter Manual Mode. Choose either High, Low or Quiet operation.
Cleaning and Maintenance
! Turn air purifier “off” and unplug before performing cleaning and maintenance.
! It is recommended that Cleaning and Maintenance be performed every 2-3 months.
1. Wipe down housing with a soft rag. Use
mild soap or a neutral detergent.
2. Vacuum dust out of the air inlets and the cavity where the
sensor is located.
3. Vacuum the dust from both sides of the combination
filter (closest to front panel). Press lightly.

Filter Replacement
When to Replace the
Combination Filter:
Note: This filter is black on one
side and white on the other. It is the
closest to the front panel.
1. When the Filter Replace
indicator lights up.
2. If the filter is badly discolored and
gives off a foul odor.
3. If the filter is packed with residue which
cannot be reasonably
removed.
! Turn air purifier “off” and unplug before replacing filters.
1. Remove Front Cover. Pull the embossments (tabs) of the front cover toward you, located at the
bottom-sides of the front cover. The bottom will detach first by pulling outward, and then the top will detach
next by lifting upward.
2. Remove Filter. With the front cover completely removed, take out the existing filter and properly
dispose.
3. Insert Replacement Filter. Remove the replacement filter from its plastic bag and insert it into its
proper place.
4. Re-Attach Front Cover. Insert the embossments (tabs) at the top of the front cover into their slots at
the top of the air purifier frame, and then snap the lower end into place.
5. Filter Reset Button. This applies only to the Combination Filter, not the Photocatalytic Filter. First,
plug the air purifier into the wall outlet. Before turning the air purifier back on, push the Filter Reset button
on the Control Panel using a needle.
Replacement Steps:
When to Replace the Photocatalytic Filter:
Replace every 3-5 years, when the surface begins to show signs of
corrosion.
Note: This filter is metallic in appearance. It sits behind the
Combination Filter.

What is covered: All parts defective in material and workmanship.
Exclusions: Regular replacement parts such as air filter cartridges and UV lamps.
For how long: Three years from purchase date.
What we will do: Repair or replace any defective parts.
What you must do:
1. Contact us for return and shipping instructions. You can call us at [phone], or email us at
[e-mail].
2. Pack the product in its original carton, and in the same manner in which you received it, or as identical
as possible.
3. Include proof of purchase inside box.
4. Label and ship the unit, freight prepaid, to the address provided.
Other Conditions
The provisions of this warranty are in lieu of any other written warranty, whether express or implied, written
or oral, including any warranty of merchantability or fitness for a particular purpose. The manufacturer’s
maximum liability shall not exceed the actual purchase price paid by you for the product. In no event shall
the manufacturer be liable for special, incidental, consequential, or indirect damages. This warranty does
not cover a defect that resulted from improper or unreasonable use or maintenance, accident, improper
packing, or unauthorized tampering, alteration, or modification as determined solely by us. This warranty
is void if the label bearing the serial number has been removed or defaced.
90-Day Replacement Policy
If any part requires repair during the first 90 days after receiving your air purifier, due to manufacturer
defect, then Surround Air will replace it with a new machine.
What you must do:
1. Contact us for return and shipping instructions. You can call us at [phone], or email us at
[e-mail].
2. Pack the product in its original carton, and in the same manner in which you received it, or as identical
as possible.
3. Include proof of purchase inside box.
4. Label and ship the unit, freight prepaid, to the address provided.
1. HEPA/Activated Carbon Combination Filter
2. TiO2/Photocatalytic Filter
Where to Buy
Surround Air
http://www.surroundair.com
Toll Free: 888.812.1516
Warranty
Spare Parts
