Samsung DF60 8 G Series User manual

Clothing Care System
(AIRDRESSER)
User manual
DF60*8****G
Untitled-3 1 2020-01-06 PM 2:23:15

English2
Contents
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
CALIFORNIA PROPOSITION 65 WARNING 5
Important safety precautions 5
General warnings 7
Electrical warnings 9
Installation warnings 11
Cleaning warnings 12
Regulatory notice 13
FCC Notice 13
IC Notice 14
Before you start 15
Installation 15
Product overview 18
Control panel 20
Cycle overview 22
Fabric care guide 26
Fabric care labels 30
Smart control 31
Product and accessory use 35
Using a cycle 35
Using the accessories 37
Cleaning and maintenance 45
Exterior 45
Water tanks 46
Water tray 47
Air Filter 48
Lint lter 50
Descaling 51
Moving the product to another location 52
Untitled-3 2 2020-01-06 PM 2:23:15

English 3
Contents
Troubleshooting 53
Notication messages 53
Checkpoint 54
Specications 56
Untitled-3 3 2020-01-06 PM 2:23:15

SAVE THESE INSTRUCTIONS
English4
Safety information
Congratulations on your new Samsung product. This manual contains important
information on the installation, use and care of your product. Please take some time to
read this manual to take full advantage of your product’s many benets and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efciently
operate the extensive features and functions of your new product. Please store the
manual in a safe location close to the product for future reference. Use this product only
for its intended purpose as described in this instruction manual. Warnings and Important
Safety Instructions in this manual do not cover all possible conditions and situations that
may occur. It is your responsibility to use common sense, caution and care when installing,
maintaining and operating your product. Because the following operating instructions
cover various models, the characteristics of your product may differ slightly from those
described in this manual and not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center or nd help and information
online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or
property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
CAUTION, Hot surface
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
Read all instructions before using the product.
As with any equipment that uses electricity and moving parts, potential hazards exist. To
safely operate this product, familiarize yourself with its operation and exercise care when
using it.
Safety information
Untitled-3 4 2020-01-06 PM 2:23:15

SAVE THESE INSTRUCTIONS
English 5
Safety information
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING - Risk of Fire
• Appliance installation must be performed by a qualied installer.
• Install the appliance according to the manufacturer’s instructions and local codes.
• To reduce the risk of severe injury or death, follow all installation instructions.
• Save these instructions.
Important safety precautions
WARNING
To reduce the risk of re, electric shock, or injury to persons
when using your appliance, follow basic precautions, including the
following:
1. Read all instructions before using this appliance.
2. Do not dry articles that have been previously cleaned in, washed
in, soaked in, or spotted with gasoline, dry-cleaning solvents, or
other ammable or explosive substances, as they give off vapors
that could ignite or explode.
3. Do not use the appliance to dry clothes which have traces of
any ammable substance, such as vegetable oil, cooking oil,
machine oil, ammable chemicals, paint thinner, etc., or anything
containing wax or chemicals, such as mops and cleaning cloths.
Flammable substances may cause the fabric to catch re by itself.
4. Do not store or use gasoline or other ammable vapors and
liquids near this or any other appliance.
Untitled-3 5 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
Safety information
English6
Safety information
5. Do not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is used
near children.
6. Before the appliance is removed from service or discarded,
remove the door to the drying compartment.
7. Do not install or store this appliance where it will be exposed to
the weather.
8. Do not tamper with internal controls.
9. Do not repair or replace any part of the appliance or attempt any
service unless specically recommended in the user-maintenance
instructions or in published user-repair instructions that you
understand and have the skills to carry out.
10. Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or
product.
11. Clean the lint screen before or after each load.
12. Do not use heat to dry articles containing foam rubber or
similarly textured rubberlike materials.
13. Do not place items exposed to cooking oils in your appliance.
Items contaminated with cooking oils may contribute to a
chemical reaction that could cause a load to catch re. To reduce
the risk of re due to contaminated loads, the nal part of a
appliance cycle occurs without heat (cool down period). Avoid
stopping a appliance before the end of the drying cycle unless
all items are quickly removed and spread out so that the heat is
dissipated.
Untitled-3 6 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
English 7
Safety information
14. Do not insert your hand under the appliance.
- This may result in injury.
15. Take care that children’s ngers are not caught in the door when
closing it.
- This may result in injury.
16. Keep area around the exhaust opening and adjacent surrounding
areas free from the accumulation of lint, dust, and dirt.
General warnings
WARNING
• To avoid electric shock, re, and/or death, make sure the product is properly installed
and grounded as described in this manual before using the product.
• Only use the product for its intended purposes. Damage incurred from using the
product for purposes other than those specied in this manual are not covered by the
warranty.
• To avoid physical injury and/or product damage, do not climb, stand, or hang on the
product.
• Do not disassemble or modify the product in any way.
• Do not allow children to play in, on, or around the product. Close supervision of
children is necessary at all times.
• To avoid re, physical injury, and/or death, keep all packaging material away from
children and properly remove and dispose all packaging material.
• Do not touch or operate the product with wet hands.
• To avoid electric shock and/or re, keep all animals or other foreign objects out of the
product.
• If you hear strange noises, smell strange odors, and/or detect smoke from the product,
immediately unplug the product.
• Do not place heavy or dangerous objects in, on, or around the product.
• To avoid electric shock, re, and/or death, do not repair or replace any part of the
product or attempt any servicing unless specically recommended in the user manual
or in published user-repair instructions that you understand and have the skills to carry
out.
Untitled-3 7 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
Safety information
English8
Safety information
• Take out all personal belongings (electric devices, lighters, matchboxes, and so on) from
pockets.
• To avoid re and/or explosions, do not dry items that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, cooking oils, or
other ammable or explosive substances.
• The product is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the product by a
person responsible for their safety.
• Before disposing of the product, remove the door to the drying compartment, and cut
off the power plug to prevent reuse.
• Do not touch or disassemble the electrical outlet of the product. In the event of a gas
leak, make sure to ventilate the location and immediately contact a Samsung service
center.
• To avoid damaging the glass panel, make sure to protect the front at all times.
• To avoid physical injury and/or product damage, do not step on the tank doors.
• Do not put hands, feet, other body parts, or metal objects under the product.
• Do not use other products to dry the interior. Do not use candles to remove interior
odors.
• Do not open the door while the product is operating. Opening the door while the
product is operating will affect product performance and may cause condensation to
damage ooring.
• Do not drink the water from the supply or drain tanks.
• Clean the lint lter before or after each load.
• Do not use fabric softeners or other products to eliminate static unless recommended
by the manufacturer of the fabric softeners or products.
• Keep ngers out of pinch point areas. Use caution when closing the door when children
are nearby.
• Do not use the product to dry items containing foam rubber or other rubber-textured
items.
• To avoid product damage, excessive noise, or re, do not insert objects into the steam
nozzle.
• Do not place your hands or body near the steam nozzle during operation. The hot
steam can cause an injury.
• Do not open the door during operation. The high internal temperature can cause an
injury.
Untitled-3 8 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
English 9
Safety information
• If a problem occurs during steam process, stop the product immediately and remove
all items from the product. If items are not removed immediately, they will stay damp,
causing damage to the fabric or smell.
• Before placing the clothing into the product, make sure to empty all pockets.
• Contains uorinated greenhouse gases.
Hermetically sealed equipment.
Do not vent gases into the atmosphere.
- Refrigerant (Type): R-134a (GWP = 1430)
- Refrigerant (Charging): 0.15 kg, 0.214 tCO2e
Electrical warnings
WARNING
• Regularly remove all foreign substances such as dust or water from the power plug
terminals and contact points using a dry cloth.
• Unplug the power plug and clean it with a dry cloth.
• To avoid risk of electric shock, always unplug the product before disassembly or repair.
• Do not pull the power cord when unplugging the power plug. To unplug the power
plug, rmly pull the power plug straight out.
• To avoid electric shock, do not use an extension cord.
• Do not use a damaged power cord or power plug. Do not attempt to repair,
disassemble, or modify the power cord or power plug. For any repairs, contact your
nearest Samsung service center.
• Plug the power cord into a wall socket that meets local electrical specications. Use the
socket for this appliance only, and do not use an extension cord.
• When moving the product, make sure to keep the power cord protected at all times.
• To avoid electric shock, re, serious injury, product damage, and/or death, the product
must be plugged into a properly grounded outlet. Make sure the wall outlet and circuit
are checked by a qualied electrician.
• The product must be equipped with a cord having an equipment-grounding conductor
and a grounding plug. The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local codes and ordinances.
• The product must be grounded. In the event of malfunction or breakdown, grounding
will reduce the risk of electric shock by providing a path of least resistance for electric
current.
Untitled-3 9 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
Safety information
English10
Safety information
• Before using, make sure there is dedicated, grounded electrical-outlet rated for use
with this product. It is the owner's responsibility to replace a standard 2-prong wall
outlet with a standard 3-prong outlet.
• To avoid electric shock, properly ground the product that conforms to all governing
codes and ordinances. Follow the instructions in the user manual.
• The product must be plugged into its own individual electrical outlet which has a
voltage rating that matches the rating plate. This provides the best performance and
also prevents overloading house wiring circuits which could cause a re hazard from
overheated wires.
• Connect to a properly rated, protected, and sized power circuit to avoid electrical
overload. Improper power circuits can melt, creating electric shock or re.
• Do not, under any circumstances, cut or remove the ground prong from the power
cord. To prevent personal injury or product damage, the electrical power cord must be
plugged into a properly grounded outlet.
• Do not use a multi socket outlet which is not properly grounded (portable). Upon using
a properly-grounded multi socket outlet (portable), use a product with the current
capacity of 15 A or higher alone. Failure to do so may result in electric shock or re
due to the heat of multi socket outlet. The power may be shut off when the circuit
breaker is operated.
• The product must be connected to a grounded metal, permanent wiring system or an
equipment-grounding conductor must be run with the circuit conductors and connected
to the equipment-grounding terminal or lead on the appliance. Electric shock can result
if the product is not properly grounded.
• Improper connection of the equipment grounding conductor can result in electric shock.
Check with a qualied electrician or service person if you are in doubt that the product
is properly grounded.
Untitled-3 10 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
English 11
Safety information
Installation warnings
WARNING
• Only install the product in a stable, well-oored location. Do not install the product
in locations prone to vibrations or where the product may tip over, such as ships
or airplanes. Contact a Samsung service center if you are unsure of the installation
location.
• Do not install the product in locations exposed to the weather or temperatures below
freezing. If the product was shipped in or at temperatures below freezing, allow the
product to warm before installing.
• To avoid electric shock, re, serious injury, product damage, and/or death, do not install
the product in humid locations (such as a bathroom or sauna).
• To avoid re, smoke, and/or product damage, do not install the product near other heat
sources (such as a stove or heater).
• To avoid re or smoke and/or product damage, do not place candles or other
ammables on, in, or around the product.
• To avoid physical injury and/or product damage, contact a Samsung service center
before moving the product.
• Install the product where the power plug is easily accessible. To avoid electric shock
and/or re, unplug the product when not in use.
• If the installation location has been ooded, do not go near the product and
immediately contact a Samsung service center.
• To avoid re, smoke, and/or product damage, remove all protective lm from the
product.
• To prevent product damage and/or physical injury, have at least two people move the
product.
Untitled-3 11 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
Safety information
English12
Safety information
Cleaning warnings
WARNING
• To avoid electric shock, do not use sharp objects to operate or clean the product.
• Do not spray water directly onto the product when cleaning it.
• Do not use bleaching agents on the exterior of the product. Bleaching agents may
discolor the exterior.
• Wipe the interior with a dry cloth after use.
• After using the product, wipe its inner side with a dry cloth.
- The product could be stained by contamination such as long hair or due to dust and
water drops that may form inside.
• If contamination (detergent, dirt, food residue, etc.) has accumulated in the product or
any accessories, unplug the power cable and then wipe the contaminated area with a
soft, wet cloth.
- Do not expose the product or the accessory to cleaning or bleaching agents or apply
these to the product or accessory.
- Otherwise, this may result in discoloration, deformation, damage, or rust.
Untitled-3 12 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
English 13
Regulatory notice
FCC Notice
CAUTION
Any changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject to following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received including interference that cause
undesired operation.
For products sold in the US and Canadian markets, only channels 1–11 are available. You
cannot select any other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated so there is at least 8 inches
(20 cm) between the radiator and your body. This device and its antenna(s) must not be
colocated or operated in conjunction with any other antenna or transmitter.
Regulatory notice
Untitled-3 13 2020-01-06 PM 2:23:16

SAVE THESE INSTRUCTIONS
Regulatory notice
English14
Regulatory notice
IC Notice
The term “IC” before the radio certication number only signies that Industry Canada
technical specications were met. Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
For products sold in the US and Canadian markets, only channels 1–11 are available. You
cannot select any other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated so there is at
least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s)
must not be colocated or operated in conjunction with any other antenna or transmitter.
Untitled-3 14 2020-01-06 PM 2:23:16

English 15
Before you start
Installation
Install the product according to the
instructions in this manual and local codes.
Grounding
This appliance must be grounded. In
the event of malfunction or breakdown,
grounding will reduce the risk of
electric shock by providing a path of
least resistance for electric current. This
appliance is equipped with a cord having
an equipment-grounding conductor and a
grounding plug. The plug must be plugged
into an appropriate outlet that is properly
installed and grounded in accordance with
all local codes and ordinances.
WARNING
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualied
electrician or service representative
or personnel if you are in doubt as
to whether the appliance is properly
grounded.
Do not modify the plug provided with the
appliance: if it will not t the outlet, have
a proper outlet installed by a qualied
electrician.
Installing the product
1. Select a solid, level location with
adequate space for the following
clearances.
Top 25 mm
Sides 5 mm
Rear 15 mm
- If the minimum clearances are not
met, performance will decrease due
poor ventilation and condensation
may occur on the product exterior.
- Do not install the product in direct
sunlight or hot and cold places.
The ambient temperature must be
between 10 °C-35 °C. If the ambient
temperature is too high or too
low, the product may not operate
normally, or performance may
decrease.
2. Turn the leveling feet (A) clockwise or
counterclockwise to adjust the height
until the product is level.
A
Before you start
Untitled-3 15 2020-01-06 PM 2:23:16

Before you start
English16
Before you start
NOTE
If the product wobbles or if you want to
raise the height of the rear side, assemble
the provided rear leveling feet on the
bottom-rear sides of the product.
3. Insert the water tray as shown in the
gures.
- Make sure the side marked ‘TOP’ is
facing upward.
4. Plug in the product to a 230 V / 50 Hz
grounded outlet.
- If you do not have grounded outlets,
contact a Samsung service center for
alternative methods to ground the
product.
NOTE
• After installing the product, you must
wait at least 2 hours before using it.
• The product consumes more water the
rst time the product is used. You may
have to ll the Rell Tank more than
one time.
Untitled-3 16 2020-01-06 PM 2:23:16

English 17
Before you start
Securing AIRDRESSER with the anti-tip
strap (optional)
AIRDRESSER may tip-over by external
force or children. If necessary, use the
anti-tip strap to secure AIRDRESSER and
prevent tip-over. (Refer to the gure.)
ՋՍ
ՋՌ
CAUTION
You must unplug the product before
securing AIRDRESSER with the anti-tip
strap.
NOTE
• Use the provided screw to fasten the
anti-strap to a wall.
• Use the screws fastened on top of
AIRDRESSER to fasten the anti-strap to
AIRDRESSER.
Setting the language
When you turn on the product for the rst
time after the installation, the language
selection screen appears on the control
panel display. Follow the instructions to
select the language.
1. Tap < or > to select a language.
2. Tap and hold Start/Pause to save the
selected language.
NOTE
• Language setting may not be applicable
in some countries.
• To change the language afterward, tap
and hold Normal and Delicates for 3
seconds, and then follow the above
instructions.
Untitled-3 17 2020-01-06 PM 2:23:17

Before you start
English18
Before you start
Product overview
01
02
03
04
06
05
07
08
09
10
11
01 Air hole 02 Air hanger 03 Air Filter
04 Shelf 05 Lint lter 06 Drain tank
07 Water tray 08 Control panel 09 Accessory care zone
10 Shelf holder 11 Rell Tank
Untitled-3 18 2020-01-06 PM 2:23:17

English 19
Before you start
Accessories
Shelf Water tray Air hanger
Weight kit Regular hanger kit Cleaning cloth
User manual Anti-tip strap Screw (for anti-tip strap)
Screw anchor (for anti-tip
strap)
Rear leveling feet
Untitled-3 19 2020-01-06 PM 2:23:18

Before you start
English20
Before you start
Control panel
01
02
03
06
04 05
07
01 Display
Displays the selected cycle and estimated time remaining, notications, and Wi-Fi
connectivity.
02 Cycles
Tap a cycle to select. For more information about cycles, see page 22.
03 Silent / Child Lock (3 sec)
Silent
Tap to turn Silent on or off. Silent reduces operating noise.
NOTE
Silent will increase cycle time.
Untitled-3 20 2020-01-06 PM 2:23:19
